Award A7061S Installation and operating instructions

461308282 10/2014
INSTRUCTIONS AND ADVICE
FOR INSTALLING, USING AND SERVICING
OF COOKERS
MODEL: A7061S

2
The appliance was designed and made in accordance with the International standards listed below:
=>IEC 60 335-1 and IEC 60 335-2-6 (electrical) plus relative amendments
The appliance complies with the prescriptions of the International Directives as below:
Electrical safety (BT).
Electromagnetic compatibility (EMC)
Gas safety.
The crossed-out dustbin symbol reported on the appliance indicates that the appliance must
be disposed of separately from other domestic refuse at the end of its useful life. It must
therefore be delivered to a waste recycling centre specically for electric and electronic
equipment or returned to the retailer at the moment of purchase of a new equivalent
appliance.
The user is responsible for delivering the appliance to the appropriate collection centre
at the end of its useful life, Failure to do so may result in a ne, as provided for by
laws governing waste disposal. Differential collection of waste products for eventual
recycling, treatment and environmentally friendly disposal helps reduce possible negative
effects on the environment and health, and also enables the materials making up the product
to be recycled.
For more detailed information on the available refuse collection systems, refer to the local
Municipal Solid Waste disposal centre or the shop where the product was purchased.
Producers and importers are responsible for fullling their obligations as regards recycling,
treatment and environmentally friendly disposal by directly or indirectly participating in the
collection system.

3
461308282 10/2014
Before this appliance left the factory it was tested and set by specialized, expert personnel in order to guarantee
the best functioning results.
Any subsequent repairs or adjustments that may be necessary must be done with the maximum of care and
attention by authorised personnel.For this reason we recommend you always contact us (refer below), specifying
the brand, model, serial number and type of problem you are having with it. You will nd the relative data printed on
a label afxed on the appliance and on the label afxed to the packing box.
IMPORTANT NOTICE
The manufacturer shall not be held responsible for any damage to persons or property caused by incorrect
installation or use of the appliance.
For prompt warranty service, please ensure that the warranty registration form is completed and return posted
to us. A duplicate data label and wiring diagram are contained in this booklet. Please attach these labels to an
accessible surface near by the appliance for easy reference.
You can purchase original spare parts from authorised dealers or direct from us.
CONTENTS
ASSISTANCE AND SPARE PART 3
IMPORTANT NOTES AND PRECAUTIONS FOR USE 4-6
DESCRIPTION OF THE APPLIANCE 7-8
INSTRUCTIONS FOR THE USER 9-16
TROUBLESHOOTING 17
INSTRUCTIONS FOR THE INSTALLER 18-24
TECHNICAL FEATURES 25-26
ASSISTANCE AND SPARE PARTS

4
IMPORTANT NOTES AND PRECAUTIONS FOR USE
You have purchased one of our
products for which we thank you. We
are condent that this new appliance,
modern, functional and practical, made
with top quality materials, will meet all
your demands. This new appliance
is easy to use but before installing
and using it, it is important to read
this handbook through carefully.
It provides information for a safe
installation, use and maintenance. Keep
this handbook in a safe place for future
reference.
The manufacturer reserves the right
to make all the modications to its
products that it deems necessary
or useful, also in your interests,
without prejudicing its essential
functional and safety characteristics.
The manufacturer cannot be held
responsible for any inaccuracies due to
printing or transcription errors that may
be found in this handbook.
N.B.: the pictures shown in the gures in
this handbook are purely indicative.
• The installation, adjustments,
conversions and maintenance
operations listed in section
«INSTRUCTIONS FOR THE
INSTALLER» must only be carried out
by authorised personnel .
• The installation of all-gas and combi
appliances must comply with the
standards in force.
• The appliance must only be used for
its original purpose, that is, cooking
for domestic use. Any other use is
considered improper and, as such,
dangerous.
• The manufacturer cannot be held
responsible for any damage to persons
or property resulting from an incorrect
installation, maintenance or use of the
appliance.
• Once the packaging has been
removed from the outer surfaces and
the various inner parts, thoroughly
check that the appliance is in perfect
condition. If you have any doubts do
not use the appliance and call in an
authorised person.
• The packaging materials used
(cardboard, plastic bags, polystyrene
foam, nails, etc.) must not be
left within easy reach of children
because they are a potential hazard
source. All packaging materials used
are environmentally-friendly and
recyclable.
• The electrical safety of this appliance
is only guaranteed if it is correctly
connected to a suitable earth system,
as prescribed by the electrical safety
standards.Themanufacturerdisclaims
all responsibility if these instructions
are not followed. Should you have
any doubts, seek the assistance of an
authorised person.
• Before connecting the appliance
ensure that the rating plate data
corresponds to that of the gas
and electricity supply (see section
«TECHNICAL FEATURES»).
• NOT FOR USE IN MARINE CRAFT,
CARAVANS OR MOBILE HOMES
UNLESS EACH BURNER IS FITTED
WITH A FLAME SAFEGUARD.
• DO NOT MODIFY THIS APPLIANCE
• DOMESTIC USE ONLY
During use the appliance becomes
hot. Care should be taken to avoid
touching heating elements inside the
oven.


