Avigilon AC-HID-LSP-ACMEC-KIT4 User manual

Installation Guide
Avigilon™ 4-Door ACM™ Embedded Controller Kit
AC-HID-LSP-ACMEC-KIT4

©2015,Avigilon Corporation. Portions © 2003 -2014 HID Global Corporation. All rights reserved. AVIGILON,the
AVIGILON logo, ACCESS CONTROL MANAGER and ACM are trademarks of Avigilon Corporation. HID, VertX,
V100, V200 and V300 are registered trademarks of HIDGlobal Corporation. Other product names mentioned
herein may be the trademarks of their respective owners. The absence of the symbols ™ and ® in proximity to
each trademark in this product or its packaging is not a disclaimer of ownership of the related
trademark.20151112
Unless stated explicitly and in writing, no license is granted with respect to any copyright, industrial design,
trademark, patent or other intellectual property rights of Avigilon Corporation or its licensors.
This document has been compiled and published covering the latest product descriptions and specifications.
The contents of this document and the specifications of the products discussed herein are subject to change
without notice. Neither Avigilon Corporation nor any of its affiliated companies guarantees the completeness or
accuracy of the information contained in this document and is not responsible for your use of, or reliance on, the
information. Avigilon Corporation shall not be responsible for any damages (including consequential damages)
caused by reliance on the information presented herein.
"WJHJMPO $PSQPSBUJPO
IUUQXXXBWJHJMPODPN
220-0453C
Revision: 1 - EN
20151112
2

Regulatory
Prior to installation, it is necessary to find a suitable site indoors (this product should always be installed indoors).
It is assumed that the installer has required certifications and required permits. The Installer must follow electrical
standards and AHJ requirements.
All National and local Electrical codes apply.
lThis equipment is intended to be powered from a limited power source output of a previously certified
power supply.
lChanges or modifications not expressly approved by the party responsible for compliance could void the
user’s authority to operate the equipment.
$MBTT "%JHJUBM %FWJDFT
'$$ $PNQMJBODF 4UBUFNFOU This equipment has been tested and found to comply with the limits for a Class A
digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection
against harmful interference when the equipment is operated in a commercial environment. This equipment
generates, uses, and can radiate radio frequency energy and, if not installed and used in accordance with the
instruction manual, may cause harmful interference to radio communications. Operation of this equipment in a
residential area is likely to cause harmful interference in which case the user will be required to correct the
interference at his own expense.
Canada Class A
CE Mark –Europe (EU)
C-Tick – Australia and New Zealand
VCCI –Japan
NCC — Taiwan
SRRC— China
IDA — Singapore
KCC —Korea
UL Recognized Component (UL294 and UL1076)
RoHS compliant
3

Table of Contents
*OUSPEVDUJPO 
Package Contents 5
*OTUBMMBUJPO 
.PVOUJOH UIF $POUSPM 1BOFM $BTF 
1PXFS 4VQQMZ #PBSE 0WFSWJFX 
Setup the FPO75 Power Supply Board 9
Setup the B100 Power Supply Board 11
Setup the D8P Power Supply Board 11
Setup the C4 Power Supply Board 12
*OTUBMM UIF "$. &NCFEEFE $POUSPMMFS BOE 7 4VCQBOFMT 
Configure and Wire Data 14
Configure and Wire Power 17
1PXFS 0O 
"DDFTTJOH "$. &NCFEEFE $POUSPMMFS "QQMJDBUJPO GPS UIF 'JSTU 5JNF 
By Virtual Port 20
By Host Name 20
$IFDLMJTUT 
Tools Checklist 21
Equipment Checklist 21
4

Introduction
The Access Control Manager (ACM) Embedded Controller from Avigilon is an all-in-one security management
application and controller.
The ACM Embedded Controller is a controller embedded with the ACM Embedded Controller application to
provide a flexible and scalable platform for an economic and high performance access control system.
The controller uses astandard TCP/IP network to connect to abrowser interface which links to the ACM
Embedded Controller application. The application allows you to effectively control access at each entry point.
Package Contents
The package contents for the 4-Door ACM Embedded Controller are:
lOne AC-LSP-4DR-HID-LCK LifeSafety Power four door HID dual voltage integrated power system
(shipped in a separate box)
lOne Avigilon AC-HID-ACMEC V1000 ACM Embedded Controller
lTwo AC-HID-VERTX-V100 reader interface modules
lFour AC-HID-READ-ICLASS-SE-R10-AVG card readers
l100 AC-HID-CARD-ICLASS-SE-3000-AVG contactless smart card, 2k bit with two application areas
Introduction 5

