Axon Synapse GDS100 User manual

Committed.
GDS100/110
HDS100/110
3Gb/s, HD and SD down converter and
synchronizer with optional audio shuffler
Installation and Operation manual

Lange Wagenstraat 55
NL-5126 BB Gilze
The Netherlands
Phone: [phone]
Fax: [phone]
E-mail: [email protected]v
Web: www.axon.tv
TECHNICAL MANUAL
GDS100/110
HDS100/110

1
WARNING: TO REDUCE THE RISK OF FIRE OR
ELECTRICAL SHOCK, DO NOT EXPOSE THIS
APPLIANCE TO RAIN OR MOISTURE
● ALWAYS disconnect your entire system from the AC mains before cleaning any component. The product
frame (SFR18 or SFR04) must be terminated with three-conductor AC mains power cord that includes an
earth ground connection. To prevent shock hazard, all three connections must always be used.
● NEVER use flammable or combustible chemicals for cleaning components.
● NEVER operate this product if any cover is removed.
● NEVER wet the inside of this product with any liquid.
● NEVER pour or spill liquids directly onto this unit.
● NEVER block airflow through ventilation slots.
● NEVER bypass any fuse.
● NEVER replace any fuse with a value or type other than those specified.
● NEVER attempt to repair this product. If a problem occurs, contact your local Axon distributor.
● NEVER expose this product to extremely high or low temperatures.
● NEVER operate this product in an explosive atmosphere.
Warranty: Axon warrants their products according to the warranty policy as described in the general terms.
That means that Axon Digital Design BV can only warrant the products as long as the serial numbers are not
removed.
Copyright © 2001 –2015 AXON Digital Design B.V.
Date created: 09-07-2009
Date last revised: 06-11-2015
Axon, the Axon logo and Synapse are trademarks of Axon Digital Design B.V.
This product complies with the requirements of the product family standards for audio, video, audio-visual
entertainment lighting control apparatus for professional use as mentioned below.
EN60950
EN55103-1: 1996
EN55103-2: 1996
Safety
Emission
Immunity
Axon Digital Design
GDS100/110
HDS100/110
Tested To Comply
With FCC Standards
FOR HOME OR OFFICE USE
This device complies with part 15 of the FCC Rules
Operation is subject to the following two conditions:
(1) This device may cause harmful interference, and
(2) This device must accept any interference received, including
interference that may cause undesired operation.

2
Table of Contents
Introduction to Synapse 6
An Introduction to Synapse 6
Local Control Panel 6
Remote Control Capabilities 6
Unpacking and Placement 7
Unpacking 7
Placing the card 7
A Quick Start 8
When Powering-up 8
Changing settings and parameters 8
Front Panel Control 8
Example of changing parameters using front panel control 9
Synapse Cortex Software 10
Menu Structure Example 10
The GDS100/110 Card 11
Introduction 11
Features 11
Conversion capabilities 12
Applications 13
Block schematic 13
Important notice 14
Settings Menu 15
Introduction 15
IO-Ctrl 15
IO_Prst_Act 15
IO_Prst_Edit 15
#Inp_SelA 16
#CVBS-frmt 16
#Out-Ctrl 16
#Out-Frmt 16
#IO_Map 16
#F-delay 16
#V-delay 17
#H-delay 17
#Freeze_A 17
#LowPassFilt_A 17
Pos-Prst_Act 18
Pos-Prst_Edit 18
#H-Pos-A 19
#V-Pos-A 19
#VANC_Trans 19
#VANC_Trans_Ln0 ~ #VANC_Trans_Ln5 19
Delay-Status 19
Lock-Mode 19
Ref-Type 19
PrstEditView 20
PatternSpeed 20
Input_Loss_A 20
Dn_CtrlA 20
Dn_Prst_actA 20
Dn_Prst_editA 20
#Dn_ArcA 20
# Dn_H-scaleA 21
# Dn_V-scaleA 21
# Dn_H-EnhA 21
# Dn_ColorConvA 21
Tr_CtrlA 21
Tr_Prst_ActA 22
Tr_Prst_EditA 22
#Tr_ArcA 22
#Tr_H-scaleA 22
#Tr_V-scaleA 22
#Tr_H-EnhA 22