5
461308282 10/2014
WARNING - Accessible parts may
become hot during use. To avoid
burns young children should be kept
away.
WARNING - Accessible parts may
become hot when the grill is in use.
Children should be kept away.
• The oven door glass and the
accessible parts will become hot
when in use. To avoid burns and
scalds young children should be
kept away.
• Do not use this appliance as a space
heater.
• Do not touch any electrical appliance
if hands or feet are wet or damp.
• Do not use the appliance bare
footed.
• Do not pull the power lead to take the
plug out of the socket.
• Do not leave the appliance outside
under the sun, rain, etc.
• This appliance is not intended for use
by persons (including children) with
reduced physical, sensory or mental
capabilities, or lack of experience
and knowledge, unless they have
been given supervision or instruction
concerning use of the appliance by a
person responsible for their safety.
• Children should be supervised to
ensure that they do not play with
the appliance. Cleaning and user
maintenance shall not be made by
children
• WARNING - ln order to prevent
accidental tipping of the appliance, for
example by a child climbing over the
open oven door, or too high weights
are leant on the open oven door, two
chains must be screwed on the back
on the cooker and xed to the wall
with hooks .Ensure the chains are
taut .Please refer to instructions for
installation..
• Before cooking for the rst time,
ensure the oven is empty and its door
closed, heat the oven at maximum
temperature for two hours. This will
allow the protective coating on the
interior of the oven to be burnt off
and dissipate the associated smells.
Ensure adequate ventilation in the
kitchen whilst burning off and don’t
be alarmed by a little bit of smoke
during this process.
• Unattended cooking on a hob with
fat or oil can be dangerous and may
result in re.
• Never try to extinguish a re with
water, but switch of the appliance
and then cover ame e.g. with a
lide or a re blanket .
• Danger of re: Do not store items
on the cooking surfaces
• Do not use harsh abrasive cleaners
or sharp metal scrapers to clean
the oven glass door since they can
scratch the surface, which may
result in shattering of the glass.
• NEVER use sponges or abrasive
products, and solvents to remove
stains or adhesives on the painted
or stainless steel surfaces.
• Switch off the oven before removing
the fan guard for cleaning. Replace
the guard after cleaning in
accordance with the instructions.
• The oven can be equipped with
temperature probe. Only use the
temperature probe recommended
for this oven by our Service
Centre.
• Remove any spillage from the lid
before opening.
IMPORTANT NOTES AND PRECAUTIONS FOR USE

6
IMPORTANT NOTES AND PRECAUTIONS FOR USE
• The appliance is not intended to be
operated by means of an external
timer or separate remote-control
system
• Ensure that the appliance is
switched off before replacing the
lamp to avoid the possibility of
electric shock..
• The cookers can be equipped with
a small compartment under the
oven that can be used for storing
things Remember that the surfaces
become hot, it is strictly forbidden to
place inammable materials inside.
• Do not use a steam cleaner to clean
a hob, oven or range.
• The appliance is to be placed directly
on the oor and shall not be mounted
on a base.
• If the appliance is tted with a glass
lid, this can shatter when heated.
Turn off all the burners or disconnect
all the plates, and allow them to cool
before closing the lid (g.3)
• Avoid using the oven as a larder or as
a saucepan cupboard when you are
not using it for cooking: if the oven is
turned on accidentally it could cause
damage and accidents.
• If you are using an electrical socket
near the appliance, make sure that
the cables are not touching the cooker
and are far enough away from all hot
parts.
• When you have nished using the
appliance check that all the controls are
in the off or closed position, checking
that the “0” of the knob corresponds to
the “•” symbol serigraphed on the front
panel.
• Switch off the electrical supply before
you start cleaning or servicing the
appliance.
• In the case of a failure or malfunction,
turn the appliance off and switch off
the electrical supply and do not tamper
with it. All repairs or adjustments must
be carried out with maximum care and
the proper attention of an authorised
person.
• For this reason we recommend you
call our Service Centre.

