AxelTech Oxygen 3000D User manual

USER MANUAL
www.axeltechnology.com
(Rev. 5.5 - ENG)

2
SUMMARY |PREFACE
OXYGEN 3000 · User Manual · ENG
SUMMARY
SUMMARY ................................................................................................................................................................... 2
SAFETY WARNINGS/ISTRUZIONI PER LA SICUREZZA ..................................................................................................... 5
PREFACE 5
SAFETY WARNINGS ...............................................................................................................................................................6
CONSIGNES DE SÉCURITÉ IMPORTANTES.............................................................................................................................8
ISTRUZIONI IMPORTANTI PER LA SICUREZZA .....................................................................................................................10
WICHTIGE SICHERHEITSHINWEISE......................................................................................................................................13
INSTRUCCIONES IMPORTANTES DE SEGURIDAD................................................................................................................15
UNPACKING AND INSPECTION.................................................................................................................................... 17
FIRST INSTALLATION RECOMMENDATIONS................................................................................................................ 18
POWER SUPPLY CABLE........................................................................................................................................................18
PROTECTION AGAINST LIGHTNING.....................................................................................................................................18
OXYGEN 3000 INSTALLATION NOTE AND FIRST STEP.................................................................................................. 19
BEST SETUP LOCATION .......................................................................................................................................................19
INTRODUCTION .......................................................................................................................................................... 20
1. GENERAL DESCRIPTION........................................................................................................................................ 21
1.1 MIXER DIMENSIONS ...........................................................................................................................................21
1.2 CUTTING TEMPLATE ...........................................................................................................................................22
1.3 TALKBOX DIMENSIONS .......................................................................................................................................23
1.4 INPUT CONNECTIONS .........................................................................................................................................24
1.5 OUTPUT CONNECTIONS......................................................................................................................................25
1.6 COMMUNICATION CONNECTORS ......................................................................................................................26
1.7 TALKBOX CONNECTIONS ....................................................................................................................................27
2. SURFACE.............................................................................................................................................................. 28
2.1 INPUTS LED METER.............................................................................................................................................29
2.2 OUTPUT LED METER ...........................................................................................................................................29
2.3 CONTROL INPUT CHANNEL.................................................................................................................................31
A. SET BUTTON........................................................................................................................................................................ 32
B. CHB BUTTON....................................................................................................................................................................... 32
C. GAIN.................................................................................................................................................................................... 33
D. F1 BUTTON.......................................................................................................................................................................... 33
E. EQ BUTTON......................................................................................................................................................................... 34
F. PGM/SUB/AUX-1/AUX-2 BUTTONS..................................................................................................................................... 35
G. FADER.................................................................................................................................................................................. 36
H. FADER LED BAR ................................................................................................................................................................... 36
I. ON/START BUTTON............................................................................................................................................................. 37
J. PFL BUTTON........................................................................................................................................................................ 38
2.4 SPECIAL FUNCTION BUTTONS.............................................................................................................................39
A. OUTPUT BUTTON................................................................................................................................................................ 39
B. METER BUTTON .................................................................................................................................................................. 40
C. TELEPHONE......................................................................................................................................................................... 41
D. BLUETOOTH ........................................................................................................................................................................ 41
2.5 MONITORS SECTION ...........................................................................................................................................42
A. CONTROL ROOM SPEAKERS (SPK-CRM).............................................................................................................................. 42
B. CONTROL ROOM HEADPHONE (HDP-CRM) ...................................................................................................................... 45
C. STUDIO –SPEAKERS............................................................................................................................................................ 46
D. STUDIO –HEADPHONES SOURCES & LEVEL........................................................................................................................ 48
E. TALKBACK –FROM CONTROL ROOM TO THE STUDIO........................................................................................................ 49

