AXIOMTEK PICO52R User manual

PICO52R
8th Generation Intel®CoreTM i7/ i5/ i3
and Celeron®Pico-ITX Board
User’s Manual

ii
Disclaimers
This manual has been carefully checked and believed to contain accurate information.
Axiomtek Co., Ltd. assumes no responsibility for any infringements of patents or any third
party’s rights, and any liability arising from such use.
Axiomtek does not warrant or assume any legal liability or responsibility for the accuracy,
completeness or usefulness of any information in this document. Axiomtek does not make any
commitment to update the information in this manual.
Axiomtek reserves the right to change or revise this document and/or product at any time
without notice.
No part of this document may be reproduced, stored in a retrieval system, or transmitted, in
any form or by any means, electronic, mechanical, photocopying, recording, or otherwise,
without the prior written permission of Axiomtek Co., Ltd.
CAUTION
If you replace wrong batteries, it causes the danger of explosion. It is recommended by the
manufacturer that you follow the manufacturer’s instructions to only replace the same or
equivalent type of battery, and dispose of used ones.
Copyright 2020 Axiomtek Co., Ltd.
All Rights Reserved
August 2020, Version A2
Printed in Taiwan

iii
ESD Precautions
Computer boards have integrated circuits sensitive to static electricity. To prevent chipsets
from electrostatic discharge damage, please take care of the following jobs with precautions:
Do not remove boards or integrated circuits from their anti-static packaging until you are
ready to install them.
Before holding the board or integrated circuit, touch an unpainted portion of the system
unit chassis for a few seconds. It discharges static electricity from your body.
Wear a wrist-grounding strap, available from most electronic component stores, when
handling boards and components.
Trademarks Acknowledgments
Axiomtek is a trademark of Axiomtek Co., Ltd.
Intel®and Celeron®are trademarks of Intel Corporation.
Windows®is a trademark of Microsoft Corporation.
AMI is a trademark of American Megatrend Inc.
IBM, PC/AT, PS/2, VGA are trademarks of International Business Machines Corporation.
Other brand names and trademarks are the properties and registered brands of their
respective owners.

iv
Table of Contents
Disclaimers.....................................................................................................ii
ESD Precautions...........................................................................................iii
Section 1 Introduction............................................. 1
1.1 Features...............................................................................................2
1.2 Specifications......................................................................................2
1.3 Utilities.................................................................................................3
Section 2 Board and Pin Assignments.................... 5
2.1 Board Dimensions and Fixing Holes.................................................5
2.2 Board Layout.......................................................................................7
2.3 Assembly Drawing..............................................................................9
2.4 Jumper and Switch Settings ............................................................11
2.4.1 LVDS +3.3V/+5V/+12V Voltage Selection (JP1)....................................... 12
2.4.2 Restore BIOS Optimal Defaults (SW1)..................................................... 12
2.4.3 Auto Power On (SSW1) ............................................................................ 12
2.5 Connectors........................................................................................13
2.5.1 Front Panel Connector (CN2) ................................................................... 14
2.5.2 Inverter Connector (CN3).......................................................................... 14
2.5.3 LVDS Connector (CN4)............................................................................. 15
2.5.4 M.2 2230 Key E Connector (CN5) ............................................................ 17
2.5.5 USB 2.0 Wafer Connector (CN6).............................................................. 18
2.5.6 SMBus Connector (CN7) .......................................................................... 18
2.5.7 Power Connector (CN8)............................................................................ 18
2.5.8 USB 3.1 Port (CN9)................................................................................... 19
2.5.9 DisplayPort Connector (CN10).................................................................. 19
2.5.10 HDMI Connector (CN11)........................................................................... 20
2.5.11 Digital I/O Connector (CN12) .................................................................... 20
2.5.12 Ethernet Port (LAN1)................................................................................. 21
2.5.13 Ethernet Wafer Connector (LAN2)............................................................ 21
2.5.14 SATA Port (SATA1).................................................................................... 22
2.5.15 CMOS Battery Connector (BAT1) ............................................................. 22
2.5.16 COM Wafer Connectors (SCN1 and SCN2) ............................................. 23
2.5.17 Fan Connector (SCN4) ............................................................................. 24
2.5.18 SATAPower Connector (SCN5)................................................................ 24
Section 3 Hardware Description ........................... 25
3.1 Microprocessors ...............................................................................25

