Avision DL-1203S User manual

Document Scanner
User’s Manual
Regulatory model: DL-1203S/DL-1210S
manual-en-250-0741-E-1880v1
Avision Inc.

ii
Trademarks
Microsoft is a U.S. registered trademark of Microsoft
Corporation.
Windows, and Windows Vista are either registered trademarks or
trademarks of Microsoft Corporation in the United States and/or
other countries.
IBM, IBM PC are registered trademarks of International Business
Machines Corp.
Other brands and product names herein are trademarks or
registered trademarks of their respective holders.
Copyright
All rights reserved. No part of this publication may be
reproduced, transmitted, transcribed, stored in a retrieval
system, or translated into any language or computer language,
in any form or by any means, electronic, mechanical, magnetic,
optical, chemical, manual, or otherwise, without the prior
written permission of Avision Inc.
Material scanned by this product may be protected by
governmental laws and other regulations, such as copyright
laws, the customer is solely responsible for complying with all
such laws and regulations.
Warranty
The information contained in this document is subject to
change without notice.
Avision makes no warranty of any kind with regard to this
material, including, but not limited to, the implied warranties
of fitness for a particular purpose.
Avision shall not be liable for errors contained herein or for
incidental or consequential damages in connection with the
furnishing, performance, or use of this material.

User’s Manual
iii
Federal Communications Commission (FCC) compliance
information statement
Part 15
The product has been tested and found to comply with the
limits for a Class A digital device pursuant to Part 15 of the FCC
Rules. Operation is subject to the following two conditions: (1)
this device may not cause harmful interference and (2) this
device must accept any interference received including
interference that may cause undesired operation.
The FCC Class A limits are designed to provide reasonable
protection against harmful interference when the equipment is
operated in a commercial environment. This equipment
generates, uses, and can radiate radio frequency energy and, if
not installed and used in accordance with the instruction
manual may cause harmful interference in which case the user
will be required to correct the interference at his own expense.
As an ENERGY STAR®Partner, Avision Inc. has
determined that this product meets the ENERGY
STAR guidelines for energy efficiency.

iv
European Union Regulatory Notice
Products bearing the CE marking comply with the following EU
Directives:
Low Voltage Directive 2006/95/EC
EMC Directive 2004/108/EC
CE compliance of this product is valid if powered with the
correct CE-marked AC adapter provided by Avision.
CE Warning
This is a class A product. In a domestic environment this
product may cause radio interference in which case the user
may be required to take adequate measures.
*This machine is certified as Class 1 LED product. This means
that this machine does not produce hazardous laser radiation.

User’s Manual
v
Disposal of Waste Equipment by Users in Private Union
This symbol on the product or on its packaging indicates that
the product can not be disposed of with your other household
waste. Instead it should be sent to appropriate facilities for
recovery and recycling in an effort to protect human health and
the environment. Fore more information about where you can
drop off your waste equipment for recycling, please contact
your local city office, your household waste disposal service or
the shop where you purchased the product.
System Requirements
IBM compatible PC 586, Pentium or higher
Microsoft Windows XP SP3, Windows Vista/Windows 7
USB port 2.0 (compatible with USB 1.1)
At least 100 MB of free hard disk space (500 MB is
recommended)
At least 128 MB of system memory (512 MB of RAM is
recommended)
At least 1 GB of RAM for Windows Vista
A CD-ROM drive

vi
Table of Contents
1. Introduction..............................................1-1
2. Scanner Installation..................................2-1
2.1 Precautions ...............................................2-1
2.2 Unlocking Your Scanner ..............................2-2
2.3 Installing the Scanner Driver and Connecting
the Cables..................................................2-3
2.3.1 Connecting to Power.........................2-3
2.3.2 Turning on the Power .......................2-4
2.3.3 Installing the Scanner Driver .............2-4
2.3.4 Connecting to Computer ...................2-6
3. Completing Your First Scan .......................3-1
3.1 Loading Your Paper ....................................3-1
3.1.1 Placing Your Document on the Flatbed 3-1
3.1.2 Loading Your Document in the ADF
Paper Tray ......................................3-2
3.1.3 Notice on Using the ADF....................3-2
3.1.4 Loading Your Cards in the ADF Paper
Tray...............................................3-4
3.1.5 Loading Your Cards and Document on
the ADF Paper Tray ..........................3-5
3.2 Using the Paper Stopper..............................3-7
3.3 Verifying Your Scanner Installation ...............3-8
3.3.1 A Glance of the Scanner Properties
Dialog Box .................................... 3-12
4. Using the Scanner Properties Dialog Box ..4-1
4.1 Buttons on the Scanner Properties Dialog Box 4-2
4.2 The Image Tab ..........................................4-4
4.2.1 The Image Selection Box...................4-5
4.2.2 Other Image Options........................4-8
4.2.3 Scanning color images.................... 4-19
4.2.4 Scanning grayscale images.............. 4-19
4.2.5 Scanning B&W images.................... 4-19

