KEYSECURE® 5 & 6 OVERVIEW
KeySecure 5 and KeySecure 6 are key control devices that retain keys for security and accountability.
The KeySecure 5 secures one or more mechanical master keys to support a traditional Knox Rapid Access
System.
The KeySecure 6 is part of the Knox eLock system and will secure an eKey with an option to also secure a
mechanical master key
KEYSECURE®5 & 6
ADMIN & USER GUIDE
MODEL DESCRIPTION
KS-6K1 KeySecure® 6, SUPPORTS 1 eKey ONLY
KS-6K2 KeySecure® 6, SUPPORTS 1 eKey and 1 Mechanical Key
KSM-200AC AC ADAPTER, WALL MOUNT, KeySecure®5 & 6
KSM-200K1 KeySecure® 5, 1 MKEY, 1 PLUG, WiFi, ETHERNET, USB, W/ ANT.
KSM-200K2 KeySecure® 5, 2 MKEY, WiFi, ETHERNET, USB, W/ ANTENNA
KLS-AP ADAPTER PLATE KIT, LEGACY BRACKETS, KeySecure® 5 & 6
KLS-FM FLAT MOUNT BRACKET, KeySecure® 5 & 6
KLS-MB-60 MOUNTING BRACKET 60º ANGLE, KeySecure® 5 & 6
KLS-MB-90 MOUNTING BRACKET 90º ANGLE, KeySecure® 5 & 6
KeySecure 5 & 6 Features
• Managed by KnoxConnect Cloud Management System
• Accessed using a 4 to 8 digit Personal Identification Number (PIN) or SecurePIN dispatcher-issued
temporary access code
• Supports optional two-PIN or supervisor-required PIN entry
• Keypad backlight for day or night operation
• Night and Blackout mode light control
• Stores up to 5,000 user PIN codes
• Records up to 16,000 audit trail events
• Capable of automatically authenticating and connecting to configured networks
• Supports automated upload of transaction history
• Supports automated PIN and hardware updates
• Stores Knox FDC wrench (wrench not included)
• Two key retention LED alerts
• Communicates via Ethernet or WiFi
• Mounts securely with optional mounting brackets (60°, 90° and flat-mount)

1601 W. DEER VALLEY RD. PHOENIX, AZ 85027 | T. 800-552-5669 | TECHSUPPORT@KNOXBOX.COM | KNOXBOX.COM | PAGE 5
OPE-ESYSLR-0325-F
©Knox Company. All rights reserved.
KEYSECURE®5 & 6
ADMIN & USER GUIDE
INSTALLATION
Power and Connectivity Requirements
• Power: use only a 7-amp @ 12-VDC vehicle power supply or Knox KSM-200AC AC to DC power adapter
• IMPORTANT: Knox KeySecure devices are designed for use with shore power
• KeySecure 5 devices may be connected to power through the ignition switch; however the device will
not be capable of communicating or releasing a key when power is o
• KeySecure 6 must be constantly powered. THE KEYSECURE 6 CHARGES THE eKEY AND REQUIRES
USE OF A POWER SOURCE WHEN THE VEHICLE IGNITION IS OFF. FAILURE TO OBSERVE THIS
REQUIREMENT MAY RESULT IN A DEAD BATTERY FOR THE eKEY OR THE VEHICLE.
• Power Wiring: 18 AWG (min) Use the supplied MOLEX 44441-2002 pigtail. 14 AWG is recommended
along with use of an inline fuse close to the power source (not supplied)
• Communication: The devices may be configured to use WiFi or Ethernet for communication with
KnoxConnect Cloud
• A mini USB connector on the left side of KeySecure 6 allows configuration of WiFi and Ethernet via
a PC. A standard RJ45 ethernet cable should be used if the device will communicate through the
vehicle’s ethernet communication gateway
KeySecure 5 & 6 Operation
Upon shipment, KeySecures are assigned to the jurisdiction. Before use, the device must be configured in
KnoxConnect. The Knox Device Sync app is then used to pass the configurations to each device via USB.
Users may be given permissions to use some or all devices. Users access keys retained in the KeySecure
through entry of a valid PIN or SecurePIN temporary access code.
When a Key is released and removed, the notification LEDs will flash to provide indication that the key is no
longer retained in the device. The alert will continue until the key is returned.
NOTE: KeySecure 6 units shipping prior to June 2019 were set for the Knox eKey retention slot deactivated.
This function is selectable in KnoxConnect and can be reactivated by a device administrator.
Night/Blackout Mode: Users with Supervisor field capabilities may temporarily dim or turn o the
KeySecure keypad and LED lights. Light adjustments expire after 8 hours, returning the keypad and LEDs to
standard mode
Dual PIN Options: Devices can be set to require the entry of two valid PINs to release the keys. There are
two options:
• Dual PIN: Release key upon entry of any two valid PINs
• Dual PIN Supervisor: Requires two valid PINs; one of any type and one Supervisor PIN.
SecurePIN Option: Devices can be set to allow use of a temporary access code issued by a Dispatcher for
users who do not have PINs

