AVR Cinema Mirror HC 37.53 Assembly instructions

INSTRUCTIONS ANDTIPS FORTHE INSTALLATION
OF THE HC 37.53 MODEL CINEMA MIRROR
GENERAL RECOMMENDATIONS FOR ASSEMBLY AND INSTALLATION
CONSIDERATIONS
Cinema Mirror is an active optic set to be
installed in false ceilings hiding the
projection equipment, and that through
a pulsation it opens a floodgate of
335x335 mm., allowing the projection of
the image, thanks to its two mirrors,
without causing the trapeze effect on the
image. For that, Cinema Mirror and the
screen must be in the same plane or with
a difference from 0 to 12 cm. (Fig. 1).
Always be sure to perpendicularly set the
projected light with the projection screen,
any difference may negatively affect the
image (Fig. 2).
The optic mirrors of this equipment are
protected by a plastic film to avoid
accidents. Remove this film when it is
indicated by this manual.
Do not do so beforehand.
1
figure 2
figure 1
d = projector’s focal – 20 cm.
y
x
x = y

2
Before proceeding to the installation and
manipulation,read carefully this manual and
follow conscientiously all the warnings and
cautions that are described.
GENERAL RULES
The equipment should be installed by
installers specialized in public locations.Install
and protect the line in accordance with the
low-tension electrical technical regulations,
as well as the MIE-BET-025 complementary
technical instructions, “Installations in
locations of public concurrence”. The
equipment should be connected to ground
protection.
All the required electric works of this
equipment should be carried out by
electricians, qualified electronics or
competent people according to the electrical
technical regulations of each country.
The alimentation requires an automatic
bipolar switch with MINIMUM 3 mm
separation between contacts.
Flammable materials must not be
placed within a radius of 1 meter of
the equipment (see instruction manual
of video projector to be installed).
Secure and protect the alimentation cables
and hoses, gear, material, etc. in such a way
that they are not near: moving parts or heat
sources.
The equipment must be installed in the
ceiling at a distance so that it is not within
arms reach of a person. Secured above the
site itself or on a metallic bracket strong
enough to hold the weight of the equipment
plus the image projector.
The equipment operation is: for interior use
in a false ceilings.
The operating position is horizontal with the
hatch facing downward.
The equipment will not be accessible during
operation, before accessing the means of
connection or the inside of the equipment,
all electrical alimentation circuits of the
equipment must be disconnected.
In the event of any questions, contact the
Technical Service or your distributor.
SAFETY
The equipment should be examined every
90 days, the structure fasteners, movable
parts,mechanical cables,electrical parts,etc.
should be checked and lubricated if
necessary.
Do not install this unit in an unstable place.
Do not alter neither modify this unit.
Do not use this unit in a bathroom neither
near liquids or inflammable gases.
Do not connect the unit to an electric tension
different from the one specified.
Do not force the storm door in their opening
or closing journey, since the mechanics of
the motor could be seriously damaged.
BEFORE USING FOR
THE FIRST TIME
INSTRUCTIONS ANDTIPS FORTHE INSTALLATION
OF THE HC 37.53 MODEL CINEMA MIRROR
GENERAL RECOMMENDATIONS FOR ASSEMBLY AND INSTALLATION

(4)
(6)
(8)
(3) (7)
(2)
(1) (9)
(9)
(5)
INCLUDED ACCESSORIES
-Connection Cable 230 V.A.C.
-Connector for push-button
(Push-button not included)
-Graded plate
-User Manual
DEFINITION AND FUNCTION OF
COMPONENTS
1Variableposition table
2Position control lever of the active lens
3
3Protection case of the electric equipment
4Protection case of the mechanic equipment
5Connection of the pushing-button and
connection 230 VAC
6Passive lens
7Active lens
8Closing connecting rod and parallelism
9Leveling supports of variable height
figure 3
1,5 meters
INSTRUCTIONS ANDTIPS FORTHE INSTALLATION
OF THE HC 37.53 MODEL CINEMA MIRROR
GENERAL RECOMMENDATIONS FOR ASSEMBLY AND INSTALLATION
ADJUSTING
SCREW

