AXIOMTEK RTP120 User manual

RTP120
All-in-One 12.1” TFT LCD
Panel PC
User’s Manual

ii
Disclaimers
The information in this manual has been carefully checked and is
believed to be accurate. AXIOMTEK Co., Ltd. assumes no
responsibility for any infringements of patents or other rights of third
parties which may result from its use.
AXIOMTEK assumes no responsibility for any inaccuracies that may be
contained in this document. AXIOMTEK makes no commitment to update or
to keep current the information contained in this manual.
AXIOMTEK reserves the right to make improvements to this document and/or
product at any time and without notice.
No part of this document may be reproduced, stored in a retrieval system, or
transmitted, in any form or by any means, electronic, mechanical,
photocopying, recording, or otherwise, without the prior written permission of
AXIOMTEK Co., Ltd.
Copyright 2004 by AXIOMTEK Co., Ltd.
All rights reserved.
September 2004, Version A1
Printed in Taiwan

iii
Safety Approvals
 CE Marking
 FCC Class A
FCC Compliance
This equipment has been tested and complies with the limits for a
Class A digital device, pursuant to Part 15 of the FCC Rules. These
limits are designed to provide reasonable protection against harmful
interference in a residential installation. If not installed and used in
accordance with proper instructions, this equipment might generate or
radiate radio frequency energy and cause harmful interference to
radio communications. However, there is no guarantee that
interference will not occur in a particular installation. If this equipment
does cause harmful interference to radio or television reception, which
can be determined by turning the equipment off and on, the user is
encouraged to try to correct the interference by one or more of the
following measurers:
 Reorient or relocate the receiving antenna.
 Increase the separation between the equipment and
receiver.
 Connect the equipment into an outlet on a circuit
different from that to which the receiver is connected.
 Consult the dealer or an experienced radio/TV technician
for help.
Shielded interface cables must be used in order to comply with
emission limits.

iv
Safety Precautions
Before getting started, read the following important cautions.
1. The RTP120 series does not come equipped with an
operating system. An operating system must be loaded
first before installing any software into the computer.
2. Be sure to ground yourself to prevent static charge when
installing the internal components. Use a grounding wrist
strap and place all electronic components in any
static-shielded devices. Most electronic components are
sensitive to static electrical charge.
3. Disconnect the power cord from the RTP120 series before
making any installation. Be sure both the system and the
external devices are turned OFF. Sudden surge of power
could ruin sensitive components. Make sure the RTP120
series is properly grounded.
4. The brightness of the flat panel display decreases with
usage. However, hours of use vary depending on the
application environment.
5. Turn OFF the system power before cleaning. Clean the
system using a cloth only. Do not spray any liquid cleaner
directly onto the screen. The RTP120 series may come
with or w/o a touchscreen. Although the touchscreen is
chemical resistant, it is recommended that you spray the
liquid cleaner on a cloth first before wiping the screen. In
case your system comes without the touchscreen, you
must follow the same procedure and not spray any
cleaner on the flat panel directly.
6. Avoid using sharp objects to operate the touchscreen.
Scratches on the touchscreen may cause malfunction or
internal failure to the touchscreen.
7. The flat panel display is not susceptible to shock or
vibration. When assembling the RTP120 series, make sure
it is securely installed.

v
8. Do not open the system’s back cover. If opening the
cover for maintenance is a must, only a trained
technician is allowed to do so. Integrated circuits on
computer boards are sensitive to static electricity. To
avoid damaging chips from electrostatic discharge,
observe the following precautions:
 Before handling a board or integrated circuit, touch an
unpainted portion of the system unit chassis for a few
seconds. This will help to discharge any static electricity on
your body.
 When handling boards and components, wear a
wrist-grounding strap, available from most electronic
component stores.
Trademarks Acknowledgments
AXIOMTEK is a trademark of AXIOMTEK Co., Ltd.
ALi is a trademark of Acer Laboratories, Inc.
AMD is a trademark of Advanced Micro Devices, Inc.
AMI is a trademark of American Megatrends, Inc.
Cyrix is a trademark of Cyrix Corporation.
IBM, PC/AT, PS/2, VGA are trademarks of International Business
Machines Corporation.
Intel and Pentium are trademarks of Intel Corporation.
MS-DOS, Microsoft C and QuickBASIC are trademarks of Microsoft
Corporation.
SMC is a trademark of Standard Microsystems Corporation.
C&T is a trademark of Chips and Technologies, Inc.
SST is a trademark of Silicon Storage Technology, Inc.
UMC is a trademark of United Microelectronics Corporation.
VIA is a trademark of VIA Technologies, Inc.
Other brand names and trademarks are the properties of their
respective owners.

