Axor One 280 1jet Showerpipe 48790 7 Series Manual

INSTALLATION
ZH ⁄ 用户手册 ⁄ 组装说明 02
EN ⁄ Instructions for use ⁄ Assembly instructions 03
Lesezeichen
中文 02
English 03
AXOR One 280 1jet Showerpipe
48790XX7

02
ZH
安装 (参见第页 06)
安全技巧
装配时为避免挤压和切割受伤，必须戴上手套。
本产品只允许作为洗浴、卫生和洁身之用。
头顶花洒夹持杆只为夹持头顶花洒而设计，不得让其承载其它物品！
不得让儿童和肢体、精神和⁄或意识有障碍的成人在不受监管的情况下使用
淋浴系统。受酒精或毒品影响的人员不得使用淋浴系统。
必须避免让身体敏感部位 (如眼睛) 接触到莲蓬头喷水。必须保持莲蓬头与
人头之间有足够的距离。
该产品不得作扶柄使用。必须安装单独的扶柄。
安装提示
⁄ 安装前必须检查产品是否受到运输损害。 安装后将不认可运输损害或表面
损伤。
⁄ 管道和阀门必须根据通用标准进行安装、冲洗和检查。
⁄ 请遵守当地国家现行的安装规定。
⁄ 本安装说明中所规定的安装尺寸理想用于身高 1700 mm 左右的人士。尺寸
可根据需要进行修改。在这种情况下，您必须留意，如果安装高度改变，
则花洒到地板的最小高度也随之改变，且必须考虑到连接尺寸的改变。
⁄ 该花洒仅允许连接在卫浴龙头或截止阀之后。
⁄ 由有资格的专业人员进行产品安装时请注意：在所有加固区域中，加固表
面是否平整 (无突出的接缝或瓷砖) ，墙体结构是否适合产品安装且未显露
出任何缺点。
⁄ 必须使用预装配好的过滤器芯，以保障手持花洒达到标准水流量并避免从
管网中冲出污物。污物可损害功能和⁄或导致损坏手持花洒的功能件，对由
此所产生的损害汉斯格雅公司将不承担责任。
技术参数
工作压强： 最大 1 MPa
推荐工作压强： 0,25 - 0,45 MPa
(1 MPa = 10 bar = 147 PSI)
热水温度： 最大 60°C
热力消毒: 70°C ⁄ 4 分钟
⁄ 该产品专为饮用水设计！
符号说明
请勿使用含有乙酸的硅胶！
保养 (参见第页 10)
⁄ 单向阀必须在符合国家或当地的法律的情况下按照EN 806-5定期检
查 (至少一年一次) 。
大小 (参见第页 04)
流量示意图 (参见第页 05)
 手持花洒
 顶置花洒
备用零件 (参见第页 11 )
XX = 颜色代码
00 = 镀铬
14 = Brushed Bronze
25 = Brushed Gold-Optic
30 = Polished Redgold
31 = Brushed Redgold
33 = Polished Black Chrome
34 = Brushed Black Chrome
67 = Matt Black
70 = Matt White
80 = Stainless Steel Optic
82 = Brushed Nickel
95 = Brushed Brass
99 = Polished Gold-Optic
选装附件 (不在供货范围内)
匹配瓷砖的圆盘 #94362XXX (参见第页 11 )
清洗 (参见第页 08)
操作 (参见第页 10)
问题 原因 补救
⁄龙头出水量小 ⁄ 水压不足 ⁄ 检查总水压
⁄ 花洒滤网有垃圾堵塞 ⁄ 清洗花洒和软管间的过滤网

