Avigilon 1.0W-H3-BO1-IR User manual

Installation Guide
Avigilon™ High Definition IP Bullet Camera Models:
1.0W-H3-BO1-IR, 1.0W-H3A-BO1-IR, 1.0W-H3-BO2-IR, 1.0W-H3A-
BO2-IR, 2.0W-H3-BO1-IR, 2.0W-H3A-BO1-IR, 2.0W-H3-BO2-IR,
2.0W-H3A-BO2-IR, 3.0W-H3-BO1-IR, 3.0W-H3A-BO1-IR, 3.0W-
H3-BO2-IR, 3.0W-H3A-BO2-IR, 5.0-H3-BO1-IR and 5.0-H3-BO2-
IR

Important Safety Information
This manual provides installation and operation information and precautions for the use of this camera. Incorrect
installation could cause an unexpected fault. Before installing this equipment read this manual carefully. Please
provide this manual to the owner of the equipment for future use.
The Warning symbol indicates the presence of dangerous voltage within and outside the product
enclosure that may constitute a risk of electric shock, serious injury or death to persons if proper
precautions are not followed.
The Caution symbol alerts the user to the presence of hazards that may cause minor or moderate injury
to persons, damage to property or damage to the product itself if proper precautions are not followed.
WARNING — Failure to observe the following instructions may result in severe injury or death.
lInstallation must be performed by qualified personnel only, and must conform to all local codes.
lThis product is intended to be supplied by a UL Listed Power Unit marked “Class 2” or “LPS” or “Limited
Power Source” with output rated 12 VDC or 24 VAC, 22 W min. or Power over Ethernet (PoE), rated 48
VDC, 22 W min.
lAny external power supply connected to this product may only be connected to another Avigilon product
of the same model series. External power connections must be properly insulated.
lDo not connect directly to mains power for any reason.
CAUTION — Failure to observe the following instructions may result in injury or damage to the camera.
lDo not install near any heat sources such as radiators, heat registers, stoves, or other sources of heat.
lDo not subject the cables to excessive stress, heavy loads or pinching.
lDo not open or disassemble the device. There are no user serviceable parts.
lRefer all servicing to qualified personnel. Servicing may be required when the device has been damaged
(such as from a liquid spill or fallen objects), has been exposed to rain or moisture, does not operate
normally, or has been dropped.
lDo not use strong or abrasive detergents when cleaning the device body.
lUse only accessories recommended by Avigilon.
Regulatory Notices
This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This
device may not cause harmful interference, and (2) this device must accept any interference received, including
interference that may cause undesired operation.
This Class B digital apparatus complies with Canadian ICES-003.
ii

FCC Notice
This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part
15 of the FCC rules. These limits are designed to provide reasonable protection against harmful interference in a
residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not
installed and used in accordance with the instructions, may cause harmful interference to radio communications.
However, there is no guarantee that interference will not occur in a particular installation. If this equipment does
cause harmful interference to radio or television reception, which can be determined by turning the equipment
off and on, the user is encouraged to try to correct the interference by one or more of the following measures:
lReorient or relocate the receiving antenna.
lIncrease the separation between the equipment and the receiver.
lConnect the equipment into an outlet on a circuit different from that to which the receiver is connected.
lConsult the dealer or an experienced radio/TV technician for help.
Changes or modifications made to this equipment not expressly approved by Avigilon Corporation or parties
authorized by Avigilon Corporation could void the user’s authority to operate this equipment.
Disposal and Recycling Information
When this product has reached the end of its useful life, please dispose of it according to your local
environmental laws and guidelines.
Risk of fire, explosion, and burns. Do not disassemble, crush, heat above 100 °C (212 °F), or incinerate.
European Union:
This symbol means that according to local laws and regulations your product should be disposed of separately
from household waste. When this product reaches its end of life, take it to a collection point designated by local
authorities. Some collection points accept products for free. The separate collection and recycling of your
product at the time of disposal will help conserve natural resources and ensure that it is recycled in a manner
that protects human health and the environment.
Legal Notices
© 2012 -2015 Avigilon Corporation. All rights reserved. Unless expressly granted in writing, no license is granted
with respect to any copyright, industrial design, trademark, patent or other intellectual property rights of Avigilon
Corporation or its licensors.
AVIGILON is a registered and/or unregistered trademark of Avigilon Corporation in Canada and other
jurisdictions worldwide. Other product names mentioned herein may be the unregistered and/ or registered
trademarks of their respective owners. ™ and ® are not used in association with each trademark in this document.
iii

