Cyclades OnSite
Branch Office Appliance
Advanced Out-of-Band Management for Branch and Remote Offices
Cyclades®OnSite branch office appliance provides both remote sites and branch offices with a
compact, cost-effective solution for managing IT assets. Unlike competitive offerings, the
Cyclades OnSite appliance has been designed specifically for co-located remote KVM and
console asset management. It may be used to access up to 16 traditional or headless servers,
networking devices, infrastructure components or any other device with a serial console or
KVM port. Cyclades OnSite appliance combines the functionality of Avocent’s KVM over IP
switches with console management features in a single appliance for effective, consolidated
remote management.
Cyclades OnSite appliance's KVM interface uses high performance KVM over IP technology; its
console management features include native support for Microsoft®Windows®2003 EMS
protocol, data buffering, event notifications, and direct access to any console ports. Using an
onboard Web browser interface, Cyclades OnSite appliance does not require special client
software.
Applications
•Easily access, diagnose and restore IT
assets
•Receive proactive notifications of prob-
lems, and manage them before they
become crises
•Perform virtual administration over
UNIX®-, Linux-, AIX®-, Solaris™-based
operating systems, Windows platforms
and network infrastructure components
Benefits
•Eliminate site visits to revive IT assets or
to install software updates
•Reduce mean time to recovery (MTTR)
significantly and increase asset and
personnel productivity
•Achieve console or BIOS-level control
over any IT device with a serial console or
KVM port
•Eliminate separate KVM- or console-
specific management platforms
Cyclades OnSite appliance is:
Powerful
• Leverages embedded Linux technology
Flexible
• Offers a variety of configurations and remote
access paths
Secure
• Supports SSL/SSH, modem dial back and server-based
authentication schemes (e.g., LDAP, Kerberos)
Efficient
• Integrates disparate management functions
Cost-Effective
• Eliminates KVM-to-serial adapters and external
power supplies
Simple to Deploy
• Includes configuration wizards and DHCP support
Server
Server
Router
Switch Windows Server
UNIX Server
Linux Server
Firewall
Router
Cyclades OnSite
Appliance
Cyclades OnSite
Appliance
Cyclades OnSite
Appliance
Cyclades OnSite
Appliance
Database
Switch
Server
Router
PBX
Router
Server
Server
Switch
Remote
Administrator
System
Administrator
Bank
Office Building
Sales Office
Warehouse

Corporate Headquarters
4991 Corporate Drive, Huntsville, AL 35805
TEL [phone] FAX [phone]
www.avocent.com
Avocent, the Avocent logo, The Power of Being There and Cyclades are trademarks or
registered trademarks of Avocent Corporation or its affiliates. All other marks are the
property of their respective owners.
Copyright © 2006. Avocent Corporation. All rights reserved.
0906-COS-DS
Hardware Specifications
CPU: PowerPC MPC859 @ 133 MHz
Memory: 128 MB SDRAM/128 MB flash
Interfaces: 1 Ethernet 10/100BT on RJ-45
1 RS -232 console on RJ-45
2 RS -232 DTE on RJ-45 for power manager or external modem
1 V.92 internal modem on RJ-11
4 or 8 RS-232 serial ports on DB-9
4 or 8 KVM ports on RJ-45
Dual PC Card
Slots Supporting: Secondary Ethernet, wireless Ethernet, GSM, CDMA, GPRS,
ISDN, fiber optic, data storage
Power: Universal AC, 100–240 VAC, 50/60 Hz, 0.7 A max
Environmental:
Operating Temperature: 50°F to 122°F (10°C to 50°C)
Storage Temperature: –40°F to 185°F (–40°C to 85°C)
Humidity: 5% to 90% noncondensing
Enclosure: Powder-coated steel
Dimensions:
(WxDxH) 17 x 10.5 x 1.75 in.
(43.18 x 26.25 x 4.45 cm)
Certifications: FCC part 15A
EN55022
A (CE)
EN55024
EN60950
CSA
C-Tick
ICES-003
VCCI
Part Number Model Description
ATP7441 Cyclades OnSite 441 4 console ports and 4 KVM ports;
1 remote and 1 local user
ATP7841 Cyclades OnSite 841 8 console ports and 4 KVM ports;
1 remote and 1 local user
ATP7881 Cyclades OnSite 881 8 console ports and 8 KVM ports;
1 remote and 1 local user
ATP7882 Cyclades OnSite 882 8 console ports and 8 KVM ports;
2 simultaneous remote KVM users or
1 remote and 1 local user
ATP4610 Cyclades KVM Terminator PS/2
ATP4620 Cyclades KVM Terminator Sun USB
ATP4630 Cyclades KVM Terminator USB PC
ADB0036 Adapter, DB-9 female to RJ-45 female crossover
CAB0036 Cable DB-9 female to RJ-45 male crossover 6 feet
CAB0286 Cable DB-9 female to DB-9 female crossover 6 feet
Features
Security
•SSHv1 and SSHv2
•Local, RADIUS, TACACS+, LDAP, NIS, NTLM, Active Directory and
Kerberos authentication
•Token-based strong authentication (RSA SecurID)
•Local backup user authentication support
•PAP/CHAP authentication (for dial-up lines)
•Dial-back support
•IP packet and security filtering
•User access lists
•System event syslog
•IPSec support
Console Management
•Sun break-safe (Solaris Ready™ Certified)
•Break-over SSH support
•Windows Server 2003 EMS support
•Offline data buffering – local or remote (NFS/Syslog)
•Time stamp for data buffering
•Unlimited number of simultaneous sessions to serial ports
•Simultaneous access on the same port (port sniffing)
•Event notification (e-mail, pager, SNMP trap)
System Management
•Configuration wizard for first time users
•Command line interface (Linux Shell)
•Web Management Interface (HTTP/HTTPS)
•On-screen display for local configuration
•SNMP
•Optional integrated power management with Cyclades PM intelligent
power distribution units (IPDUs)
Server Management via KVM
•Simultaneous access on the same port
• Cyclades OnSite 441, 841, 881, 882 appliances – 1 local and 1 remote user
• Cyclades OnSite 882 appliance – 2 remote users
•Support for VGA resolutions up to 1280 x 1024 @ 60 Hz
•CAT5-based KVM terminators for PS/2, PC USB and Sun USB keyboard and
mouse interfaces
Upgrades
•Upgrades available via FTP
•Flash upgradeable
•TFTP support for network boot
Additional Protocols Supported
•DHCP for dynamic IP address assignment
•PPP/SLIP for dial-up connections
•NTP for time server synchronization
•RFC2217 support for remote serial port access