7
461308282 10/2014
PRESENTATION
Our cooker is tted with a fully gas hotplate. This
innovative burner hotplate offers you more scope and
versatility in hotplate cooking than ever before. The
round burners are graduated in their size and output
to provide the exact heat required for every style of
cooking. For example, the large or wok burner will
give you the intense heat required for wok cookery,
while the small simmer burner will handle the smallest
of saucepans with ease and safety. The low heat
(simmer) setting is extraordinarily low, so you can cook
the most delicate sauces to perfection. This innovative,
yet very practical combination of burners allows you to
cook an entire meal on the hotplate at once and is of
special assistance when entertaining. Each knob on the
front panel has a diagram printed above it showing to
which burner it refers.
Our cookers are tted with a electric oven and an
electric grill.
To guarantee the customer a good and safe use of the
appliance, the cookers have equipped with a safety
temperature device, which automatically turns on in
case the main thermostat fails to work. In such an
event, the electricity is interrupted temporarily: do not
attempt to repair it yourself but turn the appliance
off and contact your nearest Assistance Centre.
DESCRIPTION OF THE APPLIANCE
The oven walls are tted with various guide bars or
runners (g. 1) on which the following accessories can
be placed. Supply and quantities vary from model
to model (g. 2):
• oven shelf rack (Gf). Ensure shelf is located with
dish and tray stop pointing upwards and at rear of
oven.
• drip tray (V)
• handle (D)
• drip tray grid (E) (*)
(*) Only on certain models.




1




2

8
DESCRIPTION OF THE CONTROLS
HOB GAS BURNER KNOB (A)
By rotating the knob the following symbols appear:
= Closed position
= “Full on” position
= “Reduced rate or Low” position
OVEN THERMOSTAT KNOB (B)
By turning the oven knob we will nd the different oven
temperature values (from 50°C to Max).
OVEN FUNCTION SELECTOR KNOB (8) (C)
By turning the knob we will nd the following symbols:
= Oven off
= Oven light on, which stays on for all functions
= Defrost
= Top and bottom heating elements
= Top and bottom heating elements and fan
= Bottom heating element and fan
= Fan forced heating element and fan
= Grill heating element
= Grill heating element and fan
A

C









B
DESCRIPTION OF THE APPLIANCE











D
TIMER (D)
To set cooking time, rst wind the timer up by turning it
completely once from left to right and then back to the
number of minutes you want. The timer will ring when
the set time has elapsed.
DESCRIPTION OF THE APPLIANCE
RED WARNING LIGHT
When lit it indicates that the electric grill or one of the
oven electric components is on.
YELLOW WARNING LIGHT
When lit it indicates that either the electric oven or
electric grill is working. While the oven is being used
the light will switch off when the set temperature is
reached. During baking it is normal for the yellow light
to switch on and off several times as the oven tempe-
rature is controlled.

9
461308282 10/2014
INSTRUCTIONS FOR THE USER
HOB: GENERAL NOTES ON SAFETY
• When using the burners, do not leave the appliance
unsupervised. Ensure that children and the inrm
do not play with the appliance. In particular, make
sure that pan handles are positioned correctly and
supervise the cooking of foods which use oils and
fats, as these are highly inammable.
• Do not use aerosols or sprays near the appliance
when it is in use.
• Even after use, the burners remain hot for a long
period; to avoid burning, do not place hands or
other objects on them.
• After using the appliance, ensure that all the controls
are in the closed or off position.
AUTOMATIC ELECTRIC IGNITION OF
COOKTOP BURNERS
Push lightly the knob (A) which corresponds to burner
to be ignited and turn anti clockwise to the “Full On”
position, then depress the control knob.
Automatically the ignition spark shoots. If there is no
electric power the burner may be lit with matches.
OPTIMUM USE OF COOKTOP BURNERS
In order to achieve maximum efciency with minimum
gas consumption it is useful to remember:
• Do not use large burners with pans of small diameter
in order to avoid ames spreading wider than pans
(consult the following table) and always use pans
with lids (g. 3).
• When the boiling point is reached, it is best to turn
the knob to the “Low position”.
• Avoid using over sized pans that may radiate
excessive heat and cause damage to surrounding
surfaces such as bench tops and glass lid.
• Do not place anything, e.g. ame tamer, asbestos
mat, between pan and pan support, as serious
damage to the appliance may result (g. 4).
• Locate pan centrally over the burner so that is stable
and does not overhang the appliance (g. 5).
• If gas burns with a yellow ame, do not continue to
use burner and arrange for service.
• Do not use burners without the proper pan support or
wok stand, as this will concentrate and deect the heat
onto the hotplate (g. 6) and surrounding surfaces.
• Use only a wok support supplied or recommended
by the manufacturer of the appliance (g. 7).
ABNORMAL OPERATION
Any of the following are considered to be abnormal
operation and may require servicing:
• Yellow tipping of the hob burner ame.
• Sooting up of cooking utensils.
• Burners not igniting properly.
• Burners failing to remain alight.
• Burners extinguished by the oven door.
• Gas valves, which are difcult to turn.
In case the appliance fails to operate correctly, contact
our Service Centre.
Warning: Servicing should be carried out only
by authorised personnel.
Burners Ø pan cm
Wok 22 - 24
Medium 18 - 20
Small 16 - 18
Auxiliary 12 - 14