1601 W. DEER VALLEY RD. PHOENIX, AZ 85027 | T. 800-552-5669 | TECHSUPPORT@KNOXBOX.COM | KNOXBOX.COM | PAGE 6
OPE-ESYSLR-0325-F
©Knox Company. All rights reserved.
KEYSECURE®5 & 6
ADMIN & USER GUIDE
The KeySecure 6 syncs with KnoxConnect at a maximum interval of 10 minutes while internet access is
available. If the interval has expired, or the unit is first powered up, the KeySecure 6 will sync immediately
when Internet access is available.
NOTE: Refer to the Networking User Guide for configuring WiFi and Ethernet connectivity.
USB on
Left Side
Ethernet
Power
NOTE: A mechanical Master Key may be returned to the key port while the device is powered down. The key
will be locked and retained in the device until power is restored and a valid PIN code is entered. The device
must be powered to secure or release the eKey.
KeySecure back and side views
NOTE: See battery and mounting installations instructions below:
• A coin-cell battery within the unit maintains the date and time for the audit trail

1601 W. DEER VALLEY RD. PHOENIX, AZ 85027 | T. 800-552-5669 | TECHSUPPORT@KNOXBOX.COM | KNOXBOX.COM | PAGE 7
OPE-ESYSLR-0325-F
©Knox Company. All rights reserved.
KEYSECURE®5 & 6
ADMIN & USER GUIDE
Battery and Mounting Installation
Before using the KeySecure, the battery must be installed. To access the battery compartment, the back
cover must be removed.
1. Always remove power from the KeySecure before attempting to replace the battery. Ensure the
vehicle is powered down and disconnect the device power cable.
2. Remove the technician access lock (tech-lock):
a. Locate tech-lock cover plate below the keypad
b. Using security screw wrench, remove two security screws from the tech-lock cover
c. Remove tech-lock cover plate
d. Insert tech-key into tech-lock and turn counter-clockwise until the lock is loosened and remove the lock
3. Using 5/32 Allen wrench, remove the socket cap bolts on either side of unit by turning
counter-clockwise.
4. Rotate bottom out, then lift unit up and o back cover.
NOTE: Unit should slide easily o the back cover. Do not force. Contact Knox Customer Technical
Support for assistance at 1-800-552-5669 x 3.
5. To install the battery (battery included with shipment):
a. Remove plastic circuit board cover
b. Locate the Battery socket in the upper right-hand corner of the circuit board
c. Slide battery, with positive (+) terminal facing the outer edge, into the battery socket
d. Replace circuit board cover
e. Install/reinstall on back cover
NOTE: When replacing the battery, use a 1/16” Allen wrench to move the battery down and out of the
battery socket. Install new battery as described above.
6. When mounting a KeySecure 6 with the mounting bracket:
a. Follow instructions included with the mounting bracket shipment
b. Do not place washers under hardware inside back cover - FAILURE TO OBSERVE THIS
REQUIREMENT MAY RESULT IN DAMAGE TO THE UNIT!
NOTE:To mount flat, use the KSM-FM to protect the circuit board and battery.
7. To re-install the KeySecure back cover:
a. Hook unit onto back plate and insert two (provided) #10-32 x 2” socket cap screws and
tighten to snug, being careful to avoid the coin cell battery when hooking unit onto back plate
b. Tighten tech-lock
c. Replace cover and tighten security screws
8. Attach antenna to male connector on top right side of unit.
9. Wire pigtail to power wire connected to vehicle power and ground (crimp-on butt connectors
and heat shrink included).
10. Plug pigtail connector and Ethernet cable (if applicable) into back of KeySecure device.