OXYGEN 3000 · User Manual · ENG
3
SUMMARY |PREFACE
2.6 SMART KEY / JINGLE BUTTONS*.........................................................................................................................49
2.7 DISPLAY 7’’ TFT AND CONTROL BUTTONS ..........................................................................................................50
A. COLOR DISPLAY 7’’ - 800X480 RESOLUTION ....................................................................................................................... 50
B. BUTTONS FOR THE MENU NAVIGATION............................................................................................................................. 51
C. ENCODER FOR THE MENU NAVIGATION............................................................................................................................. 51
D. MENU DISPLAY PARTS......................................................................................................................................................... 52
3. MENU .................................................................................................................................................................. 52
3.1 AUDIO/INPUTS....................................................................................................................................................52
3.1.1 MIC (MIC-1 TO MIC-5) ........................................................................................................................................53
NAME:.................................................................................................................................................................53
PREAMP: .............................................................................................................................................................54
GAIN:...................................................................................................................................................................54
EQ: ......................................................................................................................................................................55
BAL/PAN: ............................................................................................................................................................58
PHASE: ................................................................................................................................................................58
PHANTOM 48V: ..................................................................................................................................................59
SPK-CUT: .............................................................................................................................................................59
3.1.2 MIC-5 INPUT / TELCO INPUT...............................................................................................................................64
3.1.3 MONO-1 TO MONO-6.........................................................................................................................................66
LINE-1, LINE-2, LINE-3 ............................................................................................................................................................... 66
3.1.4 STEREO................................................................................................................................................................67
3.1.5 AUX-IN ................................................................................................................................................................68
3.1.6 TEL/BT.................................................................................................................................................................69
TELCO........................................................................................................................................................................................ 69
TELEPHONE HYBRID.................................................................................................................................................................. 70
BLUETOOTH .............................................................................................................................................................................. 71
3.1.7 DIGITAL ...............................................................................................................................................................72
AES/EBU.................................................................................................................................................................................... 72
USB-1, USB-2............................................................................................................................................................................. 72
3.2 AUDIO/OUTPUTS ................................................................................................................................................74
 4 STEREO OUTPUT - XLR MALE - BALANCED AUDIO CONNECTION (47Ω). ...............................................74
 4 STEREO OUTPUT - PIN RCA - UNBALANCED AUDIO CONNECTIONS. .....................................................74
 2 USB AUDIO CARD USB -TYPE B - PC CONNECTIONS...............................................................................74
 2 STEREO OUTPUT - JACK 6.3MM - UNBALANCED AUDIO CONNECTION (NOMINAL 32Ω)......................74
 6 RJ45 (SFTP CABLE) AUDIO AND GPIO CONNECTIONS. ...........................................................................74
 AES/EBU STEREO OUTPUT - XLR MALE - BALANCED DIGITAL CONNECTION (110Ω)................................74
 ANALOG TELEPHONE LINE - RJ11 - PSTN INTERFACE................................................................................74
 BLUETOOTH STEREO/MONO OUTPUT - WIRELESS –SMARTPHONE........................................................74
3.2.1 ANALOG & DIGITAL OUTPUTS......................................................................................................................................... 74
3.2.2 MONITORS ...................................................................................................................................................................... 75
SPK-CRM & SPK-STUDIO................................................................................................................................75
HDP (HEADPHONE) CRM, STUDIO & GUEST..................................................................................................78
3.2.3 TONE GEN. ( TONE GENERATOR ) ................................................................................................................................... 79
3.3 SETTINGS ............................................................................................................................................................80
INPUT MODE .................................................................................................................................................80
EXT. INPUT.....................................................................................................................................................80
PFL MODE......................................................................................................................................................80
SNAPSHOT .....................................................................................................................................................81
AUDIO/SETTINGS/VJPRO .......................................................................................................................................................... 81
3.4 GENERAL SET. .....................................................................................................................................................82
GPIO ……………………………………………………………………………………………………………………………………………………………..82

4
SUMMARY |PREFACE
OXYGEN 3000 · User Manual · ENG
COMMUNICATIONS ............................................................................................................................................................83
TCP-IP........................................................................................................................................................................................ 83
TIME&DATE............................................................................................................................................................................... 83
TIME ZONE................................................................................................................................................................................ 84
ACCESS CODE......................................................................................................................................................................84
LIGHT & DISPLAY.................................................................................................................................................................85
SMART KEYS........................................................................................................................................................................86
ONAIR TRIGGERS.................................................................................................................................................................86
4. SERVICE ............................................................................................................................................................... 87
4.1 CONFIGURATION ................................................................................................................................................87
4.2 SOFTWARE..........................................................................................................................................................88
A. UPGRADE ............................................................................................................................................................................ 88
MIXER FIRMWARE UPGRADE.................................................................................................................................................... 88
B. VERSION.............................................................................................................................................................................. 89
4.3 LOGS ...................................................................................................................................................................89
4.4 WEB LOGIN .........................................................................................................................................................89
TALKBOX CONNECTIONS AND FUNCTIONING ............................................................................................................ 90
PINOUT OF CONNECTIONS ......................................................................................................................................... 93
WEEE DIRECTIVE –INFORMATIVA RAEE ..................................................................................................................... 99
WARRANTY .............................................................................................................................................................. 100
DECLARATION OF CONFORMITY………………………………………………………………………………………………………………………………101
DICHIARAZIONE DI CONFORMITA'…………………………………………………………………………………………………………………………..102

