AVer VC520 User manual

VC520
User Manual

TRADEMARKS
“AVer” is a trademark owned by AVer Information Inc. Other trademarks used herein for description
purpose only belong to each of their companies.
COPYRIGHT
© 2016 AVer Information Inc. All rights reserved.
All rights of this object belong to AVer Information Inc. Reproduced or transmitted in any form or by
any means without the prior written permission of AVer Information Inc. is prohibited. All information
or specifications are subject to change without prior notice.
NOTICE
SPECIFICATIONS ARE SUBJECT TO CHANGE WITHOUT PRIOR NOTICE. THE INFORMATION
CONTAINED HEREIN IS TO BE CONSIDERED FOR REFERENCE ONLY.
WARNING
TO REDUCE RISK OF FIRE OR ELECTRIC SHOCK, DO NOT EXPOSE THIS APPLIANCE TO RAIN
OR MOISTURE. WARRANTY WILL BE VOID IF ANY UNAUTHORIZED MODIFICATIONS ARE
DONE TO THE PRODUCT.
Remote Control Battery Safety Information
- Store batteries in a cool and dry place.
- Do not throw away used batteries in the trash. Properly dispose used batteries through specially
approved disposal methods.
- Remove the batteries if they are not in use for long periods of time. Battery leakage and corrosion
can damage the remote control. Dispose of batteries safely and through approved disposal
methods.
- Do not use old batteries with new batteries.
- Do not mix and use different types of batteries: alkaline, standard (carbon-zinc) or rechargeable
(nickel-cadmium).
- Do not dispose of batteries in a fire.
- Do not attempt to short circuit the battery terminals.

Contents
Package Contents.............................................................................................................................. 1
Product Introduction........................................................................................................................... 2
Camera....................................................................................................................................... 2
Speakerphone ............................................................................................................................ 3
Hub............................................................................................................................................. 4
Remote Controller....................................................................................................................... 4
Setup VC520 ..................................................................................................................................... 6
Device Connection...................................................................................................................... 6
Mounting Camera....................................................................................................................... 7
Connector Retainer..................................................................................................................... 8
Use VC520 ........................................................................................................................................ 9
Make a Video Call....................................................................................................................... 9
Phone in ..................................................................................................................................... 9
Line in......................................................................................................................................... 9
LED Indicator.............................................................................................................................. 9
AVer PTZApp....................................................................................................................................11
Install AVer PTZApp...................................................................................................................11
Use AVer PTZApp......................................................................................................................11
Select Remote Control.............................................................................................................. 16
Set the Camera Number........................................................................................................... 17

1
Package Contents
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
1. Camera
2. Hub
3. Speakerphone
4. Remote Controller
5. Mount (mounting screws are included)
6. Power Cord1& Power adapter
7. Velcro for hub2
8. USB cable
9. Camera cable
10. Speakerphone cable
11. 3.5mm AUX cable
12. User Manual
13. Warranty Card
14. Quick Installation Guide
15. AAA Batteries (x2)
16. Connector Retaining Kit(4pcs)
[Note] 1. The power cord will vary depending on the standard power outlet of the country where it is
sold.
2. Adhesive fastener holds the hub when mounted under your flat surface. Use appropriate
cleaning solution when removing the fastener. Test the cleaning solution to make sure that it
will not damage the surface.

2
Product Introduction
Camera
123 4
6
5
1. IR Sensor
4. RS232 connection*
2. Power indictor
5. Kensington lock
3. Hub connection
6. Screw hole for mounting
* If you need a converter or instructions on how to use RS232,please contact AVer USA.

3
Speakerphone
1
2
3
4 5 6 7 8
1. Cellphone indicator
5. Hub connection
2. Volume up/down
6. Kensington lock
3. Mute/unmute speakerphone*
7. Line out
4. Speakerphone(daisy chain)
8. Phone in
* Red LED: speakerphone is on mute
* Blue LED: speakerphone is active (or live)

4
Hub
1 2 3 4
1. Power jack
2. USB port
3. Speakerphone
connection
4. Camera connection
Remote Controller
1
2
3
4
5
6
7
813
12
10
9
11
Name
Function
1. Camera select
1 remote can control up to 3 AVer VC/CAM. Use AVer PTZapp
sets number associated with each camera, select which camera
you like to control on remote.
2. Camera direction control
Use the direction button on the remote to control the direction of
the camera. Press the direction button to move the camera or
press and hold for continuous pan or tilt.

5
Name
Function
3. FaceLumi
Press it to optimize and lock auto focus, auto exposure and skin
tone based on faces detected by camera at this moment. When
pan, tilt, zoom or camera disconnects, this settings are unlocked.
4. OSD menu
Press to bring out OSD menu.
5. Zoom in/Zoom out
Increase/Decrease the camera zoom.
6. Preset
Press to get back to “home”position that user has set.
Move camera to desired position. Press and hold the preset
button until saved message is displayed on screen. Select
preset position button 0~9 to save current camera position.
Press preset + preset position button (0~9), camera will go to
saved position.
7. Preset position
Press preset + preset position button (0~9), camera will go to
saved position.
8. Call/answer*
Answer a call or start a call.
9. Enter
To confirm selection in OSD menu.
10.Mute/Unmute Speakerphone
Mute/Unmute the speakerphone.
11.Volume up/down
Adjust volume up or down.
12.Far site camera control
Press the Far/Near button to control the far site camera for pan,
tilt, or zoom functions.
13.Hang up*
End the call.
* Function requires AVer PTZApp

6
Setup VC520
Device Connection
DC 12V
Camera cable Speakerphone cable
Power cable
Wall outlet
Camera
Hub Speakerphone
USB cable
Laptop PC
1. Use the camera cable and the speakerphone cable to connect the camera, hub, and speakerphone
(refer to diagram above).
2. Use USB cable to connect the hub to your PC/laptop (refer to diagram above).
3. Connect the power to the hub; LED will light up, camera head will rotate, and the camera power
indictor will light up.
4. InstallAver PTZApp on laptop or PC that is connected with VC520. The app can be used to adjust
and setup the parameters of the camera (refer to section of Aver PTZApp)
5. To make a call, run your video application (SkypeTM, Microsoft ®LyncTM, Google Hangout, Cisco
WebEx®, GoToMeetingTM, WebRTC, and etc.), select VC520 as your video and audio device.

7
Mounting Camera
There are 3 ways to mount the camera –on the wall, on the ceiling, and on a table with the mount and
screws included in the package.
[Warning]
1. When securing the camera mount on a wall or celling, only use hardware and materials certified to
support 22 lb (10 kg) weight. For dry wall installation, please use Sleeve-Type Hollow WallAnchors
(a.k.a. Molly Bolts).
2. If the camera mount is secured to a table, please note excessive table movement or pulling on the
camera cables may cause the mount and camera to fall. Ensure the cables and camera are secured
properly.
Wall
Ceiling