Disclaimer
This manual has been compiled and published covering the latest product descriptions and specifications. The
contents of this manual and the specifications of this product are subject to change without notice. Avigilon
reserves the right to make changes without notice in the specifications and materials contained herein and shall
not be responsible for any damages (including consequential) caused by reliance on the materials presented,
including but not limited to typographical and other errors relating to the publication.
Avigilon Corporation
http://www.avigilon.com
920-0087A
Revision: 4 - EN
2015-01-20
iv

Table of Contents
Overview 1
Front View 1
Bottom View 2
Side View 3
Installation 4
Camera Package Contents 4
Precautions for Installing Near Salt Water 4
Installation Steps 4
Adding the Mounting Holes 5
Connecting Cables 5
Mounting and Aiming Video Analytics Cameras 5
Mounting the Camera 5
Assigning an IP Address 6
Accessing the Live VideoStream 6
Aiming the Camera 6
Focusing the Camera 7
(Optional) Configuring Onboard Storage 7
For More Information 7
Connecting to External Devices 8
LED Indicators 9
Removing the Sun Shroud 10
Reinstalling the Sun Shroud 10
Resetting to Factory Default Settings 11
Setting the IP Address Using the ARP/Ping Method 12
Specifications 13
Limited Warranty & Technical Support 15
v

Overview
Front View
1. Sun Shroud
An adjustable cover to help protect the lens against glare from the sun.
2. IR Illuminator
Provides scene illumination in the IR spectrum.
Overview 1

Bottom View
1. Connection Status LED
Provides information about device operation. For more information, see LED Indicators on page9
2. Configuration Panel
Quick access port for configuring the camera during installation. To access the Configuration Panel,
remove the plug with the supplied opening tool.
3. Cable Entry Notch
An entry notch for network, power and I/O cables.
4. Serial Number Tag
Product serial number and part number label.
5. SD Card Slot
Accepts an SD card for onboard storage.
6. Link LED
Indicates if there is an active connection in the Ethernet port.
7. Configuration Ethernet Port
A secondary Ethernet port for configuring the camera. Does not accept PoE.
2Bottom View

Side View
1. Sun Shroud Mount
Mounting bracket for the sun shroud.
2. Mount Arm
Adjustable mount arm for positioning the camera.
3. Mounting Bracket
Allows the camera to be flush mounted or surface mounted.
4. Adjustment Screws
Provides a locking mechanism for the mount arm.
Side View 3

Installation
Camera Package Contents
lAvigilon™ High Definition IP Bullet Camera
lT20 Torx key
l4 screws and anchors for solid walls
lDrill template sticker
lConfiguration Panel opening tool
Precautions for Installing Near Salt Water
Salt environments are hard on camera paint and external appearances but the camera functionality will not be
affected if the cameras are installed as described in this guide.
Follow these precautions to avoid camera issues when installing in a salt heavy environment:
lUse mounting accessories offered by Avigilon. All Avigilon accessories are tested to work with Avigilon
cameras in the rated environments.
lIf you use a third-party accessory, you must ensure that the material is compatible with the finish of the
camera housing or galvanic corrosion may occur.
lNever pair steel mounting accessories with aluminum camera enclosures. Steel corrodes aluminum when
salt is introduced. The corrosion is an electrochemical reaction and will cause the corrosion to spread
across the entire camera body.
lAlways insulate any camera surface that is in contact with another metal or conductive material. It is
recommended that you always isolate the mounting screws from the mounting surface and camera
housing with rubber or plastic shoulder washers.
Installation Steps
Complete the following steps to install the device:
Adding the Mounting Holes 5
Connecting Cables 5
Mounting and Aiming Video Analytics Cameras 5
Mounting the Camera 5
Assigning an IP Address 6
Accessing the Live VideoStream 6
Aiming the Camera 6
Installation 4

