AVK 3004/001 User manual

Page 1 of 5
Based on AVK-Tech form no. 04.186, rev 3, 15-Nov-2018 Copyright © AVK Holding A/S, original version, rev. 8, 25-MAY-
2022
Installation, Operation and Maintenance Manual -
Version 8.0
VIDI OPEN/CLOSED TRANSMITTER: (3004/001) For indicating
open/close position and transmitting to VIDI Cloud.

Page 2 of 5
Copyright © AVK Holding A/S, original version, rev. 8, 25-MAY-2022 Based on AVK-Tech form no. 04.186, rev 3, 15-Nov-2018
Table of content
Table of content ............................................................................................................................................ 2
1. Important information before installation ............................................................................................ 3
1.1 Product information .................................................................................................................... 3
1.2 General warnings and security measures .................................................................................. 3
1.3 Manufacturer............................................................................................................................... 3
1.4 Notes .......................................................................................................................................... 3
1.5 Disposal and recycling................................................................................................................ 4
1.6 Testing ........................................................................................................................................ 4
2. Installation and operation ................................................................................................................... 4
2.1 Installation guide......................................................................................................................... 5
2.2 Operation description ................................................................................................................. 5
2.3 Activation/deactivation................................................................................................................ 5
3. Maintenance....................................................................................................................................... 5
3.1 Battery replacement ................................................................................................................... 5

Page 3 of 5
Based on AVK-Tech form no. 04.186, rev 3, 15-Nov-2018 Copyright © AVK Holding A/S, original version, rev. 8, 25-MAY-
2022
1. Important information before installation
Thank you for purchasing this product. Please read the instructions carefully
for information about use and safety standards.
1.1 Product information
Model identification data are displayed on the body of the device (see label). More information
about the product can be found by scanning the QR tag on the device label or by contacting
your local AVK sales representatives for more information.
1.2 General warnings and security measures
•Please read this manual carefully, before using the device. All use and installation
instructions are described in this publication that must be stored and found in the
workplace.
•Please read the product datasheet by scanning the QR tag on the device label or by
contacting your local AVK sales representatives.
•Installation must be carried out by personnel who are properly trained to operate on
plants where they will be able to install the device. Therefore, it is absolutely forbidden to
install the device if you are unexperienced.
•Failure to comply with safety standards can have serious consequences for people’s
safety and the operation of the device. The Manufacturer will not take any responsibility
for damages because of failure to comply with these instructions.
•The device must be installed in sufficiently airy places to prevent any internal
overheating.
•Do not place the device in the vicinity of living flames such as candles, torches, etc.
•The device should not be exposed to aggressive chemicals that can damage the plastic.
•The device should be turned off during transport or in stock.
1.3 Manufacturer
ASW-ATI Srl
Via Volontari della Liberta', 54/56, 50053 Empoli FI – ITALY (the ‘Manufacturer’)
The Manufacturer is a subsidiary of AVK Holding A/S (the ‘AVK Group’).
AVK Smart Water is a brand name of the AVK Group.
1.4 Notes
All rights to this manual are exclusive to the Manufacturer. Copying and translating this manual
is prohibited without a written permission from the owner.
The Manufacturer reserves the right to modify the technical specifications or functions of its
products, to cease production of one of its products or to discontinue technical support for one
of its products without notice in writing. The Manufacturer urges its customers to ensure that the
information in their possession is valid and updated.

Page 4 of 5
Copyright © AVK Holding A/S, original version, rev. 8, 25-MAY-2022 Based on AVK-Tech form no. 04.186, rev 3, 15-Nov-2018
1.5 Disposal and recycling
This symbol on the product or packaging indicates that this
product should not be disposed with household waste. Instead,
it is responsible to dispose of waste by taking it to a designated
collection point for recycling electrical and electronic devices.
Separate collection and recycling of waste at disposal will help conserve natural
resources and ensure environmentally and human-friendly recycling.
For more information about the recycling station closest to your home, contact the nearest town
hall waste disposal service or the company where the product was purchased.
Ensure that the rules for the collection of waste and the rules for the correct disposal
and recycling are always respected.
1.6 Testing
Before being sent to the customer, all products are subject to appropriate final testing according
to an internal control plan.
2. Installation and operation

Page 5 of 5
Based on AVK-Tech form no. 04.186, rev 3, 15-Nov-2018 Copyright © AVK Holding A/S, original version, rev. 8, 25-MAY-
2022
2.1 Installation guide
To install this product correctly, please follow the steps below:
1. The open/close transmitter can be used for various types of installation.
2. Mount the switches on boundary points that should be monitored.
3. Mount the magnet facing the switches on a moving part indicating the open or closed
status.
4. Make sure that the transmitter, wires, switches, and magnet are placed without
interrupting the operation of valves or similar.
5. To secure a correct operation, make sure that the magnet is aligned in front of the
switches within 5 mm distance.
6. Mount the transmitter in a location with good radio connection using the included steel
bracket.
Please look in the VIDI Provisioning Manual for further setup.
2.2 Operation description
AVK Smart Water’s VIDI products are equipped with a long-lasting non-rechargeable lithium
battery-powered device that allow the acquisition of physical quantities and sending them using
low-power radio equipment.
The transmitter sends a data package every 30 minutes for LoRa® devices and every 60
minutes for NB-IoT devices, containing the current status of the valve. The magnet can either
be aligned in front of the open switch, in between or in front of the closed switch. The transmitter
sends a package every time the state changes.
2.3 Activation/deactivation
Provisioning and configuration are explained in the VIDI Provisioning Manual.
3. Maintenance
3.1 Battery replacement
The battery replacement can be done by opening the plastic casing. First unscrew the four
screws at the bottom with a 6mm Torx screwdriver (not included) and remove the lid, carefully.
Carefully take out the battery from the casing and disconnect the wire connector attached to the
Printed Circuit Board (PCB). Replace it with a new battery by connecting the wire connector to
the PCB.
A new battery can be requested at your local AVK supplier.
Once the battery is replaced in the case of the LoRaWAN™ transmitter, the message
counters are reset to zero. You must then also reset LoRa® server-side.
