Axon Synapse DEE28 User manual

Committed.
DEE28
Multi format Dolby stream decoder and Dolby E
encoder with Quad-Speed audio bus and voice
over module
Installation and Operation manual

Hercules 28
NL-5126 RK Gilze
The Netherlands
Phone: [phone]
Fax: [phone]
E-mail: [email protected]
Web: www.axon.tv
TECHNICAL MANUAL
DEE28

3
WARNING: TO REDUCE THE RISK OF FIRE OR
ELECTRICAL SHOCK, DO NOT EXPOSE THIS
APPLIANCE TO RAIN OR MOISTURE
● ALWAYS disconnect your entire system from the AC mains before cleaning any component. The product
frame (SFR18, SFR08 or SFR04) must be terminated with three-conductor AC mains power cord that
includes an earth ground connection. To prevent shock hazard, all three connections must always be used.
● NEVER use flammable or combustible chemicals for cleaning components.
● NEVER operate this product if any cover is removed.
● NEVER wet the inside of this product with any liquid.
● NEVER pour or spill liquids directly onto this unit.
● NEVER block airflow through ventilation slots.
● NEVER bypass any fuse.
● NEVER replace any fuse with a value or type other than those specified.
● NEVER attempt to repair this product. If a problem occurs, contact your local Axon distributor.
● NEVER expose this product to extremely high or low temperatures.
● NEVER operate this product in an explosive atmosphere.
Warranty: Axon warrants their products according to the warranty policy as described in the general terms.
That means that Axon Digital Design BV can only warrant the products as long as the serial numbers are not
removed.
Copyright © 2001 – 2016 AXON Digital Design B.V.
Date created: 26-01-2015
Date last revised: 03-06-2016
Axon, the Axon logo and Synapse are trademarks of Axon Digital Design B.V.
This product complies with the requirements of the product family standards for audio, video, audio-visual
entertainment lighting control apparatus for professional use as mentioned below.
EN60950
EN55103-1: 1996
EN55103-2: 1996
Safety
Emission
Immunity
Axon Digital Design DEE28
Tested To Comply
With FCC Standards
FOR HOME OR OFFICE USE
This device complies with part 15 of the FCC Rules
Operation is subject to the following two conditions:
(1) This device may cause harmful interference, and
(2) This device must accept any interference received, including
interference that may cause undesired operation.

4
Table of Contents
Table of Contents 4
Introduction to Synapse 7
An Introduction to Synapse 7
Local Control Panel 7
Remote Control Capabilities 7
Unpacking and Placement 8
Unpacking 8
Locating the card 8
A Quick Start 9
When Powering-up 9
Default settings 9
Changing settings and parameters 9
Front Panel Control 9
Example of changing parameters using front panel control 10
Axon Cortex 11
Menu Structure Example 11
The DEE28 Card 12
Introduction 12
Applications 13
Program Procedure 13
Block schematics 13
Settings Menu 14
Introduction 14
SRC 14
Lock-Mode 14
Backup 14
In_Out 14
Dolby_firmware 15
Output_1_mux ~ Output_4_mux 15
Dolby _in 15
Ch_main_in 15
Dolby_PCM_backup 15
Ch_backup 16
Sel_Ch1 ~ Sel_Ch16 16
Ch_1 ~ Ch_16 16
Gain-CH_1 ~ Gain-CH_16 16
Phase-CH_1 ~ Phase-CH_16 16
Stereo-CH_1/2 ~ Stereo-CH_15/16 16
Delay_CH_1/2 ~ Delay_CH_15/16 17
Override 17/24 17
Override 25/32 17
VO_Trigger 17
VO_Sel 18
VO_Ch 18
VO_Scale 18
VO_Trglvl 18
VO_Delay 18
VO_Hold 18
VO_Release 18
VO_Rampdown 18
VO_Ch_1 ~ VO_Ch_16 18
Slot1/2 ~ Slot31/32 19
Meta_BUS 19
Mon_out_program 19
Backup_out12 19
Backup_out34 19
Backup_out56 19
Backup_out78 19
Downmix 19
PCM_metadata 20
PCM_latency 20
VsyncALIGN 20
VsyncINP 20
VsyncENA 20
Ad_mix 21
Ad_2ch_mix 21
Operating_mode 21
Meta_Prgm_Sel 21
Loudness_type 21
Loud_Prgm 22
Loud-ext_RST 22
Ld_DDp_Select 22
Ld_PCM_Select 22
Main_DRC_DD 24
Main_DRC_E 24
Main_DRC_PCM 24
Aux_DRC_DD 24
Aux_DRC_E 24
Aux-DRC_PCM 24

