Avigilon H6SL Dome Camera
Installation Guide2.0C-H6SL-D1 2.0C-H6SL-D1-IR 2.0C-H6SL-DO1-IR
3.0C-H6SL-D1 3.0C-H6SL-D1-IR 3.0C-H6SL-DO1-IR
5.0C-H6SL-D1 5.0C-H6SL-D1-IR 5.0C-H6SL-DO1-IR
  8.0C-H6SL-DO1-IR

2
Legal Notices
©2023,Avigilon Corporation. All rights reserved. AVIGILON, the AVIGILON logo, AVIGILONCONTROL CENTER,
and ACC are trademarks of Avigilon Corporation. ONVIFis a trademark of Onvif, Inc. Covered by one or more claims
of the patents listed at patentlist.hevcadvance.com. Other names or logos mentioned herein may be the trademarks
of their respective owners. The absence of the symbols ™ and ® in proximity to each trademark in this document or at
all is not a disclaimer of ownership of the related trademark.
Disclaimer
This document has been compiled and published using product descriptions and specifications available at the time
of publication. The contents of this document and the specifications of the products discussed herein are subject to
change without notice. Avigilon Corporation reserves the right to make any such changes without notice. Neither
Avigilon Corporation nor any of its affiliated companies: (1) guarantees the completeness or accuracy of the
information contained in this document; or (2) is responsible for your use of, or reliance on, the information. Avigilon
Corporation shall not be responsible for any losses or damages (including consequential damages) caused by
reliance on the information presented herein.
Avigilon Corporation
avigilon.com
HTML-PROJECT-A
Revision: 1 - EN
20231130

3
Important Safety Information
This manual provides installation and operation information and precautions for the use of this device. Incorrect
installation could cause an unexpected fault. Before installing this equipment read this manual carefully. Please
provide this manual to the owner of the equipment for future reference.
WARNING
This Warning symbol indicates the presence of dangerous voltage within and outside the product
enclosure that may result in a risk of electric shock, serious injury or death to persons if proper
precautions are not followed.
CAUTION
This Caution symbol alerts the user to the presence of hazards that may cause minor or moderate
injury to persons, damage to property or damage to the product itself if proper precautions are not
followed.
WARNING
Failure to observe the following instructions may result in severe injury or death.
lInstallation must be performed by qualified personnel only, and must conform to all local codes.
lESD to the camera when it is operating could cause a temporary loss of video. When servicing the camera,
follow the appropriate ESD mitigation procedures. The operator should remove any static by grounding
themselves before servicing the camera.
lThis product is intended to be supplied by a UL Listed Power Unit marked “Class 2” or “LPS” or “Limited
Power Source” with output rated Power over Ethernet (PoE), 13 W min.
lDo not connect directly to mains power for any reason.
CAUTION
Failure to observe the following instructions may result in injury to persons or damage to the
device.
lDo not expose the camera directly to high levels of x-ray, laser, or UV radiation. Direct exposure may cause
permanent damage to the image sensor.
lDo not install near any heat sources such as radiators, heat registers, stoves, or other sources of heat.
lDo not subject the device cables to excessive stress, heavy loads or pinching.
lDo not open or disassemble the device. There are no user serviceable parts.
lRefer all device servicing to qualified personnel. Servicing may be required when the device has been
damaged (such as from a liquid spill or fallen objects), has been exposed to rain or moisture, does not operate

4
normally, or has been dropped.
lDo not use strong or abrasive detergents when cleaning the device body.
lUse only accessories recommended by Avigilon.