10
INSTRUCTIONS FOR THE USER
OVEN: GENERAL SAFETY INSTRUCTIONS
•Do not leave the oven unsupervised during use.
Ensure that children and the inrm do not play with
the appliance.
• Do not spray aerosols in the vicinity of this appliance
while it is operating.
• Where this appliance is installed in marine craft
or in caravans, it shall not be USED AS A SPACE
HEATER.
• Always grip the centre of the oven door when
opening. Do not practice excessive pressures on
the door when it is open.
• Do not store or use ammable liquids or items in the
vicinity of this appliance.
• Do not worry if condensation forms on the door and
on the internal walls of the oven during cooking.
This does not compromise its efciency.
• When opening the oven door, be very careful of
scalding vapours.
• During use the appliance becomes hot. Care
should be taken to avoid touching heating elements
inside the oven. Wear oven gloves when placing or
removing pans from the oven or use the handle (D)
(g. 2) provided. Hook the handle to the edge of the
tray and pull it out, slightly lifting it as you do so.
• When inserting or removing food from the oven,
check that excess juices do not overow onto the
oven base (oils and fats are highly inammable
when overheated).
• Use containers that will resist the temperatures
indicated on the thermostat knob.
• Never cover the base of the oven or the oven shelf
with aluminium foil or other materials, as this creates
a re hazard.
• When grilling always put a little water in the grill
pan. The water prevents the grease from burning
and from giving off bad smells and smoke. Add
more water during grilling to compensate for
evaporation.
• After using the appliance ensure that all the controls
are in the off position.
Prior to any cleaning, disconnect the appliance
from the electricity mains.
3
5
4
6 7

11
461308282 10/2014
HOW TO USE THE MULTIFUNCTION OVEN
DEFROSTING AT ROOM TEMPERATURE
Turn the selector knob to the symbol and place the
food you want to defrost inside the oven.
The length of time required depends on the quantity
and type of food.
Selecting this function will only activate the fan. Mild
air circulation around frozen food will slowly defrost it.
It is particularly suitable for fruit and cakes.
TRADITIONAL COOKING
Turn the selector knob to the symbol and adjust the
thermostat knob to the desired temperature.
If pre-heating is recommended wait till the thermostat
yellow warning light turns off before placing foods
inside the oven. This option turns on both bottom and
top heating units, evenly distributing heat on your
foods.
This type of cooking is ideal for all kind of foods (meats,
sh, bread, pizzas, cakes..).
COMBINED TRADITIONAL + FAN
COOKING
Turn the selector knob to the symbol and adjust the
thermostat knob to the desired temperature.
If pre-heating is recommended wait till the thermostat
yellow warning light turns off before placing foods
inside the oven. This option turns on both bottom
and top heating units, and heat is distributed by fan
ventilation.
This combination is suitable for rapid cooking and
allows for the use of more plates positioned on the
different levels of the oven.
DEFROSTING + WARM UP BY HOT AIR
Turn the selector knob to the symbol and adjust the
thermostat knob to the desired temperature, then
place the food inside the oven. Selecting this function
will activate the bottom heating unit and its heat is
distributed by the fan. This function is particularly
recommended to defrost and warm up ready-made
meals.
FAN FORCED COOKING
Turn the selector knob to the symbol and adjust the
thermostat knob to the desired temperature, then
place your food inside the oven.
If pre-heating is recommended wait till the thermostat
yellow warning light turns off before placing foods
inside oven. This function activates the rear heating
unit and the fan distributes the heat produced. This
combination allows for a fast and even cooking of
several different foods placed on the diverse levels of
the oven.
CONVETIONAL GRILL COOKING
Turn the selector knob to the symbol and adjust the
thermostat knob to the desired temperature.
Selecting this function the top central heating element
turns on and heat is distributed directly on food
surface.
Apart from grilling, this function is ideal to add a golden
roast to your recipes or to toast bread slices.
The grill function automatically activates the spit.
When you use the grill, do not forget to place the
drip pan beneath it to collect any sauce dripping, as
suggested in the “USEFUL COOKING TIPS“ section.
FAN GRILL COOKING
Turn the selector knob to the symbol and adjust the
thermostat knob to the desired temperature.
Selecting this function the top central heating
element turns on and heat is distributed by the fan.
This procedure mitigates the direct heat on food
surface and uses milder temperatures. It is therefore
recommended for an even golden and crispy nish
touch, ideal for whole sh and poultry.
When you use the grill, do not forget to place the
drip pan beneath it to collect any sauce dripping, as
suggested in the “USEFUL COOKING TIPS“ section.
INSTRUCTIONS FOR THE USER