5
GD_Shift 24
Prgm 25
MD_loss 25
GPI_2_prgm 25
#Metadata_set 25
#Prgm_text 25
#Bitstrm 26
#Dialogue_Lev 27
#Ch_mod 27
#Line 27
#RfMode 28
#D Srnd 28
#Pref dwnmx 28
#Lt/RT C dwnmx 28
#Lt/RT S dwnmx 28
#Lo/Ro C dwnmx 28
#Lo/Ro S dwnmx 28
#Srnd EX 29
#DC filter 29
#LFE filter 29
#Lowpass Filter 29
#Srnd 3Db atten 29
#Srnd_Ph_Shift 30
DolbyE Depth 30
Category 30
Parameter 30
Status Menu 31
Introduction 31
Lock 31
AES_Inp_1 ~ AES_Inp_4 31
Ch_1_Val ~ Ch_16_Val 31
Main_In 31
Backup_In 31
Decoder_In 31
Ref_Input 31
Nr_programs 31
(MD) Program 31
(MD) Bit_Depth 32
(MD) Dialogue_Lev 32
(MD) Datarate 32
(MD) Bitstream 32
(MD) Channel_Mode 32
(MD) LFE 32
(MD) Pref_Dwn_Mix 32
(MD) Center_mix_lvl 32
(MD) Surr_mix_lvl 32
(MD) Lt/Rt_center 32
(MD) Lt/Rt_surr 32
(MD) Lo/Ro_center 32
(MD) Lo/Ro_surr 32
(MD) DC_highpass 32
(MD) BW_lowpass 32
(MD) LFE_lowpass 32
(MD) Surr_90 32
(MD) Surr_3dB 33
(MD) Dynamic_compr 33
(MD) RF_compr 33
(MD) Surr_mode 33
(MD) Surr_ex_mode 33
(MD) Mix_meta 33
(MD) Mix_Control 33
(MD) Pscale_Ena 33
(MD) EXT_prgmscale 33
(MD) Pscale_L_Ena 33
(MD) Pscale_L 33
(MD) Pscale_C_Ena 33
(MD) Pscale_C 33
(MD) Pscale_R_Ena 33
(MD) Pscale_R 33
(MD) Pscale_Ls_Ena 34
(MD) Pscale_Ls 34
(MD) Pscale_Rs_Ena 34
(MD) Pscale_Rs 34
(MD) Pscale_LFE_Ena 34
(MD) Pscale_LFE 34
(MD) PanMean_Ena 34
(MD) PanMean 34
Int_UGTD_ld 34
Int_SPCHGTD_ld 34
Int_LVLGTD_ld 34
Int_10sUGT_ld 34
Int_10sSPCHGTD_ld 34
Int_3sUNGTD_ld 35
MOM_ld 35
S10s_ld 35