Installation
Before you install the ACM Embedded Controller, read through this entire document.
Refer to the checklist at the end of this document and gather the required information before proceeding with
these instructions.
$"65*0/ The controllers and interface panels are sensitive to Electrostatic Discharges (ESD). Observe
precautions while handling the circuit board assembly by using proper grounding straps and handling
precautions at all times.
6Installation

Mounting the Control Panel Case
Follow the steps below to mount the control panel case.
1. At the installation site, remove the control panel case from the LifeSafety Power FlexPower box.
2. Find two studs in the wall where the enclosure should be installed.
/05& In a finished setup, the enclosure and contents together weighs 11.8kg (26lb).
3. Mount the plywood board onto the wall at the desired location.
/05& It is highly recommended that the plywood board is mounted to two studs. If no studs are
available, use appropriate drywall anchors that can support the enclosure.
4. Remove one of the two high voltage knockouts.
5. Attach an appropriate cable gland to the 7/8” diameter high voltage opening.
6. Mount the enclosure to plywood using six wood screws.
High voltage knockouts
Low voltage knockouts
Screwholes
Mounting the Control Panel Case 7

7. Setup the high voltage junction box (or equivalent), as required. Attach an appropriate cable gland to the
junction box and feed the three AC wires through.
2
3
1
=6K Wb MbM\_ZR VWUV e^ZcMUR Xd]PcW^] O^g fVWZR M]Q MaR bM\_ZR PMOZR UZM]Qb
$"65*0/ Do not connect to the main power supply yet.
8. Remove knockout(s) for low voltage input/output wires, as necessary.
9. Attach an appropriate cable gland to each 13/8” diameter low voltage opening.
8Mounting the Control Panel Case

Power Supply Board Overview
Shown below is an overview of the power supply board.
FPO75
B100
D8P
C4
Setup the FPO75 Power Supply Board
Follow the steps below to setup the FPO75 power supply board:
1. Either:
lFor 120V input, leave JP1 intact.
lFor 230V input, cut JP1.
$"65*0/ Failure to cut this jumper when using the FPO with a 230VAC input will result in
damage to the system and will void the warranty.
Power Supply Board Overview 9

2. Ensure the DC output jumper is set to 24V (as circled below).
$"65*0/ Failure to set the FPO75’s DC output jumper to 24V will likely result in damage to the
system and will void the warranty.
3. Connect the inputs on the FAI (Fire Alarm Input) to the building’s fire alarm system, as required. See the
FPO Quick Start Manual (page 3 – FAI Input Usage) for more detail. Further information is available at:
http://lifesafetypower.com/docs/im_fpo.pdf.
4. Either:
lIf abackup battery is used –move the jumper to position 1, as shown below.
lIf no backup battery is used –move the jumper to position 2.
10 Setup the FPO75 Power Supply Board

Setup the B100 Power Supply Board
On the B100 board, ensure Output Voltage Selection jumper (JP3) is set to position 1 for 12VDC out, as shown
below.
See the B100 Quick Start Manual or B100 Installation Manual for more detail (available at
http://www.lifesafetypower.com/docs/im_b100.pdf) .
Setup the D8P Power Supply Board
On the D8P board, set the JP1 to 4output voltage selection jumpers to provide 12VDC.
See the D8 Quick Start Manual or D8/D8P Installation Manual for more detail (available at
http://www.lifesafetypower.com/docs/im_d8.pdf).
$"65*0/ Failure to set the JP1 to 4 jumpers may cause damage to components.
Setup the B100 Power Supply Board 11

Setup the C4 Power Supply Board
Set the jumpers properly for your installation as outlined below:
+VNQFST 1PTJUJPO
Red -1A to 4A (Zone FAI enabled)
Either:
1. FAI enabled
2. FAI disabled
Blue - 1B to 4B (Input Invert)
Either:
1. Fail Safe (NC contact input)
2. Fail Secure (NO contact input)
Black - 1C to 4C (Wet Output Selection)
Either:
1. Relay Contact Output
2. Voltage Output
Yellow - 1D to 4D (Voltage Bus Selection)
Either:
1. B1 Bus
2. B2 Bus
Black - 1E to 4E (Dry Output Selection)
Either:
1. Relay Contact Output
2. Voltage Output
White - 1F to 4F (Output Invert)
Either:
1. NO - voltage when input is activated
2. NC - voltage when input is deactivated
See the C4/C8 Quick Start Manual or C4/C4P C8/C8P Installation Manual for more detail (available at
http://www.lifesafetypower.com/docs/im_c4c8.pdf).
12 Setup the C4 Power Supply Board

