AVM Fritz!Box Quick guide

2FRITZ!Box
FRITZ!Box
This manual and the software it describes are protected by copyright. The manual and soft-
ware as presented are the object of a license agreement and may be used only in accor-
dance with the license conditions. The licensee bears all risk in regard to hazards and im-
pairments of quality which may arise in connection with the use of this product.
This manual and the software it describes may not be transmitted, reproduced or altered in
whole or in part, in any form, by any means, nor may they be translated into any other natu-
ral or computer language. The creation of a backup copy for personal use is excepted. The
information hereby made available to the licensee may be communicated to third parties
only with the written permission of AVM.
This software and documentation have been produced with all due care and checked for
correctness in accordance with the best available technology. AVM disclaims all liability
and warranties, whether express or implied, relating to this product’s quality, performance
or suitability for any given purpose which deviates from the performance specifications con-
tained in the product description.
AVM will not be liable for damages arising directly or indirectly from the use of the manual
or related software, nor for incidental or consequential damages, except in case of intent or
gross negligence. AVM expressly disclaims all liability for loss of or damage to hardware,
software or data as a result of direct or indirect errors or destruction and for any costs, in-
cluding ISDN, GSM and DSL connection charges, related to the software and manual sup-
plied and due to incorrect installations not performed by AVM itself.
The information in this manual and the software it describes are subject to change without
notice for the purpose of technical improvement.
We offer a manufacturer’s warranty for this original product. The conditions of this warranty
are contained in the WARRANTY.PDF file in the SOFTWARE/INFO folder on the product CD in-
cluded with delivery.
The product identification code is part of the license agreement.
© AVM GmbH 2004. All rights reserved.
Documentation release 07/2004
FRITZ!BoxSupport by Fax: + 49 (0)30 / 39 97 62 66
AVM in the Internet: www.avm.de/en
Trademarks: Unless otherwise indicated, all trademarks mentioned are legally protected
trademarks owned by AVM GmbH. This is especially true for product names and logos.
Microsoft, Windows and the Windows logo are trademarks owned by Microsoft Corporation
in the USA and/or other countries. Bluetooth is a trademark of Bluetooth SIG, Inc. licensed
to AVM GmbH. All other product and company names are trademarks of their respective
owners.
AVM Audiovisuelles Marketing
und Computersysteme
Alt-Moabit 95
AVM Computersysteme
Vertriebs GmbH
Alt-Moabit 95
10559 Berlin 10559 Berlin
FRITZ!Box-e.book Seite 2 Donnerstag, 8. Juli 2004 9:37 09

FRITZ!Box – Contents 3
Contents
1 This Is FRITZ!Box 7
1.1 Package Contents . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
1.2 Operation Requirements . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
1.3 FRITZ!Box LEDs . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
1.4 Technical Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
2 Starting FRITZ!Box Operation 12
2.1 Mounting FRITZ!Box . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
2.2 Connecting to the Power Supply and to DSL. . . . . . . . . . . . . . . . . . 13
2.3 Connecting FRITZ!Box to the USB Port of a Computer . . . . . . . . . . 14
2.4 Connecting FRITZ!Box to the LAN Port . . . . . . . . . . . . . . . . . . . . . . . 21
2.5 Connecting FRITZ!Box to a Network Hub or Switch. . . . . . . . . . . . . 23
3 Online with FRITZ!Box 24
3.1 Going Online with the DSL Software FRITZ!web DSL . . . . . . . . . . . 24
3.2 Going Online with Other Access Software or
a Windows XP Broadband Connection . . . . . . . . . . . . . . . . . . . . . . 27
3.3 Setting up FRITZ!Box for Multiple-Workplace Operation . . . . . . . . 28
4 Configuring FRITZ!Box 31
5 Removing FRITZ!Box 37
5.1 Uninstallation in Windows XP . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 37
5.2 Uninstallation in Windows Me and 98 . . . . . . . . . . . . . . . . . . . . . . 38
5.3 Uninstallation in Windows 2000 . . . . . . . . . . . . . . . . . . . . . . . . . . . 38
5.4 Removing the FRITZ!DSL Software . . . . . . . . . . . . . . . . . . . . . . . . . . 39
6 Guidebook 40
6.1 Setting the IP Address . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 40
6.2 Access to Remote Computers or Devices . . . . . . . . . . . . . . . . . . . . 44
6.3 Errors Opening the User Interface . . . . . . . . . . . . . . . . . . . . . . . . . . 46
6.4 DHCP Server . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 47
6.5 Using FRITZ!Box with an Apple Computer . . . . . . . . . . . . . . . . . . . . 48
6.6 Using FRITZ!Box in Linux . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 51
6.7 Connecting Cable . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 56
FRITZ!Box-e.book Seite 3 Donnerstag, 8. Juli 2004 9:37 09