03 EN
ASSEMBLY (see page 06)
SAFETY NOTES
Gloves should be worn during installation to prevent crushing and cutting injuries.
The product may only be used for bathing, hygienic and body cleaning purposes.
The arm of the shower head is intended only to hold the shower head. Do not load
it down with other objects!
Children as well as adults with physical, mental and⁄or sensoric impairments must
not use this product without proper supervision. Persons under the influence of
alcohol or drugs are prohibited from using this product.
Do not allow the streams of the shower touch sensitive body parts (such as your
eyes). An adequate distance must be kept between the shower and you.
The product may not be used as a holding handle. A separate handle must be
installed.
INSTALLATION INSTRUCTIONS
⁄ Prior to installation, inspect the product for transport damages. After it has been
installed, no transport or surface damage will be honoured.
⁄ The pipes and the fixture must be installed, flushed and tested as per the applicable
standards.
⁄ The plumbing codes applicable in the respective countries must be observed.
⁄ The installation dimensions stated in these installation instructions are ideal for
people of approximately 1700 mm in body height. The dimensions can be altered
if required. In this case, pay attention to the fact that a change of installation height
will also change the minimum height, and that the altered mounting dimensions must
be taken into consideration.
⁄ The shower may only be connected downstream of a shut-off valve or sanitary
fitting.
⁄ During installation of the product by qualified trained personnel, make sure that the
entire fastening surface is even and smooth (no protruding seams or tile offset), that
the finish of the wall is suitable to apply the product and has no weak points.
⁄ The premounted filter insert must be used to ensure a normal flow of the shower and
to prevent dirt from entering through the pipes. Dirt entering can affect the function
and⁄or lead to damages to the shower. Hansgrohe will not be held liable for this
type of damage.
TECHNICAL DATA
Operating pressure: max. 1 MPa
Recommended operating pressure: 0,25 - 0,45 MPa
(1 MPa = 10 bar = 147 PSI)
Hot water temperature: max. 60°C
Thermal disinfection: 70°C ⁄ 4 min
⁄ The product is exclusively designed for drinking water!
SYMBOL DESCRIPTION
Do not use silicone containing acetic acid!
MAINTENANCE (see page 10 )
⁄ The check valves must be checked regularly according to EN 806-5 in
accordance with national or regional regulations (at least once a year).
DIMENSIONS (see page 04)
FLOW DIAGRAM (see page 05 )
 Hand shower
 Overhead shower
SPARE PARTS (see page 11 )
XX = Colors
00 = Chrome Plated
14 = Brushed Bronze
25 = Brushed Gold-Optic
30 = Polished Redgold
31 = Brushed Redgold
33 = Polished Black Chrome
34 = Brushed Black Chrome
67 = Matt Black
70 = Matt White
80 = Stainless Steel Optic
82 = Brushed Nickel
95 = Brushed Brass
99 = Polished Gold-Optic
SPECIAL ACCESSORIES (order as an extra)
tile-matching-disk #94362XXX (see page 11 )
CLEANING (see page 08 )
OPERATION (see page 10 )
FAULT CAUSE REMEDY
⁄ Insufficient water ⁄ Supply pressure inadequate ⁄ Check water pressure (If a pump has been installed check
to see if the pump is working).
⁄ Shower filter seal dirty ⁄ Clean filter seal between shower and hose

04
939
75 425
565
989
1108
90°
87
Ø69 max.
216
G1/2
Ø69
G1/2
5 °
5 °
Ø282
91
Ø25
30
80°
80°
AXOR One 280 1jet Showerpipe
48790XX7
MontagebeispieleMaße

05
i
bar
4,5
0,0
0,5
1,0
1,5
2,0
2,5
3,0
3,5
4,0
5,0
0,45
0,00
0,05
0,10
0,15
0,20
0,25
0,30
0,35
0,40
0,50
5,50,55
6,00,60
036912151821242730
MPa
00,1 0,2 0,3 0,4 0,5
Q = l/min
Q = l/sec
12
DN 15
DN 15
DN 15
DN 15
45712X X7
48798187
+
48790XX7
2150
min. 2170
1000 939
450
1000
2
1
Montagebeispiele Durchflussdiagramme

06
AXOR One
48798187
1.
2.
3.
1 - 2 mm
Silicone
1.
2.
SW 8 mm
1.
29 - 30 mm
Armaturenfett
Grease
䀵滑油
2.
SW 17 mm
15
X
X
15 X28
15 + X + 28 mm
1 2
3 4
5 6 7
MontageMontage