4
INSTALLATION
PROCEDURE
Cinema Mirror has been built with the
knowledge of technical ceiling features.For
this reason,it has leveling supports (see Fig.
3 Detail 9) that adapt to the“T”ceiling profiles
and allow you to install it without the use of
tools.
If the ceiling is made of plaster, wood,glass,
etc. and it does not have profiles, adapt a
HC 635 model ceiling frame kit. An
aluminium profile designed to adapt ceilings
to Cinema Mirror and give access to the
interior of the ceiling (see accessory page).
Order it from your distributor.
BEFORE PROCEEDING TO INSTALL
The area where Cinema Mirror will be
installed,next to the projection equipment,
will support an extra weight. Reinforce the
perimeter next to the installation area (Fig.
4) with the accessories recommended by
the manufacturer.
CHOOSE THE PLACE OF THE
INSTALLATION
The projectors do not have the same focus
distance.If you do not know the optic data
of the projector ready to be installed proceed
as follows.
Place the projector on a table. Connect the
electric current to the projector and switch
on the projection equipment. Leave it for a
few minutes so that the projector reaches
its maximum brightness.
Keeping the zoom control in the maximum
opening, bring the equipment closer to, or
move it further away from the test wall that
you have chosen until obtaining the desired
screen - image width. In this case, measure
the distance between the lens and the image.
Put the zoom in the minimum opening,and
move the projector away until obtaining the
same screen width than the obtained in the
previous paragraph, and measure the
distance between the lens and the image.
Calculate the focal distance with the
following formula:
The average optic centre determines the
distance and the place to install the projector
and in consequence Cinema Mirror.
You can get bigger precision if you deduct
20 cm of the journey from the projector lens
to the active lens.
figure 4
Average optic center = 2
maximum zoom distance (cm)
+ minimum zoom distance (cm)
INSTRUCTIONS ANDTIPS FORTHE INSTALLATION
OF THE HC 37.53 MODEL CINEMA MIRROR
GENERAL RECOMMENDATIONS FOR ASSEMBLY AND INSTALLATION

5
INSTALLATION
Remove the 6 screws that secure the table
to the Cinema Mirror chassis.
Secure the variable position table, with its
screws,in the best place so that the projector
rests on its support feet.
Place the projector on the variable position
table horizontally centred relative to the
passive mirror.This will be its working place.
ADJUSTMENT OF THE PASSIVE
MIRROR
To centre in height the passive mirror, (Fig.3
detail 6),in relation to the lens of the projector,
remove the screws that hold it to the chassis
and move them up and down so that the
centre of the mirror stays at the centre of the
lens of the projector.Tighten firmly, but not
to strong,the axis of the mirror to the holes
of the chassis, to make possible an ulterior
adjustment of the axis.
Place the graded plate supplied with the
equipment on the Cinema Mirror profile
(Fig.6).
The passive mirror should be placed to 37º
in relation to the base of the projector.Please
turn the passive mirror up so that the angles
between the mirror and the template
coincide in parallel.Fasten strongly the screws
of the axis of the passive mirror.
UNPACKAGING AND PROCESS OF
ASEMBLY
Open the box of the Cinema Mirror and take
out the protection butt plates.
Take out the plastic covers.
Take out the rubber of protection of the
floodgate of the active mirror.
Place a fabric table cloth on a board, table,
bench, etc. to protect and take care of the
paintwork on the equipment gate.Separate
the bevel from the gate and leave it ready
to be installed later in the ceiling finish.Leave
Cinema Mirror on the table cloth.
Projectors do not always have the optic
in the same place; it can be to the left,
centred, or to the right.
For this reason, Cinema Mirror is equipped
with a tray called variable position table
(Fig.5).
The variable position table has 5 positions:
1centred, 2moved to the left, 3moved to
the right, 4turned 180º and centred, and 5
turned180º and to the right.
figure 5
figure 6
right
centred
left
INSTRUCTIONS ANDTIPS FORTHE INSTALLATION
OF THE HC 37.53 MODEL CINEMA MIRROR
GENERAL RECOMMENDATIONS FOR ASSEMBLY AND INSTALLATION