Install the ACM Embedded Controller and V100
Subpanels
Shown below is an overview of the positioning of the ACM Embedded Controller and V100 subpanels.
FPO75
B100 D8P
C4
ACM
Embedded
Controller
V100
V100
Install the ACM Embedded Controller and V100 subpanels as shown below:
1. Unbox the Avigilon ACM Embedded Controller and V100 subpanels.
2. Locate 12 screws from the accessory bag in the FlexPower box.
3. Verify battery jumper (Batt) on the ACM Embedded Controller has been set to ON position.
$"65*0/ This is a non-PoE device. Do not connect J1 (Ethernet port) to aPoE-capable port. This
applies to both direct PoE Power Sourcing Equipment (Endspan PSE) and PoE injector (Midspan PoE)
equipment. Not all PSE's correctly detect non-PoE capable devices, and such PSE's may not fucntion as
expected when connected to non-PoE equipment.
4. Set Port 1 terminating jumper (P6 Port 1TERM Resistor) to IN position.
5. Verify Port 2, 3, 4 terminating jumpers are in the OUT position.
Install the ACM Embedded Controller and V100 Subpanels 13

6. Mount the ACM Embedded Controller as shown below (the arrows show screws).
ACM
Embedded
Controller
V100
Address 0
V100
Address 1
7. Mount the V100 subpanels as shown in step 4.
8. Using a small slotted screwdriver gently turn the V100 addresses as follows:
lSet the top V100 to Address 0(as shown in step 4).
lSet the bottom V100 to Address 1(as shown in step 4).
/05& Always use stranded wires - the recommended gauges are:
l18 AWG – low voltage power wires.
l22 AWG –data wires.
Configure and Wire Data
Follow the steps below to configure and wire the ACM Embedded Controller:
1. Connect the white enclosure tamper wires to Tamper +/- on the ACM Embedded Controller. Polarity does
not matter.
ACM
EMBEDDED
CONTROLLER
14 Configure and Wire Data

2. Using 18 AWG wires (red for +and black for -), wire the 12-24VDC input to +Out1- on the D8P board’s
terminal block.
ACM
Embedded
Controller
Tamper
(Input 5)
+-+
+
---+
AC
Fail
(Input 6)
Batt
Fail
(Input 7)
+12-24VDC
IN
D8P
OUT
8
7
6
5
4
3
2
1
-
-
-
-
-
-
-
-
+
+
+
+
+
+
+
+
3. On the FPO75’s SYSFLT terminal block:
lWire C to Batt Fail + (22 AWG).
lWire NO to Batt Fail - (22 AWG).
ACM
Embedded
Controller
Tamper
(Input 5)
+-+
+
---+
AC
Fail
(Input 6)
Batt
Fail
(Input 7)
+12-24VDC
IN
FPO75
SYS FLT AC FLT FAI INPUT
C NC NO C NC NO
4. On the FPO75’s ACFLT terminal block:
lWire C to AC Fail + (22 AWG).
lWire NO to AC Fail - (22 AWG).
ACM
Embedded
Controller
Tamper
(Input 5)
+-+
+
---+
AC
Fail
(Input 6)
Batt
Fail
(Input 7)
+12-24VDC
IN
FPO75
SYS FLT AC FLT FAI INPUT
C NC NO C NC NO
Configure and Wire Data 15

5. Starting from the ACM Embedded Controller's P3\RS-485 Port1 terminal block, connect the A, B, and
Shield inputs to the V100 Subpanels as shown below (22 AWG).
A
B
Shield
ACM
Embedded
Controller
V100
(Addr 0)
A B Shield
P9
RS-485 In
V100
(Addr 1)
A B Shield
P9
RS-485 In
P3
RS-485
Port 1
/05& On the V100s make sure to use the RS-485 In; avoid using the RS-485 Out.
16 Configure and Wire Data