07
Armaturenfett
Grease
䀵滑油
1.
1.
2.
SW 2,5mm
(4 Nm)
SW 2,5mm
(4 Nm)
2.
1.
1.
2.
8 9 10
11
12 13
Montage

08
CLEANING RECOMMENDATION FOR AXOR PRODUCTS
Today, modern sanitary and kitchen tapware, showers, accessories, washstands, tubs
and radiators consist of very different materials to comply with the needs of the market
with regard to design and functionality.
To avoid damage and reclamations, it is necessary to consider certain criteria when
cleaning.
WITH REGARD TO CARING FOR THE AXOR PRODUCTS,
THE FOLLOWING MUST IN PRINCIPLE BE HEEDED:
⁄ Only use cleaning material which is explicitly provided for this type of application.
⁄ Never use cleaning materials, which contain hydrochloric acid, formic acid, chlorine
pale lye or acetic acid, as they cause considerable damage.
⁄ Phosphorus acidic cleaners are only conditionally applicable.
⁄ Mixing cleaning agents is not permitted, generally.
⁄ Never use cleaning materials or appliances with an abrasive effect, such as
unsuitable cleaning powders, sponge pads or micro fibre cloths.
⁄ The instructions of the cleaning agent manufacturers have to be followed absolutely.
⁄ Cleaning has to be carried out with a specified cleaner dosage, contact time,
object-related and adapted to the needs.
⁄ The building up of calcifications has to be removed by cleaning regulary.
⁄ When using spray cleaners, spray the cleaning solution onto a soft cloth or sponge,
never directly onto the Axor products, as the atomised spray could enter openings
and gaps in the Axor products and cause damage.
⁄ After cleaning rinse thoroughly with clean water to remove any cleaner residue.
⁄ The use of steam cleaners is not permitted. The high temperatures can damage the
products.
IMPORTANT
Residues of toiletries such as liquid soaps, shampoos and shower gels, hair dyes,
perfumes, aftershave and nail varnish can also cause damage.
Here too: Carefully rinse with water after use to remove residues.
Likewise, do not store any cleaning agents or chemicals under the products, for
example in a vanity unit, as the vapours may damage the products.
The damage of already damaged surfaces will deteriorate under the effect of the
cleansers.
COMPONENTS WITH DAMAGED SURFACES
MUST BE EXCHANGED, OTHERWISE THERE
COULD BE AN INJURY DANGER.
Damage caused by improper treatment will not be covered by our guarantee.
WARRANTY
AXOR guarantees to the consumer that this product is free of production faults. If
evertheless any defect is detected within 5 years from date of purchase, AXOR will
remedy this defect free of charge. You will find the conditions and details of this
guarantee at www.hansgrohe-int.com/guarantee. Please contact your contracting
party to claim your rights under this guarantee. This guarantee does not affect the
customer‘s rights under the respective national legislation.
QUICKCLEAN
The QuickClean cleaning function only needs a small manual rub over to remove the
lime scale from the spray channels.
, , , , ,
, .
,
.
, :
⁄ .
⁄ , , ,
.
⁄ .
⁄ .
⁄ , ,
.
⁄ .
⁄ , .
⁄ .
⁄ ,
. ,
.
⁄ , .
⁄ , .
, , , , , ,
.
: .
,
.
.

.
AX
OR , . ,
AX
OR . www.hansgrohe-int.com/guarantee.
.
QUICK
CLEAN
QuickClean, , , .
Reinigung ReinigungReinigung
QUICK
CLEAN

09
> 10 min
max. 10 min
20 mm
max. 10 min
20 mm
> 1 min
1 2 3
4 5 6
1 2 3
4 5 6
Reinigung

10
更加简单 ⁄
easier
更坚固 ⁄
harder
1.
3.
2. 2.
3. 1.
1 2 3
Wartung ServiceteileWartungBedienung

11
94362XX0
94359XX0
94358XX0
94358XX0
94361X X0
95626000
98128000
(13x2)
(M4x8)
92851000
(M5X8)
98387000
(17x2,5)
98387000
(17x2,5)
93774000
94360XX7
95480XX0
28626XX0
94357XX0
93774000
48651XX7
95626000
98128000
(13x2)
(M4x8)
94359XX0
98199000
(17x2)
98129000
(14x2)
98184000
(13x3)
94074000
95392000
98058000
92851000
(M5X8)
AXOR One 280 1jet Showerpipe
48790XX7
Serviceteile Prüfzeichen

08⁄2023 9. 0 8118 . 51