6
Now the height of the chassis can vary and
can be levelled with the roof. To level them,
please unfasten the screws of the leveling
supports which holds the chassis and screed
the latter to the same height of the surface of
the roof.Fasten again and strongly the screws.
ATTENTION PLEASE! The motor system
(active door) is not prepared to carry heavy
loads, as for example, parts in wood, cork,
glass,etc.,that one might want to install on
the door as decoration items.
If you desire this,try to modify the finish,by
painting or imitating the painting by means
of a very thin foil,to be able to integrate the
finish of the door of the Cinema Mirror to
the roof decoration in which it is installed.
Install the projector on the variable position
table.
·Placetheprojector optic as close to the
passive mirror as possible.
·Placethe projector optic centred relative
to the passive mirror.
NOW CINEMA MIRROR IS
READY TO BE INSTALLED
IN THE CEILING
INSTALLATION IN THE CEILING
Remove the plate that coincides with the
projector focal distance from the technical
ceiling and leave it aside for its use later on
the final finish of the ceiling.
If the ceiling is made of stucco, wood, glass
etc, install the HC 635 ceiling frame kit
beforehand;Four“T”profiles to be assembled
with its accessories so as to facilitate the
perfect decorative finish of the ceiling.
Insert the Cinema Mirror with the optic
mirrors facing the place where the projection
screen will be installed.Place the chassis onto
the“T”shaped profiles of the technical roof,
(or the HC 635 frame Kit ),and make coincide
the 2+2 leveling supports of the chassis
(Figure 3, detail 9) with the technical roof
profile.
IF THE INSTALLATION IS NOT EQUIPPED
WITH A WORKABLE TECHNICAL CEILING,
BUILD YOUR OWN SPACE USING THE
HC 635 MODEL CEILING FRAME KIT.
(see accessory page)
switch (not supplied) with separation among
contacts of 3 mm. (ELECTRIC DIAGRAM)
Connect the video,DVD,PC, control signals,
etc, following the instructions of the
videoprojector maker.Secure the cables with
flanges or plastic loops,(available in shops),
ELECTRICAL CONNECTION
Connect a pushing-button (not included,of
1A 230 V.A.C.) to the supplied entrance
connector. Insert the connector of the
pushing-button in the Cinema Mirror.
Connect the power source cable to the
electric net and to protect with a bipolar
checking that they do not restrict the access
and movement of the chassis on the
technical ceiling “Ts”or supports.Move the
cables away from the area to facilitate the
later handling of the videoprojector:cleaning,
lamp replacement, etc.
OPENING – CLOSING
BUTTON CONNECTION
IMPULS RELAY
MOTOR
CLOSING SWITCH OPENING SWITCH
ELECTRIC CURRENT INPUT
PHASE (L1) BROWN
EARTH ( ) YELLOW / GREEN
NEUTER (N) BLUE
INSTRUCTIONS ANDTIPS FORTHE INSTALLATION
OF THE HC 37.53 MODEL CINEMA MIRROR
GENERAL RECOMMENDATIONS FOR ASSEMBLY AND INSTALLATION

7
·Placethecontrol lever on the upper part.
·Activatethe motor with the installed push-
button.
·Observe the image that is projected on the
screen. To lower the image the control lever
should be moved downward. The motor
actives and positions the active door as
desired.
·Repeat this operation until reaching the
desired image height.
ATTENTION.
If the whole image is not represented on the
projection screen,this may be due to the fact
that:
•The projector zoom is closed.
•The projector is very near the passive mirror.
•The active mirror is excessively closed.
Correct these differences.
The image may not be parallel with the
projection screen base due to height
differences between the place of installation
of the screen and that of the projector (Fig.
7A).
In the connecting rods that move the active
mirror, (Fig 3 detail 8) there is a connecting
rod-active mirror regulation screw that
corrects the defect.If you want to lift the image,
move the connecting rod screw of the place
affected upwards. (Fig.7B)
Remember the adjustment elements that you
have to obtain a cinema image.
1.- Projector zoom and focus.
2. - Vertically adjustable feet,in the projector.
3. - Trapeze correction, manual, automatic or
electronic,in the projector.
4.- Passive mirror turn.
5.- Active mirror movement
6.- Horizontal image control in the connecting
rods.
7. - Left / right movement of the projection
screen (only some makers)
8.- Regulation of the height extension of the
projection screen.
HOW TO ADJUST THE
IMAGE TO THE SCREEN
ATTENTION – DANGER !!
Take out he rubber that blocks the door
during the transport (if you have not already
made it), before triggering the movement
pushbutton of the active mirror gate,make
sure that there are no obstacles hindering
its opening or closing.Do not make any effort
to stop or help the active mirror gate in its
path, the mechanics of the motor can be
seriously damaged and the warranty of the
product will be lost.
If you observe any defect, this may be due
to the handling or lack of care during
transport of Cinema Mirror. Contact your
distributor's technical service.
Activate the button for opening or closing
(not included) on the Cinema Mirror. The
motor of the active mirror will be put into
operation.
Remove the film that protects the optic
mirrors during transport and pre-installation.
Switch on the projector and wait a few
minutes so that the projector reaches its
maximum brightness.
The light or image thrown by the projector
through the active mirror determines the
place where the projection screen should
be installed.
Remember that you can work on the
projector zoom to fix the screen width.
Install the projection screen guided by the
light spectrum thrown by the projector. If
you use a screen with black side margins,
the image will be better profiled;as television
sets do in their cathode ray tubes.
INSERT A VIDEO OR PC SIGNAL IN
THE INSTALLED PROJECTOR
The control lever of red color regulates the
position and opening of the active mirror
(Fig. 3 detail 2) and consequently, the
projection height on the screen.
figure 7A
figure 7B
INSTRUCTIONS ANDTIPS FORTHE INSTALLATION
OF THE HC 37.53 MODEL CINEMA MIRROR
GENERAL RECOMMENDATIONS FOR ASSEMBLY AND INSTALLATION