3
Timecode_Inp 23
VITC_Ln_In 23
VITC_Ln_Ctrl 23
VITC_Ln_625 23
VITC_Ln_525 23
VITC_Ln_Dup 23
ATC_Dem_Sel 23
ATC_Emb_Sel 23
Aux_TC_SRC 24
AUX_Dem_Sel 24
AUX_Emb_Sel 24
Aux_VITC_Ln_In 24
Aux_Ln_625 25
Aux_Ln_525 25
Aux_TC_DLY 25
Ins_CtrlA 25
Ins_Prst_ActA 25
Ins_Prst_EditA 25
#VI-InsertA 25
#VI-DataA 25
#WSS-InsertA 25
#WSS-StndA 25
#WSS-ExtndA 26
#VI-DataA 26
#S2016-InsertA 26
#S2016-DataA 26
#CC_Ena_A 26
GainA 26
R-GainA 26
G-GainA 26
B-GainA 26
BlackA 26
R-BlackA 27
G-BlackA 27
B-BlackA 27
CVBS-Hue 27
Audio-Bus-IO 27
Audio_Ctrl 27
Audio_Prst_act 27
Audio_Prst_Edit 27
#Audio-Dly-sInp1 27
#Audio-Dly-sInp2 28
#EmbA_Grp 28
#EmbA1_Inp ~ #EmbA4_Inp 28
#EmbA1_Inp_Ch ~ #EmbA4_Inp_Ch 28
#EmbB_Grp 28
#EmbB1_Inp ~ #EmbB4_Inp 29
#EmbB1_Inp_Ch ~ #EmbB4_Inp_Ch 29
#EmbC_Grp 29
#EmbC1_Inp ~ #EmbC4_Inp 29
#EmbC1_Inp_Ch ~ #EmbC4_Inp_Ch 29
#EmbD_Grp 30
#EmbD1_Inp ~ #EmbD4_Inp 30
#EmbD1_Inp_Ch ~ #EmbD4_Inp_Ch 30
#EmbA1_Gain ~ #EmbD4_Gain 30
#EmbA1_Phase ~ #EmbD4_Phase 30
Contact _1 ~ Contact_5 30
GPI_A-mode ~ GPI_C-mode 31
GPI_A-Take ~ GPI_C-Take 31
IP_Conf0 31
mIP0 31
mNM0 31
mGW0 31
NetwPrefix0 31
Status Menu 32
Introduction 32
sInp1 32
sInp1_VI 32
sInp1_WSS-Stnd 33
sInp1_WSS-Extd 33
sInp1_S2016 34
sInp1_CRC_EDH 34
sInp1-Map 34

4
sInp2 34
sInp2_VI 34
sInp2_WSS-Stnd 34
sInp2_WSS-Extnd 34
sInp2_S2016 35
sInp2_CRC_EDH 35
sInp2-Map 35
sInp3_WSS-Stnd 35
sInp3_WSS-Extnd 35
sInpCVBS 35
IODelayA 35
FunctionA 35
Ref 35
Contact_Status 36
GPIA 36
GPIB 36
GPIC 36
OP47-Det-A 36
WST-Det-A 36
CC_Det_A 36
SDI1DemFrmt01/02 ~ SDI1DemFrmt15/16 36
SDI2DemFrmt01/02 ~ SDI2DemFrmt15/16 36
IP_Addr0 37
MAC0 37
IP0 37
NM0 37
GW0 37
Events Menu 38
Introduction 38
What is the Goal of an event? 38
Events 38
Announcements 38
Input_A 38
Input_B 38
Ref-Status 38
Active_Out_A 38
What information is available in an event? 38
The Message String 39
The Tag 39
Defining Tags 39
The Priority 39
The Address 39
LED Indication 40
Error LED 40
Input_A LED 40
Input_B LED 40
ANC Data LED 40
Reference LED 40
Data Error LED 40
Connection LED 40
Error LED 40
Block Schematic 41
Connector Panels 42
GPI pinning 42
Card dip-switches for BHX and fiber configuration 43
Using BPH17 with fiber I/O 43
Using BHX17b 43
GPI’s explained 45
Introduction 45
General functionality 45
Contact assignment 45
Pools 45
Take 46
Debounce time 46
Pool Mode: GPI 46
Pool Mode: GPO 47
Statuses: Contact direction 47
Statuses: Contact status 48
Statuses: GPI status 48

5
Statuses: GPO status 48
Example 1: Two pools in binary mode 48
Example 2: One pool in binary mode and one in priority mode 49
Example 3: Two pools in priority mode 49
GNU Public License version 2 51

