AXIOMTEK MANO540 Series User manual

MANO540 Series
Intel®Socket 1200 CoreTM i9/ i7/ i5/ i3
Processors Mini ITX Motherboard
User’s Manual

ii
Disclaimers
This manual has been carefully checked and believed to contain accurate information.
Axiomtek Co., Ltd. assumes no responsibility for any infringements of patents or any third
party’s rights, and any liability arising from such use.
Axiomtek does not warrant or assume any legal liability or responsibility for the accuracy,
completeness or usefulness of any information in this document. Axiomtek does not make any
commitment to update the information in this manual.
Axiomtek reserves the right to change or revise this document and/or product at any time
without notice.
No part of this document may be reproduced, stored in a retrieval system, or transmitted, in
any form or by any means, electronic, mechanical, photocopying, recording, or otherwise,
without the prior written permission of Axiomtek Co., Ltd.
CAUTION
If you replace wrong batteries, it causes the danger of explosion. It is recommended by the
manufacturer that you follow the manufacturer’s instructions to only replace the same or
equivalent type of battery, and dispose of used ones.
©Copyright 2021 Axiomtek Co., Ltd.
All Rights Reserved
June 2021, Version A1
Printed in Taiwan

iii
ESD Precautions
Computer boards have integrated circuits sensitive to static electricity. To prevent chipsets
from electrostatic discharge damage, please take care of the following jobs with precautions:
◼Do not remove boards or integrated circuits from their anti-static packaging until you are
ready to install them.
◼Before holding the board or integrated circuit, touch an unpainted portion of the system
unit chassis for a few seconds. It discharges static electricity from your body.
◼Wear a wrist-grounding strap, available from most electronic component stores, when
handling boards and components.
Trademarks Acknowledgments
Axiomtek is a trademark of Axiomtek Co., Ltd.
Intel®and Celeron®are trademarks of Intel Corporation.
Windows®is a trademark of Microsoft Corporation.
AMI is a trademark of American Megatrend Inc.
IBM, PC/AT, PS/2, VGA are trademarks of International Business Machines Corporation.
Other brand names and trademarks are the properties and registered brands of their
respective owners.

iv
Table of Contents
Disclaimers ......................................................................................................ii
ESD Precautions............................................................................................. iii
Section 1 Introduction............................................. 1
1.1 Features ................................................................................................1
1.2 Specifications ........................................................................................2
1.3 Utilities Supported .................................................................................3
1.4 Block Diagram.......................................................................................4
Section 2 Hardware Installation ............................. 5
2.1 Install Central Processing Unit (CPU) ...................................................5
2.2 Install a Heatsink...................................................................................7
2.3 Installing Memory Module .....................................................................8
2.4 Expansion Slots ....................................................................................9
Section 3 Board and Pin Assignments.................. 11
3.1 Board Layout.......................................................................................11
3.2 Rear I/O...............................................................................................13
3.3 Jumper Settings ..................................................................................14
3.3.1 AT/ATX Power Mode Select (JP2) ............................................................ 15
3.3.2 Clear CMOS (JP3) .................................................................................... 15
3.3.3 LVDS VDD Select (JP4) ............................................................................ 16
3.3.4 COM1 Data/Power Select (JP6) ............................................................... 16
3.4 Connectors..........................................................................................17
3.4.1 COM D-Sub Connector (CN1) .................................................................. 18
3.4.2 COM Headers (CN3~CN6) ....................................................................... 18
3.4.3 SATA 3.0 Connectors (CN7 and CN8) ...................................................... 19
3.4.4 USB 3.2 GEN1 Stack Port (CN10)............................................................ 19
3.4.5 LAN and USB 2.0 Connectors (CN11 and CN19)..................................... 20
3.4.6 PCI-Express Mini Card Connector (CN21) ............................................... 21
3.4.7 M.2 Key E Socket (CN22) ......................................................................... 22
3.4.8 Audio Jack (CN23) .................................................................................... 23
3.4.9 Digital I/O Connector (CN26) .................................................................... 23
3.4.10 ATX Power Input Connectors (CN30 and CN70) ...................................... 24
3.4.11 DisplayPort Connector (CN32).................................................................. 25
3.4.12 HDMI Connector (CN33) ........................................................................... 25
3.4.13 VGA Connector (CN34)............................................................................. 26
3.4.14 eDP Connector (CN50) ............................................................................. 26
3.4.15 Fan Headers (CN60 and CN61)................................................................ 27

