AWA LT20D User manual

TFT LCD TV
User’s Manual
Part No!""#$$$$$
51cm TFT LCD TV
LT20D

%

Contents SafetyInstructions
&'
Safety Instructions 4
General Safety Precautions 5-6
Front Panel 7
Rear Panel 8
Accessory 9
Remote Control Unit 10
Basic Remote Control Operation 11-14
Connecting to Home Power 15
Connecting to Car Power 15
Connecting to Watch TV,VCR or DVD 16
Changing the INPUT SELECT standard 17
PICTURE SELECTION
Changing the Picture Standard 18
Adjusting the Picture Settings 18
SOUND SELECTION
Changing the Sound Standard 19
Adjusting the Sound settings 19
Selecting the Sound mode(depending on TV mond) 20
Adjusting the Volume/Switching the Sound off Temporarily 20
SETUP SELECTION
Setup Setting (Auto Program) 21
Setup Setting (Manual Program) 22
Setup Setting (Program Edit) 23
TIME SELECTION
Time Setting 24
FUNCTION SELECTION
Function Setting 25
PC Setting 26
Connecting a PC 27
Initial set PC mode 27
Teletext Decode 28-31
Appendix A: Display Modes 32
Appendix B: Troubleshooting 33-34
Appendix C: Specification 35