1601 W. DEER VALLEY RD. PHOENIX, AZ 85027 | T. 800-552-5669 | TECHSUPPORT@KNOXBOX.COM | KNOXBOX.COM | PAGE 8
OPE-ESYSLR-0325-F
©Knox Company. All rights reserved.
KEYSECURE®5 & 6
ADMIN & USER GUIDE
NOTE: Amber LED lights will flash five times to indicate the unit is powered. Keypad backlight
will illuminate and LED lights will indicate security status of the key(s).
16. Power must be ON and the Disable eKey Retention Right setting must be unchecked in the
KnoxConnect device configuration for the eKey charging port to lock and secure the Knox
eKey in the KeySecure 6.
If the power is ON and the eKey charging port is not active, check with your KnoxConnect software
administrator to verify that the device has been enabled before contacting Knox Technical Support

1601 W. DEER VALLEY RD. PHOENIX, AZ 85027 | T. 800-552-5669 | TECHSUPPORT@KNOXBOX.COM | KNOXBOX.COM | PAGE 9
OPE-ESYSLR-0325-F
©Knox Company. All rights reserved.
PROGRAMMING INSTRUCTIONS
Prior to initial use, the KeySecure must be configured with its network, device and user settings.
Requirements
• Set up will require:
• A computer/laptop with Windows 10
• USB to mini USB connector (Included with KeySecure)
• Access to KnoxConnect Software Management System
• Knox Device Sync App or KnoxConfig (depending on device)
Editing the KeySecure Device Configuration
1. Login to KnoxConnect:
• KnoxConnect Cloud: Log into the KnoxConnect™ Management System at knoxconnect.net
• KnoxConnect Local: With KnoxConnect Local installed on the Admin computer, select the KnoxConnect
WebServer icon located on the desktop to log into KnoxConnect Local
2. Select KeySecure from the navigation menu.
3. Select the Edit button next to the KeySecure serial number (SN) to view device status and configure the
following settings:
• Device location and asset number
• PIN attempts and lockout time
• Disable left/right key retention ports
• Network and connectivity settings (KnoxConnect Cloud)
NOTE: Refer to the “KeySecure Networking Guide” for configuring WiFi and ethernet connectivity.
4. Once settings are configured, select the Save button and then the Back button to return to the
KeySecure primary screen.
5. To assign user PINs to the KeySecure, select the User PINs Edit button for the device serial number,
select the Save button when done:
• KnoxConnect Cloud: Device settings and PIN assignments take eect when the device syncs via
ethernet or WiFi
• KnoxConnect Local: Device settings and PIN assignments take eect when the KeySecure is
connected to the Admin computer via USB cable
SecurePIN
• Knox SecurePIN is a feature of the KnoxConnect Management System that enables dispatchers to create
temporary access codes that are communicated to a user to release keys from Knox KeySecures.
• SecurePINs are single use access codes that are generated for a specific device, for users who do not
have a personal identification number in the (PIN) system. Each request is recorded in the system along
with details of the dispatch user and requester.
KEYSECURE®5 & 6
ADMIN & USER GUIDE

