Axium Mini4 User manual

Audio & Control
Systems
Welcome to the plug and play & renaming zones &
source setup for an Axium Mini4 or AX-1250 Amplifier
with the AX-AMM Media Manager.

Your Mini 4, AX-1250 amplifier and AX-AMM
need to be connected to the same Network.
Audio & Control
Systems
Axium Media Manager, Mini4, AX-1250
There is no physical connection required between Axium amps and AMM

Download the Free Axium app onto your mobile
device, Navigate to either Google Play or
the Apple App store and search for Axium.
The paid version is for systems without Axium
hardware.
Audio & Control
Systems
Axium Media Manager, Mini4, AX-1250

Once discovered,
select Install
Audio & Control
Systems
After installation launch the
Axium app icon on your
device.
The app will self detect the Axium
components on the network and
prepopulate your device with a self
discover mobile template, scaled to the
mobile device, in this case the 4 zones
from a Mini4.
When not connected to a network a user
can run the demo mode.
Axium Media Manager, Mini4, AX-1250

Press the S1
(source 1) label
for Zone 1
Audio & Control
Systems
In this case you can see the AMM
sources and the 8 available network
streams from the Media Manager
These are available in all zones.
Axium Media Manager, Mini4, AX-1250

To start listening to say
TuneIn or music from your
mobile device, select a
stream, in this example
Stream 1
Audio & Control
Systems
The window below will appear
allowing you to make your
selection from the menu for the
music you want to play. Select
from the prompts that appear
after your selection.
Axium Media Manager, Mini4, AX-1250

In this example to listen to
TuneIn radio, Either press the
TuneIn name or use the scroll
up/down arrows and select
the enter button
Audio & Control
Systems
Now you can start exploring
from the list of options that
appear.
Axium Media Manager, Mini4, AX-1250

Audio & Control
Systems
Select the music you want to
listen to and start playing
Press the Devices available
tab to select a Zone
To access Spotify Connect, launch your
Spotify App on your mobile device.
Axium Media Manager, Mini4, AX-1250

Audio & Control
Systems
Then Click on this symbol.
Some phones may have a
different layout than that
shown below.
Select the Zone you want to
have music playing.
Use the Volume Up & Down buttons on your mobile device to
control the amplifiers volume.
Axium Media Manager, Mini4, AX-1250

Audio & Control
Systems
To use Airplay, select More
Devices.
Again select the zone you
want to listen in.
Axium Media Manager, Mini4, AX-1250

Audio & Control
Systems
Press S1 (source 1) Then select the cog icon
Renaming Zone and Source Names.
Ensure your mobile device is connected to the
same network as the Axium products.

Audio & Control
Systems
Press the Axium Symbol Then select device config
Axium Media Manager, Mini4, AX-1250

This will open the device settings Web page as
below, select and press the Zone tab.
Audio & Control
Systems

You can now edit names. Tap on the zone name and type
the new name i.e. Lounge, then select OK.
This will save the name in the amplifier.
Audio & Control
Systems
Axium Mini4
Repeat the previous steps for each of the remaining Zones until
all your zones are re-named.
Untick zones not used so they don’t appear in the mobile app.

Use the same process to rename sources.
Select the Source tab.
Audio & Control
Systems

Tap on a source name and type in the new name i.e. Sky,
then select OK. This will save the source name in the Amp
Audio & Control
Systems
Repeat for each of the remaining sources until all your sources
are re-named.
Untick unused sources so they are not displayed in the app.
