AWA CL-40KDF10S User manual

User’S Manual
101cm LCD Television
CL- 40KDF10S
Please read this user’s manual carefully before operating your set.
Retain it for future reference.

AWA Hot Iine
1300 366 144

Contents
2
Caution .......................................................................................................................................................... 4
Important Safety Instructions .................................................................................................................... 5
Precaution ..................................................................................................................................................... 6
Viewing the Control Panel .......................................................................................................................... 11
Viewing the Connecting Panel .................................................................................................................. 12
Remote Control ............................................................................................................................................ 13
Remote control functions ..................................................................................................................... 13
Teletext operations ............................................................................................................................... 14
Loading the Batteries ............................................................................................................................ 15
Reception Range of Remote Control................................................................................................... 15
Table Stand Installation .............................................................................................................................. 16
Wall Mount Installation (Optional) ............................................................................................................. 16
Connecting the TV Cable ........................................................................................................................... 17
Connecting the VCR .................................................................................................................................... 18
Watching VCR .............................................................................................................................................. 18
Connecting the DVD .................................................................................................................................... 19
Connecting the Set Top Box ...................................................................................................................... 20
Connecting the PC (D - Sub) ..................................................................................................................... 21
Supported Display Specification (PC Input) ........................................................................................... 22
Turning the TV On / Off ............................................................................................................................... 23
Select Source ............................................................................................................................................... 23
Source Select ............................................................................................................................................... 23
Changing Picture Mode ............................................................................................................................... 24
Color Temperature Setting ......................................................................................................................... 25
DNR Setting ................................................................................................................................................. 25
Advance Equalizer ....................................................................................................................................... 26
Adjusting the Equalizer .............................................................................................................................. 27
Manual Search .............................................................................................................................................. 27
Program Edit ................................................................................................................................................. 28
Channel List .................................................................................................................................................. 28
Favorite Channel List .................................................................................................................................. 28
Foreword
Overview
Installation
Connections
Basic Operation
Picture Settings
Sound Setting
SETUP Setting [Analogue TV]

Contents
3
Auto Search ................................................................................................................................................... 29
Manual Search............................................................................................................................................... 29
Information..................................................................................................................................................... 30
Digital Audio .................................................................................................................................................. 30
Teletext ........................................................................................................................................................... 30
Subtitle ........................................................................................................................................................... 30
EPG ............................................................................................................................................................... 30
Image Setting ................................................................................................................................................ 31
Auto Adjust .................................................................................................................................................... 31
OSD Setting .................................................................................................................................................. 32
Time ................................................................................................................................................................ 33
Date and Time .............................................................................................................................................. 33
Reset ............................................................................................................................................................... 33
Specification-42" PDP ................................................................................................................................. 34
Setup Setting [DVB-T]
Geometry Setting
System Setting
Timer Setting................................................................................................................... 34
Specification - 42”PDP

Caution
4
CAUTION
- TO PREVENT DAMAGE WHICH MAY RESULT IN FIRE OR
SHOCK HAZARD.
- DO NOT EXPOSE THIS APPLIANCE TO RAIN OR MOISTURE.
- SHOCK HAZARD DO NOT OPEN.
CAUTION
These servicing instructions are for use by qualified service
personnel only. To reduce the risk of electric shock, do not
perform any servicing other than that contained in the
operating instructions unless you are qualified to do so.
CAUTION
The stand intended for use only with this TV. Use with
other apparatus is capable of resulting in instability causing
possible injury.
WARNING
- Apparatus shall not be exposed to dripping or splashing and no objects filled with liquids, such as vases,
shall be placed on the apparatus.
- This is Class B product. In a domestic environment this product may cause radio interference in which
case the user may be required to take adequate measures.
- To reduce the risk of fire and electric shock, do not expose this product to rain or moisture.
Do not display a still picture for a long time
This causes the image to remain on the plasma screen (“image retention”).
This is not considered a malfunction and is not covered by the warranty.
To prevent image retention, lower the contrast and brightness levels.
Typical still images:-
- Channel number and other logos
- Image displayed in 4:3 modes
- Video game
- Computer
This symbol is intended to alert the user to
the presence of uninsulated "dangerous
voltage" within the product’s enclosure that
may be of sufficient magnitude to constitute
a risk of electric shock to persons.
This symbol is intended to alert the user to
the presence of important operating and
maintenance (servicing) instructions in the
literature accompanying the appliance.
RISK OF ELECTRIC SHOCK
DO NOT OPEN
CAUTION
CAUTION: TO REDUCE THE RISK OF
ELECTRIC SHOCK, DO NOT
REMOVE COVER (OR BACK), NO
USER-SERVICEABLE PARTS INSIDE.
REFER SERVICING TO QUALIFIED
SERVICE PERSONNEL.
Read all safety and operating instructions
before operating your the TV.
Keep the safety and operating
instructions for future reference.
Heed all warnings on the TV and
in the operating instructions.
Always be careful when using your the TV. To reduce the risk of fire, electrical shock, and other injuries, keep
these safety precautions in mind when installing, using, and maintaining your machine.
HEED ALL
WARNINGS ON
THE TV AND IN
THE OPERATING
INSTRUCTIONS.