v
3.2 BIOS ...................................................................................................25
3.3 System Memory.................................................................................25
3.4 I/O Port Address Map........................................................................26
3.5 Interrupt Controller (IRQ) Map .........................................................27
3.6 Memory Map ......................................................................................32
Section 4 AMI BIOS Setup Utility .......................... 33
4.1 Starting...............................................................................................33
4.2 Navigation Keys ................................................................................33
4.3 Main Menu..........................................................................................35
4.4 Advanced Menu.................................................................................36
4.5 Chipset Menu.....................................................................................49
4.6 Security Menu....................................................................................55
4.7 Boot Menu..........................................................................................56
4.8 Save & Exit Menu ..............................................................................57
Appendix A Watchdog Timer................................... 59
A.1 About Watchdog Timer.....................................................................59
A.2 How to Use Watchdog Timer............................................................59
Appendix B Digital I/O ............................................. 61
B.1 About Digital I/O................................................................................61
B.2 Digital I/O Programming...................................................................61
Appendix C iAMT Settings ...................................... 63
C.1 Entering MEBx...................................................................................63
C.2 Set and Change Password ...............................................................63
C.3 iAMT Configuration...........................................................................65
C.4 iAMT Web Console............................................................................73

vi
This page is intentionally left blank.

PICO52R Pico-ITX Board
Introduction 1
Section 1
Introduction
The PICO52R is a Pico-ITX board with the 8th Generation Intel®CoreTM i7/ i5/ i3 and Celeron®
processors that deliver outstanding system performance through high-bandwidth interfaces,
multiple I/O functions for interactive applications and various embedded computing solutions.
The PICO52R has one 260-pin unbuffered SO-DIMM socket for DDR4 2400MHz SO-DIMM
memory with maximum capacity up to 32GB. It also features two Gigabit/Fast Ethernet, two
USB 3.1 Gen2 and two USB 2.0 high speed compliant and one M.2 Key E for wireless module.
Additionally, it provides you with unique embedded features such as two serial ports which
support RS-232/422/485 and 2.5”form factor that applies an extensive array of PC peripherals.
The board can be enhanced by its built-in watchdog timer function, a special industrial feature
not commonly seen on other motherboards.

PICO52R Pico-ITX Board
2 Introduction
1.1 Features
PICO52R - 8th Generation Intel®CoreTM i7/ i5/ i3 and Celeron®processor
1 DDR4 SO-DIMM supports up to 32GB memory capacity
2 USB 3.1 Gen2 ports and 2 USB 2.0 ports
2 Gigabit Ethernet ports
LVDS/HDMI/DisplayPort
1 M.2 Key E
1.2 Specifications
CPU
8th Generation Intel®CoreTM i7/ i5/ i3 and Celeron®processor.
Thermal Solution
Active.
Operating Temperature
-20°C~+60°C.
BIOS
American Megatrends Inc. UEFI (Unified Extensible Firmware Interface) BIOS.
256Mbit SPI Flash, DMI, Plug and Play.
PXE Ethernet Boot ROM.
System Memory
One 260-pin unbuffered DDR4 SO-DIMM socket.
Maximum up to 32GB DDR4 2400MHz memory.
Serial Port
Controller: ITE8528.
Two serial ports: Support RS-232/422/485.
Storage
One SATA-600 connector.
64MB eMMC (Optional).
USB Interface
Two USB 3.1 Gen2 ports in type A on the rear I/O.
Two USB 2.0 ports in 2x5-pin internal wafer connector.
Display
A standard DisplayPort connector: Support DP1.2 and DP++. The DP resolution is
up to 4096x2304 @60Hz.
A standard HDMI connector: Support HDMI 1.4a. The HDMI resolution is up to
3840x2160 @30Hz.
One 2x20-pin connector for 18/24-bit single and dual channel LVDS (with one 8-pin
wafer connector for inverter control). LVDS resolution is up to 1920x1200 in 24-bit
dual channel.