OXYGEN 3000 · User Manual · ENG
5
SAFETY WARNINGS/ISTRUZIONI PER LA SICUREZZA |PREFACE
SAFETY WARNINGS/ISTRUZIONI PER LA SICUREZZA
SAFETY WARNINGS
CONSIGNES DE SÉCURITÉ IMPORTANTES
ISTRUZIONI IMPORTANTI PER LA SICUREZZA
WICHTIGE SICHERHEITSHINWEISE
INSTRUCCIONES IMPORTANTES DE SEGURIDAD
(Rel. 1.6)
PREFACE
For your safety and to prevent the warranty from being accidentally invalidated, please
read carefully all the texts marked with the Warning Symbols
The information contained in this manual is subject to change without notice and does not constitute
a commitment by the seller.
The manufacturer will not be liable for any loss or damage resulting from the use of information or
any errors contained in this manual or resulting from any erroneous operation or hardware failure
contained in the product.
It is recommended that any repair and maintenance of the product be carried out by the
manufacturer or its authorized agents. The manufacturer assumes no responsibility for any loss or
damage caused by service, maintenance, or repair by unauthorized personnel.

6
SAFETY WARNINGS/ISTRUZIONI PER LA SICUREZZA |
OXYGEN 3000 · User Manual · ENG
SAFETY WARNINGS
The installation and servicing instructions in this manual are for use by qualified personnel only.
Read All Instructions. All safety and operating instructions must be read before operating the
product. They also must be retained for future reference, as it contains many useful hints for
determining the best combination of equipment settings for Yr particular application.
Heed All Warnings. All warnings on the product and those listed in the operating instructions must
be adhered to.
Heat. This product must be situated away from any heat sources such as radiators or other products
(including power amplifiers or transmitters) that produce heat.
Power Sources. This product must be operated from the type of power source indicated on the
marking label and in the installation instructions. If you are not sure of the type of power supplied to
your facility, consult your local power company. Make sure the AC main voltage corresponds to that
indicated in the technical specifications. If a different voltage (ex. 110/115 VAC) is available, open
the equipment closure and set the voltage switch on the main supply circuit, located behind the AC
socket.
Power Cord Protection. Power supply cords must be routed so that they are not likely to be walked
on or pinched by items placed upon or against them. Pay particular attention to the cords at AC wall
plugs and convenience receptacles, and at the point where the cord plugs into the product.
Use only with a cart, stand, tripod, bracket, or table specified by the manufacturer, or sold with the
apparatus. When a cart is used, use caution when moving the cart/apparatus combination to avoid
injury from tip-over.
Lightning. For added protection for this product during a lightning storm, or when it is left
unattended and unused for long periods, unplug it from the AC wall outlet and the audio
connections. This will prevent damage to the product due to lightning and power-line surges.
Installation. Configuration and installation should only be carried out by a competent installation
engineer.
Cabling. Using high-quality wires, well-protected. Make sure the cable integrity.

OXYGEN 3000 · User Manual · ENG
7
SAFETY WARNINGS/ISTRUZIONI PER LA SICUREZZA |SAFETY WARNINGS
This symbol alerts you to the presence of dangerous voltage inside the closure –voltage
that may be sufficient to constitute a risk of shock. Do not perform any servicing other
than that contained in the operating instructions. Refer all servicing to qualified
personnel.
The exclamation point within an equilateral triangle is intended to alert the user to the
presence of important operating and maintenance (servicing) instructions in the
literature accompanying the appliance.
Do not change the voltage setting or replace the mains fuse without first turning the
unit off and unplugging the mains cord.
Make sure the AC main voltage corresponds to that indicated in the technical
specifications.
THIS APPARATUS MUST BE EARTHED!
To avoid the risk of fire, use the correct value fuse, as indicated on the label stuck on
the right side of the unit.
This apparatus uses a single-pole main switch and does therefore not separate the
unit completely from the mains power. To completely separate from mains power
(f.i. in the event of danger) unplug the mains power cord. As the MAINS plug is the
disconnect device, the disconnect device shall remain readily operable.