6
1
Introduction to Synapse
An Introduction to
Synapse
Synapse is a modular system designed for the broadcast industry.
High density, intuitive operation and high quality processing are
key features of this system. Synapse offers a full range of converters
and processing modules. Please visit the AXON Digital Design
Website at www.axon.tv to obtain the latest information on our new
products and updates.
Local Control
Panel
The local control panel gives access to all adjustable parameters and
provides status information for any of the cards in the Synapse
frame, including the Synapse rack controller. The local control
panel is also used to back-up and restore card settings. Please refer
to the RRC18, RRC10, RRC04, RRS18 and RRS04 manuals for a
detailed description of the local control panel, the way to set-up
remote control over IP and for frame related settings and status
information.
Remote Control
Capabilities
The remote control options are explained in the rack controller
(RRC18/RRC10/RRC04/RRS18/RRS04) manual. The method of
connection to a computer using Ethernet is described in the
RRC/RRS manual.
!
CHECK-OUT: “SYNAPSE CORTEX” SOFTWARE
WILL INCREASE SYSTEM FLEXIBILITY OF ONE OR
MORE SYNAPSE FRAMES
Although not required to use Cortex with a Synapse frame, you are
strongly advised to use a remote personal computer or laptop PC
with Synapse Cotrtex installed, as this increases the ease of use and
understanding of the modules.

7
2
Unpacking and Placement
Unpacking
The Axon Synapse card must be unpacked in an anti-static
environment. Care must be taken NOT to touch components on the
card –always handle the card carefully by the edges. The card must
be stored and shipped in anti-static packaging. Ensuring that these
precautions are followed will prevent premature failure from
components mounted on the board.
Placing the card
The Synapse card can be placed vertically in an SFR18 frame or
horizontally in an SFR04 and SFR08 frame. Locate the two guide
slots to be used, slide in the mounted circuit board, and push it
firmly to locate the connectors.
Correct insertion of card is essential as a card that is not located
properly may show valid indicators, but does not function correctly.
NOTE: On power up all LED’s will light for a few seconds, this is
the time it takes to initialise the card.
NOTE: Please check appendix 1 before connecting any backpanel!

8
3
A Quick Start
When Powering-
up
On powering up the Synapse frame, the card set will use basic data
and default initialisation settings. All LED’s will light during this
process. After initialisation, several LED’s will remain lit – the
exact number and configuration is dependant upon the number of
inputs connected and the status of the inputs.
Changing settings
and parameters
The front panel controls or the Synapse Cortex can be used to
change settings. An overview of the settings can be found in chapter
5, 6 and 7 of this manual.
Front Panel
Control
Front Panel Display and Cursor
Settings are displayed and changed as follows;
Use the cursor ‘arrows’ on the front panel to select the menu and
parameter to be displayed and/or changed.
Press ►
To go forward through the menu structure.
Press ◄
To go back through the menu structure.
Press ▲
To move up within a menu or increase the value of
a parameter.
Press ▼
To move down through a menu or decrease the
value of a parameter.
NOTE: Whilst editing a setting, pressing ► twice will reset the
value to its default.
[No Alarms]

9
Example of
changing
parameters using
front panel control
With the display as shown below
Pressing the ► selects the SFS10 in frame slot 01.
The display changes to indicate that the SFS10 has been selected. In
this example the Settings menu item is indicated.
Pressing the ► selects the menu item shown, in this example
Settings.
(Pressing ▲ or ▼ will change to a different menu eg Status,
Events).
The display changes to indicate that the SFS10 Settings menu
item SDI-Format has been selected and shows that it current
setting is Auto.
Pressing the ► selects the settings item shown, in this example
SDI-Format.
(Pressing ▲ or ▼ will change to a different setting, eg Mode,
H-Delay).
The display changes to indicate that the SFS10 Edit Setting
menu item SDI-Format has been selected.
To edit the setting of the menu item press ▲ or ▼.
All menu items can be monitored and/or changed in this way.
Changing a setting has an immediate effect.
RRC18 [Select Card]
>S01=SFS10
SFS10 [Select Menu]
>Settings
SFS10 [Settings]
>SDI-Format=Auto
SFS10 Edit Setting]
SDI-Format>Auto