6
INT_SPCH_ld 35
INT_LD_range 35
SMPL_PEAK_0 ~ SMPL_PEAK_7 35
TRUE_PEAK_0 ~ TRUE_PEAK_7 35
DDpRATE 35
Program_Discr 35
EXT_meta_pres 35
Enc rate 35
Value 35
GPI_1 35
GPI_2 35
GPI_3 35
Events Menu 36
Introduction 36
What is the Goal of an event? 36
DEE28 Events 36
Announcements 36
Audio-Data 36
Reference 36
What information is available in an event? 36
The Message String 36
The Tag 37
Defining Tags 37
The Priority 37
The Address 37
LED Indication 38
ERROR 38
INPUT 1 ~ INPUT 8 38
REFERENCE 38
DATA ERROR 38
CONNECTION 38
Block Schematics 39
Connector Panel 40
Pin description 42
Metadata cable DEE28/DBE08 43
Quad speed ADD-ON bus 44
Some examples 46

7
1
Introduction to Synapse
An Introduction to
Synapse
Synapse is a modular system designed for the broadcast industry. High
density, intuitive operation and high quality processing are key features
of this system. Synapse offers a full range of converters and processing
modules. Please visit the AXON Digital Design Website at www.axon.tv
to obtain the latest information on our new products and updates.
Local Control Panel
The local control panel gives access to all adjustable parameters and
provides status information for any of the cards in the Synapse frame,
including the Synapse rack controller. The local control panel is also
used to back-up and restore card settings. Please refer to the rack
controller manuals for a detailed description of the local control panel,
the way to set-up remote control over IP and for frame related settings
and status information.
Remote Control
Capabilities
The remote control options are explained in the rack controller manual.
The method of connection to a computer using Ethernet is described in
those manuals as well.
!
CHECK-OUT: “AXON CORTEX” SOFTWARE WILL
INCREASE SYSTEM FLEXIBILITY OF ONE OR MORE
SYNAPSE FRAMES
Although not required to use Axon Cortex with a Synapse frame, you are
strongly advised to use a remote personal computer or laptop PC with
Axon Cortex installed as this increases the ease of use and understanding
of the modules.

8
2
Unpacking and Placement
Unpacking
The Axon Synapse card must be unpacked in an anti-static environment.
Care must be taken NOT to touch components on the card – always
handle the card carefully by the edges. The card must be stored and
shipped in anti-static packaging. Ensuring that these precautions are
followed will prevent premature failure from components mounted on
the board.
Locating the card
The Synapse card can be placed vertically in an SFR18 frame or
horizontally in an SFR08 or SFR04 frame. Locate the two guide slots to
be used, slide in the mounted circuit board, and push it firmly to locate
the connectors.
Correct insertion of card is essential as a card that is not located properly
may show valid indicators, but does not function correctly.
Note: On power up all LEDs will light for a few seconds, this is the time
it takes to initialise the card.

9
3
A Quick Start
When Powering-up
On powering up the Synapse frame, the card set will use basic data and
default initialization settings. All LEDs will light during this process.
After initialization, several LEDs will remain lit – the exact number and
configuration is dependant upon the number of inputs connected and the
status of the inputs.
Default settings
In the default condition, the DEE28 acts as a Dolby E decoder locked to
ref input 1, decoding into AES outputs using external incoming meta
data program streams.
Changing settings
and parameters
The front panel controls or Axon Cortex can be used to change settings.
An overview of the settings can be found in chapter 5, 6 and 7 of this
manual.
Front Panel Control
Front Panel Display and Cursor
Settings are displayed and changed as follows;
Use the cursor ‘arrows’ on the front panel to select the menu and
parameter to be displayed and/or changed.
Press ► To go forward through the menu structure.
Press ◄ To go back through the menu structure.
Press ▲ To move up within a menu or increase the value of
a parameter.
Press ▼ To move down through a menu or decrease the
value of a parameter.
REMARK: Whilst editing a setting, pressing ► twice will reset the value
to its default.
[No Alarms]

