axing HoE 1-00 User manual

HoE 1-00
HDMI over Ethernet
Operation Instructions

Operation Instructions | HoE 1-00 | HDMI over Ethernet
2 2015-01-01 | © AXING AG | Swizzerland | Technical data are subject to change, errors and omissions excepted
Contents
1.Product description ....................................................................................................................................... 4
1.1.Disposal of wastes................................................................................................................................ 4
1.2.Scope of delivery................................................................................................................................... 4
1.3.Product description............................................................................................................................... 5
1.4.HDMI distribution system via Ethernet ................................................................................................. 5
2.Installation.................................................................................................................................................... 6
3.Network configuration.................................................................................................................................. 7
3.1.One HDMI source.................................................................................................................................. 7
3.2.Configuration of the IP address ............................................................................................................ 7
3.3.Several HDMI sources ........................................................................................................................... 8
3.4.Firmware Upgrade................................................................................................................................ 8
4.Troubleshooting............................................................................................................................................ 9
5.Technical data............................................................................................................................................. 10

2015-01-01 | © AXING AG | Swizzerland | Technical data are subject to change, errors and omissions excepted 3
Safety instructions
Do NOT use the device near water or in rooms with high humidity such as humid cellars or near swimming
pools.
Do NOT use the device outdoors. All connections must be located inside a building.
Keep the device away from moisture, dust or corrosive liquids.
Do NOT install the device, use it or perform maintenance during a thunderstorm. There is a risk of electric
shock during thunderstorm.
Connect ONLY appropriate accessories to the device.
Make sure that all cables are connected to the correct port.
Carefully lay the Ethernet, antenna and electric cables to ensure that nobody can step on or stumble over
them.
Do NOT cover the ventilation slots of the device since insufficient air supply may result in damage to the
device.
Do NOT place any objects on the device. Position the device in a place where NOBODY can step on it.
Prior to maintenance or dismounting work, disconnect the Ethernet and electric cable from the device.
In case of damage, interrupt the power supply.
Do NOT try to repair the device. Contact your local retailer to order a new device.
Do NOT open the device or unit. Opening the device or removing its covers causes risks, for example due
to high voltage. This device should ONLY be repaired or uninstalled by qualified service personnel. For
more information, contact your retailer.

Operation Instructions | HoE 1-00 | HDMI over Ethernet
4 2015-01-01 | © AXING AG | Swizzerland | Technical data are subject to change, errors and omissions excepted
1. Product description
1.1. Disposal of wastes
Your device is marked with the WEEE symbol (Waste Electronics and Electrical Equipment).
This means that the electrical and electronic components must not be disposed of as
residual waste. Used electrical and electronic components must be disposed of separately.
1.2. Scope of delivery
HoE 1-01
1 HoE 1-01 HDMI over Ethernet receiver
1 Power supply unit
1 IR receiver (adapter cable with red plug)
1 Operating manual
HoE 1-02
1 HoE 1-02 HDMI over Ethernet transmitter
1 Power supply unit
1 IR transmitter (adapter cable with black plug)
1 Operating manual
HoE 1-00
1 HoE 1-01 HDMI over Ethernet receiver
1 HoE 1-02 HDMI over Ethernet transmitter
2 Power supply units
1 IR transmitter
1 IR receiver
2 Operating manuals

2015-01-01 | © AXING AG | Swizzerland | Technical data are subject to change, errors and omissions excepted 5
1.3. Product description
The HDMI over Ethernet distribution system HoE 1-00 allows you to distribute the HDMI signals up to 1080p
via an Ethernet network. A HoE 1-02 transmitter can service up to 127 HoE 1-01 receivers.
The HoE system is used in applications where digital signals have to be distributed for public displays,
demonstration and video presentations. This distribution system puts your presentation system to a higher
level.
The HoE 1-02 transmitter converts the HDMI signal into a broadcast signal. This broadcast signal is distributed
by an Ethernet management switch. Use of network switches with management functions and support of the
broadcast protocols is mandatory. Due to the bandwidth requirements, these video broadcasts should always
be performed in a separate closed VLAN network.
1.4. HDMI distribution system via Ethernet
Cascading with network switches over 3 levels
HDMI compatible with HDCP, supports 480i to 1080p60@8 bit, 3D not supported
Supports the feedback channel for IR remote control signals (IR 940 nm, 38 kHz)