10
Synapse Cortex
Software
Synapse Cortex can be used to change the settings of Synapse
modules from a PC, either locally or remotely. The software enables
communication based on TCP/IP between the Setup PC and
Synapse frames/modules.
Each Synapse frame is addressed through its rack controller’s
unique IP address, giving access to each module, its menus and
adjustment items. Synapse Cortex has access to data contained
within the Synapse module and displays it on a GUI. The software
has an intuitive structure following that of the module that it is
controlling.
For operation of Synapse Cortex, please refer to the Cortex manual.
Menu Structure
Example
Slot
Module
Item
Parameter
Setting
▲
▲
S02
Identity
▲
▲
S01
SFS10
►
Set-
tings
►
Standard_dig
►
Auto
▼
▼
▼
▼
S00
RRC18
Status
Mode
625
▼
▼
▼
Events
Ref-Input
525
▼
H-Delay
▼
▼
NOTE: Further information about Front Panel Control and
Synapse Cortex can be obtained from the RRC and RRS operational
manuals and the Cortex help files.

11
4
The GDS100/110 Card
Introduction
The GDS100/110 and HDS100/110 are low latency down
converters with 16 channel audio transparency.
The GDS100/110 is compatible with 270Mb/s, 1.5Gb/s and 3Gb/s
for full 1080p/50 or 1080p/59.94 use. The HDS100/110 are
compatible with SD-SDI (270Mb/s) and HD-SDI (1.5Gb/s) and can
be future upgraded to 3Gb/s compatibility
Features
2 SDI inputs
Low latency conversion process (as low as 1 field in controlled timing
environment)
Compatible with the following input formats (auto selecting) (1080p
only for GDS):
1080p/59.94
1080p/50
1080i/59.94
1080i/50
1080p/23.98
1080psf/23.98
720p/59.94
720p/50
720p/23.98
SD525
SD625
Output standards
1080p/59.94
1080p/50
1080i/59.94
1080i/50
1080p/23.98
1080psf/23.98
720p/59.94
720p/50
720p/23.98
SD525
SD625
Two individual conversion paths. The inputs can be different standards
SD or HD and unlocked to the single output format.
Frame sync with output phase control in Frames, Lines and pixels with
respect to reference. Delay setting are stored per output format for a
constant latency operation.
30 Frames delay offset (per channel)
1080i/59.94
1080i/50
1080p/50
1080p/23.98
1080p/59.94
1080psf/23.98
60 Frames delay offset (per channel)
720p/59.94
720p/50
720p/23.98
125 Frames delay offset (per channel)
SD525
SD625
All ARC modes contain:
Anamorphic
Center Cut
V-Zoom
LBox-16:9
LBox-14:9
PBox-4:3
PBox-14:9
Variable H and V (50—200%)
Free individual programmable presets banks for:
Down converter ARC 16-presets
VI insertion 16-presets
WSS insertion 16-presets

12
S2016 insertion 16-presets
Embedder shuffling/Gain/Phase 16-presets (110 only)
5 GPI inputs assignable to different preset banks
Input selection
Down conversion aspect ratio
Transparent aspect ratio (equal in-output)
Insertion of VI, WSS, AFD (S2016)
Audio shuffling, gain and phase (110 only)
ARC triggers by VI, WSS, WSSext and S2016 (AFD)
Color corrector
Transparent for 16 channels of embedded audio
Embedded domain cross input audio shuffling, gain and phase control
(110 only)
Embedding and de-embedding through synapse bus
Video proc-amp (Y and C control)
Color corrector (RGB and total gain, RGB and total black)
Hue control for NTSC inputs
Full control and status monitoring through the front panel of the
SFR04/SFR08/SFR18 frame and the Ethernet port (ACP)
Conversion
capabilities
Output
CONVERSION
1080psf23.97
1080p23.97
1080p50*
1080p59.94*
1080i59.94
1080i50
720p59.94
720p50
720p23.98
480i59.94(525)
576i50(625)
SDI Input
1080psf23.97
x
x
1080p23.97
x
x
1080p50*
x
x
1080p59.94*
x
x
1080i59.94
x
x
1080i50
x
x
720p59.94
x
x
720p50
x
x
720p23.98
x
x
480i59.94(525)
x
576i50(625)
x
CVBS
480i59.94(NTSC)
x
576i50(PAL)
x
* = GDS models only