10
Example of changing
parameters using
front panel control
With the display as shown below
Pressing the ► selects the SFS10 in frame slot 01.
The display changes to indicate that the SFS10 has been selected. In this
example the Settings menu item is indicated.
Pressing the ► selects the menu item shown, in this example
Settings.
(Pressing ▲ or ▼ will change to a different menu eg Status,
Events).
The display changes to indicate that the SFS10 Settings menu item
SDI-Format has been selected and shows that it current setting is
Auto.
Pressing the ► selects the settings item shown, in this example SDI-
Format.
(Pressing ▲ or ▼ will change to a different setting, eg Mode, H-
Delay).
The display changes to indicate that the SFS10 Edit Setting menu
item SDI-Format has been selected.
To edit the setting of the menu item press ▲ or ▼.
All menu items can be monitored and/or changed in this way. Changing a
setting has an immediate effect.
RRC18 [Select Card]
>S01=SFS10
SFS10 [Select Menu]
>Settings
SFS10 [Settings]
>SDI-Format=Auto
SFS10 [Edit
Setting]

11
Axon Cortex
Axon Cortex can be used to change the settings of Synapse modules
from a PC, either locally or remotely. The software enables
communication based on TCP/IP between the Setup PC and Synapse
frames/modules.
Each Synapse frame is addressed through its rack controller’s unique IP
address, giving access to each module, its menus and adjustment items.
Axon Cortex has access to data contained within the Synapse module and
displays it on a GUI. The software has an intuitive structure following
that of the module that it is controlling.
For operation of Axon Cortex, please refer to the Axon Cortex help files
(press F1 in any window).
Menu Structure
Example
Slot
Module
Item Parameter Setting
▲
▲
S02
Identity
▲ ▲
S0
1
SFS10
►
Setti
ngs
►
SDI-
Format
►
Auto
▼ ▼ ▼ ▼
S00
RRC18 Status Mode 625
▼ ▼ ▼
Events Ref-Input 525
▼
H-Delay
▼
▼
REMARK: Further information about Front Panel Control and Axon
Cortex can be obtained from the rack controller manual and Axon Cortex
help files.

12
4
The DEE28 Card
Introduction
The DEE28 is a next generation Dolby multi format decoder and Dolby
E encoder with quad speed ADD-ON audio bus. It replaces the popular
DBD08 and DBE08 on a single card. Based on the Dolby’s Cat. No.
1100 sub module it is capable of decoding Dolby E, Dolby Digital and
Dolby Digital Plus and encoding to Dolby E. The enhanced feature set
includes the capability of decoding 7.1-channel Dolby Digital Plus or
5.1-ch Dolby Digital 5.1 with audio description, carried in a single
bitstream (Single PID), or as two bitstreams (Dual PID).
In addition to the extensive Dolby Decoding capabilities this card can
add a voice activated (or triggered by GPI) Voice Over signal to any of
the decoded streams or plain PCM streams that could enter the unit.
Individual delay and gain controls are available for all decoded or plain
PCM streams that entered the card. A dual mode I/O configuration is
possible with physical 2x AES/EBU in and 6x AES/EBU out or 4x
AES/EBU in and 4x AES/EBU out.
 Multi format ADD-ON or stand alone Dolby stream decoder
 Dolby E
 Dolby Digital
 Dolby Digital Plus
 Dolby E encoder
 16 channel PCM processing capabilities
 Quad speed audio bus for convenient routing of ADD-ON channels
 Optional re-inserting of processed audio for downstream post-
processing (DLAxx)
 2, 4 or 6 physical stereo AES/EBU inputs and 16 stereo bus inputs.
 2, 4 or 6 physical stereo AES/EBU (can contain Dolby Bit streams)
outputs and 8 stereo (into 16 stereo) bus outputs
 E decoding with automatic source selection on loss of E
 Voice activated Voice Over engine that can be applied to any of the 16
internal streams
 GPI trigger of VO is included
 GPI can be used as ‘cough button’ to mute unwanted voice
activated mixing
 Physical metadata output
 Individual offset delay per channel
 Individual gain control per channel (except bitstream input)
 Able to handle all AES/EBU input formats (optional SRC on inputs)
 Full audio channel shuffling
 Loudness measurement according to ITU BS.1770-1 and ITU
BS.1770-3 (CALM and R128)
 A tone generator is included that can be controlled by the
loudness measurement.
 It will generate a -20dBFS sinewave when the loudness
measurement reads and measures -20LUFS so a normal
peak/VU/dBFS meter can be used to read loudness

