02/03 Rev. 2.17-01 USER +SERVICE MANUAL Specifications, page 1
TTX x50/67x – Wildcats (plus) –S 45/65/95/105
Specifications TTX / Wildcats
Technical Specifications.................................2
Device types, use .......................................2
Dimensions.................................................2
Performance data .......................................3
Label material specifications ......................6
Ribbon specifications..................................6
Operation features......................................6
Connections, device data........................... 7
Test certificates .......................................... 7
CE Conformity............................................ 7
Appendix........................................................ 8
Through-run diagram ................................. 8
Index .............................................................. 9

02/03 Rev. 2.17-01 USER +SERVICE MANUAL Specifications TTX / Wildcats, Seite 2
TTX x50/67x – Wildcats (plus) –S 45/65/95/105
Technical Specifications
Device types, use
TTX 450/674
Puma/Puma plus
S 45
Label printing using thermal or thermal transfer printing process,
print width up to 106.6 mm (4 inch)
TTX 650/675
Lion/Lion plus
S 65
Label printing using thermal or thermal transfer printing process,
print width up to 127.9 mm (5 inch)
TTX 950
Tiger
S 95
Label printing using thermal or thermal transfer printing process,
print width up to 159.9 mm (6 inch)
TTX 1050
Tiger XXL
S 105
Label printing using thermal or thermal transfer printing process,
print width up to 213.2 mm (8 inch)
Dimensions
Printer type Cutter Width /
mm
Height /
mm
Depth /
mm
Weight /
kg
310 305 480 21,0
TTX 450/Puma/S45
310 305 540 22,5
350 305 480 22,5
TTX 650/674/675/
Puma/Puma plus/
Lion/Lion plus/S65 350 305 540 24,0
380 305 480 25,0
TTX 950/Tiger/S95 380 305 540 26,5
470 305 480 28,0
TTX 1050/Tiger XXL/
S105 470 305 540 29,5
Tab. 1: Dimensions and weights of the printers in the TTX x50 and TTX 67x series. All
width measures refer to the housing including the motor cover. All width measures
refer to the housing including the motor cover.

02/03 Rev. 2.17-01 USER +SERVICE MANUAL Specifications TTX / Wildcats, Seite 3
TTX x50/67x – Wildcats (plus) –S 45/65/95/105
Performance data
Print technology Thermal printing, thermal transfer printing
Printhead "Near Edge Type" type printhead, high-definition, fast, with integrated
temperature control
Resolution 12 dots/mm (300 dpi)
Print speed TTX 450/S45/Puma 100 to 300 mm/s (4 to 12 “/s)
TTX 674/Puma plus 100 to 300 mm/s (4 to 12 “/s)
TTX 675/Lion plus 100 to 300 mm/s (4 to 12 “/s)
TTX 650/S65/Lion 100 to 300 mm/s (4 to 12 “/s)
TTX 950/S95/Tiger 100 to 250 mm/s (4 to 10 “/s)
TTX 1050/S105/XXL 100 to 200 mm/s (4 to 8 “/s)
in units of respectively 25,4 mm/s (1 “/s)
Print width (actual) TTX 450/S45/Puma 106.6 mm
TTX 674/Puma plus 106,6 mm
TTX 650/S65/Lion 127.9 mm
TTX 675/Lion plus 127,9 mm
TTX 950/S95/Tiger 159.9 mm
TTX 1050/S105/XXL 213.2 mm
Impression
accuracy Printing direction (Y-):
The impression accuracy depends on the print position. With the
printout starting directly at the gap position, the accuracy is ±0.5 mm.
A distance between gap (that is label start) and print position, will add
±1% of this distance to the accuracy fault (see illustration in the
Appendix).
X-direction: +/- 0.5 mm
Fig. 1: Impression accuracy depends on the printing position.
+0,5
+1,0
+1,5
+2,0
mm
+3,0
Max. misalignment of the printing position
- 0,5
-1,0
-1,5
-2,0
-2,5
-3,0
50 100 150 200 mm 300 Distance
punch - printing position
Punch position
Printing
direction
0
Printing position 1 Printing position 2
Max. misalignment at
printing position 1
= 1,0 mm
Max. misalignment at
printing position 2
= 2,5 mm
Label
+1%
-1%
Punch
Z00521E.cdr

