Avon Avon II User manual

1 Construct suitable framework. The rafters upon which the bars will sit should be positioned at 'width of sheet + 20mm' centres.
So if you're using 1045mm wide sheeting, position the rafters at 1065mm
centres.
2 diagram showing how the components fit together to form a typical avon bar. these parts should be cut to the same length
as the rafters with an additional overhang of 60MM
assembly GUIDE
ALUMINIUM CORED GLAZING BARS
Avon II Canopy
pvc top-cap
aluminium core
pvc end bar infill
pvc bottom-cap

5Position the eaves retainers between each bar. Align the small nib on the bottom of the eaves retainer with the edge of the
timber beam.
3 Clip the aluminium bar
into the plastic base 4 Fix the connected aluminium bar
and base to the centre of each
rafter. Drill and fix along the rafter
at approximately 600 centres.
eaves retainer
timber
beam
6drill and fix down along the front beam.

8The sheet enclosures should be cut to ‘sheet width - 45mm‘
lengths and positioned over the tapes centrally.
With the sheets being approx. 1045mm wide this leave approx 22.5mm on each side
uncovered.
It is important that on the end of the sheet intended for the gutter that the drip
section faces down as to not impede the flow of water off the sheet. At the end
intended for the wall plate it is important to have the drip facing up to help act
as a water buffer if there are hard driving winds.
Polycarbonate multiwall sheets are UV treated, often this is only on one side. It is
important that this side is the top surface. The sheet will tell you which this is but
general practice is that the cover film with the text on is the UV protected side.
Do not remove the cover films as they will help protect the sheets and let you
know which side is UV treated.
7 The protective film on the sheets should be peeled back
approximately 50mm on all edges and on both sides. Ensuring
the sheet is free from dust moisture and any other debris the sheet
tapes should be applied to the two sheet ends. Vent tape for the
gutter end and and ali tape for the wall end.
22.5mm 22.5mm
Vent tape
Aluminum
tape
wall end gutter end
PREPARING THE POLYCARBONATE SHEET

9 Position the sheets into place. The bottom lip of the sheet
enclosure should tuck in to the eaves retainer which will help
hold the sheet in place.
10Once the sheets are in, click the top-cap firmly into place.
11 For the two bars at each end, place the bar infill into place before adding the top cap. The top-cap should hold the infill
firmly in place.

12
Finally fix the bar endcap
into place with 2 screws. 13click the face covering into
place
14Fix PVC flashing to wall and cut appropriately to sit across canopy.