Generalsafetyprecautions Generalsafetyprecautions
()
16. Do not install it at the unstable location such as on the bouncing prop or tilted place.
It may be tipped over as it loses balance or damaged as it is fallen down.
17. Do not install at the place with moisture or dust.
It may cause the fire or the electric shock
18. Do not install it at the place with poisonous gas.
It may cause the fire.
19. Do not install it at the location with continuous vibration.
It may be tipped over as it loses balance or damaged as it is fallen down.
20. Do not install it at the place on the strong magnetic field or current field.
It may cause fire, electric shock or break down.
This equipment may be observed deterioration of the picture by electromagnetic radiation in electromagnetic envi-
ronment.
21. Fasten the wheel of the product or shelf with wheels when installing this product.
If it moves or is tipped over, it may be damaged.
22. Do not leave it in the car under the burning sun for a long time.
The high temperature may distort the cabinet or the parts inside may be broken down or heated.
If you use this product in this condition, it may cause the fire, electric shock or breakdown due to the short circuit or
poor insulation.
23. Do not place any fire source such as candlelight close to this product or place it on this product.
If it is tipped over or fallen down, it may cause damage or fire.
24. Do not sprinkle water drops or water on this product.
It may cause the fire, the electric shock or breakdown.
25. Do not place heavy objects on this product.
It may be tipped over as it loses balance or damaged as it is fallen down.
26. Do not transport it with the power cord or the connection cable connected.
If you move this product with the power cord or the connection cable connected, the damaged power cord, connec-
tion cable or connection terminal may cause the fire, the electric shock or breakdown.
27. Pull the power cord out while holding the plug portion.
If you pull the power cord out by force, the cord may the fire or the electric shock.
28. Do not use it outdoor.
Dust or rainstorm may cause the fire, electric shock or breakdown.
29. Do not climb on this product.
If you climb on it, it may damage or hurt it.
30. 2 persons or more shall transport the device, which is heavier than 18 kg.
If you drop or tip over the device, it may damage it.
The weight is indicated on the user's manual.
31. Use the attached power cord and connection cable, or those, which are indicated on the user's manual.
If you do not use the designated power cord and connection cable, it may cause the electric shock or breakdown.
32. Turn off the power switch when connecting the power cord or connection cable.
If you not turn off when connecting it, it may cause the electric shock or breakdown.
33. Do not use any chemical such as the paint thinner or benzine to clean the cabinet.
It may scratch the surface or disappear the indication to cause wrong operation, whch can be the reason for disorder.
34. Clean the cabinet with 5~6 time diluted neutral detergent water on smooth cloth as stirring to remove the contamination.
After that, clean it with dry cloth to remove any stain.
Thank you for purchasing our product.
Before using it, please read this user's manual carefully and apply it correctly and safely.
Please keep this manual close to you so you can refer to it anytime after reading it.
Also, for the transportation of the product, please attach this manual without fail.
Please observe the notes below.
1. Use at the rated power voltage.
Use of non-rated voltage may cause fire, electric shock and breakdown.
2. Do not open the cabinet and external cover.
The high voltage inside of this product may cause the electric shock.
3. Do not remodel or disassemble this product.
Remodeling or disassembling in wrong method may cause fire, electric shock or breakdown.
4. Do not insert or drop any foreign substance such as metals or flammable object inside from the air hole.
It may cause fire, electric shock or breakdown.
If any foreign substance is inserted inside of this product, turn off the power, pull the plug out of the socket
and contact the sales department. Do not use the product with the foreign substance in.
5. Do not place any vase, potted plant, cup, medicine and any container with water on this product.
If the liquid is spilt, it may cause the fire, electric shock or breakdown.
6. Do not place this product with water nor moisten it.
If water flows in it, it may cause the fire, electric shock or breakdown.
If there is water inside of the product, turn off the power immediately, pull the plug out of the socket and con-
tact the sales department.
Do not use the product with water in it.
7. Never touch the antenna lie or power plug if it stars to thunder.
It may cause the electric shock.
8. If any impact is applied, the parts inside of the product may be fallen out or broken to be the cause of fire, elec-
tric shock or breakdown.
9. Clean the dust on the power plug periodically.
The dusty power plug may cause the poor insulation due to the moisture to be the reason of fire.
10. Do not destroy, process, make closer to heating device, bend or twist forcibly, place any heavy object on nor
bind the power cord or power plug. If it is used in the broken condition, it may cause fire or electric shock.
11. Do not touch the power plug with wet hands.
If you pull in or out the power plug with wet hands, it may cause electric shocks.
12. Put the power plug in firmly.
Putting the plug incompletely may cause the electric shock or fire by the generation of heat.
13. Do not use any non-rated power socket with numerous devices jointed on one power socket or cable device.
The wire of non-designated capacity may cause the fire due to the generation of heat.
14. In case of malfunction, turn off the power switch immediately and pull out the power plug.
If this product is used in the abnormal condition such as damage to it, foreign substance inside of the prod-
uct, generation of joints, smelling, smoking, overheating and non production of signal, it may cause fire, elec-
tric shock or breakdown.
Turn off the power switch immediately, pull the power plug out of the socket and contact to the sales store..
15. Leave space 10 cm or more from the wall for the installation of the device.
Do not install it close to the wall nor block the ventilation of the air.
Insufficient ventilation or accumulated heat inside of the product may cause the fire.

*
RearPanel
1. DC 12V To input DC power from power outlet.
2. PC D-SUB Use to connect a video signal from a personal computer
3. PC AUDIO Connects to the sound-output port of a personal computer.
4. AV IN Video/Audio signals from VCR or similar divice.
5. HDTV INPUT Video signals from HDTV player.
6. AUDIO IN Audio signal from an VCR or similar device.
(Audio input of COMPONENT IN is used commonly with S-VIDEO)
7. S-VIDEO S-Video signal from an S-VHS VCR or laserdisc player
8. ANTENNA JACK Connect to an antenna or a cable TV system
.
Rear
+
FrontPanel
Front
1. TV/VIDEO Display a menu of the available input sources.
2. MENU Display the main on-screen menu. Exit from sub-menu.
3. VOL(-/+) Press the increase or decrease the volume. Also used to increase
or reduce the value of a menu option.
4.PROG( /) Press PROG[ ] or PROG [ ] to change channels. Also used to
highlight selections on the on-screen menus.
5. POWER Sub power switch
6. STAND BY ON: The green LED is on.
OFF:The red LED is on.
7. Remote Control Sensor

