Axim PR-7085P Series Manual

TITLE
SUB TITLE
SHEET No.
4:9
TECHNICAL INFORMATION PR-7085P
160.3mm
906.5mm
to floor
17.5mm
9.5mm
Drill 4.8mm
(.188) and
countersink
(2)
21.2mm
9.5mm
23.8mm
15.8mm
47.6mm
25.4
mm
50.8mm
9.5mm
17.5mm
9.5mm
For lock cylinder only
Drill 5.2mm (203)
clearance holes (2)
and 35.7mm
cylinder hole
Lock stile (inside) Lock stile (outside)
Drill 6.7mm (.266)
holes (2)
Lock
cylinder
Actuator
link
Connecting
pin
INSTALLATION OF
ACTUATOR LINK
Actuator
pin
Place actuator link over actuator
pin & connect using connecting pin
Dogging
pin
25.4mm
25.4mm
25.4mm
47.6mm
906.5mm
22.2mm
39.7mm
Drill 3.2mm (.125) holes (4)
22.2mm x 27mm hole
for strike or 17.5mm
hole if strike not used
Strike
Adjustment screw
Trip bracket used as
release when door
stop is not used
HEADER PREPARATION
THRESHOLD PREPARATION
Strike
22.2mm x 27mm hole
for strike or 17.5mm
hole if strike not used
Drill 3.2mm (.125) holes (2)
16.7mm
8.7mm
11.9mm
Drill 5.2mm (.203)
& countersink (3)
See note #6
14.3mm
See note #6
Drill 5.2mm
(.203) and
countersink (3)
9.5mm
191mm
Floor line
MOUNTING INSTRUCTIONS
1. Determine hand of door and prepare inside of lock and hinge
stiles as show.
2. If Cylinder Key Lock is to be used, prepare inside and outside
of lock stile as shown.
3. Insert Rod and Case Assembly into lock stile and secure with
(2) 1/4-20 Shoulder Studs.
4. If Key Lock is used, insert Cylinder in Mounting Pad and
secure with Locking Ring. Install using (2) #8-32x1-23.8mm
Flat Head Machine Screws.
5. Position Exit Pad over stile and attach Actuator Link to Actuator
Pin using Connecting Pin provided. Place on stile over 1/4-20
Shoulder Studs and tighten 3 Socket Head Set Screws to
secure in place.
6. Adjust length of top and bottom Latch Bolts by turning in or
out. When the Panic Arm is fully depressed, the Latch Bolts
should be slightly recessed from flush with the top and bottom
of the door. NOTE: Flat notch side of Bolt must face the
outside of the door. Install top and bottom Latch Bolt Guides
using (6) #10x12.7mm Flat Head Self-threading Screws.
7. Install (2) 1/4-20 Shoulder Studs on hinge stile. Place other
Exit Pad over Studs and tighten 3 Socket Head Set Screws to
secure in place.
8. Prepare header and threshold as shown. If Header and
Threshold Strikes are required, install using (4) #8x9.5mm
Flat Head Self-threading Screws or (4)#8x25.4mm Flat Head
All-purpose screws.
DOGGING EXIT DEVICE USING DOGGING PIN:
Fully depress push paddle and hold, push up Dogging Pin with
screwdriver and rotate 90oin either direction.
TO RELEASE EXIT DEVICE:
Hold push paddle down and rotate Dogging Pin with
screwdriver in either direction until Dogging Pin releases.
DOGGING EXIT DEVICE USING CYLINDER KEY:
Fully depress push paddle and hold, turn Key clockwise
approximately 60o, return Key to centre and remove.
TO RELEASE EXIT DEVICE:
Turn key counterclockwise 90o, return Key to centre and remove.
SCALE
DATE
A Member of
A Member of THE PARKSIDE GROUP LTD
UNIT 5, THE WILLOW CENTRE
17 WILLOW LANE, MITCHAM, SURREY, CR4 4NX
Tel: [phone] Fax: [phone]
Email: [email protected]
Web Site: http://www.axim.co.uk
For scaled technical or CAD drawings,
please contact AXIM.
NTS @A4
MARCH 2014
CONCEALED ROD PADDLE HANDLE
PR-7085P SERIES EXIT DEVICE

TITLE
SUB TITLE
SHEET No.
4:10
1) Remove securing
screw in back of handle unit
2) Once securing screw is
removed existing pin should be
ejected by internal spring
3) Replace existing pin with knurled pin
(retaining original spring)
4) Replace securing screw holding knurled
pin in far enough that notch on dogging
pin can locate on securing screw
SCALE
DATE
A Member of
A Member of THE PARKSIDE GROUP LTD
UNIT 5, THE WILLOW CENTRE
17 WILLOW LANE, MITCHAM, SURREY, CR4 4NX
Tel: [phone] Fax: [phone]
Email: [email protected]
Web Site: http://www.axim.co.uk
For scaled technical or CAD drawings,
please contact AXIM.
NTS @A4
MARCH 2014
FITTING GUIDE FOR DOGGING PIN DP-713
CONCEALED ROD PADDLE HANDLE
PR-7085P SERIES EXIT DEVICE

