Award WO701S User manual

Cooker / User Manual
EN
WO701S

EN -2-
Dear Customer,
Our goal is to offer you high quality products that exceed your expectations. Your
appliance is produced in modern facilities and is thoroughly tested for quality. This
manual is intended to help you use your appliance, which has been manufactured using
the most recent technology with condence and maximum efciency. Before using your
appliance, carefully read this guide which includes basic information on safe installation,
maintenance and use. Please contact your nearest Authorised Service centre for the
installation of your product.

EN -3-
CONTENTS
SAFETY INSTRUCTIONS .....................................................................................4
INSTALLATION AND PREPARATIONS FOR USE ..............................................9
Instructions for the Installer...............................................................................9
Installation of the Oven .....................................................................................9
Electrical Connection and Safety.................................................................... 11
PRODUCT FEATURES .......................................................................................13
List of Components.........................................................................................13
Control Panel ..................................................................................................13
USE OF PRODUCT .............................................................................................14
Control of Oven...............................................................................................14
Use of Visio Display Timer..............................................................................17
CLEANING AND MAINTENANCE ......................................................................24
Cleaning..........................................................................................................24
Maintenance ...................................................................................................25
TROUBLE SHOOTING&TRANSPORT...............................................................27
Trouble shooting .............................................................................................27
Transport.........................................................................................................28
Energy Fiche...................................................................................................29

EN -4-
SAFETY INSTRUCTIONS
Read these instructions carefully and completely before
using your appliance and keep them in a convenient place
for reference when necessary.
This manual is prepared for more than one model. Your appliance
may not have some of the features described in this manual.
Pay particular attention to any gures while you are reading
the operating manual.
General Safety Warnings
• This appliance can be used by children aged from 8 years and
above and persons with reduced physical, sensory or mental
capabilities or lack of experience and knowledge if they have
been given supervision or instruction concerning use of the
appliance in a safe way and understand the hazards involved.
Children shall not play with the appliance. Cleaning and user
maintenance shall not be made by children without supervision.
•WARNING: The appliance and its accessible parts become
hot during use. Care should be taken to avoid touching heating
elements. Keep children less than 8 years of age away unless
they are continuously supervised.
•WARNING: Danger of re: do not store items on the cooking
surfaces.
• Do not operate the appliance by means of an external timer or
separate remote-control system.
• During use the appliance will get hot. Care should be taken to
avoid touching heating elements inside the oven.
• During use handles held for short periods in normal use may
get hot.
• Do not use harsh abrasive cleaners or sharp metal scrapers to
clean the oven door glass and other surface. They can scratch

EN -5-
the surface which may result in shattering of the glass or damage
to the surface.
• Do not use steam cleaners for cleaning the appliance.
•WARNING: To avoid the possibility of electric shocks, make
sure that the appliance is switched off before replacing the lamp.
•CAUTION: Accessible parts may be hot when cooking or
grilling. Keep young children away from the appliance when it is
in use.
• Your appliance is produced in accordance with all applicable
local and international standards and regulations.
• Maintenance and repair work must only be carried out by
authorised service technicians. Installation and repair work that
is carried out by unauthorised technicians may be dangerous.
Do not alter or modify the specications of the appliance in any
way. Inappropriate hob guards can cause accidents.
• Before connecting your appliance, make sure that the local
distribution conditions (nature of the gas and gas pressure or
electricity voltage and frequency) and the specications of the
appliance are compatible. The specications for this appliance
are stated on the label.
•CAUTION: This appliance is designed only for cooking food
and is intended for indoor domestic household use only. It should
not be used for any other purpose or in any other application,
such as for non-domestic use or in a commercial environment
or room heating.
• Do not use the oven door handles to lift or move the appliance.
•All possible measures have been taken to ensure your safety.
Since the glass may break, care should be taken while cleaning
to avoid scratching. Avoid hitting or knocking the glass with
accessories.
• Make sure that the supply cord is not trapped or damaged during
installation. If the supply cord is damaged, it must be replaced by
the manufacturer, its service agent or similarly qualied persons
in order to prevent a hazard.