8
SAFETY WARNINGS/ISTRUZIONI PER LA SICUREZZA |CONSIGNES DE
SÉCURITÉ IMPORTANTES
OXYGEN 3000 · User Manual · ENG
CONSIGNES DE SÉCURITÉ IMPORTANTES
Lire ces consignes.
Conserver ces consignes.
Observer tous les avertissements.
Suivre toutes les consignes.
Ne pas utiliser cet appareil à proximité de l’eau.
Ne pas obstruer les ouvertures de ventilation. Installer en respectant les consignes du fabricant.
Ne pas installer à proximité d'une source de chaleur telle qu'un radiateur, une bouche de chaleur, un
poêle ou d'autres appareils (dont les amplificateurs) produisant de la chaleur.
Ne pas annuler la sécurité de la fiche de terre, la troisième branche est destinée à la sécurité. Si la
fiche fournie ne s'adapte pas à la prise électrique, demander à un électricien de remplacer la prise hors
normes.
Protéger le cordon d'alimentation afin que personne ne marche dessus et que rien ne le pince, en
particulier aux fiches, aux prises de courant et au point de sortie de l’appareil.
Utiliser uniquement les accessoires spécifiés par le fabricant.
Utiliser uniquement avec un chariot, un support ou une table spécifié par le fabricant ou vendu avec
l’appareil. Si un chariot est utilisé, déplacer l’ensemble chariot–appareil avec précaution afin de ne pas
le renverser, ce qui pourrait entraîner des blessures.
Débrancher l’appareil pendant les orages ou quand il ne sera pas utilisé pendant longtemps.
Confier toute réparation à du personnel qualifié. Des réparations sont nécessaires si l’appareil est
endommagé d’une façon quelconque, par exemple: cordon ou prise d’alimentation endommagé,
liquide renversé ou objet tombé à l’intérieur de l’appareil, exposition de l’appareil à la pluie ou à
l’humidité, appareil qui ne marche pas normalement ou que l’on a fait tomber.
NE PAS exposer cet appareil aux égouttures et aux éclaboussements. Ne pas poser des objets
contenant de l'eau, comme des vases, sur l'appareil.

OXYGEN 3000 · User Manual · ENG
9
SAFETY WARNINGS/ISTRUZIONI PER LA SICUREZZA |CONSIGNES DE SÉCURITÉ IMPORTANTES
Ce symbole indique la présence d'une tension dangereuse dans l'appareil
constituant un risque de choc électrique.
Ce symbole indique que la documentation fournie avec l'appareil contient
des instructions d'utilisation et d'entretien importantes.
Avant de modifier le commutateur de changement de tension ou replacer
le fusible il faut débrancher l’appareil de la prise électrique. Pendant son
usage, l’appareil doit etre branchee à la prise de terre.
Utiliser le fusible principal AC avec le valeur qui est indiquée sur l'étiquette
collée sur le coffret.
Assurez-vous que la tension principale AC correspond à celle indiquée dans
les spécifications techniques.
L’interrupteur d’alimentation interrompt un pôle du réseau d’alimentation
excepté le conducteur de terre de protection. En cas de danger, debrancher
le cordon d'alimentation. Parce que la prise du réseau de alimentation est
utilisée comme dispositif de déconnexion, ce dispositif doit demeuré
aisément accessible.