Important Safety Instructions
5
Always be careful when using your the TV. To reduce the risk of fire, electrical shock, and other injuries, keep
these safety precautions in mind when installing, using, and maintaining your machine.
1. Read these instructions.
2. Keep these instructions.
3. Heed all warnings.
4. Follow all instructions.
5. Do not use this apparatus near water.
6. Clean only with a damp cloth.
7. Do not block any of the ventilation openings. Install in accordance with the manufacturer's instructions.
8. Do not install near any heat sources such as radiators, heat registers, stoves, or other apparatus
(including amplifiers) that a produce heat.
9. Do not defeat the safety purpose of the polarized or grounding type plug. A polarized plug has two blades
with one wider than the other. A grounding type plug has two blades and a third grounding prong.
The wide blade or the third prong is provided for your safety. When the provided plug does not fit into
your outlet, consult an electrician for replacement of the obsolete outlet.
10. Protect the power cord from being walked on or pinched particularly at plugs, convenience receptacles,
and the point where they exit from the apparatus.
11. Only use the attachments/accessories specified by the manufacturer.
12. Use only with a cart, stand, tripod, bracket, or table specified by the manufacturer, or sold with the
apparatus. When a cart is used, use caution when moving the cart/apparatus combination to avoid injury
from tip-over.
13. Unplug this apparatus during lightning storms or when unused for long periods of time.
14. Refer all servicing to qualified service personnel. Servicing is required when the apparatus has been
damaged in any way, such as power supply cord or plug is damaged, liquid has been spilled or objects
have fallen into the apparatus, the apparatus has been exposed to rain or moisture, does not operate
normally, or has been dropped.
15. When installing the PDP TV, do not block the appliance coupler with any structure.
User can easily have access to the coupler to disconnect it from AC main power.

Precaution
6
In case of the following cases, unplug the unit from the wall outlet and contact qualified
service center.
- When power supply cord or plug is damaged.
- If liquid has been spilled on the unit or if alien objects have fallen into the unit.
- If the TV has been exposed to rain or water.
- If the TV does not operate normally by following the operating instructions.
- If the TV dropped or the cabinet has been damaged.
- When the TV exhibits a distinct change in performance.
Ground outdoor antennas. If an outside antenna or cable system is connected to the TV, be sure the
antenna or cable system is grounded so as to provide some protection against voltage surges and built-up
static charges. Section 810 of the National Electrical Code, ANSI/NFPA No.70-1984, provides information
about proper grounding of the mast and supporting structure, grounding of the lead-in wire to an antenna
discharge unit, size of grounding conductors, location of antenna discharge unit, connection to grounding
electrodes, and requirements for the grounding electrode.
Setting
CAUTION
Follow all operating and use
instructions.
Do not use the TV where contact with
or immersion in water is a possibility,
such as near bath tubs, sinks, washing
machines, swimming pools, etc.
Avoid overhead power lines. An outside
antenna system should not be placed in the
vicinity of overhead power lines or other
electric light or power circuits or where it
can fall into such power lines or circuits.
When installing an outside antenna system,
be extremely careful to keep from touching
the power lines or circuits. Contact with
such lines can be fatal.
NO!!
Bend antenna cable between inside
and outside building to prevent rain
from flowing in.
- This may cause water damaged inside
the TV and could give an electric shock.
Do not place an outside antenna in the
vicinity of overhead power lines, or
other electric light or power circuits.
- This may cause an electric shock.
There should be enough distance
between an outside antenna and
power lines to keep the former from
touching the latter even when the
antenna falls.
- This may cause an electric shock.
NO!!
THIS MAY CAUSE WATER DAMAGED
INSIDE THE TV AND COULD GIVE AN
ELECTRIC SHOCK.