vi
Table of Contents
Chapter 1 Introduction.....................................................1
1.1 General Description ................................................1
1.2 Specifications..........................................................2
1.2.1 Core System for RTP120 series system with
SBC85610VE ........................................................................ 2
1.2.2 System I/O outlet .................................................... 2
1.2.3 Built-in Peripherals .................................................. 3
1.2.4 Net Weight............................................................... 3
1.2.5 12.1" TFT LCD Specification..................................... 4
1.2.6 Environmental ......................................................... 4
1.2.7 Dimension (main body size) .................................. 4
1.3 Utilities Supported ..................................................4
1.4 Dimensions..............................................................5
1.5 I/O Outlets ................................................................6
Chapter 2 System Configuration ...................................9
2.1 Pedestal Versatility .................................................9
2.1.1 Desktop Standing.................................................. 10
2.1.2 Vertical Wall Mounting ......................................... 11
2.1.3 Wall Mounting ....................................................... 12
2.1.4 30oTable Standing................................................ 14
Chapter 3 Hardware Installation .................................15
3.1 CPU ......................................................................16
3.2 DRAM .....................................................................16
3.3 HDD ......................................................................16
3.4 Three Serial Ports .................................................18
3.5 Parallel Port ...........................................................18
3.6 VGA ......................................................................19
3.7 Ethernet..................................................................19
3.8 Cash Drawer (RTP120-610e only) ........................20

vii
3.9 Keyboard and Mouse............................................20
3.10 Expansion Slot ....................................................21
3.11 USB and Dallas Key Installation ........................22
3.12 System O/S and Software Installation...............22
Appendix A Power Supply Specifications ................23
Appendix B System Configuration Limitation Notice
...............................................................................................25

viii
This page does not contain any information.

RTP120 All-in-One 12.1” TFT LCD Panel PC User’s Manual
Introduction 1
C h a p t e r 1
Introduction
This chapter contains the general information and detailed
specifications of RTP120 series. Chapter 1 includes the following
sections:
 General Description
 System Specification
 Utilities Supported
 Dimensions
 I/O Outlets
1.1 General Description
The RTP120 series super slim industrial panel PCs are mainly
designed for industrial automation and some space-constricted
embedded applications. For some space-concerned industries, a
traditional PC with a separate main system, display monitor and
keyboard is simply not integrated enough.
Ruggedly designed, the RTP120 series is 100% IBM PC/AT
compatible and it integrates super I/Os, 12.1” TFT touch screen,
Ethernet, and packs special industrial features like watchdog timer all
in a single system. The full PC functionality coupled with its
industrial-grade construction easily tailors the system for any
embedded applications -- allowing the system to endure continuous
operation in any hostile industrial environments where stability and
reliability is a must.
The RTP120 series feature a versatile stand suited for a wide variety
of applications. With the pedestal kit assembled to the main unit, both
can transform into different positions such as desktop free standing,
30°table standing, panel mount and wall mounting. Its cable
management device also trims the operation environment. The NEMA
4/12 water/dust-proof front panel is specially designed for the
continuous operation in outdoor environments. Common applications
of these PANEL PCs include POS, POI terminals, Hospitality.

RTP120 All-in-One 12.1” TFT LCD Panel PC User’s Manual
Introduction
2
Designed by the PC experts for PC professionals, the RTP120 series
are virtually the ultimate one-step solution for your space-limited
applications.
1.2 Specifications
1.2.1 Core System for RTP120 series system with
SBC85610VE
 CPU:
Socket370 for Intel Celeron/Pentium III and VIA C3
processor
 System Chipset:
VIA VT8601T, VT82C686B with integrated real-time clock
 BIOS:
Phoenix-Award BIOS, 4Mbit with RPL/PXE LAN Boot ROM
 System Memory:
Two 168-pin DIMM Socket Maximum of 1GB SDRAM
 Watchdog Timer:
Generates a system reset or NMI by jumper selectable;
software programmable Time interval; 64 levels, 0.5~8 /
5~80 / 50~800 / 100~1600 seconds
1.2.2 System I/O outlet
 Standard I/O:
 3 x serial ports with power; 2 x RS-232(COM1,4), 1 x
RS-232/422/485(COM2) jumper selectable
 1 x parallel port, SPP/EPP/ECP
 1 x VGA port
 1 x keyboard interface
 1 x PS/2 mouse interface