10
SAFETY WARNINGS/ISTRUZIONI PER LA SICUREZZA |ISTRUZIONI
IMPORTANTI PER LA SICUREZZA
OXYGEN 3000 · User Manual · ENG
ISTRUZIONI IMPORTANTI PER LA SICUREZZA
Leggere le presenti istruzioni.
Conservare queste istruzioni.
Osservare tutte le avvertenze.
Seguire scrupolosamente tutte le istruzioni.
Non usare questo apparecchio in prossimità di acqua.
Non ostruire alcuna apertura per il raffreddamento. Installare l’apparecchio seguendo le istruzioni.
Non installare l'apparecchio accanto a fonti di calore quali radiatori, aperture per l'afflusso di aria
calda, forni o altri apparecchi (amplificatori inclusi) che generino calore.
Non rimuovere il terminale di connessione a terra sul cordone di alimentazione: esso ha lo scopo di
tutelare l’incolumità dell’utilizzatore. Se la spina in dotazione non si adatta alla presa di corrente,
rivolgersi ad un elettricista per far eseguire le modifiche necessarie.
Evitare di calpestare il cavo di alimentazione o di comprimerlo, specialmente in corrispondenza
della spina e del punto di inserzione sull’apparato.
Utilizzare solo dispositivi di collegamento e gli accessori specificati dal produttore.
Utilizzare l’apparecchio solo con un carrello, un sostegno, una staffa o un tavolo di tipo specificato
dal produttore o venduto insieme all’apparecchio. Se si utilizza un carrello, fare attenzione negli
spostamenti per evitare infortuni causati da ribaltamenti del carrello stesso.
Scollegare l’apparecchio dalla presa di corrente durante i temporali o quando inutilizzato a lungo.
Per qualsiasi intervento, rivolgersi a personale di assistenza qualificato. È’ necessario intervenire
sull’apparecchio ogniqualvolta si verificano danneggiamenti di qualsiasi natura. Ad esempio, la spina
o il cavo di alimentazione sono danneggiati, è entrato liquido nell’apparecchio o sono caduti oggetti
su di esso, l’apparecchio è stato esposto alla pioggia o all’umidità, non funziona normalmente o è
caduto.
Non esporre a sgocciolamenti o spruzzi. Non appoggiare sull'apparecchio oggetti pieni di liquidi, ad
esempio vasi da fiori.
Il prodotto deve essere connesso ad impianti costruiti secondo la regola dell'arte e muniti di
protezione differenziale del circuito con valore non superiore agli 0,03A.
Tenere il prodotto lontano da liquidi.

OXYGEN 3000 · User Manual · ENG
11
SAFETY WARNINGS/ISTRUZIONI PER LA SICUREZZA |ISTRUZIONI IMPORTANTI PER LA SICUREZZA
Il prodotto deve essere utilizzato solo se integro e non danneggiato. Se il prodotto è stato
sottoposto a forti urti o fosse venuto a contatto con liquidi è necessario contattare l'assistenza
prima di accenderelo.
Il prodotto non và aperto per nessun motivo, non và modificato o manomesso. E' vietato tentare
qualsiasi tipo di riparazione.
E' obbligatorio leggere il manuale utente prima di utilizzare il prodotto.
Il prodotto deve essere utilizzato da persone adulte. Tenere il prodotto fuori dalla portata dei
bambini
Il prodotto và collegato ad impianti costruiti secondo la regola dell'arte e muniti di protezioni
magnetotermiche del circuito.
E' proibito sovraccaricare le prese di corrente. E' obbligatorio spegnere il prodotto se non utilizzato.
E' proibito ostruire le aperture di raffreddamento e aerazione.
E' obbligatorio tenere materiali infiammabili/combustibili lontani dal prodotto.
E' vietato utilizzare il prodotto in presenza di sostanze che possano creare atmosfera esplosiva.
Il prodotto và utilizzato posizionato e utilizzato in maniera stabile.

12
SAFETY WARNINGS/ISTRUZIONI PER LA SICUREZZA |ISTRUZIONI
IMPORTANTI PER LA SICUREZZA
OXYGEN 3000 · User Manual · ENG
Questo simbolo indica la presenza di alta tensione all'interno dell'apparecchio,
che comporta rischi di scossa elettrica.
Questo simbolo indica la presenza di istruzioni importanti per l'uso e la
manutenzione nella documentazione in dotazione all'apparecchio.
Non sostituire il fusibile o cambiare la tensione di alimentazione senza aver
prima scollegato il cordone di alimentazione. L’APPARATO DEVE ESSERE
CONNESSO A TERRA.
Sostituire il fusibile generale con uno di identico valore, come indicato sulla
etichetta applicata sul mobile dell’apparato
Assicurarsi che la tensione di rete corrisponda a quella per la quale è configurato
l’apparecchio.
Questo apparato utilizza un interruttore di alimentazione di tipo unipolare e
l’isolamento dalla rete elettrica non è pertanto completo. Per ottenere un
isolamento totale (ad esempio in caso di pericolo), scollegare il cordone di
alimentazione. Inoltre, poichè la spina di alimentazione è utilizzata come
dispositivo di sezionamento, essa deve restare facilmente raggiungibile.