4:11
51
RC 785 AL Rim cylinder & MP 786 mounting
pad for use with 7085/7100 panic exit devices
RC 795 AL Rim cylinder for
use with 7095 panic exit device
25.5
73
19
9.5 R4
R18
6.5
136.5
10.5
21
R15
6.5Ø
R7.5
TITLE
SUB TITLE
SHEET No.
SCALE
DATE
A Member of
A Member of THE PARKSIDE GROUP LTD
UNIT 5, THE WILLOW CENTRE
17 WILLOW LANE, MITCHAM, SURREY, CR4 4NX
Tel: [phone] Fax: [phone]
Email: [email protected]
Web Site: http://www.axim.co.uk
For scaled technical or CAD drawings,
please contact AXIM.
NTS @A4
MARCH 2014
RIM CYLINDERS PR-7085P
CONCEALED ROD PADDLE HANDLE
PR-7085P SERIES EXIT DEVICE

TITLE
SUB TITLE
SHEET No.
4:12
KEY CONTROLLED OUTSIDE TRIM LOCKING HANDLE FOR
PR7085, PR7085P & PR7100 EXIT DEVICES
LH-725 Locking handle
Key Controlled Outside trim for use
with PR7085, PR7085P, and PR7100
concealed rod Panic Devices.
Uses Axim screw in Mortice cylinder
with MS type CAM.
Not handed. (Field reversible).
All Axim Panic Exit Hardware is
supplied with comprehensive
instructions and full size templates
for ease of installation.
SCALE
DATE
A Member of
A Member of THE PARKSIDE GROUP LTD
UNIT 5, THE WILLOW CENTRE
17 WILLOW LANE, MITCHAM, SURREY, CR4 4NX
Tel: [phone] Fax: [phone]
Email: [email protected]
Web Site: http://www.axim.co.uk
For scaled technical or CAD drawings,
please contact AXIM.
NTS @A4
MARCH 2014
29
133
110
57
181 172
45
22
CONCEALED ROD PADDLE HANDLE
PR-7085P SERIES EXIT DEVICE

TITLE
SUB TITLE
SHEET No.
4:10
1) Remove securing
screw in back of handle unit
2) Once securing screw is
removed existing pin should be
ejected by internal spring
3) Replace existing pin with knurled pin
(retaining original spring)
4) Replace securing screw holding knurled
pin in far enough that notch on dogging
pin can locate on securing screw
SCALE
DATE
A Member of
A Member of THE PARKSIDE GROUP LTD
UNIT 5, THE WILLOW CENTRE
17 WILLOW LANE, MITCHAM, SURREY, CR4 4NX
Tel: [phone] Fax: [phone]
Email: [email protected]
Web Site: http://www.axim.co.uk
For scaled technical or CAD drawings,
please contact AXIM.
NTS @A4
MARCH 2014
FITTING GUIDE FOR DOGGING PIN DP-713
CONCEALED ROD PADDLE HANDLE
PR-7085P SERIES EXIT DEVICE

4:11
51
RC 785 AL Rim cylinder & MP 786 mounting
pad for use with 7085/7100 panic exit devices
RC 795 AL Rim cylinder for
use with 7095 panic exit device
25.5
73
19
9.5 R4
R18
6.5
136.5
10.5
21
R15
6.5Ø
R7.5
TITLE
SUB TITLE
SHEET No.
SCALE
DATE
A Member of
A Member of THE PARKSIDE GROUP LTD
UNIT 5, THE WILLOW CENTRE
17 WILLOW LANE, MITCHAM, SURREY, CR4 4NX
Tel: [phone] Fax: [phone]
Email: [email protected]
Web Site: http://www.axim.co.uk
For scaled technical or CAD drawings,
please contact AXIM.
NTS @A4
MARCH 2014
RIM CYLINDERS PR-7085P
CONCEALED ROD PADDLE HANDLE
PR-7085P SERIES EXIT DEVICE

TITLE
SUB TITLE
SHEET No.
4:12
KEY CONTROLLED OUTSIDE TRIM LOCKING HANDLE FOR
PR7085, PR7085P & PR7100 EXIT DEVICES
LH-725 Locking handle
Key Controlled Outside trim for use
with PR7085, PR7085P, and PR7100
concealed rod Panic Devices.
Uses Axim screw in Mortice cylinder
with MS type CAM.
Not handed. (Field reversible).
All Axim Panic Exit Hardware is
supplied with comprehensive
instructions and full size templates
for ease of installation.
SCALE
DATE
A Member of
A Member of THE PARKSIDE GROUP LTD
UNIT 5, THE WILLOW CENTRE
17 WILLOW LANE, MITCHAM, SURREY, CR4 4NX
Tel: [phone] Fax: [phone]
Email: [email protected]
Web Site: http://www.axim.co.uk
For scaled technical or CAD drawings,
please contact AXIM.
NTS @A4
MARCH 2014
29
133
110
57
181 172
45
22
CONCEALED ROD PADDLE HANDLE
PR-7085P SERIES EXIT DEVICE