5
Regulatory Notices
This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1)this
device may not cause harmful interference, and (2) this device must accept any interference received, including
interference that may cause undesired operation.
This Class B digital apparatus complies with Canadian ICES-003 (B)/NMB-3 (B).
The H6SL-DO1-IR models comply with EN 60529 IP66 and IP67 rating.
This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of
the FCC rules. These limits are designed to provide reasonable protection against harmful interference in a
residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed
and used in accordance with the instructions, may cause harmful interference to radio communications. However,
there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful
interference to radio or television reception, which can be determined by turning the equipment off and on, the user
is encouraged to try to correct the interference by one or more of the following measures:
lReorient or relocate the receiving antenna.
lIncrease the separation between the equipment and the receiver.
lConnect the equipment into an outlet on a circuit different from that to which the receiver is connected.
lConsult the dealer or an experienced radio/TV technician for help.
Changes or modifications made to this equipment not expressly approved by Avigilon Corporation or parties
authorized by Avigilon Corporation could void the user’s authority to operate this equipment.
To meet the requirements of the EN 50121-4 Railway Applications Standard, use an external power supply or POE
injector that is also compliant with EN 50121-4. Please contact Avigilon for assistance regarding supporting
equipment.
To meet the requirements of the EN 50130-4 Alarm Systems Applications standard, use an external uninterruptible
power supply (UPS).
This equipment contains a coin cell battery. Risk of fire, explosion, and burns. Do not disassemble, crush, heat above
100°C (212°F), or incinerate.
The use of EMC compliant support and auxiliary equipment with this device is required in order to fully comply with
the EMC regulatory standards.

6
For Korea
Disposal and Recycling Information
When this product has reached the end of its useful life, please dispose of it according to your local environmental
laws and guidelines.
European Union:This symbol means that according to local laws and regulations your product should be disposed of separately from
household waste. When this product reaches its end of life, take it to a collection point designated by local
authorities. Some collection points accept products for free. The separate collection and recycling of your product at
the time of disposal will help conserve natural resources and ensure that it is recycled in a manner that protects
human health and the environment.

7
Table of Contents
Overview 9
Camera Base Front View 9
Camera Base Rear View 10
Camera Base Bottom View 11
Cover View, Surface Mount 11
Mounting Adapter View, Surface Mount 12
(Optional) Cover View, In-Ceiling Mount 12
(Optional) Mounting Adapter View, In-Ceiling Mount 13
(Optional) Cover View, Pendant Wall Mount 13
(Optional) NPT Adapter View, Pendant Mount 14
(Optional) Pendant Wall Mount View 14
Pendant Wall Mount Bracket View 15
Preparing the Installation 16
Pre-Deployment In-Box Configuration 16
Removing the Dome Cover 17
Removing the Configuration Cable 17
Surface Mount Installation 18
Required Tools and Materials 18
Camera Package Contents 18
Installation Steps 18
Using the Surface Mount Adapter 18
Mounting the Dome Camera Using the Bottom Cable Entry 19
Mounting the Dome Camera Using the Side Cable Entry 19
Mounting the Dome Camera to an Electrical Box 21
Installing the Camera Base to the Mounting Adapter 22
In-Ceiling Mount Installation 24
Required Tools and Materials 24
Camera Package Contents 24
Installation Steps 24
Using the In-Ceiling Mounting Adapter 24
Installing the Camera Base to the Mounting Adapter 27
Pendant Mount Installation 29
Package Contents 29
Installation Steps 30
Mounting the Dome Camera to a Pipe 30
(Optional) Mounting the Dome Camera to the Pendant Wall Mount 31

8
Installing the Camera Base to the Mounting Adapter 33
Connecting to the Camera 35
Initializing a Camera Username and Password 35
(Optional) Using the USB Wi-Fi Adapter 35
Assigning an IP Address 36
Setting the IP Address Using the ARP/Ping Method 37
Accessing the Live VideoStream 37
Aiming the Dome Camera 39
(Optional) Configuring microSD Card Storage 40
(Optional) Installing the Microphone Accessory 41
Installing the Dome Cover 42
Zooming and Focusing the DomeCamera 43
Configuring the Camera 43
Connecting to External Devices 45
Connection Status LED Indicator 46
Troubleshooting Network Connections and LED Behavior 46
Removing the Dome Camera from the Mounting Adapter 48
Resetting to Factory Default Settings 49
For More Information 50
Limited Warranty and Technical Support 51

Overview 9
Overview
Camera Base Front View
1. IRIlluminatorProvides scene illumination in the IRspectrum.
Only available on IR models.
2. Ethernet portAccepts power and Ethernet connection to the network. Server communication and image data transmission
also occur over this connection.
3. Link LED indicatorAmber LED indicates if there is an active connection in the Ethernet port.
4. Connection status LED indicatorGreen LED provides information about device operation. For more information, see Connection Status LED Indicator on page46.
5. microSD card slotAccepts a microSD card for onboard storage. For more information, see (Optional) Configuring microSD Card Storage on page40.

