Axis JS022K User manual

1
2WARRANTY
YEAR
JS022K
HEAVY DUTY 7” REARVIEW
SAFETY SYSTEM with CCD CAMERA
INCLUDED:
- Dash Mount Monitor Bracket
- Monitor Sunvisor
- Monitor Remote Control
- 2 Meter Power/Trigger/2 Video Input Loom
- Installation Hardware
- Installation Manual
INCLUDED:
- 20 Meter 4-Pin Camera Extension Cable
- Camera Mounting Bracket
- Adjustable Camera Sunvisor
- 1 Meter 4-Pin Camera Fly Lead
MONITOR:
- Monitor: 178mm (7”) TFT Active Matrix LCD
LED Backlighting
- Power Input: 12V - 24V
- Power Consumption: 10W Max
- Aspect Ratio: 16:9 Widescreen
- Video System: Auto PAL/NTSC
- Resolution: 800 (W) X 480 (H)
- Contrast Ratio: 400:1
- Viewing Angle: 70° x 70° x 60° x 70°
- Operating Temp: -20 ~ +70° C
- Camera Inputs: 2 x 4-Pin
- Parking Guidelines: Yes, adjustable
- Speaker: Built In
- Dimensions: 180mm (W) x 123mm (H)
CAMERA:
- Image Device: 1/3” Sharp CCD Image Sensor
- Picture Resolution: 582 x 500 Pixels
- Horizontal Resolution: 420 TV Lines
- Minimum Illumination: 1 Lux (LED On)
- Signal-To-Noise Ratio: Better Than 45 Db
- Field Of View: 120°
- Image: Mirror
- IR LED Quantity: 18 Pcs
- IR LED Automatic On/Off: 5 Lux On (Night) / Off (Day)
- Waterproof Rating: IP67
- Power Supply: 12V (From Monitor)
- TV System: PAL
SYSTEM LCD
MONITOR
CCD CAMERA
1
2V
- Rearview Safety and Mobile Entertainment System
- 2 Camera Inputs with Auto Reverse Trigger
- Ideal for Car, Truck and Bus applications
I
P67
W
EATHER
P
ROOF
PARKING
GUIDELINES

2
1234567
COLOUR MONITOR GUIDELINES
Congratulations for purchasing our mobile safety product! Before connecting, operating or
adjusting this product, please read these instructions. AXIS wants you to achieve the best
performance from your investment.
1. As the monitor is composed of many precise electronic components, please do not
attempt to make repairs. If a problem occurs, please shut down the monitor immediately.
Restart after disconnecting any external sources such as a camera or video source. If a
problem still exists, contact our Service Department or your local dealer.
2. Carefully select the installation location so the operator can comfortably view the image
(when vehicle is reversing etc) without obstructing normal driving. Do not mount the
monitor in direct sunlight or near any heater ducts.
3. Do not expose the monitor to extreme conditions such as humid air, dust, vapour or
direct sunlight.
4. Watching video whilst driving is dangerous and illegal in most states of Australia and
New Zealand. Always connect the monitor to function only when reverse gear is selected,
or the park brake ON.
JS022
Sunvisor Power Cable 20m Extension
Cable
Remote
Control
CA 10 Bracket
PARTS IDENTIFICATION
 'HFUHDVH EXWWRQ
 ,QFUHDVH EXWWRQ
 0HQX
 &DPHUD 9LGHR VHOHFWLRQ $9$9
 0RGH 9LGHR VHOHFWLRQ $9$9
 3RZHU VZLWFK
 3RZHU LQGLFDWRU
NOTE: Enter MENU to choose 3 settings for Parking Guidelines.

3
Put the bracket in the monitor
holder
INSTALLATION
CONNECTIONS
4-Pin Socket (Female) Connection
3LQ)HPDOH'H¿QLWLRQ 3LQ0DOH'H¿QLWLRQ
4-Pin Plug (Male) Connection
1
2
4
3
1
2
4
3
VIDEO
(YELLOW)
POWER
(RED)
AUDIO
(WHITE)
GROUND
(BLACK)
AUDIO
(WHITE)
GROUND
(BLACK)
VIDEO
(YELLOW)
POWER
(RED)
Monitor
Camera
Reversing Light / Power Wire
Camera
Put
the b
rac
k
ho
lde
r
Monitor
Note: Be sure to adjust the camera to the best viewing angle as above.

4