Precaution
7
Setting
WARNING
When installing the TV on a table, be careful not
to place it too close to the edge of the table.
- This may cause the TV to fall, causing serious injury
to a child or adult, and serious damage to the TV.
Provide ventilation for the TV. The unit is designed with
slots in the cabinet for ventilation to protect it from
overheating. Do not block these openings with any
object, and do not place the TV on a bed, sofa, rug or
other similar surface. Do not place it near a radiator or
heat register. If you place the TV on a rack or
bookcase, ensure that there is adequate ventilation
and that you've followed the manufacturer's
instructions for mounting.
NO!!
This TV is designed to be mounted
horizontally (wide viewing). Any inquiry
regarding its vertical position should be
forwarded to the manufacture directly.
NO!!

Precaution
8
Power
CAUTION
Use only the accessory cord designed for this product to
prevent shock. The power supply voltage rating of this
product is AC100-240V, the power cord attached conforms
to the following power supply voltage. Use only the power
cord designated by our dealer to ensure Safety and EMC.
When it is used by other power supply voltage, power
cable must be changed. Consult your product dealer.
Unplug the TV from the wall outlet before cleaning.
Use a damp cloth; do not use liquid or aerosol cleaners.
Unplug the TV from the wall outlet and disconnect the
antenna or cable system during a lightning storm or
when left unattended and unused for long periods of
time. This will prevent damage to the unit due to
lightning and power-line surges.
NO!!
AC100-125V AC200-240V AC240 (SAA-TYPE)
NO!!
Protect the power cord. Power supply cords should be
routed so that they won't be walked on or pinched by
objects placed on or against them. Pay particular attention
to cords at plugs, convenience receptacles, and the point
where they exit from the unit.
Do not touch the plug with wet hand.
- It can make an electric shock.
AC100-240V

Precaution
9
Operation
CAUTION
Upon completion of any service or
repairs to this the TV, ask the service
technician to perform safety checks to
determine that the TV is in a safe
operating condition.
Do not place anything containing
liquid on top of the TV.
- This may cause a fire or could give
an electric shock.
Never add any attachments and/or
equipment without approval of the
manufacturer. Such additions can
increase the risk of fire, electric
shock, or other personal injury.
NO!!
NO!!
Operation
WARNING
When replacement parts are required,
be sure the service technician uses
replacement parts specified by the
manufacturer or those that have the
same characteristics as the original
part. Unauthorized substitutions may
result in additional damage to the unit.
If you make adjustments yourself,
adjust only those controls that are
covered by the operating instructions.
Adjusting other controls may result
in damage and will often require
extensive work by a qualified
technician to restore the TV to normal.
Do not let children hang on or
ride on the TV.
In case of smoke or strange smell from the
TV, switch it off, unplug it from the wall outlet
and contact your dealer or service center.
- This may cause a fire or could give an electric shock.
Do not insert anything through the openings
in the unit, where they can touch dangerous
voltage points or damage parts. Never spill
liquid of any kind on the TV.
NO!!

Precaution
10
Operation
WARNING
Do not use new battery with old one.
- This can lead a fire or electric shock
caused by leakage liquid from abused
batteries.
Put the batteries in right direction (+/-).
- Otherwise, it can make a fire, injury and
pollution caused by bursting of batteries.
Only use the specified batteries.
- This make cause damaged the TV
or could give an electric shock.
More than two people are necessary
to move or take off the package due
to the product’s weightiness.
- Otherwise, it can cause personal injury.
Keep the batteries out of reach of
children when exchanged.
- Seek urgent medical advice if child
swallows a battery.
The distance between eyes and the
screen should be about 5~7 times as
long as diagonal length of the screen.
- If not, eyes will strain.