12
INSTRUCTIONS FOR THE USER
COOKING / BAKING TIMETABLE
FOODS Weight
kg
Position of the
oven shelf from the
bottom
COOKING BY
NATURAL CONVECTION
COOKING BY
FORCED CONVECTION
Temperature
in °C Cooking Time in min Temperature in °C Cooking Time in min
MEAT
Roast veal
Roast beef
Roast pork
Roast lamb
1
1
1
1
1-2
1-2
1-2
1-2
200-225
200-225
200-225
200-225
100-120
40-50
100-120
100-120
190
190
190
190
100-120
40-50
100-120
100-120
GAME
Roast hare
Roast pheasant
Roast partridge
1
1
1
1-2
1-2
1-2
200-Max
200-Max
200-Max
50-60
60-70
50-60
200-Max
200-Max
200-Max
50
60
50
POULTRY
Roast chicken
Roast turkey
Roast duck
1
1
1
1-2
1-2
1-2
200-225
200-225
200-225
80-90
100-120
90-110
190
190
190
70-80
90-110
80-100
FISH
Roast sh
Casseroled sh
1
1
2
2
200
175
30-35
20-25
170-190
160-170
25-30
15-20
BAKED PASTA
Lasagne
Cannelloni
2,5
2,5
2
2
210-225
210-225
60-75
60-75
225-Max
225-Max
30-40
30-40
PIZZA 12 225-Max 25-30 225-Max 20-25
BREAD 12 225-Max 20-25 220 20
PASTRIES
Biscuits in general
Shortcrust pastry
Victoria sponge 0,8
2
2
2
190
200
200
15
20
40-45
170-190
190-200
190-200
15
20
40-45
CAKES
Angel cake
Fruit cake
Chocolate cake
0,8
0,8
0,8
2
2
2
190
200
200
52
65
45
170-190
190-200
190-200
45
65
45
The values given in the tables (temperatures and cooking times) are approximate and may vary according to each person’s
cooking habits. This table gives cooking times on only one shelf. If you are cooking with a fan oven and you are using more
than one shelf (placing the shelves on the 2nd and 4th position or on the 1st and and 3rd position) cooking time will be about
5 to 10 minutes longer.
GRILLING TIMETABLE
FOODS Weight
kg
Position of
the oven
shelf from
the bottom
COOKING BY NATURAL
CONVECTION
COOKING BY FORCED
CONVECTION
Temperature
in °C
Cooking Time in min Temperature
in °C
Cooking Time in min
1st side 2nd side 1st side 2nd side
MEAT
Chop
Beefsteaks
Half chicken (each half 0.5 kg)
0,50
0,15
1
3
3
2-3
225-Max
200-225
225
12-15
5
20
12-15
5
20
200
=
=
15
=
=
10
=
=
FISH
Trout
Sole
0,42
0,20
3
3
225-Max
225-Max
=
=
=
=
200
200
10
7
10
7
BREAD
Toast 3-4 225-Max 2-3 2-3 200 2-3 2-3
The values given in the tables (temperatures and cooking times) are approximate and may vary according to each person’s
cooking habits. In particular, temperatures and times for grilling meat will greatly depend on the thickness of the meat and on
personal tastes.

13
461308282 10/2014


8
INSTRUCTIONS FOR THE USER
USING THE GRILL
• The grill is located in the top of the oven and makes
for an extremely versatile and controllable method
of cooking.
• Preheat the grill for a few minutes for quicker
cooking and more succulent results. Preferably add
seasonings after cooking is completed
• The food should be seasoned before cooking. Oil
or melted butter should also be spread on the food
before it is cooked.
• Foods to be grilled should be placed directly on the
shelf. Then place this on the oven shelf required.
Use the oven tray to collect any meat juices (g.
8)
• With electric grill the oven door must be kept
closed.
• The grill offers a xed heat setting but, a great
degree of heat control is possible by selecting the
most suitable oven shelf position for grilling the
particular food. The lower the shelf, the less intense
the heat. This ability to adjust shelf positions also
allows for a range of bulky foods to be prepared
under the grill which ordinarily couldn't be prepared
in a standard grill compartment. Use Shelf 3 or 4 for
thick cuts of meat, sh llets or chicken pieces.
Use Shelf 2 for larger portions of foods, such as
half chicken, whole sh or browning the tops of
casserole dishes etc.
• The grill tray allows an array of foods to be prepared
under the grill. The most intense heat is directly
beneath the grill burner. Foods requiring more
gentle heat can be placed around the perimeter
of the tray where heat is not quite as intense, for
example, seafood or vegetable kebabs, savouries,
warming hamburger buns or keeping foods warm.