Focusing the Camera 7
(Optional) Configuring Onboard Storage 7
Adding the Mounting Holes
lUse the drill template to drill four mounting holes in the ceiling or wall.
Only drill the optional center hole if you are flush mounting the camera. Once the center cable hole has
been drilled, pull the required cables through.
Connecting Cables
To connect the cables required for proper operation, complete the following:
1. If there are external input or output devices that need to be connected to the camera (for example: door
contacts, relays, speakers, etc), connect the devices to the camera's I/O connector cable.
NOTE: You are using the +12 V output for relay drive, you must power the camera using PoE Plus or
auxiliary power.
2. Connect power using one of the following methods:
oPower over Ethernet (PoE) Class 3 or PoE Plus Class 4— If PoE is available, the camera LEDs will
turn on.
oExternal Power — Connect an external 12 VDC or 24 VAC power source through the auxiliary power
cables.
3. Connect a network cable to the Ethernet Port (RJ-45 connector).
The Link LED will turn on once a network link has been established.
4. Check that the Connection Status LED indicates the correct state. For more information, see LED
Indicators on page9.
Mounting and Aiming Video Analytics Cameras
If you are installing an Avigilon™ video analytics camera, follow the listed mounting and aiming recommendations
to maximize the camera's analytics capabilities:
lThe camera should be installed above 274 cm (9').
lThe camera should tilt downwards no more than 45 degrees.
lThe camera image should be level with the horizon line.
lThe camera should be mounted to a stable surface to minimize the physical movement of the camera
after installation.
For more details, see Designing a Site for Video Analytics. The document is available in the eDocs app and on
the Avigilon website.
Mounting the Camera
After the cable connections have been made, mount and secure the camera.
5Adding the Mounting Holes

1. Tuck the extra lengths of cables away:
lIf you are flush mounting the camera, push the extra lengths of cable through the cable hole in the
wall or ceiling.
lIf you are surface mounting the camera, remove the mounting gasket and tuck the connected
cables to one side through the cable entry notch in the mounting bracket. When installed
outdoors, the cable entry notch must face downwards.
2. Ensure the mounting gasket is used when flush mounting the camera.
The gasket is required to maintain the mounting bracket’s water resistance when installed outdoors.
3. Drive the provided screws into the mounting holes and tighten the camera bracket to the mounting
surface.
Assigning an IP Address
The camera automatically obtains an IP address when it is connected to a network.
NOTE: If the camera cannot obtain an IP address from a DHCP server, it will use Zero Configuration Networking
(Zeroconf) to choose an IP address. When set using Zeroconf, the IP address is in the 169.254.0.0/16 subnet.
The IP address settings can be changed using one of the following methods:
lCamera's web browser interface: http://<camera IP address>/
lARP/Ping method. For more information, see Setting the IP Address Using the ARP/Ping Method on
page12
lNetwork Video Management software application (for example, Avigilon™ Control Center).
NOTE: The default camera username is admin and the default password is admin.
Accessing the Live VideoStream
Live video stream can be viewed using one of the following methods:
lWeb browser interface: http://<IP address>/
lNetwork Video Management software application (for example, the Avigilon Control Center software).
NOTE: The default camera username is admin and the default camera password is admin.
Aiming the Camera
1. (Optional) To help you aim the camera, you can connect an Ethernet cable to the secondary Ethernet port
in the Configuration Panel.
a. Use the opening tool to unscrew the plug from the Configuration Panel at the bottom of the
camera.
b. When you remove the plug, be aware that there is a desiccant pack stored inside the plug. If the
desiccant pack falls out, put it back inside the plug before you screw it back over the
Configuration Panel.
Be aware that while the Configuration Ethernet Port is in use, the primary Ethernet port at the back of the
camera will only be used for PoE.
Assigning an IP Address 6

Important: While the Configuration Ethernet Port is in use, the camera will only stream video and accept
commands from the Configuration Ethernet Port. Also, the Indicator LEDs will only show the connection
status for this Ethernet port.
2. To aim the camera, loosen the adjustment screws on the camera mount arm.
Only loosen the screws that can be rotated by the supplied Torx key.
3. Rotate and move the camera and mount arm as required. Review the camera’s live video stream to help
aim the camera correctly.
4. Slide the sun shroud forward or back to protect the camera against glare from the sun. In outdoor
installations, the sun shroud should be set as far forward as possible without intruding on the video image.
lTo move the sun shroud, hold down the black tabs on either side of the camera then slide the sun
shroud forward or back.
5. Once satisfied, tighten the adjustment screws on the mount arm to secure the camera’s position.
6. In theAvigilon Camera Installation Tool or camera web browser interface, adjust the camera’s Image and
Display settings to achieve the desired zoom position.
Focusing the Camera
lIn the Avigilon Camera Installation Tool or camera web browser interface, use the camera’s Image and
Display settings to focus the camera lens.
a. In the Image and Display settings page, use the Auto Focus button to focus the lens.
If the desired focus position was not achieved, use the focus near and far buttons to adjust the
focus.
(Optional) Configuring Onboard Storage
To use the camera’s onboard storage feature, you must insert an SD card into the SD card slot.
It is recommended that the SD card have a capacity of 8GB or more, and a write speed of class 6 or better. If the
SD card does not meet the recommended capacity or write speed, the performance of the onboard storage
may suffer and result in the loss of frames or footage.
1. Insert an SD card into the camera.
CAUTION — Do not force the SD card into the camera or you may damage the card and the
camera. The SD card can only be inserted in the orientation shown on the camera.
2. Access the camera’s web interface to enable the onboard storage feature. For more information, see the
Avigilon High Definition H.264 Camera Web Interface User Guide.
For More Information
Additional information about setting up and using the device is available in the following guides:
lAvigilon™ Control Center Client User Guide
lAvigilon™ High Definition H.264 Web Interface User Guide
The manuals are available on the Avigilon website: http://avigilon.com/support-and-downloads
7Focusing the Camera