v
3.4.16 USB Header (CN62) ................................................................................. 27
3.4.17 Front Panel Header (CN80) ...................................................................... 28
3.4.18 SPI Header (CN81) ................................................................................... 29
3.4.19 M.2 Key B Socket (SCN1) ...................................................................... 30
3.4.20 SIM Card Slot (SCN2) ............................................................................... 31
Section 4 AMI BIOS Setup Utility .......................... 33
4.1 Starting................................................................................................33
4.2 Navigation Keys ..................................................................................33
4.3 Main Menu ..........................................................................................35
4.4 Advanced Menu ..................................................................................36
4.5 Chipset Menu ......................................................................................49
4.6 Boot Menu...........................................................................................52
4.7 Security Menu .....................................................................................53
4.8 Save & Exit Menu................................................................................54
Appendix A Watchdog Timer................................... 55
A.1 About Watchdog Timer........................................................................55
A.2 Sample Program .................................................................................55
Appendix B Digital I/O ............................................. 57
B.1 About Digital I/O ..................................................................................57
B.2 Sample Program .................................................................................57
Appendix C BIOS Update ........................................ 61
C.1 How to update system BIOS using <F12> key....................................61

vi
This page is intentionally left blank.

MANO540 Mini ITX Motherboard
Introduction 1
Section 1
Introduction
The MANO540 Mini-ITX motherboard supports the new 14nm 10th Generation Intel® Core™ i9
/ i7/ i5 / i3 and Pentium® processors in LGA1200 package. Featuring the new Intel® H410
Express chipset with two DDR4 2933MHz memory support, this motherboard is built to
perform best stability and reliability for industrial applications.
It comes with two SATA 3.0, two USB 3.2 GEN1, four USB 2.0 and one RS-232/422/485 port
providing robust storage and I/O options. Users also can increase board functionality with
PCI-Express x16 and full type PCI-Express Mini Card slot. The high quality MANO540 allows
four display interfaces via VGA, HDMI, DisplayPort and eDP in quadruplicate views, making it
an ideal solution for gaming, workstation, digital signage, medical and other IoT&M2M
applications.
1.1 Features
⚫LGA1200 Socket for 10th Generation Intel® Core™ i9/ i7/ i5/ i3 and Pentium® processors
(Comet Lake-S)
⚫2 DDR4 2933MHz memory with maximum capacity up to 64 GB
⚫1 PCI-Express x16
⚫1 M.2 Key E with size 22x30
⚫1 full type PCI-Express Mini Card
⚫1 M.2 key B type 2242/2280/3042/3052
⚫2 SATA-600
⚫2 USB 3.2 GEN1 and 5 USB 2.0

MANO540 Mini ITX Motherboard
2 Introduction
1.2 Specifications
⚫CPU
◼Intel®Comet Lakes for LGA1200 Socket CPU (Max TDP at 65W).
⚫Chipset
◼Intel®H410.
⚫BIOS
◼AMI BIOS via SPI interface.
⚫System Memory
◼Two 260-pin SO-DIMM sockets.
◼Maximum up to 64GB DDR4 memory.
◼Support 2933MHz.
⚫Onboard Multi I/O
◼Six serial ports (RS-232):
- COM1~COM2 in 9-pin D-Sub (on the rear I/O). Only COM1 supports
RS-232/422/485.
- COM3~COM6 in 2x5-pin header (internal).
⚫USB Interface
◼Two USB 3.2 GEN1 ports (on the rear I/O).
◼Four USB 2.0 ports (on the rear I/O).
◼One 4-pin USB 2.0 wafer for Touch (internal).
⚫Ethernet
◼LAN1: 1000/100/10Mbps Gigabit/Fast Ethernet supports Wake-on-LAN, PXE with
Intel®i211AT.
◼LAN2: 1000/100/10Mbps Gigabit/Fast Ethernet supports Wake-on-LAN, PXE with
Intel®i219V.
⚫Serial ATA
◼Two SATA 3.0 port (6Gb/s).
⚫Audio
◼Realtek Codec ALC897.
◼Support line-out/MIC-in (on the rear I/O).
⚫Display
◼Intel®Integrated Graphics:
- One eDP 40-pin connector.
- One DisplayPort connector combo with dual USB 3.2 GEN1 connector, support
resolution 4096x2304 @60Hz.
- One HDMI connector, resolution up to 4096x2160 @24Hz.
- One VGA 15-pin D-Sub connector.
⚫Expansion Interface
◼One PCI-Express x16 slot.
◼One PCI-Express Mini Card.
◼One SIM card slot co-lay with MINIPCIe and M.2 Key B socket (Default is M.2 Key B,
by BOM option).
◼One M.2 Key B type 2242/2280/3042/3052 includes PCIe x2, PCIe + SATA3.0, PCIe
+ USB 3.2 GEN1 interfaces by BOM option. Default is PCIe + USB 3.2 GEN1.
◼One M.2 Key E type 2230 with PCIe x1 and USB2.0.