#
Accessory
RemoteControlUnit
"$
1. SOURCE Button
2. MULTI Button
3. PC Button
4. LANGUAGE Button
5. PICTURE Button
6. SLEEP Button
7. MENU Button
8. M/S Button
9. Two digit Button
10. Numeric Buttons
11. Teletext Buttons
12. POWER Button
13. AutoADJ Button
14. MUTE Button
15. WIDE Button(Not available)
16. S-STD Button
17. P-STD Button
18. SKIP Button
19. PROGRAM Up( ) / Down( )Button
20. VOLUME Up(+) / Down(-) Button
21. EXlT Button
22. DISPLAY Button
23. Q-VIEW Button
You must insert or replace the batteries in the remote controller when you:
Purchase the set.
Find that the remote controller is no longer operating correctly.
Remove the cover of the
remote controller by pressing
the symbol and pulling the
cover space in the direction
of the arrow.
Insert 2 batteries(AAA size),
taking care to respect the
polarities.
Replace the cover by put in
it in the direction of the
arrow.
You can use your remote controller within a distance of 7-10m and an angle of 30
degrees from the left and right sides of the remote controller receptor of your monitor.
12 3
!
Power Sources-This product should be operated only from the type of power source
indicated on the marking label. If you are not sure of the type of power supply to
your car, consult your product dealer.
!

"%
""
BasicRemoteControlOperation
1. Source Button
Select input source.
2. Multi Button
It is converted with Digtal Source.
3. PC Button
Select PC signal.
4. Language Button
Language Selection.
5. Picture Button
You can sequentially select and adjust one of five picture levels.
6. Sleep Button
The television is automatically turned off after an elapse of the set sleep time.
1) The set time ranges from 15 to 90 minutes, which is repeated in sequence each time
you press.
2) If you'd like to check the remaining SLEEP TIME after OSD disappears, press DIS-
PLAY button.
7. Menu Button
It displays all the functions that user can control.
8. M/S Button
Sound Selection.
BasicRemoteControlOperation
9. Tow digit Button
1) -/-- key selects one-digit (0 to 9) or two-digit program number (10 to 99)
2) (-) or (--) is displayed by turns on the upper right position if you press this
key repeatedly.
3) You can choose one-digit program number if (-) is shown and two-digit program
number if(--) shewn.
ex1) Press 7 if you’d like watch program number 7.
ex2) Press -/-- 1 7 if you’d like to watch program number 17.
* If you want to watch progrma number 7 while (--) is alread on, press -/-- 7 or 0 7.
10. Numeric Buttons
Direct Channel select.
11. Teletext Buttons
See the teletext section for details.
12. Power Button
Turns the TV the TV on and OFF.
13. Auto ADJ Button
Auto adjusting the screen in PC mode.
14. Mute Button
Switch the sound output either ON or OFF.
15. WIDE Button
This button is not available.
OFF 10 30 60 90 120 150 180

"'
"&
BasicRemoteControlOperation
16. S-STD Button
Whenever this button is pressed, the mode will be changed as follows.
17. P-STD Button
By pressing the P.STD button, sequentially select one of the 4 pre-sets
picture standard.
Standard : Select this mode to watch TV at standard state.
Dynamic : Select this mode to watch in a room with bright illumination.
Mild : Select this mode when the room is dark or to lessen eye fatigue.
User: Select this mode to view the picture to your set picture state preference.
18. Skip Button
1) It can used so that the unnecessary program number may not be displayed.
2) If you press this at a specific program number, OSD color of the current program
number will change from yellow to red.
3) If you want to watch the skipped program number, use 10 digit key to view it,
then press SKIP button, or operate AUTO PROGRAM in setup.
19. Program up( ) / down ( ) Button
1) It is used to select the channel you want to watch on either upward or downward direction.
2) It makes the cursor to move while in main MENU.
20. Volume up(+) / down (-) Button
1)It adjusts the volume level of sound.
2) It is used to choose a specified mode in the main MENU by pressing VOL(+) button.
3) It controls the increase or decrease of each mode you selected.
21. Exit Button
When you are satisfied with the settings, Press the EXIT Button repeatedly to return to
normal viewing
BasicRemoteControlOperation
22. Display Button
When TV mode displays the current channel number, picture mode, sound mode,
sleep and clock.
23. Q-view Button
Quick view for previous channel.