Operation Instructions | HoE 1-00 | HDMI over Ethernet
6 2015-01-01 | © AXING AG | Swizzerland | Technical data are subject to change, errors and omissions excepted
2. Installation
Switch off all devices before installation.
1. Use a HDMI cable to connect the output of the HDMI source (Blu-ray player, Media Player etc.) to the HDMI
input (4) of the transmitter HoE 1-02.
2. Connect the IR connection cable with the black plug to the IR connection (3) of the transmitter.
3. Attach the IR transmitter before the IR receiver of the HDMI source. Use the double-sided adhesive tape of
the IR transmitted.
4. Use a HDMI cable to connect the HDMI output (4) of the receiver to the HDMI input of the HDTV television
sets.
5. Connect the IR connection cable with the red plug to the IR connection (3) of the receiver (optional).
6. Connect the Ethernet connections of the HoE 1-01 receiver and HoE 1-02 transmitter to the Ethernet switch.
7. Connect the plug-in power supply unit to the transmitter and receiver and switch on all devices.
Configure your Ethernet management switch in such a way that functionally connected transmitters and
receivers work in a separate closed VLAN respectively.
1. DC connection
2. Reset
3. IR TX/IR RX
4. HDMI port
5. Data traffic status
6. Power LED
7. Ethernet RJ 45 port
7
1
2
3
5
6
4
4

2015-01-01 | © AXING AG | Swizzerland | Technical data are subject to change, errors and omissions excepted 7
3. Network configuration
3.1. One HDMI source
Network configuration of transmitter and receiver for a HDMI source for max. 127 receivers. This
configuration is mandatory!
The HoE 1-0x are configured using the web browser. The factory IP address of the HoE 1-02 transmitter is
192.168.168.55 and the IP address of the HoE 1-01 receiver is 192.168.168.56. (after a factory reset the
device is again set to the IP addresses mentioned above). Every HoE 1-01 receiver requires a suitable IP
address, for example IP:192.168.168.XX (1-254), subnet mask 255.255.255.0.
3.2. Configuration of the IP address
1. Change the IP address of the PC / laptop, for example to 192.168.168.11:
Control panel > Network connections > LAN connection >Properties >
Internet protocol version 4 TCP/IPv4 > Properties > Use the following IP address:
Press OK to save.
2. Switch on the HoE 1-0x to be configured, the Power LED lights up red
and the Status LED lights up green after approx. 10 seconds.
If you do not know the set IP address, reset the IP address to the factory setting. Press the Reset key, for
example by means of a paper clip, for approx. 5-10 seconds, until the green Status LED goes out.
3. Connect the HoE 1-0x using a LAN patch cable to the PC / laptop. The Status LED is flashing green.
4. Now enter the IP address (transmitter) 192.168.168.55 in the web browser Internet Explorer. For the
receiver the IP address is 192.168.168.56.
A Welcome menu window is displayed.
5. The IP address and the subnet mask can be changed in the System menu. Press the Apply button to confirm
the change, the green Status LED goes out. Step 4 is repeated for each receiver with its own IP address.
6. Note down the new IP address on the enclosed "IP address" sticker and glue the sticker onto the mounting
bracket.
7. To check if the HoE 1-0x can be reached correctly, you can enter the new IP addresses in the web browser, a
menu window should be displayed.

Operation Instructions | HoE 1-00 | HDMI over Ethernet
8 2015-01-01 | © AXING AG | Swizzerland | Technical data are subject to change, errors and omissions excepted
8. Switch off the HoE 1-0x and unplug the patch cable.
Note that the IP address is reset to the factory IP address after a reset.
3.3. Several HDMI sources
Network configuration of transmitters and receivers for several HDMI sources. This
configuration is mandatory!
If several HDMI sources are to be distributed to different receiving networks, then the Ethernet Management
switch must be configured in such a way that the transmitter and receiver of one source work in a separate
closed VLAN network respectively.
3.4. Firmware Upgrade
A firmware upgrade is performed in the Advanced Tools menu. For current firmware go to www.axing.com and
then click Download | Software/Firmware:

2015-01-01 | © AXING AG | Swizzerland | Technical data are subject to change, errors and omissions excepted 9
4. Troubleshooting
Check whether all Power LEDs are lit and replace the power supply unit, if necessary.
Check if all cable connections are fitted tightly.
Check whether the HoE 1-0x devices can be accessed with the set IP address via the web browser.
If you do not use a VLAN separated network, overloads and failures may occur in the network. If this is the
case, have your network configured by an experienced network technician.
If you cannot locate the problem and a network problem is present, contact an experienced network
technician.

Operation Instructions | HoE 1-00 | HDMI over Ethernet
10 2015-01-01 | © AXING AG | Swizzerland | Technical data are subject to change, errors and omissions excepted
5. Technical data
Input video signal 0.5-1.0 Vpp
Input DDC signal 5 Vpp (TTL)
Video format (DTV/HDTV) 480i/576i/480P/576P/720P/1080i/1080P
Video output HDMI, HDCP1.2
Maximum transmission range
with 1080P 8-bit
120 m (CAT5E/6 /24AWG/Solid)
IR frequency 38 kHz
Transmission rang of the IR receiver
(HoE 1-01)
7 m
Operating voltage 5 VDC
Maximum power consumption 3 W
Operating temperature -5 - +35°C
Air humidity range 5 - 90% RH
Dimensions (W×H×D) 104 x 94 x 25 mm
Weight (transmitter/receiver) 220g