14
INSTRUCTIONS FOR THE USER
USEFUL COOKING TIPS
Cakes and bread:
• Heat the oven for at least 15 minutes before you
start cooking bread or cakes.
• Do not open the door during baking because the
cold air would stop the yeast from rising.
• When the cake is cooked turn the oven off and
leave it in for about 10 minutes.
• Do not use the enamelled oven tray or drip pan,
supplied with the oven, to cook cakes in.
• How do you know when the cake is cooked? About
5 minutes before the end of cooking time, put a
cake tester or skewer in the highest part of the
cake. If it comes out clean the cake is cooked.
• And if the cake sinks? The next time use less
liquids or lower the temperature 10°C.
• If the cake is too dry: Make some tiny holes
with a toothpick and pour some drops of fruit
juice or spirits on it. The next time, increase the
temperature 10°C and set a shorter cooking
time.
• If the cake is too dark on top: the next time put
the cake on a lower shelf, cook it at a lower
temperature and longer.
• If the top of the cake is burnt: cut off the burnt layer
and cover with sugar or decorate it with cream,
jam, confectioner’s cream, etc..
• If the cake is too dark underneath: the next time
place it on a higher shelf and cook it at a lower
temperature.
• If the cake or bread is cooked nicely outside but
is still uncooked inside: the next time use less
liquids, cook at a lower temperature and longer.
• If the cake will not come out of the tin: slide a
knife around the edges, place a damp cloth over
the cake and turn the tin upside down. The next
time grease the tin well and sprinkle it with our or
bread crumbs.
• If the biscuits will not come away from the baking
tray: put the tray back in the oven for a while and
lift the biscuits up before they cool. The next time
use a sheet of baking parchment to prevent this
happening again.
Meat:
• If, when cooking meat, the time needed is more
than 40 minutes, turn the oven off 10 minutes
before the end of cooking time to exploit the
residual heat (energy saving).
• Your roast will be juicier if cooked in a closed pan;
it will be crispier if cooked without a lid.
• Normally white meat, poultry and sh need
medium temperatures (less than 200°C).
• To cook “rare” red meats, high temperatures (over
200°C) and short cooking times are needed.
• For a tasty roast, lard and spice the meat.
• If your roast is tough: the next time leave the meat
to ripen longer.
• If your roast is too dark on top or underneath: the
next time put it on a higher or lower shelf, lower
the temperature and cook longer.
• Your roast is underdone? Cut it in slices, arrange
the slices on a baking tray with the gravy and
nish cooking it.
Grilling:
• Sparingly grease and avour the food before
grilling it.
• Always use the grill pan to catch the juices that drip
from the meat during grilling.
• Always put a little water in the drip pan. The water
prevents the grease from burning and from giving
off bad smells and smoke. Add more water during
cooking because it evaporates.
• Turn the food half way through cooking.
• If you are grilling fatty poultry (goose) pierce the
skin so the fat can drip away.
The aluminium can be easily corroded if it
comes into contact with organic acids present
in the foods or added during baking (vinegar,
lemon juice). Therefore it is advised not to put
directly the foods on aluminium or enamelled
trays, but ALWAYS use the proper oven paper.