")
"(
ConnectingtowatchTV,VCRorDVD
1. Connect a set of audio cables between the component AUDIO IN jacks on the TFT
LCD TV and the AUDIO OUT jacks on the DVD Player.
2. Connect video cables between the Y, P b and P r inputs on the TFT LCD TV and Y, P b
and P r outputs on the DVD Player.
(Note : For an explanation of Component video, see your DVD Player's Owner's
manual.)
Connecting a DVD Player (Connecting to Y, Pb, Pr)
Connecting the Aerial or Cable Television Network
ConnectingtoCarPower
Note : The cable assembly used to connect the set to the 12-Volt power supply varies
depending on product packaging.
Connect to the vehicle s CIGARETTE LIGHTER SOCKET by using the DC CAR CORD
accessory as shown in the diagram.
TO DC INPUT JACK
DC CAR CORD
CIGAR PLUG
CIGARETTE
SOCKET
Make sure that the set s MAIN
POWER is switched OFF before
connecting it to power.
After use, the AC Adapter should be
unplugged from the AC supply and
detached from the set.
Home
Power connecter
AC ADAPTER
TO DC INPUT
JACK
ConnectingtoHomePower
To view television channels directly, a signal must be received by the set from one of following
sources:
An outdoor aerial
An indoor aerial (not recommendable)
A cable television network
1. In the first three cases, connect the aerial or network input cable to the 75 ohm coaxial socket
on the rear of the TFT LCD TV.
2. Press the TV button on the remote control.
Connecting the VCR, DVD or Other external devices
1. Connect video and audio cable according to the shape and color or the video / audio cable.
When an external devices is in MONO, the audio connection cable can be connected to
either the left and S.MODE/MTS should be set MONO.
2. For optimal visual image, use S-VIDEO connector instead of video (yellow) connector.

"*
You can select the type of picture which best corresponds to your viewing requirements.
The following picture effects are available the order given:
STANDARD, DYNAMIC, MILD, USER
1. Press the MENU button.
Result : The PICTURE menu is display.
2. Press the VOL[ + ] button.
Result : The "PICTURE MODE" menu is active.
3. Select to satisfy your preference by pressing the
VOL [ + ] or VOL[ - ] button.
4. When you have been finished, press the MENU
button repeatedly to return to normal viewing.
ChangingthePicturestandard
Your TV have several setting which allow you to control
picture quality:
CONTRAST, BRIGHTNESS, COLOUR,
SHARPNESS
1. Press the MENU button.
Result : The “PICTURE” menu is display.
2. Press the VOL[ - ]button.
Result : The "PICTURE MODE" menu is active.
3. Use the PROG[ ] or PROG[ ]button to select
setting menu.
4. Press the VOL[ - ] button.
Result : The “Contrast” menu is displayed.
Result : The “Brightness” menu is displayed.
Result : The “Colour” menu is displayed.
Result : The “Sharpness” menu is displayed.
5. Adjust to satisfy your preference by pressing the
VOL[ + ] or VOL[ - ] button.
6. Press the TV MENU button twice to exit and save
the changes.
"+
ChangingtheINPUTSELECTStandard
You can select the type of INPUT which best corresponds to your viewing requirements.
The following picture effects are available the order given:
TV, AV, S-VIDEO, COMPONENT, PC
1. Press the TV/VIDEO button.
Result : The INPUT SELECT menu is display.
2. Press the PROG[ ] button.
3. Select to satisfy your preference by pressing the
VOL[ + ] or VOL [ - ] button.
4. When you have been finished, press the MENU
button repeatedly to return to normal viewing.
AdjustingthePicturesettings