OXYGEN 3000 · User Manual · ENG
13
SAFETY WARNINGS/ISTRUZIONI PER LA SICUREZZA |WICHTIGE SICHERHEITSHINWEISE
WICHTIGE SICHERHEITSHINWEISE
Diese Hinweise LESEN.
Diese Hinweise AUFHEBEN.
Alle Warnhinweise BEACHTEN.
Alle Anweisungen BEFOLGEN.
Dieses Gerät NICHT in der Nähe von Wasser verwenden.
KEINE Lüftungsöffnungen verdecken. Gemäß den Anweisungen des Herstellers einbauen.
Nicht in der Nähe von Wärmequellen, wie Heizkörpern, Raumheizungen, Herden oder anderen
Geräten (einschließlich Verstärkern) installieren, die Wärme erzeugen.
Die Schutzfunktion des Schukosteckers NICHT umgehen. Bei Steckern für die USA gibt es
polarisierte Stecker, bei denen ein Leiter breiter als der andere ist; US-Stecker mit Erdung verfügen
über einen dritten Schutzleiter. Bei diesen Steckerausführungen dient der breitere Leiter bzw. der
Schutzleiter Ihrer Sicherheit. Wenn der mitgelieferte Stecker nicht in die Steckdose passt, einen
Elektriker mit dem Austauschen der veralteten Steckdose beauftragen.
VERHINDERN, dass das Netzkabel gequetscht oder darauf getreten wird, insbesondere im Bereich
der Stecker, Netzsteckdosen und an der Austrittsstelle vom Gerät.
NUR das vom Hersteller angegebene Zubehör und entsprechende Zusatzgeräte verwenden.
NUR in Verbindung mit einem vom Hersteller angegebenen oder mit dem Gerät verkauften
Transportwagen, Stand, Stativ, Träger oder Tisch verwenden. Wenn ein Transportwagen verwendet
wird, beim Verschieben der Transportwagen-Geräte- Einheit vorsichtig vorgehen, um Verletzungen
durch Umkippen.
Das Netzkabel dieses Geräts während Gewittern oder bei längeren Stillstandszeiten aus der
Steckdose ABZIEHEN.
Alle Reparatur- und Wartungsarbeiten von qualifiziertem Kundendienstpersonal DURCHFÜHREN
LASSEN. Kundendienst ist erforderlich, wenn das Gerät auf irgendwelche Weise beschädigt wurde,
z.B. wenn das Netzkabel oder der Netzstecker beschädigt wurden, wenn Flüssigkeiten in das Gerät
verschüttet wurden oder Fremdkörper hineinfielen, wenn das Gerät Regen oder Feuchtigkeit
ausgesetzt war, nicht normal funktioniert oder fallen gelassen wurde.
Dieses Gerät vor Tropf- und Spritzwasser SCHÜTZEN. KEINE mit Wasser gefüllten Gegenstände wie
zum Beispiel Vasen auf das Gerät STELLEN.

14
SAFETY WARNINGS/ISTRUZIONI PER LA SICUREZZA |WICHTIGE
SICHERHEITSHINWEISE
OXYGEN 3000 · User Manual · ENG
Dieses Symbol zeigt an, dass gefährliche Spannungswerte, die ein
Stromschlagrisiko darstellen, innerhalb dieses Geräts auftreten.
Dieses Symbol zeigt an, dass das diesem Gerät beiliegende Handbuch
wichtige Betriebs- und Wartungsanweisungen enthält.
Vor Änderung der Netzspannung oder Sicherungswechsel Netzkabel
trennen.
Das Gerät muss für den Betrieb geerdet werden.
Vor Änderung der Netzspannung oder Sicherungswechsel Netzkabel
trennen.
Das Gerät muss für den Betrieb geerdet werden.
Hauptsicherung nur mit einer gleichwertigen austauschen
(s. entsprechende Etikette).
Vor Einschalten Netzspannungseinstellung am Gerät überprüfen bzw.
anpassen.
Inpoliger Netzschalter. In Notfälle oder für Wartungsarbeiten Netzkabel
trennen. Der Netzstecker fungiert auch als Trennelement muss deshalb
zugänglich bleiben.

