Volt/Ma Calibrator
AX-C800
OPERATION MANUAL

2
Safety Infor ation
To avoid possible electric shock or personal injury:
•Never apply more than 30V between any two jacks, or between any jack
and earth ground.
•ake sure the battery door is closed and latched before you operate the calibrator.
•Remove test leads from the calibrator before you open the battery door.
•Do not operate calibrator if it is damaged.
•Do not operate the calibrator around explosive gas, vapor or dust.
To avoid possible damage the calibrator:
•ake sure choose the right jack and rang, before use the calibrator to measurement or calibrator.
•Take away the calibrator from the used circumstance, before operate the calibrator or after
closed calibrator.
Introduction
Volt/mA Calibrator is a source and measurement tool. This Calibrator is use to measure or output
0 to 24 mA DC current loop, and 0 to 15 DC voltage. But the calibrator cannot be used to
measurement and source simultaneously.
Volt/mA Calibrator include this accessories: Holster, a pair of Test Leads, AAA*6 battery, and this
manual.
If the calibrator is broken or short of some accessories, please contact the supplier. Please contact
the distributor about other accessory’s information.
The following table has showed the technical parameter and function of the Calibrator.
Measure ent and output voltage para eter
Function Range Resolution
DC V mV Input Auto range 0 ~ 110 mV 0,01 mV
0 ~ 15 V 0,001 V
DC V mV Output manual range 0 ~ 100 mV 0,01 mV
0 ~ 15 V 0,001 V
Loop Power Output 24 V DC N/A
Measure ent and output A para eter
Function Range Resolution
DC mA Input 0 ~ 24 mA 0,001 mA
DC mA Output 0 ~ 24 mA 0,001 mA

3
Specification
Specification are based on a one year calibration cycle and apply from +18°C to + 28°C unless states
otherwise. “Counts” means number of increments or decrements of the least significant digit.
DC V Input and Output.
Range Resolution Accuracy ±(% of Reading + Counts)
100 mV 0,01 mV 0,02% + 3
15 V 0,001 V 0,02% + 3
Input impedence 2 Ω (nominal) < 100pF
Over voltage protection 30 V
Voltage driver capability 1mA
DC A Input and Output
Range Resolution Accuracy ±(% reading + counts)
24 mA 0,001 mA 0,015% + 3
Overload protection 250V Fast acting fuse
Percent display 0% = 4 mA, 100% = 20 mA
Source mode Compliance 1000Ω at 20mA
for battery voltage ≥6.8V
(700 Ω at 20mA for battery voltage 5.8 to 6.8V)
Simulate mode External loop voltage requirement: 24V
nominal, 30V maximum, 12V minimum
Loop power
24 V ± 10%
General specifications
aximum voltage applied between any jack and earth ground or between any tow jack: 30V
Storage temperature: -40°C~60°C
Operating temperature: -10°C~55°C
Operating altitude: 3000 meters maximum
Temperature coefficient: ±0.005% of range per °C for the temperature range -10°C
to 18°C and 28°C to 55°C.
Relative humidity: 95% up to 30°C, 75% up to 40°C, 45% up to 50°C,

4
35% up to 55°C
Shock: Random 2g, 5 Hz to 500Hz
Safety: 1 meter drop test
Power requirements: AAA*6
Size: 204mmL x 99mmW x 46mmH
Weight: 460g (include battery)
International Sy bols
Sy bol Meaning
Earth ground
Conform to European Union directives
Refer to his instruction sheet for information abort his feature
Explanation on Front Panel
The front panel is show as in right figure:
1. Loop power 24V to ground
2. mA measurement input jack
3. Input or output negative( ground) jack
4. V, mV input or output jack
5. Power switch
6. V mV conversion key
7. mA mA% conversion key
8. Input/Output conversion key