13
Applications
 Multi format Dolby Stream monitoring decoder
 Dolby E encoer
 Efficient Dolby stream processing to Quad Speed Master Cards.
 Extra Dolby channel processing next to G/HEP100, G/HPD100 and
G/HED100
Program Procedure
This card can be updated with new firmware when new firmware
versions are released by Axon. You can download the .spf file from our
website when new releases are announced. To upgrade the DEE28 you
can follow the instructions as described in the ‘reprogramming cards
quick-guide’, downloadable via our website.
It is strongly recommended to back-up the card’s setting after
reprogramming and restoring the default values when done.
Block schematics
RACK
CONTROLLER
ΜP
32
CHANNEL
ADD-ON EMBED MULTIPLEXING
8 X 2-CHANNELS INTO 32
DEE28
[QUAD SPEED AUDIO BUS]
INTERNAL SYNAPSE BUS
LOSS OF
DOLBY
ST REAM
FAIL SW ITCH
GAIN DELAY
GAIN DELAY
GAIN DELAY
GAIN DELAY
GAIN DELAY
GAIN DELAY
GAIN DELAY
GAIN DELAY
50x17
INPUT
MUX
32CH
IN
32CH
OUT
32CH
IN
FROM M AS TE R
TO MA ST ER
TO N EX T
A DD - ON
FROM NE XT
A DD -ON
MUX
OPTIONAL RE-
INSE RTING OF
PROCESS ED AUDIO
VOX
DETECT
DELAY
2Ch
2Ch
2Ch
2Ch
2Ch
2Ch
2Ch
2Ch
OPTIONAL
SRC
OPTIONAL
SRC
OPTIONAL
SRC
OPTIONAL
SRC
AES/EBU OUT 9/10
AES/EBU OUT 11/12
VO
MIXER
+
+
+
+
+
+
+
+
2Ch
2Ch
2Ch
2Ch
2Ch
2Ch
2Ch
2Ch
REFERENCE
INPUTS
1 2
PLL
R128
GEN
E
DIGITAL
DIGITAL PLUS
DECODER
WITH 7.1 &
AUDIO DESCRIPTION
LOUDNESS METER
DOWNMIX CHANNEL
OPTIONAL
SRC
OPTIONAL
SRC
E-ENCODER
AES/EBU OUT 5/6
AES/EBU OUT 7/8
METADATA
PROCESSOR

14
5
Settings Menu
Introduction
The settings menu displays the current state of each setting within the
DEE28 and enables the item to be changed or adjusted.
Settings can be changed using the front panel of the Synapse frame
(SFR18, SFR08 or SFR04) or Axon Cortex.
Please refer to chapter 3 for information on the Synapse front panel
control and Axon Cortex.
SYSTEM CONTROL
SRC
The AES/EBU inputs are connected to a Sample Rate Converter. This
enables the input to use audio sample rates that are non-synchronous to
video of the master card (setting On). For Non PCM audio data (Dolby
Digital, Dolby E, etc.) the SRC can be bypassed and the data is inserted
in the card transparently (Trans). The default setting is On.
Lock-Mode
The DEE28 can be used as an ADD_ON card (in combination with an
embedder/de-embedder card). In this case you are referred to the setting
MasterCard, which will extract the reference from the master card. It
is also possible to use an external signal to lock to. In that case you are
referred to the setting:
AES1 = Locks to the AES/EBU signal on input 1(default)
AES4 = Locks to the AES/EBU signal on input 4
Ref1 = The B&B reference input of the rack controller
Ref2 = The second B&B reference input of the rack
controller (if available)
Mastercard = Locks to the ADD-ON bus input (always use
this setting when using quad speed add-on bus
functionality).
Backup
This is the backup input enable/disable for the Dolby decoder. Set to on
will switch the decoder outputs to the assigned backup channels when
dolby is lost. Which channel will be the backup channel is set with
Dolby_PCM_backup and Ch_Backup. The delay compensation of
the backup is always 1 frame (equal to Dolby E decoding).
In_Out
In the block schematic you can see that 2 of the 4 AES inputs and 2 of
the 6 AES outputs are colored grey. With this setting you decide which
inputs and outputs are active. There’s two possible settings:
■ 4In-4Out: 4 AES/EBU input and 4 AES/EBU outputs
■ 2In-6Out: 2 AES/EBU input and 6 AES/EBU outputs
Refer to the block schematic for more details on the difference modes.