4FRITZ!Box – Contents
7 Information, Updates and Support 57
7.1 Sources of Information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 57
7.2 Updates . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 58
7.3 Assistance from AVM Support . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 59
Index 61
Declaration of CE Conformity 63
FRITZ!Box-e.book Seite 4 Donnerstag, 8. Juli 2004 9:37 09

FRITZ!Box – Typographical Conventions 5
Typographical Conventions
The following highlighting and icons are used to designate im-
portant information:
The hand indicates important instructions that must be ob-
served to avoid malfunctions.
FRITZ! marks useful hints to assist you in working with the
product.
The table below explains the highlighting used in this manual.
Highlighting Function Example:
Quotation marks Keys, buttons, icons,
tabs, menus, com-
mands
“Start / Programs” or
“Enter”
Capital letters Path and file names in
running text
SOFTWARE\INFO.PDF
or README.DOC
Pointed brackets Variables <CD-ROM drive>
Typewriter font Information to be typed
in using the keyboard
a:\setup
Gray italics Tips, instructions and
warnings
...for more informa-
tion, see...
FRITZ!Box-e.book Seite 5 Donnerstag, 8. Juli 2004 9:37 09

6FRITZ!Box – Safety Instructions
Safety Instructions
Observe the following instructions to protect yourself from
physical harm.
!Do not open the FRITZ!Box housing. The device contains
hazardous components and should only be opened by
authorized repair technicians.
!Never let liquids get inside the FRITZ!Box. Otherwise,
electric shocks or short circuits may result.
!Do not install FRITZ!Box during an electrical storm.
Disconnect FRITZ!Box from the power mains during
electrical storms.
!FRITZ!Box is intended for indoor use only.
FRITZ!Box-e.book Seite 6 Donnerstag, 8. Juli 2004 9:37 09

This Is FRITZ!Box
FRITZ!Box – 1 This Is FRITZ!Box 7
1 This Is FRITZ!Box
FRITZ!Box is a DSL modem for fast and easy Internet access.
All you have to do to go online is connect FRITZ!Box with the
computer and with the DSL line and configure an Internet
connection.
FRITZ!Box is equipped with two LAN ports and one USB port,
so that up to three computers can be connected. Each con-
nected computer can establish an Internet connection over
FRITZ!Box.
Other network devices can be connected to the FRITZ!Box
LAN ports as well, including game consoles and network
hubs.
Connection possibilities of FRITZ!Box
With FRITZ!Box all connected computers can share one Inter-
net access. FRITZ!Box contains a router for this purpose. The
firewall integrated in the router protects your network from
attacks from the Internet.
All connected computers are networked together and can ac-
cess shared resources on each other’s drives.
This manual contains information about installing, configur-
ing and operating FRITZ!Box.
DSL
line
FRITZ!Box
DSL
LAN
Expandable: Connect
more computers or a LAN
through a switch or hub
LAN
Windows, Linux or
Apple computer Network devices, such as
g
ame console
s
Computer
Switch/Hub
USB
FRITZ!Box-e.book Seite 7 Donnerstag, 8. Juli 2004 9:37 09

Package Contents
8FRITZ!Box – 1 This Is FRITZ!Box
1.1 Package Contents
The box contains:
!FRITZ!Box
!one power supply unit
!one USB cable (white)
!one network cable (red)
!one DSL cable (black)
Use the DSL cable to connect FRITZ!Box to the DSL line.
!one FRITZ!Box CD with
–Installation Help
–Driver software for installing FRITZ!Box at a comput-
er’s USB port
–FRITZ!Box manual in the “Info” folder
–FRITZ!DSL, the software package for dialing into the
Internet, complete with firewall, port forwarding and
budgeting
!one FRITZ!Box installation manual
!one drilling template (supplied in the installation
manual)
!The Product Identification Code is printed on the back
of the CD case. This number is part of your license
agreement with AVM. Be sure to keep it in a safe place.
FRITZ!Box-e.book Seite 8 Donnerstag, 8. Juli 2004 9:37 09