5
9. Increase more value key
10. Reduce more value key
11. Increase less value key
12. Reduce less value key
13. Low power indication
14. Input state indication
15. Output state indication
16. Result value
17. Voltage V mV indication
18. Current mA mA% indication
Operation Instructions
DC V easure ent
1
Press the power switch
5
, turn on the Calibrator
2
Press the input/output conversion key , when the state of no input indicator. ake it under
the state of measurement.
3
Press the V V conversion key
6
, make it indicate mVDC
17
.
4
Put the red test lead in V jack
4
, black one to the CO jack
3
5
Connect the red test lead with the positive of voltage which is waiting for measurement,
black one to the negative(ground)
6
The value of result show
16
*The number In the , refering to the Explanation on Front Panel (Page 5)
DC V output
1
Press the Power switch
5
, turn on the Calibrator.
2
Press the input/output conversion key
8
, when the state of no output indicator
15
.
ake it under the state of output.
3
Press the V mV conversion key
6
,make it indicate VDC or mVDC
17
, at the range of output
you need.

6
4
Press the value adjust key
9
,
10
,
11
,
12
make the value you want.
5
Put the red test lead in V jack
4
, black one to the CO Jack
3
6
Connect the red test lead with the positive of voltage which is waiting for measurement,
black one to the negative(ground).
7
If you want to change the output value or range, then press the value adjust key
9
,
10
,
11
,
12
or the V mV conversion key
6
.
DC A easure ent
Outside supply power measurement
1
Press the Power switch
5
turn on the Calibrator.
2
Press the input/output conversion key
8
, when the state of no input indicator
14
.
ake it under the state of measurement.
3
Press the mA mA% conversion key
7
, make it indicate mA or mA%
18
, at the state of
measure you Reed.
4
Put the red test lead In mA Jack
2
, black one to the CO jack
3
5
Connect the red test lead with the positive of current which is waiting for measurement,
black one to the negative (ground)
6
The value of result show
16

7
Calibrator supply Loop power easure ent
1
Press the power switch
5
, turn on the Calibrator
2
Press the input/output conversion key
8
, when the state of no input indicator
14
.
ake it under the state of measurement.
3
Press the mA mA%
18
, at the state of measure you need.
4
Put the red test lead in LOOP jack
1
, black one to the mA jack
2
5
Connect the red test lead with the in of current which is waiting for measurement, black one to
the out of current.
6
The value of result show
16

8
DC A output
Sourcing mA
1
Press the power switch
5
, turn on the Calibrator.
2
Press the input/output conversion key
8
, when the state of no output indicator
15
.
ake it under the state of output.
3
Press the mA mA% conversion key
7
, make it indicate mA or mA%
18
, at the state of output
you need.
4
Press the value adjust key
9
,
10
,
11
,
12
, make the value on you want.
5
Put the red test lead in LOOP Jack
1
, black one to the V Jack
4
.
6
Connect the red lead with the positive of current which is waiting for output, black one to the
negative.
7
If you want to change the output value or state then press the value adjust key
9
,
10
,
11
,
12
or the mA mA% conversion key
7
.
Si ulating a Trans itter
1
Press the power switch
5
, turn on the Calibrator.
2
Press the input/output conversion key
8
, when the state of no output indicator
15
.
ake it under the state of output.
3
Press the mA mA% conversion key
7
, make it indicate mA or mA%
18
, at the state of output
you need.
4
Press the value adjust key
9
,
10
,
11
,
12
, make the value you want.
5
Put the red test lead in V jack
4
, black one to the CO jack
3

9
6
Connect the red test lead with the positive of power which is outside, black one to the negative
of current which is waiting test.
7
If you want to change the output value or state, then press the value adjust key
9
,
10
,
11
,
12
or the mA mA% conversion key
7
.
Maintenance
Cleaning:
Periodically wipe the case with a damp cloth and detergent; do not use abrasives or solvents.
Calibration:
Calibrate your calibrator once a year to ensure that it performs according to its specifications.
Replacing the Battery
Please change the battery when the LCD indicates .
Turn if the power of the Calibrator, when you change the battery, and screw off the breechblock on
the battery cabinet cover, then take off it and instead the fresh battery.
Replacing a Fuse
Warning!
To avoid personal injury or da age to the calibrator, use only a 0.125A 250V Fast fuse.
Fuse 1 is probably blown if:
In the V output mode, with the test leads removed from the calibrator, the display flashes OL.
Fuse 2: is probably blown if:
In the mA mode, the calibrator always reads 0.000, even with a signal applied.