1601 W. DEER VALLEY RD. PHOENIX, AZ 85027 | T. 800-552-5669 | TECHSUPPORT@KNOXBOX.COM | KNOXBOX.COM | PAGE 10
OPE-ESYSLR-0325-F
©Knox Company. All rights reserved.
KEYSECURE®5 & 6
ADMIN & USER GUIDE
The device does not require a connection to KnoxConnect for a SecurePIN to be generated and used.
The feature can be used in conjunction with normal PIN use. For more information, see the SecurePIN Quick
Start Guide.
Dual PIN
• A primary or secondary administrator has the ability to enable the Dual-PIN feature for KeySecure units.
Dual-PIN requires users to enter 2 PINs to release a key on the KeySecure Units. Definitions of PIN features
are below, and the default setting is single PIN.
• Single PIN (Independent PIN) Only one PIN is required to release key for KeySecure units
• Dual PIN (Dependent PIN) Two PINs of any type are required to release the keys
• Supervisor PIN Supervisor PINs are non-dependent and do not require a second PIN.
Also used for changing keypad/display brightness on KeySecure
Light Management
The brightness of a KeySecure’s LEDs and keypad backlight can be adjusted to temporarily reduce
intensity when driving at night or supporting operations requiring no lights. PIN users with Supervisor field
capabilities assigned in KnoxConnect have permission to adjust settings.
Light Modes
• Standard: Default setting of keypad backlight and key retention LEDs
• Night: Reduces intensity of backlight and LEDs to 50%
• Blackout: Turns o all device lights
NOTE: If keys will be used while the unit is in Blackout Mode, Knox recommends removing prior to adjusting
settings as keypad feedback and indicator lights will not be available.
Adjust Light Settings Using Device Keypad:
1. Enter valid Supervisor PIN
2. Press the Knox button. The light mode toggles in the following order:
a. Press once for Night Mode
b. Press twice for Blackout Mode
c. Press three times to return to Standard Mode
TIP: Selection mode will time out after 5 seconds. The device will automatically revert to Standard Mode
after 8 hours.
Programming and Updating the KeySecure
To conduct initial configuration of the KeySecure, you must use the provided USB cable to connect the
KeySecure to a computer.
• A SecurePIN can be generated in advance or upon demand. SecurePINs are generated and used for
the specific device selected. It becomes inactive after it is used and will also deactivate any previously
generated SecurePINs generated for that device.

1601 W. DEER VALLEY RD. PHOENIX, AZ 85027 | T. 800-552-5669 | TECHSUPPORT@KNOXBOX.COM | KNOXBOX.COM | PAGE 11
OPE-ESYSLR-0325-F
©Knox Company. All rights reserved.
KEYSECURE®5 & 6
ADMIN & USER GUIDE
NOTE: The mini USB connection is on the top left side of the KeySecure:
• KnoxConnect Cloud: Download Device Sync App from KnoxConnect and follow prompts to update
the KeySecure
NOTE: Refer to the “KeySecure Networking Guide” for KeySecure programming instructions:
• KnoxConnect Local: Download Device Sync App or KnoxConfig App from KnoxConnect and follow
prompts to update the KeySecure
NOTE: Refer to the Knox Networking Guide for detailed communications setup instructions.
Resetting the KeySecure Device
• To reset the KeySecure, press and hold the arrow (return) key for 10 seconds. Release after LEDs and
keypad backlight turn o.
Syncing the KeySecure Device
After initial configuration, most PIN, configuration and firmware updates will require the following:
• KnoxConnect Cloud: A KeySecure device must have access to the internet via WiFi or ethernet via a
wireless hub in order to receive updates:
• The KeySecure device syncs with KnoxConnect Cloud at a maximum interval of 10 minutes while
internet access is available
• If the interval has expired or the unit is first powered up the KeySecure device will sync immediately
when internet access is available
• KnoxConnect Local: A computer/laptop with Windows is required along with a USB to mini USB
connector (Included with KeySecure) in order to update the KeySecure:
• Syncing is conducted by physically connecting the Admin computer (PC/laptop) with KnoxConnect
Local via USB cable to the KeySecure 5

