Axor Allegroh 36135XX1 User manual

Starck
10133XX1
Carlton
17135XX1
Steel
35033801
Terrano
37135XX1
Phoenix
17105XX1
Phoenix
17115XX1
Phoenix
17114XX1
Terrano
37136XX1
Phoenix
17104XX1
Carlton
17235XX1
Installation Instructions / Warranty

2
Starck
10133XX1
Phoenix
17105XX1
Phoenix
17104XX1
Phoenix
17114XX1

3
Carlton
17135XX1
Carlton
17235XX1
Phoenix
17115XX1
Steel
35033801

4
Terrano
37135XX1
Terrano
37136XX1
Technical Information
Recommended water pressure 14.7 - 72.5 psi
Max. water pressure 147 psi
Recommended hot water temp. 120° - 140° F*
Max. hot water temp 176ºF*
Hole size - spout 1-3/8"
Hole size - valve 1-1/4"
Max. mounting surface depth see diagrams
Flow rate -- 17104/17105 only 1.5 gpm max.
Flow rate -- all other models 2.2 gpm max.
Requires 1/2" hot and cold supply hoses -- not included
*Please know and follow all applicable local plumbing codes when setting
the temperature on the water heater.
Installation Considerations
For best results, Hansgrohe
recommends that this unit be
installed by a licensed, profes-
sional plumber.
Please read over these instruc-
tions thoroughly before begin-
ning installation. Make sure that
you have all tools and supplies
needed to complete the instal-
lation.
•
•

5
Installation
Starck only
Remove the valve mounting nuts from the valves.
Push the valves up into the holes. Install the mounting nuts
on the valves.
Tighten the tensioning screws.
Place the handles over the valve mounting nuts. Tighten
the handles by rotating the escutcheons clockwise.
The handles should be parallel to the basin.
Install the spout
Position the sealing ring, escutcheon, and spout on the
mounting surface.
Install the mounting flange. Thread the collar onto the
stud and tighten.

6
Screw the connection hoses into the mounting angle.
Connect the mounting angle to the spout tube using
the 10 mm compression fitting.
The metal side of the compression ferrule must face
up toward the spout.
Turn to page 10 to continue the installation.

7
Install the hot and cold valves
Install the mounting nut, metal washer and the fiber
washer on the valve.
Insert the valve through the hole in the deck.
Install the stop ring on the valve.
Install the mounting flange. The stop ring will stop it at the
proper height.
Rest the valve on the mounting surface. Turn the valve so
that the outlet points toward the center.
Tighten the mounting nut.
Tighten the tensioning screws.
Installation – Carlton, Phoenix, Terrano,
and Steel
Carlton, Phoenix, and Steel only
Install the handle escutcheons.
Carlton, Phoenix, and Terrano only
Position the handle over the valve stem. Rotate the lower
part of the handle clockwise so that it threads down over
the valve.

8
Terrano 37135XX1 only
Place the spout and sealing ring on the mounting surface.
Install the friction washer, fiber washer, and nut.
Tighten the tensioning screws.
Install the spout
Carlton only
Place the spout and sealing ring on the mounting surface.
Install the mounting flange. Thread the collars onto the
studs and tighten.
Steel only
Install the color rings: red on the left and blue on the right.
Install the handle snap connectors.
Position the handle over the valve. Push it firmly into
place on the snap connector.

9
Steel only
Position the spout, escutcheon and sealing ring on the
mounting surface.
Install the mounting flange. Thread the collar onto the
stud and tighten.
Terrano 37136XX1, Phoenix only
Position the spout and sealing ring on the mounting
surface.
Install the mounting flange. Thread the collar onto the
stud and tighten.

10
Install the connecting hoses
Push a 3/8" compression nut and ferrule over the end
of the connecting hose.
Push the end of the hose into the valve outlet.
Tighten the compression nut wrench tight.
Use two wrenches. Do not allow
the connecting hose to twist, or
it will become loosened from the
spout.
All models
Install the drain pull rod
Finish the installation
Install the 1/2" hot and cold supply lines (not included).
Install the pop-up drain.
7/16"
11/16"