"# %$
ChangingtheSoundStandard
You can select the type of special sound effect to be used when watching a given broadcast.
The following sound effects are available in the order given:
STANDARD, MUSIC, MOVIE, SPEECH, USER
1. Press the menu button.
Result : The "PICTURE" menu is displayed.
2. Press thePROG[ ] or PROG[ ] button to select
"SOUND"
3. Press the VOL[ - ] button.
Result : The "SOUND MODE" menu is Active.
4. Press the VOL[ - ] button.
5. Select to satisfy your preference by pressing the
VOL[ + ] or VOL[ - ] button.
6.
When you have been finished, press the MENU
button repeatedly to return to normal viewing.
The sound settings can be adjusted to suit your person-
al preference:
Bass, Treble. Balance
1. Press the menu button.
Result : The "PICTURE" menu is displayed.
2. Press thePROG[ ] or PROG[ ] button to select
"SOUND"
3. Press the VOL[ - ] button.
Result : The "SOUND MODE" menu is Active.
4. Press the PROG[ ] button.
5. Press the VOL[ - ] button.
Result : The “Bass” menu is displayed.
Result : The “Treble” menu is displayed.
Result : The “Blance” menu is displayed.
6. Adjust to satisfy your preference by pressing the
VOL[ + ] or VOL[ - ] button.
7. Press the TV MENU button twice to exit and save
the changes.
AdjustingtheSoundsettings
SelectingtheSound Mode(depending on TV mode)
The "M/S" button displays/controls the processing and output of the audio signal.
When power is switched ON, the mode is automatically preset to either "Dual" or "Stereo"
depending on the current transmission.
If the receiving conditions deteriorate, listening will be easier if the mode is set to the "Mono"
position using the M/S button.
If the stereo signal is weak (or if intermittent Stereo-Mono) and automatic switching occurs,
then switch to the "Mono" mode.
When receiving mono sound in the AV mode, connect to the "L" input jack on the panels. If
the mono sound comes out only from the left speaker, then press the M/S button.
You can adjust the volume by pressing the VOL+ or
VOL- button on the remote control.
You can switch the sound off temporarily by pressing
the MUTE button on the remote control, for example
you may wish to answer the telephone.
1. Press the VOL[ + ] button to increase the volume.
(cursor moves to the right)
2. Press the VOL[ - ] button to decrease the volume.
(cursor moves to the left)
3. Press the MUTE button.
Result : The sound is switched off and " " is
displayed.
4. When you wish to turn the sound back on at the
same volume as before, press the MUTE button
again (or either of the volume buttons).
Adjusting the Volume/Switching the Sound Off Temporarily

%" %%
SetupSetting
You can scan the frequency ranges available on your
television in your country and store all the channels found
automatically.
The channels are stored in the order in which they appear
in the frequency bands. It is possible that the automatical-
ly allocated numbers may not correspond to those by
which you wish to identify the channels.
If this is the case, you can then sort them manually.
1. Press the MENU button.
Result : The "PICTURE" menu is displayed.
2. Press the
PROG[ ] or PROG[ ] button to select
"SET UP"
3. Press the
VOL[ - ] button.
Result : The "SET UP menu is active.
4. Press the PROG[ ] button.
5. Press the VOL[ - ] button.
Result : The "AUTO PROGMAM" menu is active.
6. Press the PROG[ ] button.
7. Press the VOL[ - ] button.
Result: The "START" menu is active.
8. Press the VOL[ - ] button.
Result: The horizontal bar is displayed, and then
channels are stored in an order which reflects
their positions in the frequency range. Finally,
the search will end automatically.
9. When searching and storing is complete,
"AUTO PROGRAM” menu is displayed.
10 Press the
PROG[ ] button.
Result: The “Color System" menu is displayed.
11. Press the
VOL[ + ] or VOL[ - ] to select the
broadcast color system which you want.
AUTO PROGRAM
SetupSetting
When storing Channels manually, you can
choose whether or not store each of the channels
found.
The number by which you wish to identify each
stored channel.
1. Press the MENU button.
Result: The "PICTURE" menu is displayed.
2.
Press the PROG[ ] or PROG[ ] buttons to
select "SET UP".
3. Press the VOL[ - ] button.
Result: The setup menu is active.
4.
Press the PROG[ ] or PROG[ ] button to select
“MANUAL SEARCH
".
5. Press the VOL[ - ] button.
Result: The MANUAL SEARCH menu is
active.
6.
Press the PROG[ ] or PROG[ ] button to select
Sound System and press
the VOL[ - ] button,
pressPROG[ ] or PROG[ ] button repeatedly
until the sound is of the best quality.
Result: The Sound system is changed.
7. With same method, it will want and to set the
system, the program, the fine and the name
of channel which it will be able to store.
Store " [ - ] ", Exit "MENU"
8. When you have finished, press the MENU button
repeatedly to return to normal viewing.
MANUAL PROGRAM