5
Front/Back Panel Diagram
Front/OSD Button Position
CH-CH+ VOL-VOL+ POWERINPUTMENU
IR Sensor
Warnings and Cautions
3
5
6
8
Remote Control Power Cord Alkaline Batteries User's Manual
Accessories
Composite Cable

12
Viewing the Connecting Panel
Back Panel and Jacks
TV In
S-Video In
AV Video Out
AV Audio Out
YPb Pr 1 In
YPb Pr 1 Audio In
YPb Pr 2 In
YPb Pr 2 Audio In
HDMI 1 In
HDMI 2 In
12
13
11
14
15
16
17
18
19
1
2
3
4
5
6
7
8
9
10
PC(RGB) In
PC Audio In
DVI Audio In
AV Video In
AV Audio In
Digital Audio Out (Optical)
Digital Audio Out (Coaxial)
USB (Service Port)
AC Inlet
Back panel of the TV
119151421618 11 12 13 910 5 6
7 8 17 3 4

Remote Control
13
Remote control functions
MTS
When stereo programme is received, press this key to select
STEREO or MONO.
When bilingual programmes received, press this key to select
Language1, Language 2 or MONO.
SOUND
Press this key to select the desired sound mode.
STILL
Press this key to freeze the picture.
DNR
Press this key to select the mode of the DNR.
ASPECT
Press this key to select different image sizes.
Press this key to select the desired picture mode.
NUMERIC and LETTER keys
Press the number keys to select a channel or input some
letters.
QUICK VIEW key
Press this key to return the previous selected programme.
FAV
Press this key to display the favorite programme list.
EPG
Press this key to call up the EPG (Electronic Programme
Guide).
AUDIO
Press this key to display the Digital Audio menu in DVB
programme.
SUBTITLE
Press this key to enter into subtitle mode.
MENU
Press this key to enter the menu screens for various optional
adjustable settings.
EXIT
Press this key to exit from the current menu.
VOL+/-
Press these keys to adjust the volume level up or down.
CH+/-
Press these keys to select channels in ascending or
descending order.
OK
Press this key to execute the selected item in the menu
screen or enter the desired value in any input mode.
SOURCE
Press this key to switch among TV broadcast, AV input
programme and other source.
INFO
Press this key to display the setting on the screen.
(e.g. Channel number for TV input)
Colour keys
Press these keys to access directly to the corresponding
menus displayed in DVB.
TV (ANALOG)
Press this key to select analog TV.
DTV (DIGITAL)
Press this key to select digital TV.
HDMI
Press this key to move to HDMI input directly.
5
4
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
7
6
25
23
12
14
16
18
21
10
26
1
34
20
8
9
13
11
15
22
17
19
24
25
STANDBY
Press this key to switch on the TV when at standby
mode or enter standby mode.
MUTE
Press this key to mute or restore sound.
SLEEP
Press this key to set the sleep timer. When the pre-
set length of time has passed, the TV set enters
standby mode.
1
2
3

Remote Control
14
Teletext operations
TXT / CC
Press this key to enter the Teletext. Press this key
again to exit.
INDEX
Press this key to go to the index page.
CANCEL
Press this key to cancel the Teletext but not exit the
Teletext. Press this key again to exit from cancel
mode.
SIZE
Press this key to change the Teletext screen display
mode.
MIX
Press this key to lucidity mode. For SUBTITLE or
NEWS FLASH page, please use mix mode.
HOLD
Press this key to hold the teletext page on display to
prevent the page from changing. Press again to
release the hold state.
SUBPAGE
Some teletext pages (e.g.P250) may contain
several sub-pages. Press this key once, “P250/- - -”
will be displayed on screen. Enter number keys
(0~9) to display the sub-page if available. Press this
key again to exit from sub-page mode.
REVEAL
Press this key to reveal the hidden information for
some Teletext pages (e.g. answers to puzzles or
riddles). Press again to hide the information.
Colour keys
Press these keys to access directly to the
corresponding pages displayed at the lower part of
the Teletext screen.
TELETEXT PAGE UP/DOWN keys
Press these keys to increase or decrease the
teletext page number.
PAGE NUMERIC SELECTION keys
Press these numeric keys to select a Teletext page
number.
1
2
3
4
5
6
7
8
9
10
11
9
11
1
2
5
6
4
3
8
7
10

Remote Control
15
Press on the cover and slide in the direction of the arrow.
Load two AAA batteries, taking care that the + and - ends face the correct direction.
Close the cover until it clicks.
Loading the Batteries
Reception Range of Remote Control
1
2
3
Left 5m (Front) Right
Upper
Lower
IR Sensor