User’s Manual
vii
4.2.6 Editing Profiles............................... 4-20
4.3 The Compression Tab ............................... 4-23
4.4 The Color Dropout Tab.............................. 4-25
4.4.1 Color Dropout Selection .................. 4-25
4.4.2 Other Color Dropout Options............ 4-27
4.5 The Paper Tab ......................................... 4-29
4.5.1 Cropping....................................... 4-30
4.5.2 Other Paper Selection..................... 4-35
4.6 The Multi-Feed Detection Tab..................... 4-38
4.7 The Preview Tab ...................................... 4-46
4.8 The Options Tab....................................... 4-47
4.9 The Setting Tab ....................................... 4-55
4.10 The Imprinter Tab ................................. 4-58
4.11 The Information Tab .............................. 4-62
5. ISIS Interface Operation...........................5-1
6. Using the Buttons......................................6-1
6.1 Installing Button Manager V2.......................6-1
6.2 Checking the Button Configurations Before
Scanning...................................................6-2
6.4 Scanning From One Touch of the Buttons.......6-4
7. Maintenance..............................................7-1
7.1 Cleaning the Flatbed Glass...........................7-1
7.2 Cleaning the ADF .......................................7-2
7.3 Cleaning the Calibration Area.......................7-5
7.4 Replacing the ADF Friction Roller ..................7-6
7.5 Replacing the ADF Roller .............................7-9
8. Troubleshooting........................................8-1
8.1 Clearing a Paper Jam..................................8-1
8.2 Questions and Answers...............................8-3
8.3 Technical Service .......................................8-6
9. Specifications............................................9-1
Index .................................................................. a

User’s Manual
1-1
1. Introduction
Congratulations on your purchase of the color sheet-fed
image scanner. With this scanner, you can you scan your
multi-page documents from the auto document feeder at a
rated speed or scan irregular single-page document from the
flatbed.
Before you install and operate the new scanner, please take
a few minutes to read through this manual. It provides
proper instructions for you to unpack, install, operate and
maintain the scanner.
The following figure indicates the package contents. Please
check all the items against your checklist. If you do not
receive all the items, please contact your authorized local
dealer immediately.

1-2
1. Scanner Main Unit
2. Software CD
3. USB Cable
4. Power Adapter & Power Cord
Note:
1. Only use the AC adapter HEG42-240200-7L by Hitron/DA-
48M24 by APD included in the machine. Using other AC
adapters may damage the machine and void the warranty.
2. Please unpack the packing carefully, and check the contents
against the checklist. If any items are missing or damaged,
please contact your dealer immediately.
2 3 4
1

User’s Manual
2-1
2. Scanner Installation
2.1 Precautions
Keep the scanner out of direct sunlight. Direct
exposure to the sun or excessive heat may cause
damage to the unit.
Do not install the scanner in a humid or dusty place.
Be sure to use the proper AC power source.
Place the scanner securely on an even, flat surface.
Tilted or uneven surfaces may cause mechanical or
paper-feeding problems.
Retain the scanner box and packing materials for
shipping purposes.

2-2
2.2 Unlocking Your Scanner
The scan unit is locked during transport to protect the scanning
mechanism from being damaged. Be sure to unlock the scan
unit before using the machine.
Turn over the machine to
locate the lock switch.
Move the lock switch to the
"unlocked position".
If you need to transport the
machine, please move the
lock switch to the “Locked”
position. Before doing this,
make sure the scan unit at
the left end of the glass as
indicated. (If not, please
turn on the machine. When
the scan unit moves to the
left end, turn off the
machine.)
T
he scan unit
must be at
this position
before being
locked.
“Locked Position”
“Unlocked Position”