MANO540 Mini ITX Motherboard
Introduction 3
⚫Power Input
◼One 24-pin ATX power input connector.
◼One 4-pin ATX v-core power input connector.
⚫Operating Temperature
◼0°C ~ 60°C.
⚫Storage Temperature
◼-10°C ~ 70°C.
⚫Form Factor
◼Mini ITX (6.7”x 6.7”, 17.0cm x 17.0cm).
Note
All specifications and images are subject to change without notice.
1.3 Utilities Supported
⚫Chipset driver
⚫Graphics driver
⚫Intel ME driver
⚫Ethernet driver
⚫Audio driver

MANO540 Mini ITX Motherboard
4 Introduction
1.4 Block Diagram

MANO540 Mini ITX Motherboard
Hardware Installation 5
Section 2
Hardware Installation
2.1 Install Central Processing Unit (CPU)
1. Locate the CPU socket on the motherboard.
Note
⚫Remove pin cap before installation, and make good preservation for future
use. When the CPU is removed, cover the pin cap on the empty socket to
ensure pin legs won’t be damaged.
⚫The motherboard might equip with two different types of pin cap. Please refer
below instruction to remove the pin cap.
2. Pull the socket locking lever out from the socket and then raise the lever up.

MANO540 Mini ITX Motherboard
6 Hardware Installation
3. Remove the pin cap.
4. Hold processor with your thumb and index fingers, oriented as shown. Align the notches
with the socket. Lower the processor straight down without tilting or sliding the processor
in the socket.
5. Hold the CPU down firmly, and then lower the lever to locked position to complete the
installation.
Note
⚫Ensure that you install the correct CPU designed for LGA1200 socket.
⚫The CPU fits only in one correct orientation. Do not force the CPU into the
socket to prevent damaging the CPU.

MANO540 Mini ITX Motherboard
Hardware Installation 7
2.2 Install a Heatsink
1. Place the CPU fan assembly on top of the installed CPU and make sure that the four
fasteners match the motherboard holes. Orient the assembly and make the fan cable is
closest to the CPU fan connector.
2. Press down two fasteners at one time in a diagonal sequence to secure the CPU fan
assembly in place. As each fastener locks into position a click should be heard.
Note
⚫Apply the thermal interface material on the CPU before heatsink installation,
if necessary.
⚫Do not forget to connect the CPU fan connector.
⚫For proper installation, please kindly refer to the installation manual of your
CPU heatsink.

MANO540 Mini ITX Motherboard
8 Hardware Installation
2.3 Installing Memory Module
DIMM1/DIMM2: DDR4 Memory Module Slot (260-pin SO-DIMM).
Note
If the DIMM does not go in smoothly, do not force it. Pull it all the way out and try
again.
Insert memory module into SO-DIMM socket at backside of motherboard.
1. Hold the SO-DIMM with its notch aligned with the memory socket of the board and insert
it at a 30 degree angle into the socket.
2. Press down on the SO-DIMM so that the tabs of the socket lock on both sides of the
module.
Note
To avoid generating static electricity and damaging the SO-DIMM, ground yourself
by touching a grounded metal surface or use a ground strap before you touch the
SO-DIMM.