PICO52R Pico-ITX Board
Introduction 3
Watchdog Timer
1~65536 seconds or minutes; up to 65535 levels.
Ethernet
Two 1000/100/10Mbps Gigabit/Fast Ethernet ports.
LAN1: Intel®i219LM supports 1000/100/10Mbps Gigabit/Fast Ethernet with
Wake-on-LAN and PXE Boot ROM in RJ-45 connector.
LAN2: Intel®i211AT supports 1000/100/10Mbps Gigabit/Fast Ethernet with
Wake-on-LAN and PXE Boot ROM in 1x15-pin header.
Audio
N/A
Expansion Interface
One M.2 Key E connector with 22mm(width) x 30mm(length).
Power Input
One 2x2-pin connector.
+12V DC-in only at minimum 12V/2A.
Auto power on function supported.
Power Management
ACPI (Advanced Configuration and Power Interface).
Form Factor
Pico-ITX form factor.
Note
All specifications and images are subject to change without notice.
1.3 Utilities
Chipset and graphics driver
Ethernet driver
Rapid Storage Technology driver
ME driver

PICO52R Pico-ITX Board
4 Introduction
This page is intentionally left blank.

PICO52R Pico-ITX Board
Board and Pin Assignments 5
Section 2
Board and Pin Assignments
2.1 Board Dimensions and Fixing Holes
Top View

PICO52R Pico-ITX Board
6 Board and Pin Assignments
Bottom View
Side View

PICO52R Pico-ITX Board
Board and Pin Assignments 7
2.2 Board Layout
Top View
Rear I/O

PICO52R Pico-ITX Board
8 Board and Pin Assignments
Bottom View

PICO52R Pico-ITX Board
Board and Pin Assignments 9
2.3 Assembly Drawing
For thermal dissipation, a thermal solution enables the PICO52R’s components to dissipate
heat efficiently. All heat generating components are thermally conducted to the heatspreader in
order to avoid hot spots. Images below illustrate how to install the thermal solution on
PICO52R.
1. Standard –Heatsink with fan for PICO52R (see image below):

PICO52R Pico-ITX Board
10 Board and Pin Assignments
2. Optional -- Heatspreader for PICO52R (see image below):
Note
Heatspreader has a large, flat surface on top. It has no fan and no fins. Instead of
cooling by forced air, it is pressed directly up against another large flat surface
(for example: the frame or the inside wall of a sealed container) and heat is
allowed to pass from the small heatspreader out to the larger metal surface.
Heatspreader does not cool the CPU by itself, it only transfer the heat to another
object where it can safely dissipate away from the processor.
The standard heatsink with fan cannot be screwed above heatspreader.

PICO52R Pico-ITX Board
Board and Pin Assignments 11
2.4 Jumper and Switch Settings
Jumper is a small component consisting of jumper clip and jumper pins. Install jumper clip on 2
jumper pins to close. And remove jumper clip from 2 jumper pins to open. Below illustration
shows how to set up jumper.
Properly configure jumper and switch settings on the PICO52R to meet your application
purpose. Below you can find a summary table of jumper, switch and onboard default settings.
Note
Once the default jumper or switch setting needs to be changed, please do it under
power-off condition.
Jumper and Switch
Description
Setting
JP1
LVDS +3.3V/+5V/+12V Voltage Selection
Default: +3.3V Level
1-2 Close
SW1
Restore BIOS Optimal Defaults
Default: Normal Operation
Release
SSW1
Auto Power On
Default: Enable
2-3 Close