Connecting the TV Cable
17
Connect the TV Antenna cable to the TV input jack. Press TV/AV button on the remote control and select
TV on OSD.
Use button or numeric button to change TV programme for your programme selection.
Also, you can tune to cable service provided programmes using the cable box. For further information
regarding cable TV service, contact cable TV service provider(s).
TV IN
Connection the TV Cable
1
2
3

With AV Input
Connect a composite cable to the AV video jacks of the VCR and the TV.
Connect L (White), R (Red) sound cable (Composite) to the sound jacks of the VCR and the TV.
With S-VIDEO
Connect a S-Video cable to the S-Video jacks of the VCR and the TV.
Connect L (White), R (Red) sound cable (Composite) to the sound jacks of the VCR and the TV.
Press TV/AV button on the remote control and select video sources.
Insert a video tape into the VCR and press the PLAY button on the VCR.
Connecting the VCR
18
Connecting the VCR
1
2
Watching VCR
S-VIDEO IN AV AUDIO IN
AV VIDEO IN
NNootteess
•To avoid picture noise (interference), leave an adequate distance (over 3m) between the VCR and TV.
• When connecting the TV with external equipment, match the colour of connecting ports (e.g. Video -Yellow,
Audio(L) - White, Audio(R) - Red).
•If you have a mono VCR, connect the audio cable from the VCR to the AUDIO (L/Mono) input of the TV.
• If you connect an S-VHS VCR to the S-VIDEO input socket, you can get a better picture quality than normal video
input (AV).

• Connect the three separate component video cables to the DVD player's Y, Pb and Pr jacks and to the
component jacks on the TV.
• Connect the audio cable to the DVD player's audio L (White) and R (Red) jacks and to the L and R audio
jacks beside the component jacks on the TV.
• Connect the HDMI cables to the DVD player’s and to the HDMI cables on the TV.
Turn on the DVD player.
Press INPUT button on the remote control
of the TV and select HDMI, COMPONENT.
You can get better picture quality if you
connect DVD player with component input
sockets as below.
Connecting the DVD
19
How to Use
Connecting the DVD
1
2
HDMI
YPb Pr 1 in
YPb Pr 2 in
YPb Pr 2 AUDIO In
YPb Pr 1 AUDIO In
NNoottiiccee
•Normal DVD source is based on 480i, which should be through normal Y Pb Pr of component signal.
It may occur screen noise, blank screen in case of using HDMI Cable unauthorized by ATC.
It may easily occur as specially HD signal (720p or 1080i) input. Suggest HDMI Cable only authorized by ATC.
480i/60Hz
480p/60Hz
576i/50Hz
576p/50Hz
720p/50Hz
720p/60Hz
1080i/50Hz
1080i/60Hz
1080p/24Hz
1080p/50Hz
1080p/60Hz
COMPONENT
Supported Signals
PC HDMI
Component(Y Pb Pr 1,2) Input Ports
Component ports of the
TV YP
Video output ports of
DVD player
Y
Y
Y
Y
Pb
B-Y
Cb
P
B
PB
B
Pr
R-Y
Cr
PR
PR

Connecting the Set Top Box
20
Connect set top box video inputs to AV, Y Pb Pr, HDMI, PC on the TV.
Audio inputs to Audio sockets beside the L (White) and R (Red) audio jacks which you connect video inputs.
Turn on the set top box.
Press TV/AV button on the remote control of the
TV and select Y Pb Pr, HDMI or PC.
With Component (Y Pb Pr)
Connect a three separate component cables to the component jacks of the STB and the TV.
Connect L (White) and R (Red) sound cables (Composite) to the sound jacks of the STB and the TV.
With HDMI
Connect a HDMI cable to the HDMI jacks of the STB and the TV.
With PC (RGB)
Connect a D-Sub cable to the AV video jacks of the STB and the TV.
Connect L (White) and R (Red) sound cables (Composite) to the sound jacks of the STB and the TV.
The interlace mode in not supported.
How to Use
How to Connect
How to Connect
1
2480i/60Hz
480p/60Hz
576i/50Hz
576p/50Hz
720p/50Hz
720p/60Hz
1080i/50Hz
1080i/60Hz
1080p/24Hz
1080p/50Hz
1080p/60Hz
COMPONENT
Supported Signals
PC HDMI