Connecting to External Devices
External devices are connected to the device through the I/O terminal. The pinout for the I/O terminal is shown in
the following diagram:
NOTE: The camera can be connected to an external microphone and speaker through the I/O connector.
1. Purple — +12 V output for relay drive
NOTE: If you are using this relay output, the camera must be powered using PoE+ or the auxiliary power
cables.
2. Grey — Relay ground return
3. Red — Relay input 1
4. Pink — Relay output 1
5. * — Relay
6. ** — Switch
lYellow — Audio ground return
lBrown — Audio input
lGreen — Audio output
NOTE: The 12 V connection can be used to energize a relay coil with up to 50 mA. If more than 50 mA is
required, an external power supply up to 25 VDC at 120 mA can be used.
Connecting to External Devices 8

LED Indicators
Once connected to the network, the Connection Status LED will display the progress in connecting to the
Network Video Management software.
The following table describes what the LEDs indicate:
Connection State Connection Status
LED Description
Obtaining IPAddress One short flash every
second Attempting to obtain an IP address.
Discoverable Two short flashes
every second
Obtained an IPaddress but is not connected to the NetworkVideo
Management software.
Upgrading Firmware
Two short flashes
and one long flash
every second
Updating the firmware.
Connected On Connected to the Network Video Management software.
9LED Indicators

Removing the Sun Shroud
The sun shroud is not required when the camera is installed indoors.
1. As you press down on the center of the sun shroud, pull up the corners of the shroud from one side of the
camera. Avoid the black tab on the sun shroud mount.
The sun shroud should lift off the camera.
2. Use a 2mm or 5/64” hex driver to unscrew and remove the sun shroud mount from the camera.
Reinstalling the Sun Shroud
1. Use a 2mm or 5/64” hex driver to screw on the sun shroud mount.
2. Align one side of the sun shroud on to the mount.
3. Press down on the center of the sun shroud until it clicks into place.
Removing the Sun Shroud 10

Resetting to Factory Default Settings
If the camera no longer functions as expected, you can choose to reset the camera to its factory default settings.
Use the firmware revert button to reset the camera.
Figure 1: The firmware revert button in the Configuration Panel.
1. Ensure the camera is powered on.
2. Unscrew the Configuration Panel Plug at the bottom of the camera with the supplied opening tool.
3. Using a straightened paperclip or similar tool, gently press and hold the firmware revert button for 2
seconds.
4. Screw the Configuration Panel Plug back into place.
CAUTION — Do not apply excessive force. Inserting the tool too far will damage the device.
11 Resetting to Factory Default Settings

Setting the IP Address Using the ARP/Ping Method
Complete the following steps to configure the camera to use a specific IP address:
1. Locate and copy down the MAC Address (MAC) listed on the Serial Number Tag for reference.
2. Open a Command Prompt window and enter the following commands:
a. arp -s <New Camera IP Address> <Camera MAC Address>
For example: arp -s 192.168.1.10 00-18-85-12-45-78
b. ping -l 123 -t <New Camera IP Address>
For example: ping -l 123 -t 192.168.1.10
3. Reboot the camera.
4. Close the Command prompt window when you see the following message:
Reply from <New Camera IP Address>: ...
Setting the IP Address Using the ARP/Ping Method 12

