AXIOMTEK IRU152-I User manual

IRU152-I
Software Development
Kit
Reference Manual

ii
Revision History
Version
Revised
Date
Author
Description
1.0
2018/12/05
Young
- 1st release

iii
How to Use This Document
This document is written to provide the information of the SDK and helps users
implement their own applications
Chapter 1, “Basic Structure” introduces the fundamental information for applying
the functions in this document.
Chapter 2, “Function Description” introduces the detailed information of the
functions provided by the SDK.
Appendix A, “Error Code”describes the meaning of the error code returned by
the functions.
Appendix B, “Function Table”shows all IRU152 function.

iv
Table of Contents
Revision History............................................................................................ii
How to Use This Document ........................................................................iii
CHAPTER 1 Introduction...........................................................1
1.1 The Basic of the Programming.................................................1
1.2 Create a Receiver Data Example ..............................................3
1.3 The Calibration Flow Chart .......................................................5
CHAPTER 2 Function Description ............................................7
2.1 Open_Device ..............................................................................7
2.2 CloseDevice................................................................................8
2.3 GetDevInfoEx..............................................................................9
2.4 EnAIReceiver............................................................................10
2.5 DisAIReceiver...........................................................................11
2.6 ReadAIDataEx...........................................................................12
2.7 ReadAIVoltEx............................................................................13
2.8 SetAITrigConfEx.......................................................................15
2.9 SetAIChannel............................................................................16
2.10 SetAISampleRate .....................................................................17
2.11 SetAInputRange .......................................................................18
2.12 FactoryCalibratedRestore .......................................................19
2.13 ReadCaliFactors.......................................................................20
2.14 GetAISingleValueEx.................................................................21
2.15 GetAIinitConfEx........................................................................23
2.16 SetAIinitConf ............................................................................24
2.17 AICalibrationEx ........................................................................25
2.18 RestoreAIConf..........................................................................27
2.19 GetAIDataLength......................................................................28
2.20 GetDITrigConfEx ......................................................................29
2.21 ClearDITrigConf........................................................................30
2.22 SetDITrigConf...........................................................................31
2.23 GetDILevelEx............................................................................32
2.24 EnDIReceiver............................................................................33
2.25 DisDIReceiver...........................................................................34
2.26 EnDICounterEx.........................................................................35
2.27 DisDICounterEx........................................................................36
2.28 GetDICounterEx .......................................................................37
2.29 SetDICounterCompletedCallback...........................................38
2.30 SetDIStatusChangedCallback.................................................39
2.31 GetDOInitConfEx......................................................................40

v
2.32 ClearDOInitConf .......................................................................41
2.33 SetDOInitConf...........................................................................42
2.34 SetDOStatus.............................................................................43
2.35 GetDOStatus.............................................................................44
2.36 EnDOPWM ................................................................................45
2.37 DisDOPWM ...............................................................................46
2.38 GetDOPWMConf.......................................................................47
APPENDIX A Error Code..........................................................49

vi
This page is intentionally left blank.

IRU152-I Programmer Guidel
Introduction 1
CHAPTER 1
Introduction
This chapter introduces the information of the SDK.
1.1 The Basic of the Programming
To create an application with SDK, please follow the steps below.
Step 1 : Include IRU head file.
When user program a IRU application to call IRU API, user has to include "libiru.h"
and "axiomtek_err.h" files.
"libiru.h" files is for API and control IRU device.
and "axiomtek_err.h" files. Is error code respectively.
It can help user to analyze what problem is.
#include "libiru.h"
#include "axiomtek_err.h"
Step 2 : Create a device
int ret;
ret = Open_Device("IRU152");
if(ret != AXIO_OK)
printf("Create Device Failure\n");
(Continue)

IRU152-I Programmer Guidel
2 Introduction
Step 3 : Get information from device via API
int i=0;
char *pDevInfo;
short length;
(Continue)
int modelidx = 1;
ret = GetDevInfo(modelidx, &pDevInfo, &length);
if(ret == AXIO_OK){
for(i=0;i<length;i++)
printf("%c", toascii( *(pDevInfo +i)));
printf("\n");
} else
printf("Get Device info failure\n");
Step 4 : Close a device.
Close_Device();
Step 5 : The application can be closed

IRU152-I Programmer Guidel
Introduction 3
1.2 Create a Receiver Data Example
This example shows how to receive DI data. The sample is for a digital I/O receiver.
#define AXIO_OK 0x00
int channel = 1;
int filter = 0
int trig = 2;
int stop;
int ret;
ret = Open_Device("IRU152");
if(ret != AXIO_OK){
printf("open IRU152 failure …\n");
return;
}
while(1)
{
switch(stop){
case 0:
ret = EnDIReceiver(channel, filter, trig);
if(ret != AXIO_OK)
printf("Enable DI Receiver failure \n");
break;
case 1:
ret = DisDIReceiver(channel);
if(ret != AXIO_OK)
printf("Enable DI Receiver failure \n");
break;
case 2:
printf("Exit \n");
break;
}

IRU152-I Programmer Guidel
4 Introduction
if(stop == 2){
break;
}
}
Close_Device();