Camera Base Rear View 10
Camera Base Rear View
Displayed IR illuminators only available on -IR models.
1. Azimuth controlProvides control of the image angle.
2. Microphone portProvides connection to the Microphone accessory (ACMICR-1001). Indoor models only.
3. I/O connector blockProvides connections to external input/output and audio devices.
4. Micro USB portAccepts a micro USB to USB adapter. Only required when using the USB Wi-Fi Adapter.
5. Tilt lock thumb screwProvides a locking mechanism for the image tilt adjustment.
6. Serial number tagDevice information, product serial number and part number label.
7. I/O Cable Management ClipClip to help secure the I/O cable in place.

Camera Base Bottom View 11
Camera Base Bottom View
1. Cable entry holeAn entry hole for the cables required for camera operation.
2. Lanyard anchorThe safety lanyard attaches to the anchor to prevent the camera from falling during installation.
3. VentVent to allow moisture vapor to escape the sealed housing and equalize pressure.
Cover View, Surface Mount
1. Dome coverVandal resistant dome cover.
2. Surface mount adapterUsed to mount the dome camera to a wall, ceiling or electrical box.
3. Tamper resistant screwsStar-shaped captive screws to fix the dome cover to the mount adapter.
4. Side cable entry coverCovers the side cable entry hole.

Mounting Adapter View, Surface Mount 12
Mounting Adapter View, Surface Mount
1. LanyardConnects to the lanyard anchor on the camera base.
2. Camera housing clipsSnaps to hold camera module during installation.
3. Cable entry holeAn entry hole for the cables required for camera operation.
4. Mounting holesHoles for mounting the adapter to the following:
 A — UK standard single gang box
 B — Octagon gang box
 D — US standard single gang box
(Optional) Cover View, In-Ceiling Mount

(Optional) Mounting Adapter View, In-Ceiling Mount 13
1. In-ceiling mount adapterUsed to mount the dome camera to a wall, ceiling or electrical box.
2. Dome coverVandal resistant dome cover.
3. Tamper resistant screwsStar-shaped captive screws to fix the dome cover to the mount adapter.
(Optional) Mounting Adapter View, In-Ceiling Mount
1. Camera housing clipsSnaps to hold camera module during installation.
2. LanyardConnects to the lanyard anchor on the camera base.
3. ClampsManually adjustable clamps for securing the dome camera to the ceiling.
4. Clamp retainerUsed to hold the clamps together before installation.
(Optional) Cover View, Pendant Wall Mount

(Optional) NPT Adapter View, Pendant Mount 14
1. Pendant wall mountUsed with the NPT adapter to mount the dome camera to a wall in pendant installations.
2. NPT adapterUsed to mount the dome camera to NPT pipes.
3. Tamper resistant screwsStar-shaped captive screws to fix the dome cover to the mount adapter.
4. Dome coverVandal resistant dome cover.
(Optional) NPT Adapter View, Pendant Mount
1. Camera housing clipsSnaps to hold camera module during installation.
2. LanyardConnects to the lanyard anchor on the camera base.
3. 1-1/2” NPT thread mountStandard male 1-1/2" NPT thread mount for mounting the dome camera to a pole or bracket.
(Optional) Pendant Wall Mount View

Pendant Wall Mount Bracket View 15
1. 1-1/2” NPS thread mountFemale NPS thread mount for pendant camera installations.
2. Pendant wall mount screwsScrews for securing the pendant wall mount to the mounting bracket.
3. NPT pipe entry holeA 3/4” NPT threaded hole for NPT pipe conduits.
Pendant Wall Mount Bracket View
1. Bracket mounting holesPoints for mounting the pendant wall mount bracket to a mounting surface.
2. Mounting tabsTabs for placing the pendant wall mount onto the bracket.
3. Mounting pointsPoints for securing the pendant wall mount to the mounting bracket.