1601 W. DEER VALLEY RD. PHOENIX, AZ 85027 | T. 800-552-5669 | TECHSUPPORT@KNOXBOX.COM | KNOXBOX.COM | PAGE 12
OPE-ESYSLR-0325-F
©Knox Company. All rights reserved.
KEYSECURE®5 & 6
ADMIN & USER GUIDE
KEYSECURE® 6 USER INSTRUCTIONS
The Knox eKey can be charged and programmed via the KeySecure 6. When the Knox eKey is retained, the
KeySecure will not display any LED lights. The Knox eKey, however, will slowly flash green while charging.
Refer to the Knox eKey User Guide for information on the color status of the LEDs.
Remove and Return the Electronic Knox eKey
1. Enter a valid PIN, SecurePIN or two valid PINs if Dual PIN is enabled on the keypad. PIN entry should be
followed by pressing the arrow (Return) key to complete the PIN entry:
• The Keypad numbers will dim upon each key press and illuminate upon each keypad release
• Single PIN: If a correct PIN is entered and only a single PIN is required, both amber LED lights will
illuminate and the device will begin the key release process
• Dual PIN: If a correct PIN is entered both amber LED lights will fast flash. The second user will have 15
seconds to enter their PIN:
• Flashing will discontinue upon the first keypress or the 15 second time out
• When the correct second PIN is entered, both amber LED lights will illuminate and the device will begin
the key release process
• If an incorrect PIN is entered, both amber LED lights will double flash. Repeat step 1 using a correct PIN
• Key release process:
• The master key and eKey retainer will become physically unlocked (this may take several seconds -
DO NOT attempt to remove the eKey or key during this time). The LED lights will then stay lit for an
additional 5 seconds allowing the key or eKey to be removed.
2. To remove the key from the KeySecure device:
• eKey: Flip down the retention latch and remove it from the KeySecure
NOTE: The amber LED light above the electronic key will flash, indicating the key is unsecured.
• Mechanical key: Turn the master key clockwise (right) and remove it from the KeySecure.
NOTE: The amber LED light above the key will flash, indicating the key is unsecured
NOTE: The key and eKey remain in a released position for five (5) seconds. If they are not removed within
the specified release time they will be relocked. To release, repeat step 1.
3. Return the key to the KeySecure device:
• eKey: Insert the eKey and push the retention latch up to activate the retention motor. The LED on the
KeySecure will display light solid red while the retention latch locks the eKey securely and verifies it, the
LED light will then turn o.
• Mechanical key: Insert the master key and turn counterclockwise (left) to lock it into the retention port.
The LED light on the KeySecure will stop flashing.

1601 W. DEER VALLEY RD. PHOENIX, AZ 85027 | T. 800-552-5669 | TECHSUPPORT@KNOXBOX.COM | KNOXBOX.COM | PAGE 13
OPE-ESYSLR-0325-F
©Knox Company. All rights reserved.
KEYSECURE®5 & 6
ADMIN & USER GUIDE
KEYSECURE® 5 USER INSTRUCTIONS
Remove and Return Mechanical Knox Master Key
1. Enter a valid PIN, SecurePIN or two valid PINs if Dual PIN is enabled on the keypad. PIN entry should be
followed by pressing the arrow (Return) key to complete the PIN entry:
• The Keypad numbers will dim upon each key press and illuminate upon each keypad release
• Single PIN: If a correct PIN is entered and only a single PIN is required, both amber LED lights will
illuminate and the device will begin the key release process
• Dual PIN: If a correct PIN is entered both amber LED lights will fast flash. The second user will have 15
seconds to enter their PIN:
• Flashing will discontinue upon the first keypress or the 15 second time out
• When the correct second PIN is entered, both amber LED lights will illuminate and the device will begin
the key release process
• If an incorrect PIN is entered, both amber LED lights will double flash. Repeat step 1 using a correct PIN
• Key release process:
• The master key retainer will become physically unlocked (this may take several seconds - DO NOT
attempt to remove the eKey or key during this time). The LED lights above the key will then stay lit for
an additional 5 seconds while the key is able to be removed, if not removed, the key will be relocked.
2. To remove the key: After the device has completed its key release process, remove the master key by
turning it clockwise (right) and remove:
NOTE: The LED light, located above the key, will flash, indicating the key has been removed or not in a
locked position.
NOTE: The key remains in a released position for five (5) seconds. If the key is not removed within the
specified release time, repeat the PIN entry process
3. To return the key: Insert the key and turn it counterclockwise (left) to its original position. This will
capture the key and lock the key retention unit. The LED light above the returned key turns o
when fully locked.