15
Dolby_firmware
Please only change to No_Update when told so by Axon Support.
Output_1_mux ~
Output_4_mux
With these setting you can choose to either route the default channels to
the output muxes (CH1/2 for output 1, CH3/4 for output 2, CH5/6 for
output 3 and CH7/8 for output 4) or to route the encoded Dolby E
signal to the specific output.
INPUT CONTROL
Dolby _in
Here you select where the Dolby E comes from: from the local
AES/EBU inputs, or from the master card via the add-on bus. Default
is local. Please note that when set to master the lock-mode setting
should also be set to mastercard.
Ch_main_in
With this setting you appoint specific channels within the input source
set with Dolby_E_in, which should contain Dolby E. Dependant on
the source, you can choose any of the following audio pairs:
■ 1/2 AES/EBU input 1 when source is local, Add-on
bus channels 1/2 when source is master
■ 3/4 AES/EBU input 2 when source is local, Add-on
bus channels 3/4 when source is master
■ 5/6 AES/EBU input 3 when source is local, Add-on
bus channels 5/6 when source is master
■ 7/8 AES/EBU input 4 when source is local, Add-on
bus channels 7/8 when source is master
■ 9/10 only available when source is master
■ 11/12 only available when source is master
■ 13/14 only available when source is master
■ 15/16 only available when source is master
■ 17/18 only available when source is master
■ 19/20 only available when source is master
■ 21/22 only available when source is master
■ 23/24 only available when source is master
■ 25/26 only available when source is master
■ 27/28 only available when source is master
■ 29/30 only available when source is master
■ 31/32 only available when source is master
Dolby_PCM_backup
With Dolby_PCM_backup you select which source is your backup
input for the Dolby decoder (only used when Backup is set to on). Can
be set to local (the physical AES/EBU inputs) or to master (audio
coming from master card, via add-on bus). Default is local.

16
Ch_backup
With this setting you appoint specific channels within the input source
set with Dolby_PCM_backup, which should contain Dolby E.
Dependant on the source, you can choose any of the audio pairs listed
under Ch_E_in.
Sel_Ch1 ~ Sel_Ch16
With these settings you set a source for the corresponding output
channel. You can set each individual channel to source:
 Local: physical AES/EBU inputs
 Master: audio coming from master card via add-on
 Decoded_PCM: audio coming from the Dolby decoder
 Monitor: this is the monitoring output of the decoder. This
channel contains for instance a downmix or audio description.
 LoudnessLVL: this is a representation of the loudness level as a
PCM signal (a 1Khz sine). This signal can be put on a normal
audio level meter to represent the loudness measurement.
Channels 1 till 8 (dependant on the In_Out setting) are the physical
AES/EBU outputs as well as outputs towards the add-on bus and are by
default set to Decoded_PCM. Channels 9 and 10 are default set to
Monitor. Channels 11 till 16 are add-on bus only (dependant on the
In_Out setting) and by default set to Master.
Ch_1 ~ Ch_16
With these settings you select the actual source channel in the above
selected source. Default Ch_1 till Ch_16 are set to respectively 1 till
16.
Note: When Local is selected, you can choose channel 1 till channel 8.
When Master is selected, you can choose channel 1 till channel 32.
PROCESS CONTROL
Gain-CH_1 ~
Gain-CH_16
These items allow you to gain the audio for each individual channel in a
range from –60dB to 12 dB in steps of 0.25 dB. –999dB mutes this
channel. Default is 0dB.
Phase-CH_1 ~
Phase-CH_16
These items allow you to gain the audio for each individual channel with
180 degrees. Default is 0 degree.
Stereo-CH_1/2 ~
Stereo-CH_15/16
With these settings you can configure the corresponding channels
(channels 1/2, channels 3/4, channels 5/6, etc.) as being mono channels
(In which case for instance channel 1 and 2 will both contain a mix of
channel 1 + channel 2) or combined stereo channels.