Configure and Wire Power
Do the following for each V100 in order for the ACM Embedded Controller application to not show an alarm:
1. Place a jumper across Tamper +and -(22AWG).
2. Place a jumper across AC Fail + and -(22AWG).
3. Place a jumper across Batt Fail + and -(22AWG).
4. Connect the 12VDC +/- to the D8P board (18AWG), as noted below:
lConnect the Addr 0V100 12VDC +to Out2+ and -to Out2-.
lConnect the Addr 1V100 12VDC +to Out3+ and -to Out3-.
V100
(Addr 0)
Tamper
(Input 5)
-++ ---+
AC
Fail
(Input 6)
Batt
Fail
(Input 7)
+12VDC
IN
V100
(Addr 1)
Tamper
(Input 5)
+-+
+
---+
AC
Fail
(Input 6)
Batt
Fail
(Input 7)
+12VDC
IN
D8
OUT
8
7
6
5
4
3
2
1
+
+
-
-
-
-
-
-
-
-
+
+
+
+
+
+
+
+
/05& For steps below ensure that the card reader, door monitor (if available), request-to-exit (if
available) and lock wiring from the door are fed into the power supply enclosure and route to the
corresponding port on each V100 as desired.
5. If door monitors are available, connect them appropriately to P2\Door Monitor and P5\Door Monitor.
(Refer to the Door Monitor manual.)
Configure and Wire Power 17

6. If request-to-exit inputs from the door are available, connect them appropriately to the P2\REX and
P5\REX. (Refer to the appropriate Request-to-Exit device manual.)
7. Connect cabling from the R10 readers at the door to the appropriate P1/P4 reader connection on the
V100.
8. Wire the V100s’ strike relay outputs to the C4 board inputs as shown below:
/05& Shown below is the recommended configuration.
IN1A -
IN4B
O1A -
O4B
IN1A, IN1B
IN4A, IN4B
IN3A, IN3B
IN2A, IN2B
NO
C
NO
C
NO
C
NO
C
Using the default C4 configuration:
7 4USJLF 3FMBZ DPOGJHVSBUJPO -PDLFE 6OMPDLF E
NO/C (recommended) 0V 24V
C/NC (alternate option) 24V 0V
If deviation from the default configuration is desired, see the C4/C8 Quick Start Manual or C4/C4P C8/C8P
Installation Manual for more detail (available at http://www.lifesafetypower.com/docs/im_c4c8.pdf).
9. Wire the C4 board’s outputs 1to 4to their corresponding door locks. (See the C4/C8 and Door Lock
manuals for more detail.)
18 Configure and Wire Power

Power On
Follow the steps below to power on and verify the installation:
/PUF:Once connected, the card readers may beep – this will go away once the ACM Embedded Controller has
been configured.
1. Connect the High Voltage AC input to the main power supply.
$"65*0/ Take necessary precautions when handling high voltage wiring.
1
2
/05& On the FPO75 PSU the AC light (green -see 1above) should be on and all warning lights (see 2
above) should be off.
2. Connect the battery set(s), if applicable. See the FPO Quick Start Manual (page 1 – Battery Terminal
Connection) for more detail. Further information is available at: http://lifesafetypower.com/docs/im_
fpo.pdf.
$"65*0/ Observe battery polarity or damage to the system will occur.
3. Connect the ACM Embedded Controller J1 Ethernet port to a laptop or desktop computer (preferably
offline as if you are networked the network may interfere with the IP address).
$"65*0/ Do not connect the ACM Embedded Controller to aPoE port.
Power On 19

Accessing ACM Embedded Controller Application
for the First Time
After the controller has been installed, you need to access the ACM Embedded Controller application to
complete the system configuration.
You can access the application by using the controller hostname or virtual port.
By Virtual Port
By default, every controller can be accessed from this IP address: 169.254.242.121
To perform this procedure, you must use a Windows computer with a web browser and anetwork port.
1. Disconnect the computer from the network.
2. Connect the computer to the controller using an Ethernet cable.
3. On your computer, open command prompt.
4. Enter ipconfig/renew
Wait for DHCP to timeout (approximately 60 seconds). The computer will acquire a 169.254.x.x address.
5. Open aweb browser and enter this address: 169.254.242.121
The controller is now accessible through this virtual port.
6. Enter your login for the application.
The default username and password is admin.
By Host Name
To access the ACM Embedded Controller application by this method, your DHCP server must support hostname
access and only have one controller in the local area network (LAN).
1. Make sure the controller has aLAN connection.
2. Power the controller and wait 60 seconds for the controller to start up.
3. In aweb browser, enter this address: https://acm-ec.γ]Rcf^aY Q^\MW]δ
For example: https://acm-ec.example.lan
The controller is now accessible through this URL.
4. Enter your login for the application.
The default username and password is admin.
See the 24? 6\ORQQRQ 4^]ca^ZZRa ;]bcMZZMcW^] 8dWQR or the 24? 6\ORQQRQ 4^]ca^ZZRa GbRa 8dWQR for more
detail.
20 Accessing ACM Embedded Controller Application for the First Time