Specifications
Camera
Audio Input/Output Line level input and output
Lens
H3-BO1-IR: 3-9mm, F1.2, P-iris
H3-BO2-IR: 9-22mm, F1.6, P-Iris
Onboard Storage SD/SDHC/SDXC slot – minimum class 4; class 6 or better recommended
Network
Network 100Base-TX
Cabling Type CAT5
Connector RJ-45
ONVIF
ONVIF compliance version 1.02, 2.00, Profile S (www.onvif.org).
H3A models are also compliant with version 2.4.2 of the Analytics Service Specification
(bounding boxes and scene descriptions not available with third-party VMS)
Security Password protection, HTTPS encryption, digest authentication, WS authentication, user
access log, 802.1x port based authentication.
Streaming Protocols
IPv4, HTTP, HTTPS, SOAP, DNS, NTP, RTSP, RTCP, RTP, TCP, UDP, IGMP, ICMP, DHCP,
Zeroconf, ARP RTP/UDP, RTP/UDP multicast, RTP/RTSP/TCP, RTP/RTSP/HTTP/TCP,RTP/
RTSP/HTTPS/TCP, HTTP
Mechanical
Dimensions
L x W x H 241.7 mm x 94.9 mm x 70 mm (9.5” x 3.7” x 2.8”)
Weight 1.15 kg (2.5 lbs)
Body Aluminum
Housing Surface mount, vandal resistant
Finish Powder coat, cool gray 2
Adjustment Range ±175° pan, -45° to +90° tilt, ±175° azimuth
Cable Length 45 cm (17.72”)
Electrical
Power Consumption
22 W with external power or IEEE802.3at Class 4 PoE Plus
12.95 W with IEEE 802.3af Class 3 PoE
Power Source
VDC: 12 V +/- 10%, 22 W min
VAC: 24 V +/- 10%, 28 VA min
PoE+: IEEE802.3at Class 4 PoE Plus
PoE: IEEE802.3af Class 3 compliant (Do not use PoE if connecting to +12 V output relay)
RTC Backup Battery 3V Manganese Lithium
13 Specifications

(models with onboard storage only)
Environmental
Operating
Temperature -40°C to +50°C (-40°F to 122°F)
Storage
Temperature -10 °C to +70 °C (14 °F to 158 °F)
Humidity 0-95% non-condensing
Certifications
Safety
UL 60950
CSA 60950
CB Scheme
UVV
CE
ROHS
WEEE
RCM
Environmental IK10 Impact Rating
Meets IP66 Weather Rating
Electromagnetic
Emissions
FCC Part 15 Subpart B Class B
EN 55022 Class B
IC ICES-003 Class B
Electromagnetic
Immunity
EN 55024 Class B
EN 61000-4-2
EN 61000-4-3
EN 61000-4-4
EN 61000-4-5
EN 61000-4-6
EN 61000-4-11
Specifications 14

Limited Warranty & Technical Support
Avigilon warrants to the original consumer purchaser, that this product will be free of defects in material and
workmanship for a period of 3 years from date of purchase.
The manufacturer’s liability hereunder is limited to replacement of the product, repair of the product or
replacement of the product with repaired product at the discretion of the manufacturer. This warranty is void if
the product has been damaged by accident, unreasonable use, neglect, tampering or other causes not arising
from defects in material or workmanship. This warranty extends to the original consumer purchaser of the
product only.
AVIGILON DISCLAIMS ALL OTHER WARRANTIES EXPRESSED OR IMPLIED INCLUDING, WITHOUT LIMITATION,
ANY IMPLIED WARRANTIES OF MERCHANTABILITY OR FITNESS FOR A PARTICULAR PURPOSE, EXCEPT TO
THE EXTENT THAT ANY WARRANTIES IMPLIED BY LAW CANNOT BE VALIDLY WAIVED.
No oral or written information, advice or representation provided by Avigilon, its distributors, dealers, agents or
employees shall create another warranty or modify this warranty. This warranty states Avigilon’s entire liability
and your exclusive remedy against Avigilon for any failure of this product to operate properly.
In no event shall Avigilon be liable for any indirect, incidental, special, consequential, exemplary, or punitive
damages whatsoever (including but not limited to, damages for loss of profits or confidential or other information,
for business interruption, for personal injury, for loss of privacy, for failure to meet any duty including of good faith
or of reasonable care, for negligence, and for any other pecuniary or other loss whatsoever) arising from the use
of or inability to use the product, even if advised of the possibility of such damages. Since some jurisdictions do
not allow the above limitation of liability, such limitation may not apply to you.
This Limited Warranty gives you specific legal rights and you may also have other rights which vary from
jurisdiction to jurisdiction.
Warranty service and technical support can be obtained by contacting Avigilon Technical Support by phone at
1.888.281.5182 or via email at [e-mail].
15 Limited Warranty & Technical Support