13
Applications
Transmission output down conversion with backup input
GDS110 and HDS110 only:
Combining embedded audio channels of 2 inputs into 1 (see
image below)
3GB/S, HD, SD IN A
3GB/S HD, SD IN B
16 CHANNEL
DE-EMBEDDING
UP-
CONVERTION
UP-
CONVERTION
3GB/S, HD, SD OUT A1
3GB/S, HD, SD OUT A2
3GB/S, HD, SD OUT B1
3GB/S, HD, SD OUT B2
16 CHANNEL
DE-EMBEDDING
CROSS INPUT AUDIO SHUFFLING EXPLAINED
INTERNAL SYNAPSE BUS
AUDIO
SHUFFLING
AUDIO
SHUFFLING
EMBEDDING
EMBEDDING
Block schematic
INTERNAL SYNAPSE BUS
GDS100 –GDS110 - HDS100 - HDS110
RACK
CONTROLLER
GPI #5 OUT #2 TRACKING OUT
ΜP [LINUX]
LOW LATENCY
DOWN CONVERSION
- ARC -
- BYPASS -
FRAME
SYNC
&
OFFSET
DELAY
EMB A
4 CH
3Gb/s, HD, SD IN 1
3Gb/s, HD, SD OUT A1
3Gb/s, HD, SD OUT A2
3Gb/s, HD, SD OUT B1
3Gb/s, HD, SD OUT B2
3Gb/s, HD, SD IN 2
S2016
DETECTION
EQ
EQ
EMB B
4 CH
EMB C
4 CH
1234
EMB D
4 CH
16 CHANNEL
DE-
EMBEDDING
COLOR
CORR.
&
VI/WSS
INSERT
PRESET BASED 4 CHANNEL
AUDIO GAIN, PHASE & DELAY
CONTROL (‘110’ ONLY)
BUS MULTIPLEXER
EMBEDDING OR
DE-EMBEDDING 4 CH
4 CH
4 CH
4 CH
16 CHANNEL
DE-
EMBEDDING PRESET BASED 4 CHANNEL
AUDIO GAIN, PHASE & DELAY
CONTROL (‘110’ ONLY)
PRESET BASED 4 CHANNEL
AUDIO GAIN, PHASE & DELAY
CONTROL (‘110’ ONLY)
PRESET BASED 4 CHANNEL
AUDIO GAIN, PHASE & DELAY
CONTROL (‘110’ ONLY)
REFERENCE
INPUTS
1 2
PLL
16 CH
PRESET BASED
SHUFFLING
48X16 MUX
(‘110’ ONLY)

14
Important notice
Historically, closed captions were transmitted in NTSC line 21
according to EIA-608. This allows two caption data bytes per field
to be transmitted.With the introduction of HD and DTV a new
Closed Caption specification was made, EIA-708. This allows
sending more data per field, for extended language, color support,
PMT and EIT and timecode data.
The new DTV caption format cannot be translated back to EIA-608.
However the EIA-708 may include EIA-608 data as "NTSC closed
captions" for compatibility with old decoders.
This card only de-embeds the NTSC closed captions, not the DTV
closed captions. It will not function with a DTV-only 708 closed
caption source.

15
5
Settings Menu
Introduction
The settings menu displays the current state of each GDS-
HDS100/110 setting and allows you to change or adjust it. Settings
can be changed using the front panel of the Synapse frame (SFR18,
SFR08 or SFR04) or with Cortex. Also the SCP08 control can be
used. Please refer to chapter 3 for information on the Synapse front
panel control and Cortex.
Note: All items preceded with a #-sign are part of the presets.
SYSTEM SETTINGS
IO-Ctrl
This card has separate presets for the input and output settings under
the ‘SYSTEM SETTINGS’ header. With this item you select how
the IO presets are controlled: Manually (manual, default), via GPI-
triggers (GPI, GPI-A,GPI-B or GPI-C) or by the input format
on input 1 (SDI1-Format) or input 2 (SDI2-Format). The
input formats are mapped to the preset as followed:
Format:
Preset:
1080i60
Preset 1
1080i50
Preset 2
1080p30
Preset 3
1080p25
Preset 4
1080p24
Preset 5
720p60
Preset 7
720p50
Preset 8
720p30
Preset 9
720p25
Preset 10
720p24
Preset 11
SD525
Preset 12
SD625
Preset 13
1080p50
Preset 14
1080p60
Preset 15
IO_Prst_Act
With this item you can manually change the currently active IO
settings. Can be any preset between 1 and 8. By default it is set to 1.
All menu settings that are preceded with a ‘#‘-prefix under the
‘SYSTEM SETTINGS’ header are part of the preset.
IO_Prst_Edit
Here you can select which of the 8 selectable IO settings presets
you want to edit. Changing this will not change the active preset,
unless the currently active preset is the same you are going to edit.
All menu settings that are preceded with a ‘#‘-prefix under the
‘SYSTEM SETTINGS’ header are part of the preset.