Preparing the Installation 16
Preparing the Installation
Pre-Deployment In-Box Configuration
The camera comes equipped with an RJ45 configuration cable pre-installed for users that want to configure camera
settings before installing the camera. The RJ45 connector on the configuration cable is accessible through the small
flap on the side of the camera box for easy configuration before unpacking the camera.
NOTE
The maximum recommended duration of in-box configuration is 1 hour. The maximum
recommended ambient temperature is 30°C (86°F).
1. Locate and open the flap on the side of the camera packaging. Look for the Config label.
2. Connect a network cable to the RJ45 plug on the configuration cable. The network cable must provide PoE.
IEEE 802.3af Class 3, to power the camera during configuration.
3. Connect to the camera using an ACC Client, Unity Video Client, the Camera Configuration Tool, or the
camera's web browser interface to configure the camera's settings. For more information about connecting to
the camera, see Setting the IP Address Using the ARP/Ping Method on page37.
4. Once you have finished making configuration changes, unplug the network cable.
NOTE
Be careful when handling the camera after configuring it inside the packaging. The camera may be
hot when handling it or removing from the packaging immediately after in-box configuration.

Removing the Dome Cover 17
Removing the Dome Cover
NOTE
Be careful not to scratch or touch the dome bubble. The resulting marks or fingerprints may affect
the overall image quality. Keep the protective covers on the outside of the dome bubble until the
installation is complete.
lRemove the dome cover by releasing the elastic strap holding the dome cover to the camera base.
Removing the Configuration Cable
NOTE
Remove the configuration cable by pushing down on the connector's tab and pulling it out of the
port. Next, pull the cord out through the cable entry hole. This cable can be discarded.

Surface Mount Installation 18
Surface Mount Installation
Required Tools and Materials
The following tools are required to complete the installation but are not included in the package:
lNo. 2 Phillips screwdriver — for attaching camera to an electrical box or mounting surface.
Camera Package Contents
Ensure the package contains the following:
lAvigilon H6SL Dome Camera (Indoor models)
oMounting template sticker
o4 screws and anchors for solid walls
oSurface mount adapter
oCable entry grommet
oSide conduit cover
oT20 Pin-In star-shaped driver
lAvigilon H6SL Dome Camera (Outdoor models)
oMounting template sticker
o4 screws and anchors for solid walls
oSurface mount adapter
oSide conduit cover
o1/2" Side conduit plate
oConduit grommet
oCable entry grommet
oT20 Pin-In star-shaped driver
Installation Steps
Complete the following sections to install the device.
Using the Surface Mount Adapter
The dome camera is provided with a surface mount adapter that can be mounted to a wall, ceiling or electrical box.
If the dome camera needs to be installed in a different way, use one of the other mounting adapter options and refer
to their sections in this manual for more information.

Mounting the Dome Camera Using the Bottom Cable Entry 19
lIn-ceiling mounting adapter (SLSPCIL-1001). For more information, see In-Ceiling Mount Installation on
page24.
lPendant NPT mounting adapter (H6SL-MT-NPTA1). For more information, see Pendant Mount Installation on
page29.
oPendant wall mounting adapter (CM-MT-WALL1) — must be used with NPT mounting adapter.
Mounting the Dome Camera Using the Bottom Cable EntryPerform the following steps if the required cables will be coming from inside the mounting surface and the camera
will be mounted immediately over the cable hole. Use this procedure on surfaces that can be easily drilled into, and
when the cables should be kept out of sight.
Perform the following steps to mount the dome camera to a ceiling or wall:
1. Use the mounting template to drill four mounting holes into the mounting surface and drill the cable entry
hole.
2. Pull the required cables through the cable entry hole.
3. Drive four screws to fasten the mounting adapter to the ceiling or wall.
Mounting the Dome Camera Using the Side Cable EntryPerform the following steps if you will be mounting to a surface with the required cables coming out of an external
conduit pipe. Use this procedure if the mounting surface cannot be easily cut, or when cables must be brought along
the outside of the mounting surface.
1. Use the mounting template to drill four mounting holes into the mounting surface.
Make sure the mounting template is aligned to where the conduit will enter the mounting adapter.
2. Pull the required cables through the conduit.

Mounting the Dome Camera Using the Side Cable Entry 20
3. Slide the side cable cover off the mounting adapter.
4. Depending on the conduit used, make the required adjustments to the side cable entry hole:
lIf you are using an interior conduit, install the side conduit cover on to the mounting adapter. Proceed
to step 5.

lIf you are using an exterior conduit:
oInstall a conduit plate to an external conduit adapter. Ensure the plate is compatible with the
size of conduit used.
oIf you are installing an environmental model, you may need to cut off part of the rubber gasket
on the mounting adapter to make room for the plate.
