Axor Terrano 37001XX1 User manual

Installation Instructions / Warranty
Terrano
37001XX1
Terrano
37200XX1
Terrano
37020XX1
37028XX1

2
Technical Information
Recommended water pressure 14.7 - 72.5 psi
Max. water pressure 147 psi
Recommended hot water temp. 120° - 140° F*
Max. hot water temp 165° F*
Hole size in mounting surface 1⅜"
Max. mounting surface depth 1¾"
Flow rate – lavatory 1.5 gpm
Flow rate – bidet 2.2 gpm
⅜" supply hoses
*Please know and follow all applicable local plumbing codes
when setting the temperature on the water heater.
37001XX1 37200XX1 37020XX1
less drain 37028XX1
Do not allow the supply hoses to
twist or kink.

3
Installation
Place the faucet and sealing ring on the mounting surface.
Install the slide washer, friction washer, and collar nut.
Tighten the collar nut by hand.
Tighten the tensioning screws.
Install the drain pull rod.
Installation Considerations
For best results, Hansgrohe recommends that
this unit be installed by a licensed, professional
plumber.
Please read over these instructions thoroughly
before beginning installation. Make sure that
you have all tools and supplies needed to com-
plete the installation.
Keep this booklet and the receipt (or other proof
of date and place of purchase) for this product
in a safe place. The receipt is required should it
be necessary to request warranty parts.
•
•
•
Signicant pressure dierences between the hot
and cold supplies should be corrected.
Flush the hot and cold supplies thoroughly
before installation of this faucet. Damage
caused by debris is not covered by the warranty
Model 37028XX1 does not include a drain or
a pull rod.
•
•
•

4
Connect the hot and cold supply hoses to the stops.
Use two wrenches, as shown in the
diagram, to prevent hose twisting.
Install the pop-up drain*.
Turn on the water and check all connections for leaks.
* Drain not included with 37028XX1

5
Install the pop-up drain
Attach the swivel connector to the end of the
horizontal rod.
Attach the swivel connector to the end of the
pull rod. Position as desired and tighten with a
small, flat bladed screwdriver.
Remove the plunger assembly.
Unscrew the drain outlet flange from the tee.
Unscrew the tailpiece from the tee. Wrap the
threads with Teflon tape and replace.
Install the white, flexible sealing gasket to the
flange. Place it in the sink outlet.
Install the black mack gasket, white friction ring
and retainer nut on the flange.
Do not tighten the nut against the bottom of the
sink at this time.
Thread the tee and tailpiece to the flange. The
pivot must face the faucet. Turn the drain assem-
bly if necessary.
Tighten the retainer nut.
Place the plunger assembly in the drain.
Install the horizontal rod so that the end goes
through the loop in the bottom of the plunger.
Install and hand tighten the pivot ball nut.