1601 W. DEER VALLEY RD. PHOENIX, AZ 85027 | T. 800-552-5669 | TECHSUPPORT@KNOXBOX.COM | KNOXBOX.COM | PAGE 14
OPE-ESYSLR-0325-F
©Knox Company. All rights reserved.
KEYSECURE®5 & 6
ADMIN & USER GUIDE
KEYSECURE® LED LIGHT STATUS
The KeySecure 5 and 6 LEDs provide information about the current status of the unit. The left LED serves
the mechanical key (if available). The right LED serves the electronic key. Both LEDs and keypad backlight
indicate current PIN status.
CONDITION LED AND BACKLIGHT INDICATION ACTION
eKey in, retention latch closed Charging, programmable, no amber LED None
eKey out, retention latch open Amber LED flashes above eKey port Return eKey and close retention latch
eKey retention latch open/will not close No amber LED flashes above eKey port Enable eKey port in KnoxConnect and
sync KeySecure
eKey in, PIN entered, retention latch closed Amber LED on, and latch unlocks for
approximately 5 seconds, then amber
LED goes out and the latch locks
Flip retention latch down within 5
seconds; otherwise, re-enter PIN and
start over
Mechanical key in, retained No amber LED None
Mechanical key out, not retained Amber LED flashes above mechanical
key port
Replace key and turn
counterclockwise to lock
Mechanical key out, not retained No amber LED flashes above
mechanical port
Enable mechanical port in
KnoxConnect and sync KeySecure
Mechanical key in locked position, PIN
entered
Amber LED is on, and key unlocks for
approximately 5 seconds, then amber
light goes out and key locks
Remove key within 5 seconds;
otherwise, re-enter PIN and start over
DC Power On Keypad backlight is on, indicates fully
functionality status None
PIN entry Keypad backlight flashes for every
numeric key
Enter PIN and press arrow (Return)
key
PIN good Both amber LEDs are on for
approximately 5 seconds Remove eKey or Mechanical key
PIN bad Both amber LEDs double flash
simultaneously Re-enter valid PIN
eKey in and retention latch is open Amber LED flashes continuously, Knox
eKey not charging Close retention latch
eKey missing and the retention latch is
closed
Amber LED continues to flash above
eKey retention port Replace eKey and close latch
KeySecure device is not syncing regularly
with KnoxConnect
Ensure that KeySecure is successfully
connecting to your network
Lockout Continuous flash of keypad backlight KeySecure is locked out due to
excessive invalid PIN attempts
eKey from wrong jurisdiction or
nonresponsive and retention latch is
closed
Amber LED fast flashes above secured
eKey
Error code saved in the audit trail -
release and replace with correct eKey
and close latch
No lights but able to release key with valid
PIN entry Blackout Mode Enter Supervisor PIN and press Knox
button to toggle to standard or Night
Mode setting
Keypad lights are too dim Night Mode Enter Supervisor PIN and press Knox
button to toggle to standard setting
Other manuals for KeySecure 5
1
This manual suits for next models
1
Table of contents
Other Knox Lock manuals
Popular Lock manuals by other brands

D&D Technologies
D&D Technologies Lokk-Latch quick start guide

Eaton
Eaton IZMY Series Instruction leaflet

Schlage
Schlage Sentronic LCN 4040-SE instruction sheet

Fenner Drives
Fenner Drives B-LOC B106 Installation & Removal Instructions

Cansec
Cansec VIA installation manual

Sargent and Greenleaf
Sargent and Greenleaf 6128-240 A Series Programming and operations guide