Operation Requirements
FRITZ!Box – 1 This Is FRITZ!Box 9
1.2 Operation Requirements
In order to operate FRITZ!Box, you must have the following:
!one DSL Line: city network providers, Standard ITU
G.992.1 Annex B, T-Com 1TR112 (U-R2)
!If you want to connect FRITZ!Box over your computer’s
LAN interface, a computer with the following specifica-
tions is required:
–computer with LAN port (standard network adapter
Ethernet 10/100 Base-T), game console or other de-
vices that support a network
–To connect an additional computer with a network
cable, a computer with a network adapter and a net-
work cable are required.
–To connect additional computers or a network, you
also need an Ethernet hub or switch.
–FRITZ!Box also can be connected to a Linux or an
Apple computer via the LAN interface.
!If you want to connect FRITZ!Box over your computer’s
USB interface, a computer with the following specifica-
tions is required:
–computer with USB port (USB version1.1 or 2.0),
hard drive and CD drive
–Operating system: Microsoft Windows XP,
Windows Me, Windows 2000, Windows 98,
Mac OS X from Version 10.3.3 or SUSE Linux
from 9.0 upwards
!To install the FRITZ!DSL software package, the minimum
computer requirements are:
–300 MHz Pentium II processor with Windows XP,
2000, Me or 98 and CD drive
–32 MB RAM
–20 MB free memory on the hard drive
FRITZ!Box-e.book Seite 9 Donnerstag, 8. Juli 2004 9:37 09

FRITZ!Box LEDs
10 FRITZ!Box – 1 This Is FRITZ!Box
1.3 FRITZ!Box LEDs
The LEDs on your FRITZ!Box indicate the following condi-
tions:
LED Event type
Power shows the operation status of FRITZ!Box
remains lit when the device has electrical power and
the DSL line is ready for operation
flashes if the device is connected to the power mains,
but the connection to DSL has been lost
LAN remains lit when a network connection is active to at
least one connected device (network adapter or net-
work hub/switch)
USB remains lit when a USB connection to a computer is
active and the computer is switched on
DSL remains lit when an Internet connection is active (PPP)
Info flashes when the system software is being updated
FRITZ!Box-e.book Seite 10 Donnerstag, 8. Juli 2004 9:37 09

Technical Specifications
FRITZ!Box – 1 This Is FRITZ!Box 11
1.4 Technical Specifications
!approximate dimensions: 160 x 122 x 31 mm
!DSL modem in accordance with the ITU G.992.1 Annex A
or B standard (depending on the model)
!one USB port (USB version 1.1)
!two LAN ports via RJ45 sockets
(standard Ethernet, 10/100 base-T)
!five LEDs that signal the device status
!supply voltage: 230 V / 50 Hz
!maximum power consumption: 9 W
!average power consumption: 6 W
!data transmission rate: max. 8 Mbit/s (downstream),
1 Mbit/s (upstream)
!updatable firmware
!DHCP Server
!DSL router
!firewall and packet filter
!IP Masquerading/NAT
!conforms to CE standard
FRITZ!Box-e.book Seite 11 Donnerstag, 8. Juli 2004 9:37 09

Starting FRITZ!Box Operation
12 FRITZ!Box – 2 Starting FRITZ!Box Operation
2 Starting FRITZ!Box
Operation
This chapter describes the various possibilities for connect-
ing and installing FRITZ!Box. This includes:
!mounting FRITZ!Box
!connecting FRITZ!Box to the mains and to DSL
!connecting FRITZ!Box to the computer
You can connect FRITZ!Box to your computer by means
of a network cable or a USB cable.
These kinds of connections can be combined when
multiple computers are connected.
2.1 Mounting FRITZ!Box
Set or hang up FRITZ!Box in a dry, dust-free location shaded
from any direct sunlight. If you would like to connect
FRITZ!Box using the USB or network cable supplied with the
package, remember to consider the length of the cable and
select a location close to your computer.
If you would like to hang FRITZ!Box on the wall, use the drill-
ing template on the last page of the installation manual.
FRITZ!Box-e.book Seite 12 Donnerstag, 8. Juli 2004 9:37 09