EN -6-
• Do not let children climb on the oven door or sit on it while it is
open.
Installation Warnings
• Do not operate the appliance before it is fully installed.
• The appliance must be installed by an authorised technician. The
manufacturer is not responsible for any damage that might be
caused by defective placement and installation by unauthorised
people.
• When the appliance is unpacked, make sure that it is has not
been damaged during transportation. In case of any defect do
not use the appliance and contact a qualied service agent
immediately. The materials used for packaging (nylon, staplers,
styrofoam...etc) may be harmful to children and they should be
collected and removed immediately.
• Protect your appliance against atmospheric effects. Do not
expose it to effects such as sun, rain, snow, excessive humidity
etc.
• The material around the appliance (cabinet) must be able to
withstand a minimum temperature of 100°C.
During Usage
• When you rst use your Oven you may notice a slight smell. This
is perfectly normal and is caused by the insulation materials on
the heater elements. We suggest that before using your Oven for
the rst time you leave it empty, and set at maximum temperature
for 45 minutes. Make sure that the environment in which the
product is installed is well ventilated.
• Take care when opening the oven door during or after cooking.
The hot steam from the oven may cause burns.
• Do not put ammable or combustible materials in or near the
appliance when it is operating.
• Always use oven gloves to remove and replace food in the oven.

EN -7-
•Do not leave the cooker unattended while cooking with solid
or liquid oils. They may catch fire under extreme heating
conditions. Never pour water on to ames that are caused by oil,
instead switch the cooker off and cover the pan with its lid or a
re blanket.
•If the product will not be used for a long period of time, turn
the main control switch off. Also when not using a gas appliance,
turn the gas valve off.
• Make sure the appliance control knobs are always in the “0”
(stop) position when it is not used.
• The trays incline when pulled out. Take care not to spill or drop
hot food when removing it from the ovens.
• Do not place anything on the oven door when it is open. This
could disrupt the balance of the oven or damage the door.
• Do not place heavy items or ammable or ignitable items (e.g.
nylon, plastic bag, paper, cloth, etc.) into the drawer. This includes
cookware with plastic accessories (e.g. handles).
• Do not hang towels, dishcloths or clothes from the appliance or
its handles.
During Cleaning and Maintenance
•Always turn the appliance off before operations such as
cleaning or maintenance. You can do it after plugging the
appliance off or turning the main switches off.
• Do not remove the control knobs to clean the control panel.
• To maintain the efciency and safety of your appliance, we
recommend you always use original spare parts and to call our
authorised service agents in case of need.

EN -8-
Warning Serious injury or death risk
Risk of electric shock Dangerous voltage risk
Caution Injury or property damage risk
Important Operating the system correctly

EN -9-
INSTALLATION AND PREPARATIONS FOR USE
WARNING : This appliance must be installed by an authorised service person or
qualied technician, according to the instructions in this guide and in compliance with
the current local regulations.
•Incorrect installation may cause harm and damage, for which the manufacturer
accepts no responsibility and the warranty will not be valid.
•Prior to installation, ensure that the local distribution conditions (electricity voltage
and frequency) and the adjustments of the appliance are compatible. The adjustment
conditions for this appliance are stated on the label.
•The laws, ordinances, directives and standards in force in the country of use are to be
followed (safety regulations, proper recycling in accordance with the regulations, etc.).
Instructions for the Installer
General instructions
•After removing the packaging material from the appliance and its accessories, ensure
that the appliance is not damaged. If you suspect any damage, do not use it and
contact an authorised service person or qualied technician immediately.
• Make sure that there are no ammable or combustible materials in the close vicinity,
such as curtains, oil, cloth etc. which may catch re.
•The worktop and furniture surrounding the appliance must be made of materials
resistant to temperatures above 100°C.
•The appliance should not be installed directly above a dishwasher, fridge, freezer,
washing machine or clothes dryer.
Installation of the Oven
The appliances are supplied with installation kits and can be installed in a worktop with the
appropriate dimensions. The dimensions for hob and oven installation are given below.
A (mm) B (mm) C (mm) D (mm) E (mm) min./max.
F (mm)
min. G
(mm)
min. H
(mm)
min. I
(mm)
min. J/K
(mm)
557 550 595 575 576 560/580 555 590 600 5/10

EN -10-
F
F
A
A
B
B
C
C
C
C
D
D
E
E
G
G
H
H
J
J
K
J
I
I
Installation under a worktop
Installation in a wall unit
1.After making the electrical connections, insert the oven into the cabinet by pushing
it forward. Open the oven door and insert 2 screws in the holes located on the oven
frame. While the product frame touches the wooden surface of the cabinet, tighten
the screws.See figure 3 on EN-11
If the oven is installed under a hob:
2. The distance between the worktop and the top panel of the oven must be a minimum
of 50 mm and the distance between the worktop and the top of control panel must
be a minimum of 25 mm. See figure 2 on EN-11
3.The distance between the base of the hob and the top panel of the oven must be a
minimum of 10 mm for air circulation.See figure 3 on EN-11