15
461308282 10/2014


9
INSTRUCTIONS FOR THE USER
CLEANING AND MAINTENANCE
• Prior to any maintenance work or cleaning,
disconnect the appliance from the electricity
mains.
• Do not use a steam cleaner to clean a hob,
oven or range.
• Do not wash the parts if they are still hot.
• Do not use metal pads, abrasive powders or
corrosive spray products for cleaning
• Do not leave vinegar, coffee, milk, salty water
or the juice of lemon or tomato on enamelled
surfaces for any length of time.
• Switch off the oven before removing the fan guard
for cleaning. Replace the guard after cleaning
HOT PLATE
The enamelled steel pan supports, enamelled burner
caps and burner heads need to be cleaned after each
time they are used with warm soapy water, rinsed and
then dried well to keep them in good condition.
WARNINGS:
• After cleaning, check that the heads burners and
the relative burner caps, are correctly positioned in
their housings (g. 9).
• Take care not to disturb the ignition spark plugs or
ame failure devices.
• If you nd a tap is difcult to open or close do not
force it but call for technical assistance urgently.
• Remove any spillage from the lid before opening.
• The hob surface should be cool before closing the
lid (if any).
• The appliance is not intended to be operated by
means of an external timer or separate remote-
control system
STRUCTURE
All the cooker parts (in enamelled or painted metal,
steel, or glass) should be cleaned frequently with warm
soapy water and then rinsed and dried with a soft cloth.
DO NOT use harsh abrasive cleaners or sharp metal
scrapers to clean the oven glass door since they can
scratch the surface, which may result in shattering of
the glass. NEVER use sponges or abrasive products,
and aromatic or aliphatic solvents to remove stains or
adhesives on the painted or stainless steel surfaces.
OVEN CAVITY
Do not spray or wash the thermostat bulb with
acid based products (check the product label
before use).
The manufacturer cannot be held liable for any
damage caused by incorrect cleaning.
The oven cavity should be cleaned after each use
to remove cooking residuals and or grease or sugar
which, if burnt on when the oven is used again, will
form deposits or unremovable stains as well as
unpleasant smells.
To maintain the shine of the enamelled parts, clean
them with warm soapy water, rinse and dry them
thoroughly. ALWAYS wash the accessories used.
OVEN SEAL
The oven seal guarantees the correct functioning of
the oven. We recommend you:
• clean it, avoiding abrasive tools or products.
• check its state now and then.
If the oven door seal has become hard or is
damaged, contact our Service Centre and avoid
using the oven until it has been repaired.


10

16
INSTRUCTIONS FOR THE USER
12
OVEN DOOR REMOVAL
The oven door can be removed to give easier access
to the oven when cleaning.
To remove, proceed as follows:
• Open the oven door and insert rivet or nail (R) in the
hole (F) of the hinge (g. 11).
• Partially close the door, forcing it upwards at the
same time to free stop tooth and hinge sector.
• Once the hinge is free, pull the door forwards tilting
it slightly upwards to free sector.
• To reassemble proceed in the reverse order, paying
attention to the correct position of sectors.
HOW TO CLEAN THE INNER OVEN DOOR
GLASS
One of the features of our cookers is that the inner oven
door glass can be easily removed for cleaning without
the aid of specialized personnel. Just open the oven door
and remove the support securing the glass (g. 12).
ATTENTION!!
This operation can be done also with the door
tted on appliance, but in this way, pay attention
that when the glass is pull upwards, the force of
the hinges can close the door roughly.
LOCK AT LEAST ONE HINGE (g.11)

13
REPLACING THE OVEN LAMP (g. 13)
Ensure the appliance is switched off before
replacing the lamp to avoid the possibility of
electric shock..
In the event one or both oven lamps need replacing, the
new lamps must comply with the following requisites:
15 W - 230 V~ - 50 Hz - E 14 - and must be resistant
to high temperature (300°C).
The appliance can have two different types of lamp
holder:
• Draw out the side guide rails as described above.
Then, remove the glass protection cap (V) from
the bulb socket, lifting it with a screwdriver placed
between the cap and the oven wall and replace the
lamp (L). Fit the accessories back in reverse order.
OVEN SIDEWALL GRIDS (g. 10)
To allow for a better cleaning of the side grids, you can
extract them this way:
1. Push with a nger on the last of the slots to release
the grid from its hold.
2. Lift it towards the top and extract the grid.
To put them back into place, reverse the order of this
operation.


11

17
461308282 10/2014
TROUBLESHOOTING
Some problems can be caused either as the results of simple maintenance operations or by incor-
rect selection of settings. Prior to contacting a Service Centre please check the following chart.
PROBLEM REMEDY
The appliance is not working • Make sure the gas cock is open
• Check the plug is in
• Check that the knobs are set correctly for cooking and then
repeat the operations given in the handbook
• Check the electrical system safety switches (RCD). If there is
failure in the system call an electrician in.
The thermostat is not working • Contact Service Centre..
The oven light does not switch
on
• Make sure the lamp is rmly screwed in place
• Buy a lamp for high temperatures at one of our Service Centre
and t it following the instructions REPLACING THE OVEN
LAMP paragraph.
Warning: Servicing should be carried out only by authorised personnel.