Connecting to the Power Supply and to DSL
FRITZ!Box – 2 Starting FRITZ!Box Operation 13
2.2 Connecting to the Power Supply and
to DSL
First connect FRITZ!Box to the power supply and to DSL. For
this step you need the power supply unit and the black DSL
cable.
Perform the following steps:
1. Connect FRITZ!Box to the power supply using the power
supply unit.
Use only the mains adapter included with delivery. The
use of other adapters may cause malfunctions.
The “Power” LED on FRITZ!Box starts to flash.
2. Connect FRITZ!Box to the DSL line using the black DSL
cable.
Insert one end of the cable into the DSL socket on
FRITZ!Box and the other end in the socket labeled
“DSL” on the DSL splitter.
Connecting FRITZ!Box to the power supply and to DSL
FRITZ!Box
DSL splitter Power
supply
unit
DSL cable
Power cable
FRITZ!Box-e.book Seite 13 Donnerstag, 8. Juli 2004 9:37 09

Connecting FRITZ!Box to the USB Port of a Computer
14 FRITZ!Box – 2 Starting FRITZ!Box Operation
After connecting FRITZ!Box to DSL, the connection be-
tween the device and the DSL line is synchronized
(training). This procedure can take up to 15 minutes. As
soon as the connection to the DSL line is ready for oper-
ation, the “Power” LED stops flashing and stays lit.
2.3 Connecting FRITZ!Box to the USB Port
of a Computer
If you would like to connect FRITZ!Box to your computer over
a USB cable, you must install device drivers on the
computer.
Read the section that describes the installation for your op-
erating system.
In some operating systems the display of menus and folders
can be changed. The following instructions are based on the
standard installation of each operating system.
Installing FRITZ!Box in Windows XP
Administrator rights are required to install the driver soft-
ware in Windows XP.
For this step you require the white USB cable and the
FRITZ!Box CD supplied with the hardware.
Insert the FRITZ!Box CD in your CD-ROM drive to start the In-
stallation Help automatically. Follow the instructions in the
Installation Help to install FRITZ!Box at your computer’s USB
port.
Perform the following steps to install FRITZ!Box without using
the Installation Help:
1. Connect FRITZ!Box to the power supply and to DSL as
described on page 13.
2. Start the computer and then insert the FRITZ!Box CD.
3. Connect FRITZ!Box to the USB port. The USB cable has
two different plugs: one is flat and rectangular and the
other is square.
FRITZ!Box-e.book Seite 14 Donnerstag, 8. Juli 2004 9:37 09

Installing FRITZ!Box in Windows XP
FRITZ!Box – 2 Starting FRITZ!Box Operation 15
Pick up the USB cable and insert the flat plug into a free
USB port on your computer.
4. Then insert the square connector into the socket la-
beled “ ” on FRITZ!Box.
Connecting FRITZ!Box to the USB port of a computer
5. The Windows XP “Add New Hardware Wizard” starts.
Follow the instructions displayed on the screen.
6. A message appears: “New network device installed”.
Confirm by clicking “Finish”.
If FRITZ!Box is installed correctly, the “USB” LED on the
device will be lit up.
FRITZ!Box is now connected and ready for operation.
You can only connect to the Internet if Internet access is con-
figured on the computer. See the section ”Online with
FRITZ!Box“ from page 24 for information about how to config-
ure an Internet connection.
FRITZ!Box
USB cable
FRITZ!Box-e.book Seite 15 Donnerstag, 8. Juli 2004 9:37 09

Installing FRITZ!Box in Windows Me
16 FRITZ!Box – 2 Starting FRITZ!Box Operation
Installing FRITZ!Box in Windows Me
Insert the FRITZ!Box CD in your CD-ROM drive to start the In-
stallation Help automatically. Follow the instructions in the
Installation Help to install FRITZ!Box at your computer’s USB
port.
Perform the following steps to install FRITZ!Box without using
the Installation Help:
1. Connect FRITZ!Box to the power supply and to DSL as
described on page 13.
2. Start the computer and then insert the FRITZ!Box CD.
3. Connect FRITZ!Box to the USB port. The USB cable has
two different plugs: one is flat and rectangular and the
other is square.
Pick up the USB cable and insert the flat plug into a free
USB port on your computer.
4. Then insert the square connector into the socket la-
beled “ ” on FRITZ!Box.
Connecting FRITZ!Box to the USB port of a computer
FRITZ!Box
USB cable
FRITZ!Box-e.book Seite 16 Donnerstag, 8. Juli 2004 9:37 09