16
#Inp_SelA
With this item you can select which input you want to use for
Channel A. Can be SDI-1 (SDI input 1), SDI-2 (SDI input 2) or
Analog (CVBS in). You can also choose a Zoneplate or
Colorbar as input. Can also be set to Off to switch off channel
A entirely. The default for this setting is SDI-1.
#CVBS-frmt
With this item you can set the format of the CVBS input. Possible
formats to select here are (default is Auto):
PAL-M
PAL-N
NTSC-M
NTSC-4.43
NTSC-J
SECAM
PAL-60
PAL-BGHID
Auto (automatic detection and selection)
#Out-Ctrl
This setting controls the output format of the card. When set to
Manual, the output format corresponds to the Out-Frmt setting.
When set to Auto, the output format follows the input format.
Possible settings are:
Manual (default)
Auto
#Out-Frmt
With Out-Frmt you can set what the output should be of channel
A as well as channel B. Possible settings are:
1080i60 (default), 1080i50
1080p50, 1080p60
1080p24
1080psf24
720p60, 720p50
720p24
SD525, SD625
#IO_Map
With this setting you can configure the output as LevelA or
LevelB (according to SMPTE S425) when the output format is
1080p50 or 1080p60.
#F-delay
F-Delay sets the amount of delayed Frames. The available range
is from 0 to 250 fields (dependant on the I/O). Default is 0F. The
preset master for this is Out-Frmt, hence the ‘#’-prefix.

17
#V-delay
V-Delay setting allows adjustment of the vertical phase of the
output signal with respect to the selected reference input.
The V-Delay setting gives a delay in addition to the reference
timing. For example: if the V-Delay is set to 10 TV HD lines, the
output signal will be delayed by reference timing + 10 TV HD lines.
The signal is delayed (advanced) with respect to the phase of the
reference signal. The available range is from 0 to a maximum of
1125 lines (dependant on I/O format). The default setting is 0ln.
The preset master for this is Out-Frmt, hence the ‘#’-prefix.
#H-delay
The H-Delay setting allows adjustment of the Horizontal phase of
the output signal with respect to the selected reference input.
The H-Delay setting gives a delay in addition to the reference
timing. For example: if the H-Delay is set to 10 pixels, the output
signal will be delayed by reference timing + 10 pixels. The signal is
delayed (advanced) with respect to the phase of the reference signal.
The available range is from 0 to a maximum of 5124 pixels
(dependant on I/O format). The default setting is 0px. The preset
master for this is Out-Frmt, hence the ‘#’-prefix.
#Freeze_A
Freeze enables the capture of one Video Frame. The settings of
Freeze are On or Off. The default setting is Off.
#LowPassFilt_A
Here you can set the horizontal and vertical video low-pass filter for
channel A. These are the possible settings:
■Off: the normal broadband filters will be used when the card is
converting. A 64 taps brick wall type horizontal filter:
■H_only: a less steep filter with no aliasing Y and soft for C for
less ringing effects:

18
■V_only: vertical filters will be active which “soften” the image
and prevents “ring”-effects in down converted content.
■H_And_V: same horizontal filter as described under H_Only
will be active, together with the vertical filters described under
V_only.
■H2_Only: less steep filter with aliasing and soft for C for less
ringing, more sharpness but with aliasing:
■H2_And_V: same horizontal filter as described under
H2_Only will be active, together with the vertical filters
described under V_only.
Note: When the card is in transparent mode, the filters will be
entirely bypassed.
Pos-Prst_Act
Active preset control for the position controls #H-Pos-A and #V-
Pos-A. With this item you can manually change the currently active
positioning settings. Default setting is 1.
Pos-Prst_Edit
Edit preset control for the position controls #H-Pos-A and #V-Pos-
A. Here you can select which of the 8 selectable positioning settings
presets you want to edit. Default setting is 1.