8
Place the bevel on the marks A and B, and
draw the contour lines.With a cutting tool
remove the space that must be occupied by
the gate.
The installer should locate his working
position in the square of the technical ceiling
plate, adjacent to the Cinema Mirror
installation.
Move the Cinema Mirror-projector set as
much as is necessary to install the modified
technical plate.
Place the Cinema Mirror-projector set in the
space chosen.
Lightly press the bevel pins outwards and
adjust them to the gate.
Check the light-image on the screen.
Provide the finishing touches to the ceiling
finish according to the characteristic
requirements of the space.
FINAL FINISH OF THE CEILING
Once we are definitively satisfied with the
image obtained,we will proceed to close the
ceiling with the same material used by the
maker of the technical ceiling. If you use
other materials, try to use materials with a
very low weight.Consult the possibilities of
painting or masking of the material used for
a correct simulation with the original ceiling.
ATTENTION PLEASE! The motor system
(active door) is not prepared to carry heavy
loads, as for example, parts in wood, cork,
glass,etc.,that one might want to install on
the door as decoration items.
If you desire this,try to modify the finish, by
painting or imitating the painting by means
of a very thin foil,to be able to integrate the
finish of the door of the Cinema Mirror to
the roof decoration in which it is installed.
Take the measurements in which the gate
was located with the frame,measurements
A and B (Fig 8). Mark the measurements A
and B on the technical ceiling plate
(60x60cm), (or replacement material).
figure 8
MAINTENANCE
The mechanics and mobile parts of the
equipment don't specify of a severe
maintenance, but if it is convenient the
application of a lubricant in the mobile parts,
with a minimum periodicity of 90 days.
Revise the electric installation and its
connections, likewise revise the anchorage
from the unit to the roof.
The optic lenses will clean with non abrasive
cloths, using neuter soaps or simply with
common water.
A B
INSTRUCTIONS ANDTIPS FORTHE INSTALLATION
OF THE HC 37.53 MODEL CINEMA MIRROR
GENERAL RECOMMENDATIONS FOR ASSEMBLY AND INSTALLATION

9
TECHNICAL SPECIFICATIONS
TECHNICAL FEATURES HC37.53
Supply: Mod.E 230 VAC / 50Hz.
Mod.US 115 VAC / 60Hz.
Power: 10 W
Starter (push-button not included): Instantaneous / 1 A to 230 VAC
Noise level: < 15 dB
False ceiling minimum height: From 170 mm to 217 mm
Maximum height of floodgate slope: 265 mm
Mirror opening time: 30”
Motor reducer: 500/1
Minimum dimension of the hole to embed: 335 mm x 335 mm
Mechanical Dimensions (mm): LONG 625 / WIDE 395 / HIGH 170
Packed Dimensions (mm): LONG 680 / WIDE 460 / HIGH 240
Max.weight admitted: 5,0 Kg
Net weight: 8.2 Kg
Gross weight with packing: 12.3 Kg
ACTIVE
MIRROR
DOOR
OPTIONAL ACCESSORIES
Frame Kit HC 635
Four aluminium sections,squares,screws,etc..
to build a frame that replace the technical
ceiling outlines (Armstrong or similar), and
gives a professional ending and support in
plaster ceilngs, wood ceilings, etc… With a
professional ending as support on your
Cinema Mirror installations.
Inside Dimensions: 597x597 mm
Outside Dimensions: 640x640 mm
395
610
625
395
max 217 / min 170
max 265
max 43
min 24
(dimensions in mm).
INSTRUCTIONS ANDTIPS FORTHE INSTALLATION
OF THE HC 37.53 MODEL CINEMA MIRROR
GENERAL RECOMMENDATIONS FOR ASSEMBLY AND INSTALLATION