Installing FRITZ!Box in Windows 2000
FRITZ!Box – 2 Starting FRITZ!Box Operation 17
5. Windows Me detects a new plug-and-play device to be
installed. Follow the instructions displayed on the
screen.
Keep your Windows CD ready.
6. When asked: “What would you like to do?”, select the
option “Automatic search for a better driver (Recom-
mended).”.
The drivers for FRITZ!Box are installed.
7. Conclude the installation by clicking “Finish”.
If FRITZ!Box is installed correctly, the “USB” LED on the
device will be lit up.
FRITZ!Box is now connected and ready for operation.
You can only connect to the Internet if Internet access is con-
figured on the computer. See the section ”Online with
FRITZ!Box“ from page 24 for information about how to config-
ure an Internet connection.
Installing FRITZ!Box in Windows 2000
Administrator rights are required to install the driver soft-
ware in Windows 2000.
Insert the FRITZ!Box CD in your CD-ROM drive to start the In-
stallation Help automatically. Follow the instructions in the
Installation Help to install FRITZ!Box at your computer’s USB
port.
Perform the following steps to install FRITZ!Box without using
the Installation Help:
1. Connect FRITZ!Box to the power supply and to DSL as
described on page 13.
2. Start the computer and then insert the FRITZ!Box CD.
3. Connect FRITZ!Box to the USB port. The USB cable has
two different plugs: one is flat and rectangular and the
other is square.
FRITZ!Box-e.book Seite 17 Donnerstag, 8. Juli 2004 9:37 09

Installing FRITZ!Box in Windows 2000
18 FRITZ!Box – 2 Starting FRITZ!Box Operation
Pick up the USB cable and insert the flat plug into a free
USB port on your computer.
4. Then insert the square connector into the socket la-
beled “ ” on FRITZ!Box.
Connecting FRITZ!Box to the USB port of a computer
5. The Windows 2000 Hardware Wizard starts automati-
cally. Follow the instructions displayed on the screen.
6. When asked “What do you want Windows to do?”, se-
lect the option “Search for the best driver for your de-
vice. (Recommended)”. Confirm with “Next”.
7. In the next window, select “CD-ROM drives” as the
source for the driver files. Confirm with “Next”.
8. The program reports that a driver was found. Click “Next”
to install the driver.
Then you are informed that a driver for the FRITZ!Box
has been found.
9. Once the files have been copied onto your computer,
conclude this step of installation by clicking “Finish”.
If FRITZ!Box is installed correctly, the “USB” LED on the
device will be lit up.
FRITZ!Box
USB cable
FRITZ!Box-e.book Seite 18 Donnerstag, 8. Juli 2004 9:37 09

Installing FRITZ!Box in Windows 98
FRITZ!Box – 2 Starting FRITZ!Box Operation 19
FRITZ!Box is now connected and ready for operation.
You can only connect to the Internet if Internet access is con-
figured on the computer. See the section ”Online with
FRITZ!Box“ from page 24 for information about how to config-
ure an Internet connection.
Installing FRITZ!Box in Windows 98
Insert the FRITZ!Box CD in your CD-ROM drive to start the In-
stallation Help automatically. Follow the instructions in the
Installation Help to install FRITZ!Box at your computer’s USB
port.
Perform the following steps to install FRITZ!Box without using
the Installation Help:
1. Connect FRITZ!Box to the power supply and to DSL as
described on page 13.
2. Start the computer and then insert the FRITZ!Box CD.
3. Connect FRITZ!Box to the USB port. The USB cable has
two different plugs: one is flat and rectangular and the
other is square.
Pick up the USB cable and insert the flat plug into a free
USB port on your computer.
4. Then insert the square connector into the socket la-
beled “ ” on FRITZ!Box.
FRITZ!Box-e.book Seite 19 Donnerstag, 8. Juli 2004 9:37 09

Installing FRITZ!Box in Windows 98
20 FRITZ!Box – 2 Starting FRITZ!Box Operation
Connecting FRITZ!Box to the USB port of a computer
5. Windows 98 detects a new plug-and-play device to be
installed. Follow the instructions displayed on the
screen.
Keep your Windows CD ready.
6. When asked: “What do you want Windows to do?”, se-
lect the option “Search for the best driver for your de-
vice. (Recommended).”
7. When the program asks where the driver is located, ac-
tivate only the option “CD-ROM drive”.
Specifying the driver location in Windows 98
FRITZ!Box
USB cable
FRITZ!Box-e.book Seite 20 Donnerstag, 8. Juli 2004 9:37 09