02/03 Rev. 2.17-01 USER +SERVICE MANUAL Specifications TTX / Wildcats, Seite 4
TTX x50/67x – Wildcats (plus) –S 45/65/95/105
Automatic ribbon
economy Beginning at 10 mm print-free zone
Label width 25.4 to max. 254 mm (depending on printer type)
Label length 5 to max. printing length
The maximum printing length depends on the following points:
–Firmware intalled to the printer (standard or extended, furthermore of
the version of the respective firmware)
–Use of bar code cards
–Useofimage cards
Depending on the combination of firmware, bar code card and image card
results a different maximum print length.
Maximum printing length with firmware:Printer
Standard
(1H..)
Extended
(1X..)
Extended +
1 x 1 MB
S-RAM
Extended +
1 x 2 MB
S-RAM
Extended +
2 x 2 MB
S-RAM
TTX 450/ S45 /Puma 356 mm
(383 mm*)
245 mm 339 mm 679 mm 1359 mm
TTX 650/ S65/ Lion/
TTX 674/ TTX 675
301 mm
(324 mm*)
245 mm 339 mm 679 mm 1359 mm
TTX 950/ S95/ Tiger 245 mm
(263 mm*)
245 mm 339 mm 679 mm 1359 mm
TTX 1050/ S105/
Tiger XXL
188 mm 123 mm 169 mm 339 mm 679 mm
Tab. 2: The max. printing length can be extended by aid of S-RAM cards; assuming that
the special "extended firmware" (code 1X ..) is installed. This firmware takes more
memory space than the standard firmware, that´s why the max. printing length with
extended firmware and without plugged-in S-RAM card is even lower than with
standard firmware. *) with spooler set to 8 KB (standard: 65 KB)
Max. printing length with
standard firmware (1H..)
Max. printing length with
extended firmware (1X..)
Printer
Without bar
code card
With bar code
card
Without bar
code card
With bar code
card
TTX 450/ S45 /Puma 356 mm 274 mm 245 mm 197 mm
TTX 650/ S65/ Lion/
TTX 674/ TTX 675
301 mm 242 mm 245 mm 197 mm
TTX 950/ S95/ Tiger 245 mm 197 mm 245 mm 197 mm
TTX 1050/ S105/
Tiger XXL
188 mm 151 mm 123 mm 99 mm
Tab. 3: The bar codes are loaded to the printer memory, as soon as the printer is switched
on. Because those bar codes take some memory space, the resuming print length
is shorter than without bar code card.

02/03 Rev. 2.17-01 USER +SERVICE MANUAL Specifications TTX / Wildcats, Seite 5
TTX x50/67x – Wildcats (plus) –S 45/65/95/105
Be aware, that the max. printing length may vary from one firmware version
to the next. Adding features to the printer means often taking away some
millimeters of printing length from the image buffer!
For detailed information on the different firmware versions refer to the
service manual, topic section "Firmware", "Firmware Versions".
For details about applying plug-in cards refer to the cards manual.
Output mode 1:1 and 100 % printable, either with or without cut.
Non-printable area:
1 mm from the front label edge (1st edge in feed direction) and
1 mm from the left band border (right border in feed direction).
Gap detection Self-initialising light transmission sensor, optional reflex sensor (at the
bottom side of the material).
Correction of gap displacement in feed direction is possible by modifying
the gap offset (parameter PRTP >PUNO),
Light transmission
sensor
Reflex sensor
Setting range 2-17 mm 13-26 mm
Punch length
(in feed direction)
0.8-14 mm 12 mm
(recommended)
Punch width
(across the web)
min. 4 mm 4 mm
(recommended)
Tab. 4: Punch dimensions and setting ranges.
Cutter Optional high-performance, low-noise cutter with double-cut function from
1 to 5 mm
Emulation Easy Plug, Line Printer, Hex Dump
Character sets 17 fonts including OCR-A and OCR-B, 2 scalable fonts
Character
modification Scaling in X/Y direction up to factor 8,
Rotation 0, 90, 180, 270 degrees
Bar codes EAN 8 and EAN 13 with Add-On 2 and 5, UPC-A, UPC-E, Code 39,
Code 39 Ratio 3:1 and Ratio 2,5:1, Code ITF, Codabar, Code 128,
Code 2/5, Code 2/5 1, Code 2/5 5, Code 2/5 Interleaved Ratio 1:3,
Code 2/5 Matrix Ratio 1:2,5; Code 2/5 Matrix Ratio 1:3; Code MSI,
Code EAN 128; Postcode (Guide- and Identity Code), UPS-Code 128
All bar codes scalable in 16 widths and the height.

02/03 Rev. 2.17-01 USER +SERVICE MANUAL Specifications TTX / Wildcats, Seite 6
TTX x50/67x – Wildcats (plus) –S 45/65/95/105
Label material specifications
Material supply Roll with max. outer ∅210 mm,
inner ∅1,5“ (38 mm), 3“ (76 mm), 4“ (102 mm)
Material width TTX 450/S45/Puma 25.4 to 113 mm
TTX 650/S65/Lion 25.4 to 154 mm
TTX 674/Puma plus 25.4 to 154 mm
TTX 675/Lion plus 25.4 to 154 mm
TTX 950/S95/Tiger 30.2 to 185 mm
TTX 1050/S105/XXL 100 to 254 mm
Material type Self-adhesive, card and synthetic materials up to the max material weigth
(see below), suitable for printing in thermal direct process and thermal
transfer process.
Use of fan-folded material possible.
Material weight max. weight: TTX 1050/S105/XXL 160 g/m2
all other printers 240 g/m2
min. weight: 80 g/m2
Roll weigth TTX 450/S45/Puma max. 4250 g
TTX 650/S65/Lion max. 4250 g
TTX 674/Puma plus max. 4250 g
TTX 675/Lion plus max. 4250 g
TTX 950/S95/Tiger max. 7200 g
TTX 1050/S105/Tiger XXL max. 7200 g
Ribbon specifications
Ribbon roll Max. outer ∅90 mm, inner ∅1" (25,4 mm)
Ribbon width TTX 450/S45/Puma 30 to 110 mm
TTX 650/S65/Lion 30 to 132 mm
TTX 674/Puma plus 30 to 132 mm
TTX 675/Lion plus 30 to 132 mm
TTX 950/S95/Tiger 30 to 164 mm
TTX 1050/S105/Tiger XXL 30 to 217 mm
Operation features
Operation 3-key control panel with 4-figure display
Settings Definition of parameters using menu or Easy Plug commands
Test copies Copies for parameter settings, adding logo and font, line and barcode
library
Test functions Print tests with cut, test routines for memory and sensors, interface test
Error reports Display of error reports on the display,
continuation of print jobs without label loss.

