Avonic AO-CAP100 User manual
www.avonic.eu
2
Contents
Inhoud
Contents.....................................................................................2
Introduction .............................................................................. 3
Congratulations............................................................................................................................. 3
Safety Notes .................................................................................................................................... 3
Package contents and Accessories....................................3
Product Overview ....................................................................4
Features............................................................................................................................................ 4
Product Description...................................................................................................................... 4
Installation ................................................................................5
Connection Diagram ................................................................................................................... 5
Operation Instructions ...........................................................5
VLC ....................................................................................................................................................... 6
Contact.......................................................................................7
Appendix....................................................................................8
Technical Data ............................................................................................................................... 8
www.avonic.eu
3
Introduction
Congratulations
Thank you for purchasing the Avonic AV-CAP100 device. Before beginning to
operate this device, please read the manual in order to make sure the best
performance is obtained. Save this manual for future reference.
Safety Notes
•Installation and servicing should only be done by Qualified Service
Personnel and conform to all local codes.
•This unit is designed for indoor use only and it must not be installed where
exposed to water or other liquids and moisture.
•Before powering on the device, check the input power voltage carefully.
•Avoid shock and vibration when transporting and installing the device.
•Use wall mount brackets or ceiling mount brackets available at Avonic for
safe installation.
•Electronic devices produce heat. Do not block the ventilation slots of the
device and make sure the installation environment is well ventilated to
avoid overheating.
•Before cleaning, unplug the power cable. Use a soft, damp cloth to clean the
device, do not use strong or abrasive detergent to clean that will damage
the device.
•If you wish to dispose this product, please contact Avonic to obtain info
about the take-back procedure.
Package contents and Accessories
Quantity
Decription
Avonic SKU
1 pc
HDMI to USB3.0 Video Capture Dongle
AV-CAP100
1 pc
USB 3.0 cable
-
www.avonic.eu
4
Product Overview
The Avonic AV-CAP100 HDMI to USB3.0 Video Capture Dongle is easy to carry, has a
superior performance and superior compatibility. It can capture one HDMI 1080p60
input and output signal; compatible with Windows, Linux, Mac OS X and USB 3.0
interface. Compatible with many USB 3.0 chipset (Intel, Renesas, ASMedia, Fresco
Logic), compatible with PCIe Gen1.1 x1 expansion via USB 3.0 interface. The HDMI
video capture meets UVC and UAC standard, without having to install any
additional drivers.
Features
•It doesn’t need to install a driver, and it is truly PnP.
•It is compatible with Windows, Linux, OS X operating systems
•USB3.0, 300-350MB/s throughput and it is compatible with USB 2.0
•The process of video and audio is done by the dongle and will not occupy
the CPU.
•It can capture one single channel HD HDMI video signals.
•It can automatically detect the input video formats and it will adjust to the
set output size and frame rate automatically.
•The input and output video signal can reach 1080p60 Hz.
•It is compatible with UVC video capture and YUV 4:2:2 video output.
Product Description
www.avonic.eu
5
1. HDMI Input: connect the HDMI source output like DVD, Set-top Box or
Notebook.
2. USB3.0 Capture out: connect to the USB3.0 input of the computer or
Notebook.
3. Power indicator: LED illuminates when the device is connected to computer
USB port.
4. Action indicator: LED illuminates when the device capture the video
normally.
Installation
Connection Diagram
Use a high quality HDMI cable connect the source to the dongle.
Use a USB 3.0 cable to connect from the dongle to PC or Notebook.
Operation Instructions
The Avonic AV-CAP100 HDMI to USB3.0 Video Capture Dongle is based on UVC (USB
video class) and UAC (USB audio class) standard. No additional drivers have to be
installed. After installation in operating system, the relevant video and audio
devices will be added. In the Windows Device Manager, for example, will appear
two new devices:
•Under Imaging Devices: USB3.0 Capture video
•Under Audio inputs and outputs: USB3.0 Capture audio
Use a third party Video Media Player like PotPlayer, VLC, Windows Media Player to
play and store the captured video content.
www.avonic.eu
6
VLC
To view the image from the AV-CAP100 in VLC, open a new media.
Open Media, Capture Device, Device Name, enter the desired Video Size in the
Options section
Press Advanced Options, enter the desired aspect ratio
www.avonic.eu
8
Appendix
Technical Data
Host Interface
USB3.0, *300-350MB/s, USB2.0, *40MB/s
Input Interface
HDMI interface
HDMI Input Formats
1080p24/25/30/50/60;
Output Formats
Resolutions:
640x480 / 720x480 / 720x576 / 768x576 / 800x600 /
1024x768 / 1280x720 / 1280x800 / 1280x960 / 1280x1024 /
1368x768 / 1440x900 / 1600x1200/ 1680x1050/ 1920x1080/
1920x1200/ 640x360/ 856x480 /960x540/ 1024x576
Frame Rate:
25/29.97/30/50/59.94/60 fps
Audio and video
capture
standards of UVC and UAC
OS
Windows7, Windows Server 2008 R2,Linux (Kernel
version 2.6.38 and above), OS X (10.8 and above)
Software
compatibility
Windows Media Encoder, Adobe Flash Media Live
Encoder, Real Producer Plus, VLC, Linux, QuickTime
Broadcaster, QuickTime Player, Wirecast, Potplayer
etc.
Size
98x56x16 (L/W/H, mm)
Power consumption
<= 2.5W
Working
Temperature
0-50 °C
Storage
Temperature
-20-70 °C
Storage Humidity
5%-90%