User’s Manual
2-3
2.3 Installing the Scanner Driver and Connecting the
Cables
NOTE:
1). The Windows system CD may be required when installing
on some PC’s.
2). To ensure your computer can identify the USB scanner,
please install scanner driver first before connecting the
scanner to your computer.
3). The scanner driver contains TWAIN, ISIS and WIA driver.
If you are running Windows Me, Windows XP, or Windows
Vista, after the installation of scanner driver is completed,
this scanner allows you to scan via a TWAIN, ISIS, or a
WIA (Windows Image Acquisition) interface. Start your
TWAIN-compliant image editing software application to
select a TWAIN or WIA user interface or your ISIS software
to select a ISIS user interface. You may also launch
Microsoft’s Scanner and Camera Wizard to scan via a WIA
user interface.
2.3.1 Connecting to Power
Before connecting, make sure the power switch is off.
Plug the small end of the power adaptor into the power jack of
your scanner. Insert the other end to an appropriate power
outlet.

2-4
2.3.2 Turning on the Power
Press the Power Switch button on the front panel, the Power
LED will flash. When it is finished and ready to scan, the
LED indicator will stop flashing and become steadily on. To
turn off the scanner, press the Power Switch button for
about 3 seconds, the Power LED will be off.
2.3.3 Installing the Scanner Driver
1. Place the supplied CD-ROM onto your CD-ROM drive.
2. The software installation graphic appears. If not, run
“setup.exe”.

User’s Manual
2-5
Contents on the installation graphic:
Install Button Manager V2: To use the buttons
on the scanner, you need to install Button Manager
V2. To ensure Button Manager V2 works properly,
please FIRST install Button Manager V2 before
installing the scanner driver.
Install Scanner Driver: To communicate with
your scanner, you need to install the scanner driver.
After installing the Button Manager V2 software,
click Install Scanner Driver to install the scanner
driver on your computer.
Install Adobe Reader: To view the user’s
manuals for the scanner and Button Manager V2,
you need to use Adobe Reader to open and view the
manuals in pdf file format. If you already have
Adobe Reader installed on your computer, you may
disregard this item.
View Manual: Click “View Manual” to view or
print the detailed user manual for the scanner and
Button Manager V2 respectively.
3. Click Install Button Manager V2 to install the Button
Manager V2 software and then click Install Scanner
Driver to install the scanner driver on your computer.

2-6
2.3.4 Connecting to Computer
1. Connect the square end of the USB cable to the USB port of
your scanner. Connect the rectangle end to the USB port of
your computer.
2. The computer should detect a new USB device and prompt
a “New Hardware Found” message.
3. In Windows XP, click the Next button to continue. When
the XP certification screen appears, click Continue
Anyway to complete the installation.
4. When the Finish dialog is prompted, click the Finish
button.

User’s Manual
3-1
3. Completing Your First
Scan
3.1 Loading Your Paper
3.1.1 Placing Your Document on the Flatbed
Open document cover. Place your document FACE DOWN on
the document glass and align the document to the reference
mark as indicated. Close document cover.

3-2
3.1.2 Loading Your Document in the ADF Paper Tray
3.1.3 Notice on Using the ADF
Before using the ADF, please make sure that your paper meets
the following specifications:
Document(s) can range in size from 3.5 by 2 inches to
8.5 by 14 inches (Legal).
Document(s) can range in weight from 7 to 54 lbs (28
~200 g/m2) (28 g/m2 <A6).
ID cards up to 1.25 mm (0.05 in.) thick
Document(s) should be square or rectangular and in good
condition (not fragile or worn).
Document(s) should be free of curl, wrinkle, tears, wet
ink, or punch holes.
Document(s) should be free of staples, paper clips, paper
sticky notes.

User’s Manual
3-3
Fanning Your Document
Standard paper size should feed easily through the scanner.
To avoid occasional paper jam when automatically feeding
multiple documents, loosen the paper before loading.
Document Feeding
1. Load the stack of document face down with the top of
the pages pointing into the feeder.
2. Verify that the paper guides are aligned with the edges
of the stack.
Your
Document
(Face
Down)
Paper
Guide

3-4
3.1.4 Loading Your Cards in the ADF Paper Tray
1. Place the stack of cards face down with the long dimension
parallel to the paper guide.
2. Adjust the paper guides to center the original. Make sure
the paper guides touch the edges of the original.

User’s Manual
3-5
3.1.5 Loading Your Cards and Document on the ADF
Paper Tray
1. Place your document in the auto document feeder. Adjust
the paper guides to center the original. Make sure the
paper guides touch the edges of the original.