%'
%&
TIMESetting
1. Press the MENU button.
2. Press the PROG[ ] or PROG[ ] button to
select "TIME".
3. Press the VOL[ - ] button.
Result: The "CLOCK" menu is displayed.
4. Press PROG[ ] or PROG[ ] button to
setting time.
Press the VOL[ - ] button.
5.
Repeat step 4 for "ON TIME" setting and
"OFF TIME" setting.
Result : The setting is satisfied with “On” displayed,
will be activated time setting.
6. Press the PROG[ ] or PROG[ ] button to
select "SLEEPE TIME”
7. Press the VOL[ - ] button.
Result: The "SLEEP TIMER" menu is displayed.
8. Press the MENU button.
9. Press the PROG[ ] or PROG ] button to select
“ON CHANNEL” settingON TIME and OFF TIME.
Result: About clock setting menu is completed
9. Press the PROG[ ] or PROG[ ] button to select
“ON VOLUME”.
Result: About clock setting menu is completed
AAuuttoommaattiiccPPoowweerrOOffffFFuunnccttiioonn
Turned off automatically after "( minutes in
the absence of picture signal!
SetupSetting
You can create channel list at this menu and it is
available to redefining the channel or deleting the
channel and copy, move the channel of each list
The user wants it will be able to edit with the name. When
it selects channel which it wants edit it will enter in
PROGRAM mode and the user will be able to change a
name with option.
PROGRAM EDIT

%)
PCSETTING
When the screen is unstable in PC settings, or to make your PC sta-
ble by adjusting the Clock and Phase, set the PC in the following
sequence:
1. Press the MENU button.
2. Press the PROG[ ] or PROG[ ] button to select
"PC” and press the VOL[ - ] button.
3. Press the VOL[ - ] button
Result: The AutoAdjust menu is active.
3. Press the PROG[ ] or PROG[ ] button to
select frequency.
4. CLOCK VOL[ + ] or VOL[ - ] button.
PHASE VOL[ + ] or VOL[ - ] button.
H- Position VOL[ + ] or VOL[ - ] button.
V- Position VOL[ + ] or VOL[ - ] button.
Auto Adjust:
Adjust the screen’s status in PC mode automatically
Clock:
Adjusts the horizontal size of screen by
increasing/decreasing the number of pixels.
Phase:
Sets the focus of screen.
Adjusts when some noise exists or the character lines
are seen overlapped.
H Position/V Position:
Adjusts the horizontal/Vertical focus of screen
When you are satisfied with the settings, press the
MENU button repeatedly to return to normal viewing.
LanguageSetting
1 Press the Menu button.
2.
Press the PROG[ ] or PROG[ ] buttons
to select
“FUNCTION”
3. Press the VOL[ - ] button.
4. Result: The "OSD LANGUAGE" menu is
displayed.
5. Press the VOL[ + ] or VOL[ - ] button to
select which you want language.
INPUT
1 Press the Menu button.
2.
Press the PROG[ ] or PROG[ ] buttons to
select "FUNCTION"
3. Press the VOL[ + ] or VOL[ - ] button to
select "INPUT".
4. I
t will able to select want signal byusing the
VOL[ + ] or VOL[ - ] buttons.
FunctionSetting
English Francais Deutch Italiano Español
TV AV S-VIDEO COMPONENT PC
%(