RTP120 All-in-One 12.1” TFT LCD Panel PC User’s Manual
Introduction 3
 4 x USB ports
 1 x LAN
 1 x dallas key(option)
 2 x RJ-11 cash drawer ports (610e only)
 Cash Drawer Port:
RJ-11 cash drawer x 2 (610e only)
 Ethernet:
 Realtek 8139C PCI Bus 10/100M Base-T
 Wake-On-LAN
 RJ-45 interface equipped
 VGA/Flat Panel Controller:
 VIA VT8601T chip with integrated Trident 2D/3D accelerator
 2/4/8 MB frame buffer sharing system memory
 LCD/Simultaneous mode:
1024x768 @ 16bpp (60Hz)
 CRT mode:
1024x768 @ 16bpp (85Hz)
1.2.3 Built-in Peripherals
 AT80W power supply(PW-080A-03Y)
 3.5” Hard disk drive bay
 3M 12.1” resistive 8-wire FG Touch Screen(R812.112)
with RS-232(COM3)
 System cooling fan
 Dallas key(option)
1.2.4 Net Weight
 RTP120 series: 4.2 Kgs

RTP120 All-in-One 12.1” TFT LCD Panel PC User’s Manual
Introduction
4
1.2.5 12.1" TFT LCD Specification
 Display area 245(H)x184(V)(12.1"diagonal)
 Resolution 1024×768 (XGA)
 Pixel pitch 0.240(H)x0.240(V)(TYP.)
 Contrast Ratio 200 (MIN.)
 Average Luminance 150cd/m²(TYP.)
 Viewing Angle θL(40 )θR(40)ΦH(10)ΦL(30)
1.2.6 Environmental
 Operating Temperature Range: 0oC ~ 40oC
 Relative Humidity: 20% ~ 85%; non-condensing
 EMC: FCC
 Safety: CE
1.2.7 Dimension (main body size)
 RTP120 series: 360 x 277 x 81.2 mm (WxHxD)
NOTE1 For more detailed information on the system engine board
used in your PANEL PC, refer to the system board User’s
Manual that came with the system packaging.
NOTE2 In order to avoid system over load, therefore a system
power limitation list is necessary to limit power load of
key parts and user’s devices. For more detailed
information on the Appendix B System Configuration
Limitation Notice.
1.3 Utilities Supported
 Watchdog Utility
 Ethernet Utility
 VGA Drivers
 Touchscreen Utility(3M 8-wire)

RTP120 All-in-One 12.1” TFT LCD Panel PC User’s Manual
Introduction 5
1.4 Dimensions

RTP120 All-in-One 12.1” TFT LCD Panel PC User’s Manual
Introduction
6
1.5 I/O Outlets
The following figure shows the I/O arrangement of the RTP120 series.
RTP120-610/ 610e Side View
1 2XUSB ports 2 Dallas Key (option)

RTP120 All-in-One 12.1” TFT LCD Panel PC User’s Manual
Introduction 7
RTP120-610 Bottom View
RTP120-610e Bottom View
3 2x USB ports 9 LAN port
4 2x cash drawer ports
(RTP120-610e only) 10 COM1 port
5 COM4 port 11 COM2 port
6 PCI expansion slot
outlet 12 printer port
7 mouse 13 VGA port
8 keyboard 14 power switch ON/OFF

RTP120 All-in-One 12.1” TFT LCD Panel PC User’s Manual
Introduction
8
This page does not contain any information.

RTP120 All-in-One 12.1” TFT LCD Panel PC User’s Manual
System Configuration 9
C h a p t e r 2
System Configuration
This chapter details the system parts and components with figures.
Sections include:
 System Major Parts
 Pedestal Versatility
 System Key Components
2.1 Pedestal Versatility
The RTP120 series features a versatile stand designed for various
environmental applications. A complete set of pedestal is provided to
make up the various stands.

RTP120 All-in-One 12.1” TFT LCD Panel PC User’s Manual
System Configuration
10
2.1.1 Desktop Standing
The standard kit that makes up a free-standing computer include:
1 System main body 4 Small back metal
fixtures
2 Cable management
shroud 5 Main prop
3 Pedestal 6 Small hinge caps
By assembling these components to the main body of RTP120 series,
the computer stands on the table as an independent unit. This
space-saving computer is commonly adapted for office automation,
video conference and hotel information counter. The unit after proper
assembly would look as illustrated below.

RTP120 All-in-One 12.1” TFT LCD Panel PC User’s Manual
System Configuration 11
2.1.2 Vertical Wall Mounting
For panel mounting only a set of mounting kit is needed, there is no
pedestal kit or cable management shroud required. Please refer to the
following figures.

RTP120 All-in-One 12.1” TFT LCD Panel PC User’s Manual
System Configuration
12
2.1.3 Wall Mounting
The standard kit that makes up a wall-mount unit includes:
1. System main body
2. Cable management shroud
3. Small back metal fixtures
4. Main prop
5. Rubber slip:
The rubber slip has to be inserted to the top opening of
the main prop to make the whole unit look complete and
integrated.
6. Small hinge caps
7. Metal mounting kit
During assembling, the main prop has to be rotated 90°and
screwed to the system’s main body by the back metal fixture.