17
Delay_CH_1/2 ~
Delay_CH_15/16
These settings allow you to delay the audio of each pair of channels in a
range of 0 to 1300 ms. In steps of 0.01 ms. Default is 0ms.
IN BUS CONTROL
Override 17/24
If you want to pass processed audio from one quad speed add-on card to
the other (for instance if you want to pass decoded Dolby E audio from
this card to for instance a Loudness Control or Dolby D encoder add-on
card next to this card) you have to use this setting. You can choose to
override input channels 17/24 on the add-on bus of the next card (right
side) with output channels 1 to 8 or pass the master-card audio.
Override 25/32
With this setting you can choose whether you want to override input
channels 25/32 on the add-on bus of the next add-on card (right side)
with output channels 9 to 16 or pass the master-card audio.
VO CONTROL
The DBD handles Voice Over channels. With the following settings you can set how the involved
program out channels should react to a voice over signal and how everything is triggered. The
following graphic gives a visualisation of the settings.
VO_Trigger
With this setting you set how a voice over trigger is generated. Can be set
to off (in which case a voice over is never triggered), GPI_0 (voice over
processing is triggered by GPI contact 0) or Auto (voice over processing
is triggered when the voice over channels reaches the trigger level
volume set with VO_Trglvl). Default is Off.

18
VO_Sel
Here you set a source which contains the voice over channel. Can be set
to Local (physical AES/EBU inputs), Master (audio coming from
master card via add-on) or Decoded_PCM (audio coming from the
Dolby decoder). Default is Local.
VO_Ch
Here you select which channel in the above selected source contains the
voice over content. Default is channel 7.
VO_Scale
With this setting you set a scale in dB with which the program out
channels should be decreased in volume when a voice over is triggered.
Can be between -95dB and 0dB. Default is -60dB.
VO_Trglvl
This setting is used when VO_Trigger is set to auto. You set a
threshold in dBFS between -95 and 0dBFS. When the voice over channel
reaches this threshold, voice over processing is triggered.
VO_Delay
This is the delay in ms (up to 1000 ms) with which the voice over
channel is delayed. This is the time between the trigger and the actual
insertion (see graphic in VO control header). Default is 256ms.
VO_Hold
This is the time between the end of the voice over (audio goes below the
VO_Trgrlvl threshold or GPI_0 is released, depending on what is set
in VO_Trigger) and the start of the voice over release (see graphic in
VO control header). Default is 256ms.
VO_Release
This is the “release” time. The time between the end of the VO hold and
the point where the program out channels are at their full volume level
again (see graphic in VO control header). Default is 256ms.
VO_Rampdown
This is the “ramp down” time. The time between the VO trigger and the
point where the program out channels have reached the volume level set
with VO_scal (see graphic in VO control header). Default is 256ms.
VO_Ch_1 ~
VO_Ch_16
With these settings you set which program out channels should be
affected by VO settings. You can set channels to VO (affected by the
voice over like indicted in the graph), Duck_Only (only ramp down the
program out channel, but don’t mix in the voice over) or No_VO
(channel unaffected by voice over). Default is No_VO for all channels.