%*
%+
TeletextDecode
Note: The teletext feature dose work with TV, AV,
S-Video signals.
Most television channels carry "teletext", pages of
written information that provide information such as:
Television program tables
News bulletins
Weather forecasts
Sports results
Subtitles for the hard of hearing
The teletext pages are organized according to six categories:
Part contents
A Selected page number.
B Broadcasting station identity.
C Current page number or search status.
D Date and time.
E Text.
F Status information.
Connecting a PC
1. Turn off your computer and LCD TV.
2. Connect a PC D-sub(DVI) cable between your PC and
PC-VIDEO-IN of the LCD TV.
And then fasten the screws of both sides of the cable.
3. Connect a PC Audio cable between the sound output
jack of the sound card on a PC and the PC-AUDIO-IN
of the LCD TV.
4. Power on the computer before turning on the LCD TV.
1. Power on your LCD TV by pressing the POWER but-
ton on the main set or on the remote controller.
2. Press the PC button on the remote controller to
switch to the PC mode.
Then the PC screen is automatically set.
When a CD-Title runs, the music is output from
speakers.
(You can use an external speaker via the Audio
Output jack on the rear of the main set.)
Initial set PC mode

&$
%#
SelectingaSpecificTeletextPage
NOTE: The teletext feature dose work with TV, AV,
S-Video signals.
Press the numeric buttons on the remote control to
enter the page number directly:
1 Enter the three-digit page number listed in the con-
tents by pressing the corresponding numeric but-
tons.
Result: The current page counter is incremented
and the page is then displayed.
2. If the selected page is linked with several sec-
ondary pages, the secondary pages are displayed
in sequence.
To freeze the display on a given page, press the
HOLD ( ) button.
Press the HOLD ( ) button again to resume.
3. Using the various display options"
To display ...
Both teletext information and
the normal broadcast
Hidden text
(answers to quiz games, for
example)
The normal screen
The next page
The previous page
FLOF/LIST select
Press the ...
TV/TEXT ()
REVEAL ()
REVEAL () again
PAGE UP ( )
PAGE DOWN ( )
FLOF/LIST
DisplayingTeletextInformation
NOTE: The teletext feature dose work with TV, AV,
S-Video signals.
You can watch teletext information at any time, but sig-
nal reception must be good. Otherwise:
Information may be missing.
Some pages may not be displayed.
To activate the teletext mode and display the contents
page:
1 Using the PROG[ ] or PROG[ ] button, select
the channel providing the teletext service.
2. Press the TV/TEXT ( ) button to activate the
teletext mode.
3. To display the actual broadcast simultaneously with
the teletext page, press the MIX ( ) button.
4. Return to normal viewing, press the MIX ( )
button.

&%
&"
If the signal from the system equals to the standard signal mode, the screen is adjusted auto-
matically. If the signal from the system doesn't equal to the standard signal mode, adjust the
mode with referring to the videocard user guide because the screen might not display or only
the power LED might be on. For the display modes listed below, the screen image has been
optimized during manufacture.
APPENDIXA:Displaymodes
Mode
VGA
Resolution
720 * 400
640 * 480
640 * 480
640 * 480
Horizontal
Frequency
(KHz)
31.469
31.469
37.500
43.269
Vertical
Frequency
(Hz)
70.087
59.940
75.000
85.008
Pixel Clock
Frequency
(MHz)
28.322
25.175
31.500
36.000
UsingFLOFtoSelectaTeletextPage
NOTE: The teletext feature dose work with TV, AV,
S-Video signals.
The various included in the teletext pages are color-coded,
and can be selected by pressing the colored buttons on the
remote control.
1. Display the teletext contents page by pressing the
TV/TEXT () button.
2. Press the colored button corresonding to the topic that
you wish to select (The available topics are listed on
the status information line).
Result: The page is displayed with additional color-
coded information that can be selected in the same
way.
3. To display the: Press the:
Previous page Red button
Next page Green button
NOTE:
The teletext feature dose work with TV, AV,
S-Video signals.
Up to four teletext pages can be stored.
1. Select the LIST mode.
Result: For 3-digit numbers are displayed in differ-
ent colors at the buttom of the screen.
2. Press the colored button corresponding to the page
that will be replaced.
3.
Enter the new page number using the numeric buttons.
4. Repeat steps 2 and 3 for each page to be stored,
using a different colored button each time.
5. Press the STORE button until the corresponding
blocks are displayed in white.
The LIST button is used to switch between:
LIST mode/FLOF mode
StoringTeletextPages