OXYGEN 3000 · User Manual · ENG
15
SAFETY WARNINGS/ISTRUZIONI PER LA SICUREZZA |INSTRUCCIONES IMPORTANTES DE
SEGURIDAD
INSTRUCCIONES IMPORTANTES DE SEGURIDAD
LEA estas instrucciones.
CONSERVE estas instrucciones.
PRESTE ATENCION a todas las advertencias.
SIGA todas las instrucciones.
NO utilice este aparato cerca del agua.
NO obstruya ninguna de las aberturas de ventilación. Instálese según lo indicado en las
instrucciones del fabricante.
No instale el aparato cerca de fuentes de calor tales como radiadores, registros de calefacción,
estufas u otros aparatos (incluyendo amplificadores) que produzcan calor.
NO anule la función de seguridad del enchufe polarizado o con clavija de puesta a tierra. Un
enchufe polarizado tiene dos patas, una más ancha que la otra. Un enchufe con puesta a tierra
tiene dos patas y una tercera clavija con puesta a tierra. La pata más ancha o la tercera clavija se
proporciona para su seguridad. Si el toma corriente no es del tipo apropiado para el enchufe,
consulte a un electricista para que sustituya el toma corriente de estilo anticuado.
PROTEJA el cable eléctrico para evitar que personas lo pisen o estrujen, particularmente en sus
enchufes, en los toma corrientes y en el punto en el cual sale del aparato.
UTILICE únicamente los accesorios especificados por el fabricante.
UTILICESE únicamente con un carro, pedestal, escuadra o mesa del tipo especificado por el
fabricante o vendido con el aparato. Si se usa un carro, el mismo debe moverse con sumo cuidado
para evitar que se vuelque con el aparato.
DESENCHUFE el aparato durante las tormentas eléctricas, o si no va a ser utilizado por un lapso
prolongado.
TODA reparación debe ser llevada a cabo por técnicos calificados. El aparato requiere reparación si
ha sufrido cualquier tipo de daño, incluyendo los daños al cordón o enchufe eléctrico, si se derrama
líquido sobre el aparato o si caen objetos en su interior, si ha sido expuesto a la lluvia o la
humedad, si no funciona de modo normal, o si se ha caído.
NO exponga este aparato a chorros o salpicaduras de líquidos. NO coloque objetos llenos con
líquido, tales como floreros, sobre el aparato .

16
SAFETY WARNINGS/ISTRUZIONI PER LA SICUREZZA |INSTRUCCIONES
IMPORTANTES DE SEGURIDAD
OXYGEN 3000 · User Manual · ENG
Este símbolo indica que la unidad contiene niveles de voltaje peligrosos que
representan un riesgo de choques eléctricos.
Este símbolo indica que la literatura que acompaña a esta unidad contiene
instrucciones importantes de funcionamiento y mantenimiento.
Antes de cambiar la alimentacion de voltaje o de cambiar el fusible,
desconecte el cable de alimentacion. Para reducir el riesgo de descargas
electricas, esta unidad debe ser conectada a tierra.
Remplaze el fusible con lo mismo, que corresponde a lo indicado en el panel
del equipo.
Antes de encender, controlar que la linea de alimentacion de voltaje
corresponda a la indicada.
El interruptor de alimentación es unipolar. En el caso de peligro, desconecte
el cable de alimentación. Porque la clavija de conexion a red sirve por la
desconection de la unidad, la clavija debe ser ubicada en proximidad de la
unidad.

OXYGEN 3000 · User Manual · ENG
17
UNPACKING AND INSPECTION |INSTRUCCIONES IMPORTANTES DE SEGURIDAD
UNPACKING AND INSPECTION
Your equipment was packed carefully at the factory in a container designed to protect the unit
during shipment. Nevertheless, we recommend making a careful inspection of the shipping
carton and the contents for any signs of physical damage.
Damage & Claims
If the damage is evident, do not discard the container or packing material. Contact your carrier
immediately to file a claim for damages. Customarily, the carrier requires you, the consignee, to
make all damage claims. It will be helpful to retain the shipping documents and the waybill
number.
Save all packing materials! If You should ever have to ship the unit (e.g. for servicing), it is best to
ship it in the original carton with its packing materials because both the carton and packing
material have been carefully designed to protect the unit.
Under normal conditions, no user maintenance or calibration is required. Internal links and preset
controls may be set to configure the unit during installation. Any service work required should
be carried out by qualified service personnel only.
We can offer further product support through our worldwide network of approved dealers and
service agents.
To help us provide the most efficient service please would you keep a record of the unit serial
number and date and place of purchase to be quoted in any communication regarding this
product.
The actual equipment Serial Number is indicated on the silver label stuck on the rear panel of the
equipment closure.
Tools and Equipment Needed
Only standard technician tools are required to install this equipment.