02/03 Rev. 2.17-01 USER +SERVICE MANUAL Specifications TTX / Wildcats, Seite 7
TTX x50/67x – Wildcats (plus) –S 45/65/95/105
Connections, device data
Mains voltage 115 V, 230 V and 240 V, ±10 %, changeable
Mains frequency 50/60 Hz
Power
consumption approx. 336 VA, approx. 450 VA for TTX1050/S105/XXL
Current
consumption approx. 3 A (at 115 V) and 1.5 A at 230/240 V
Fuses 8 A slowblow at 115V,
4 A slowblow at 230 V,
4 A slowblow at 240 V
Ambient
conditions Operating temperature: +5 to +35 °C
Storage temperature: -20 to +70 °C
Humidity: 45 to 75 %, non-condensing
Interfaces Standard: serial and parallel interfaces (Centronics),
optional RS485 in exchange for RS 232,
bi-directional mode for all interfaces possible
Memory 2 slots for PCMCIA-cards with max. 2 MB each, 1 MB dynamic RAM
Test certificates
TÜV GS TÜV GS test certificate: Tested safety (according to EN 60950:97)
CE Conformity
The devices conform to CE-requirements and are marked with the CE
label. The manufacturer declares that the device conforms with the relevant
European guidelines.
EMC The EMC test was made according to the following norms:
EN 55022:98
EN 55024:98
EN 61000-3-2:95
EN 61000-3-3:95
EN 61000-6-2:99

02/03 Rev. 2.17-01 USER +SERVICE MANUAL Specifications TTX / Wildcats, Seite 8
TTX x50/67x – Wildcats (plus) –S 45/65/95/105
Appendix
Through-run diagram
Printhead extendable to
max. mat. width
TTX 450 not possible
TTX 650 possible
TTX 950 possible
TTX 1050 possible
Printer Print width
TTX 450/674 106.6 mm
TTX 650/675 128.0 mm
TTX 950 160.0 mm
TTX 1050 213.2 mm
Printer min. mat. width
TTX 450/674 26
,
0 mm
TTX 650/675 26
,
0 mm
TTX 950 on demand
TTX 1050 100 mm
Printer max. ribbon width
TTX 450 110.6 mm
TTX 650/67x 132.0 mm
TTX 950 164.0 mm
TTX 1050 217.0 mm
Printer max. mat. width
TTX 450 113.7 mm
TTX 650/67x 154.0 mm
TTX 950 185.9 mm
TTX 1050 254.0 mm

02/03 Rev. 2.17-01 USER +SERVICE MANUAL Specifications TTX / Wildcats, Seite 9
TTX x50/67x – Wildcats (plus) –S 45/65/95/105
Index
A
Automatic ribbon economy..........................4
B
Bar codes ....................................................5
C
Centronics ...................................................7
Character modification.................................5
Character sets .............................................5
Cutter...........................................................5
D
Device types................................................2
Dimensions..................................................2
E
EMC.............................................................7
Emulation.....................................................5
Error reports ................................................6
F
Fonts............................................................5
Fuses...........................................................7
G
Gap detection ..............................................5
I
Impression accuracy....................................3
Interfaces.....................................................7
L
Label length.................................................4
Labelwidth ...................................................4
M
Material
-fan-folded ................................................ 6
Material supply ............................................ 6
Material type................................................ 6
Material weight............................................ 6
Material width.............................................. 6
Memory ....................................................... 7
O
Output mode ............................................... 5
P
PCMCIA ...................................................... 7
Print
-head ........................................................ 3
-speed ...................................................... 3
-technology............................................... 3
Print tests .................................................... 6
Printing length, maximum............................ 4
Printwidth .................................................... 3
Punch dimensions....................................... 5
Punch sensor .............................................. 5
R
RAM, dynamic............................................. 7
Reflex mark, size......................................... 5
Resolution ................................................... 3
Ribbon saving ............................................. 4
Ribbon specification.................................... 6
Roll weight, label material ........................... 6
RS232 ......................................................... 7
RS485 ......................................................... 7
W
Weight......................................................... 2