19
OUTPUT CONTROL
Slot1/2 ~ Slot31/32
These menu items are to fill the Quad speed audio bus with the
appropriate outputs. You can fill any of the 16 audio pairs (32 channels
in total) with the audio that is set to Out1/2, Out3/4, etc till
Out15/16. You can also switch the concerning pair to off, making the
concerning audio pair empty.
Meta_BUS
The DEE28 can output the dolby metadata to the ADD-ON bus. This
metadata signal is always put onto slots 25 till 32. When this setting is
switched on, the setting Slot25/26 till Slot31/32 will not be used
anymore. This function must be supported by the master can you send it
to.
DOLBY GENERAL
Mon_out_program
With this setting you select which output program you want to monitor in
the status tab. You can choose any available program (up to 8 depending
on the program configuration: 7.1, 5.1+2, 5.1, 4x2, 3x2, 2+2, 8x1, etc.).
Backup_out12
With the DEE28 you can decide which of the decoder outputs contains
the backup audio channel (set with settings backup,
Dolby_PCM_backup and back_ch). With Backup_out12 set to
on, decoder outputs 1 and 2 will contains the assigned backup channel in
case the back switch is activated.
Backup_out34
With Backup_out34 set to on, decoder outputs 3 and 4 will contain
the assigned backup channels in case the backup switch is activated.
Backup_out56
With Backup_out56 set to on, decoder outputs 5 and 6 will contain
the assigned backup channels in case the backup switch is activated.
Backup_out78
With Backup_out78 set to on, decoder outputs 7 and 8 will contain
the assigned backup channels in case the backup switch is activated.
Downmix
Here you can set the downmix mode of the downmix output of the Dolby
Decoder. Can be Lt/Rt (Left total/right total, a downmix suitable for
decoding with a Dolby Pro Logic upmixer to obtain 5.1 channels again),
Lr/Ro (Left only/right only, a downmix suitable when mono
compatibility is required), or Auto (Lt/Rt or Lo/Ro is chosen dependant
on the whether or not there’s a 5.1 program config or not). Default is
Auto.

20
PCM_metadata
With this setting you decide whether you want to keep generating
metadata in case the Dolby E is lost. Default is off.
PCM_latency
Here you define the delay in case the Dolby signal is lost. Can be set to
SingleFrame (equal to Dolby E decoding) or to minimum.
VIDEO SYNC CONTROL
Dolby E decoders generally require a valid video sync input signal when
operating. This signal must be aligned and matched to the timing and rate
of the incoming Dolby E signal. Many facilities use a Vsync signal as a
reference for timing throughout a larger broadcast chain.
VsyncALIGN
If the Vsync signal is present and properly matched, the DOLBY
DECODER/ENCODER can then attempt to perfect the alignment. This
option (vsyncALIGN) enables latency adjustment of the decoded audio
so that the Dolby E stream is aligned exactly to the Vsync signal. The
latency adjustment amount is up to plus or minus half the guard band
length listed in the following table.
Guard Band Length Frame Rate
360 samples 23.98 Hz
360 samples 24 Hz
192 samples 25 Hz
160 samples 29.97 Hz
160 samples 30 Hz
VsyncINP
Here you set the input for the vsync. Can be either ref1 or ref2.
VsyncENA
If the option (vsyncALIGN) to align a Vsync signal when decoding
Dolby E is set, and the signal is not aligned (within the tolerance
window), the DOLBY DECODER/ENCODER can then attempt to
reconstruct the alignment. This option (VsyncENA) adjusts the latency
of the decoded
audio so that the Vsync signal is aligned exactly to the Dolby E stream.
The amount of latency added for the alignment is limited by the
corresponding video frame length.