&'
&&
APPENDIXB:Troubleshooting
Problem
Sound level is too low
Sound is too high pitched or
too low pitched
TV signal is not received
Suggested Actions
Check the volume level.
If the volume is still too low after turning the control to
its maximum, check the volume control on the
computer sound card or software program.
Adjust the equalizer to appropriate level.
Ensure that the antenna cable is firmly connected to
the VHF/UHF jack.
Check "Channel Memory" and make sure you
choose the correct channel system.(PAL Model)
Select "Auto Tuning" to configure the channel
system automatically.(PAL Model)
If you have a problem setting up or using your LCD TV, you may be able to solve it yourself.
Before contacting customer service, try the suggested actions that are appropriate to your problem.
APPENDIXB:Troubleshooting
What you see...
Screen is blank and
power indicator is off
"NO SIGNAL” message
The image is too light or too dark
Vertical bars appear to flicker,
jitter or shimmer on the image
Horizontal bars appear to flicker, jit-
ter or shimmer on the image.
Screen is blank
Image is not stable and
may appear to vibrate
Image is not centered on the screen.
Suggested Actions
Ensure that the power cord is firmly
connected and the LCD TV is on.
Ensure that the signal cable is firmly connected to the
PC or video sources.
Ensure that the PC or ideo sources are turned on.
Adjust the Brightness and Contrast.
Adjust the Frequency function.
Auto Tracking will clear it automatically.
Adjust the phase function and then adjust the clock
function.
Auto tracking will clear it automatically.
The monitor is using its power management system.
Move the computer's mouse or press a key on the
keyboard.
Auto tracking will clear it automatically
Check that the display resolution and frequency from
your PC or video board is an available mode for your
monitor.
On your computer check:
Control Panel, Display, Settings
Auto tracking will set the best position automatically
Adjust the horizontal and vertical position.

&)
&(
APPENDIXC:Specification
Panel Type
Display Area
Display Color
Pixel Pitch
Recommended Resolution
PC
Video
Audio
Euro A/V
Antenna
Color System
Sound System
Stereo Type
Text
Certifications
Power Consumption
Speaker
Plug & Play
Screen Control
Weight
Power Supply
Remote Controller
Dimension
Panel
In/Out
TV Signal
Others
20.1" TFT Color LCD
408.0mm x 306.0mm
16.7 million
0.6375 x 0.6375 x RGB mm
640 x 480
Analog RGB 15 pin D-sub
PC Audio Input
Composite Input
S-Video In
DVD (Y, Pb, Pr) Input
Composite Input
PC Input
Component (Y,Pb,Pr)
RCA
75 ohm Coaxial cable
PAL/SECAM
B/G, D/K, I
NICAM, A2
TELETEXT
CE
50W
3W x 3W
DDC 2 B
On Screen Display Menu
Net : 9Kg / Gross 11Kg
AC 100-250V~
Yes
with stand : 496(W) X 514.5(H) X 220(D)mm
without stand : 496(W) X464.5(H) X 65(D)mm
SPECIFICATION

&+ &*