PICO52R Pico-ITX Board
12 Board and Pin Assignments
2.4.1 LVDS +3.3V/+5V/+12V Voltage Selection (JP1)
The board supports voltage selection for flat panel displays. Use these jumpers to set
LVDS connector (CN4, See section 2.5.3) pin 1~6 VCCM to +3.3V, +5V or +12V. To
prevent hardware damage, before connecting please make sure that the input voltage of
flat panel is correct.
2.4.2 Restore BIOS Optimal Defaults (SW1)
Use SW1 to clear CMOS. Press the tact switch for at least 3 second to restore BIOS
optimal defaults.
2.4.3 Auto Power On (SSW1)
If SSW1 is enabled for power input, the system will be automatically power on without
pressing soft power button. If SSW1 is disabled for power input, it is necessary to
manually press soft power button to power on the system.
Function
Setting
+3.3V level (Default)
1-2 close
+5V level
2-4 close
+12V level
5-6 close
Function
Setting
Normal (Default)
Release
Restore BIOS optimal defaults
Press
Function
Setting
Disable auto power on
1-2 close
Enable auto power on (Default)
2-3 close

PICO52R Pico-ITX Board
Board and Pin Assignments 13
2.5 Connectors
Signals go to other parts of the system through connectors. Loose or improper connection
might cause problems, please make sure all connectors are properly and firmly connected.
Here is a summary table of connectors on the hardware.
Connector
Description
CN1
DDR4 SO-DIMM Connector
CN2
Front Panel Connector
CN3
Inverter Connector
CN4
LVDS Connector
CN5
M.2 2230 Key E Connector
CN6
USB 2.0 Wafer Port 3 and 4
CN7
I2C Connector
CN8
Power Connector
CN9
USB 3.1 Port
CN10
DisplayPort Connector
CN11
HDMI Connector
CN12
Digital I/O Connector
LAN1
Ethernet Port
LAN2
Ethernet Wafer Connector
SATA1
SATA Port
BAT1
CMOS Battery Connector
SCN1, SCN2
COM1 and COM2 Wafer Connectors
SCN4
Fan Connector
SCN5
SATA Power Connector

PICO52R Pico-ITX Board
14 Board and Pin Assignments
2.5.1 Front Panel Connector (CN2)
This is a 2x6-pin header (pitch=2.0mm) for front panel interface.
Internal Buzzer
Pin 1(-) and 2(+) connect the internal buzzer cable, 594H3186800E for buzzer.
Power Status
Pin 4 and pin 3 are for power status button; letting user know the power status of this
board.
Power LED
Pin 6 connects anode (+) of LED and pin 5 connects cathode (-) of LED. The power LED
lights up when the system is powered on.
Power On/Off Button
Pin 8 and 7 connect the power button on front panel to CPU board, which allows users to
turn on or off power supply.
System Reset Switch
Pin 10 and 9 connect the case-mounted reset switch that reboots your computer without
turning off the power switch. It is a better way to reboot your system for a longer life of
system power supply.
HDD Activity LED
This connection is linked to hard drive activity LED on the control panel. LED flashes
when HDD is being accessed. Pin 12 and 11 connect the hard disk drive to the front
panel HDD LED, pin 11 is assigned as cathode(-) and pin 12 is assigned as anode(+).
2.5.2 Inverter Connector (CN3)
This is an 8-pin (pitch=1.25mm) connector which is compliant with Hirose
DF13-8P-1.25V for inverter interface. We strongly recommend you to use the matching
connector, DF13-8S-1.25C, to avoid malfunction.
Pin
Signal
Pin
Signal
1
BUZZER-
2
BUZZER+
3
GND
4
PWR_PSON
5
PWRLED-
6
PWRLED+
7
PWRSW-
8
PWRSW+
9
HW RST-
10
HW RST+
11
HDDLED-
12
HDDLED+
Pin
Signal
1
+12VM1 (+12V level)
2
+12VM1 (+12V level)
3
+V5S
4
LVDS Enable Control
5
GND
6
GND
7
GND
8
LVDS Brightness Control