MANO540 Mini ITX Motherboard
Hardware Installation 9
Memory capacity:
DIMM Socket Location
DDR4 Module
Total Memory Size
DIMM1
512MB/1GB/2GB/4GB/8GB
Max is 32GB
DIMM2
512MB/1GB/2GB/4GB/8GB
2.4 Expansion Slots
CN20: PCI-Express Gen3 x16 Slots (x16 mode)
⚫PCI-Express 3.0 compliant.
⚫The maximum bandwidth of the PCIe slot is 32GB/s.
CN21: Mini PCI-Express Connector
⚫The half-size mPCIe socket supports mini PCIe module.

MANO540 Mini ITX Motherboard
10 Hardware Installation
CN22: M.2 Key E Socket
⚫Support M.2 socket 2230 type module.
⚫Support PCIe x1 and USB2.0.
SCN1: M.2 Key B Socket
⚫Support M.2 socket 2242/2280/3042/3052 type module.
⚫Support PCIe x2, PCIe + SATA3.0, PCIe + USB 3.2 GEN1 interfaces by BOM option.
Default is PCIe + USB 3.2 GEN1.
Installing WiFi Module.
1. Insert WiFi module into mini PCIe slot (CN21).
2. Secure screw to the motherboard.
Note
Wi-Fi module and screw sold separately.

MANO540 Mini ITX Motherboard
Board and Pin Assignments 11
Section 3
Board and Pin Assignments
3.1 Board Layout
1
97
3
2
13
12
10
6 8
14
1718
11
5
4
16
15
19
Top View

MANO540 Mini ITX Motherboard
12 Board and Pin Assignments
20 21
Bottom View

MANO540 Mini ITX Motherboard
Board and Pin Assignments 13
3.2 Rear I/O
25 28
23
2924 26 27
22
Jumpers/Headers/Connectors
1
4-pin ATX Power Input Connector (CN70)
16
AT/ATX Power Mode Select Jumper
(JP2)
2
PCI-Express x16 Slot (CN20)
17
COM Headers (CN3~CN6)
3
M.2 Key E Socket (CN22)
18
SPI Header (CN81)
4
PCI-Express Mini Card Connector (CN21)
19
COM VDD Select Jumper (JP6)
5
DDR4 SO-DIMM Connectors (DIMM1,
DIMM2)
20
SIM Card Slot (SCN2)
6
System Fan Header (CN61)
21
M.2 Key B Socket (SCN1)
7
LVDS VDD Select Jumper (JP4)
22
USB 3.2 GEN1 Port (CN10)
8
eDP Connector (CN50)
23
VGA Connector (CN34)
9
CPU Fan Header (CN60)
24
HDMI Connector (CN33)
10
24-pin ATX Power Input Connector
(CN30)
25
DisplayPort Connector (CN32)
11
Front Panel Header (CN80)
26
COM1 and COM2 D-Sub Connector
(CN1)
12
Digital I/O Connector (CN26)
27
LAN1(RJ-45) and USB 2.0 Connector
(CN11)
13
SATA 3.0 Connectors (CN7 and CN8)
28
LAN2(RJ-45) and USB 2.0 Connector
(CN19)
14
USB Header (CN62)
29
Audio Jack (CN23)
15
Clear CMOS (JP3)

MANO540 Mini ITX Motherboard
14 Board and Pin Assignments
Note
To identify the first pin of a header or jumper, please refer to the following
information:
⚫Usually, there is a thick line or a triangle near the header or jumper pin 1.
⚫Square pad, which you can find on the back of the motherboard, is usually
used for pin 1.
3.3 Jumper Settings
Jumper is a small component consisting of jumper clip and jumper pins. Install jumper clip on 2
jumper pins to close. And remove jumper clip from 2 jumper pins to open. The following
illustration shows how to set up jumper.
Before applying power to MANO540 Series, please make sure all of the jumpers are in factory
default position. Below you can find a summary table of all jumpers and onboard default
settings.
Note
Once the default jumper setting needs to be changed, please do it under power-off
condition.