18
FIRST INSTALLATION RECOMMENDATIONS |POWER SUPPLY CABLE
OXYGEN 3000 · User Manual · ENG
FIRST INSTALLATION RECOMMENDATIONS
POWER SUPPLY CABLE
A power supply cable of approx. 2 mt. lengths is supplied with the device, which has a
moulded IEC plug attached –this is a legal requirement.
The type of plug for the power supply depends on the country in which it is delivered.
If for any reason, you need to use this appliance with a different plug, you should use the
following wiring guidelines in replacing the existing plug with the new one:
Earth
Green, or green and yellow
Neutral (N)
Blue
Live (L)
Brown
Supply cables should be laid in such a manner that one does not step or walk on them. They
should not be squashed by any objects.
THIS EQUIPMENT MUST BE EARTHED.
The chassis is always connected to mains earth to ensure your safety: check your mains wiring
and earthing before switching on.
PROTECTION AGAINST LIGHTNING
Should the device be put out of action due to being struck by lightning or
excess voltage, disconnect it from the power supply without delay. Do not
reconnect until the device has been checked. If in doubt contact the
technical support service.
Make sure there is suitable lightning protection to protect the device.
Alternatively, you should disconnect all connectors from the device during a
storm or when the device is going to be unsupervised or not used for a
longer period.
These measures will protect against damage by lightning or excess voltage.

OXYGEN 3000 · User Manual · ENG
19
OXYGEN 3000 INSTALLATION NOTE AND FIRST STEP |PROTECTION AGAINST LIGHTNING
OXYGEN 3000 INSTALLATION NOTE AND FIRST STEP
Best setup location
The Oxygen 3000 should be installed avoiding direct sunlight, close proximity to radiators and air
conditioning, dust, water, and chemicals. Choose a console location that permits a clear view of the
indicators on the device and ensures a sufficient heat dissipation of the device.
Power supply
The device is designed for operation with 100 to 240 VAC, 50 Hz to 60 Hz. Check the corresponding
device labelling for compatibility with the domestic line voltage and frequency before connecting the
IEC power connector to the mains supply!
Power Supply
Please make sure that the device and the contained fuse(s) (please
see p. 17) are compatible with the domestic line voltage and
frequency. If the device is compatible, connect the power supply cord
fully to the IEC power connector at the rear side of the device and a
mains power outlet. The “LCD Screen” will then turn on.
Network
configuration
OXYGEN has a display, so you can configure the IP settings directly:
See step “LAN-1 PAGE FUNCTIONALITY (HOW TO SET THE TCP/IP ETH-
1)”
Connect to network
Connect a network patch cable to the “10/100-Base-T” connector on
the rear side of the device and your existing IP network.
Ready!
These first steps are only intended for a quick first start and do not
cover all device functions. Please read carefully the entire manual to
be able to use all functions of the device.
WARNING
Disconnect the mains power plug before you open
the housing. Repair of the equipment must only be
carried out by authorized and qualified personnel.

20
INTRODUCTION |PROTECTION AGAINST LIGHTNING
OXYGEN 3000 · User Manual · ENG
INTRODUCTION
Oxygen 3000 is the new concept digital console and defines a new standard in the
broadcast market.
Characterized by an elegant design and compact size, Oxygen 3000 has been
designed for both On-Air and Production studios.
Oxygen 3000 is based on digital technology with DSP audio processing to deliver high-
end quality, latest features, and flexibility with ease of use.
Oxygen 3000 is the number 1 in the category at the best quality/price ratio.
Oxygen 3000 is a powerful and compact unit featuring 10 faders, meters for every
single channel, a built-in 7” display for settings, a wide range of connectivity, and
accessories in a rugged and classy steel chassis. Easy and reliable as the analog mixing
consoles,
Oxygen 3000 adds the value of the digital engine that grants a near 0 latency (< 0,7
ms I/O) and plenty of advanced functions as the internal routing signal, customizable
pre-set and easy recall, user-defined smart keys, analog, and digital I/O.