18




TECHNICAL INFORMATION
• The installation, adjustments, conversions and
maintenance operations listed in this part must
only be carried out by qualied personnel. The
manufacturer cannot be held responsible for any
damage to persons or property resulting from an
incorrect installation of the appliance.
• The safety and automatic adjustment devices of the
appliances may, during its life, only be modied by
the manufacturer or duly authorised supplier.
• In accordance with the gas standard, the all-gas
and combi appliances are “class 1” (free standing)
or “class 2 subclass 1” (recessed) and, as such,
must comply with the clearances specied in gure
below,consequently any side walls must be no
higher than the work top.
The appliance is to be placed directly on the oor and
should not be mounted on a base.
• The walls adjacent to and surrounding the appliances
must be able to withstand an temperature of 95 °C.
• The installation of all-gas and combi appliances
must comply with the standards in force.
• This appliance is not connected to a ue for
discharge of the combustion products; therefore, it
must be connected in compliance with the above
mentioned installation rules. Particular attention
must be paid to the instructions given below for
ventilation and aeration.
INSTALLATION
UNPACKING YOUR COOKER
• Once the wrapping has been removed from
the outer surfaces and the various inner parts,
thoroughly check that the appliance is in perfect
condition. If you have any doubts do not use the
appliance and call in a qualied person.
• Some parts mounted on the appliance are protected
by a plastic lm. This protection must be removed
before using the appliance. We recommend slitting
the plastic lm along the edges with a sharp knife or
pin.
• Do not move the appliance by the handle.
The packaging materials used (cardboard, bags,
polystyrene foam, nails etc.) must not be left
anywhere within easy reach of children as they
are a potential hazard source.
INSTRUCTIONS FOR THE INSTALLER

19
461308282 10/2014
17

18

POSITIONING THE COOKER
The appliances are tted with the following parts to
enable them to be correctly positioned:
• Adjustable feet (g. 17), to be tted to the
appliance, which allow the height of the cooker
to be aligned with other kitchen furniture.
• Backguard (A). In order to install the backguard,
it is necessary to loosen the screws (V)
positioned on the back of the hob and then
to x the backgaurd as indicated in gure 18
15
16
VENTILATION
The room where the appliance is installed should be
no less than 20 m³.
The quantity of air necessary is that required for a
regular combustion of the gas and for the ventilation of
the room. The natural ow of air must be direct through
permanent apertures in the walls of the room that open
directly to the outside with a minimum cross section of
100 cm2 (g. 14). These apertures must be positioned
in such a way as not to be obstructed.
Indirect ventilation is also allowed by taking air from
adjacent rooms to the one to be ventilated, and must
comply with all current standards.
AIR INLET MIN. SECT. 100 cm2
AIR INLET MIN. SECT. 100 cm2
AIR INLET MIN. SECT. 100 cm2
LOCATION AND AERATION
Gas cookers must always discharge combustion
products and moisture through hoods connected to
ues or directly to the outside (g. 15).
If it is impossible to use a hood, a fan should be
installed in a window or on an external wall. The fan
should be switched on each time the appliance is used
(g. 16) and must comply with all relevant standards
regarding ventilation
14
INSTRUCTIONS FOR THE INSTALLER

20
INSTRUCTIONS FOR THE INSTALLER















SECURING THE COOKER TO WALL
Note:- The installation of the chain provided
is for safety reasons, it must be installed as
indicated below.
To prevent the cooker tipping forwards in the event of
children standing on the oven door or where users put
extreme weight on the door when in open position, two
chains MUST BE xed to the back of the oven which
should at all times be secured to the threaded pins .
The threaded pins should be secured to the wall at
the back of the cooker. The chains should always be
attached to the upper threaded pins when the cooker
is in its position against the wall. Pay attention in fact
that the chain must be xed without slack.
WARNING: IF THE COOKER IS INSTALLED
BETWEEN TWO CUPBOARDS YOU MUST DRILL
A 16MM HOLE LEVEL TO THE SAFETY CHAIN
HEIGHT ON EITHER CUPBOARD AS FAR BACK
AS POSSIBLE, LOCATE THE COOKER INTO
POSITION AND PASS THE SAFETY CHAINS
THROUGH THE 16MM HOLES, WITH THE
COOKER IN FINAL POSITION PULL BOTH SAFETY
CHAINS AND SECURE THEM TO THE INSIDE OF
THE CUPBOARD WITH TWO SCREWS ON EACH
SAFETY CHAIN.
PLEASE TEST THAT THE COOKER DOES NOT
TILT FORWARD.
Assembly instructions
• Secure threaded pins into wall immediately behind
and to the left-hand side about 770 mm from the
oor.
• Secure the chain under the nut before using or
cleaning etc. of the cooker .
• NOTE FOR INSTALLER
• To prevent strain on the Flexible Hose assembly, a
chain & hook is necessary approx. 100 mm up from
the oor (not provided).
• Attach the chain to the lower hooks if the cooker is
installed with a hose assembly so that there is no
strain on the hose when the cooker is pulled forward
for cleaning or maintenance.
• The socket or the switch must be accessible once
the appliance is installed.
