Axor Terrano 37030XX1 Installation guide

Installation Instructions / Warranty
Terrano
37030XX1
Terrano
37230XX1

2
3
Terrano two handle lavatory mixer
37030XX1
Terrano two handle bidet mixer
37230XX1

2
3
7
1
10
hot cold
3
2
4
5
8
9
11

4
5
Assembly
1. Flush pipe lines thoroughly.
2. Place the mixer including the sealing washer in
position on the basin / bidet.
3. Slip the fixation piece including the washer over
the threaded pin and tighten the nut.
4. Connect the supply pipes to the supply valves:
hot-left; cold-right.
5. Connect the pop-up rod to the pop-up waste
assembly.
Large differences in pressure between the hot and
cold water supply should be balanced.
Technical Data
Operating pressure: max. 147 psi
Recommended operating press.: 14.7 - 72.5 psi
Test pressure: 232 psi
Hot water temperature: max. 176° F
Recommended hot water temp.: 149° F
Hole size in deck:
Minimum: 1 1/4"
Maximum: 1 5/8"
Spare parts (see page 3)
1 Handle for cold/hot water 37299XXX
2 Screw cover cold/hot water 96481XXX
3 Spout lav mixer 96521XXX
4 Aerator lav mixer 96336XXX
5 Stop unit 94149000
6 Lift rod 94006XXX
7 Lift rod extension 96617000
8 Fixation set 96016000
9 Tube 30622210
10 Spout bidet mixer 96522XXX
11 Aerator bidet mixer 94005XXX
XXX = Colors
000 chrome
810 satinox®
Install the pop-up drain
• Remove the plunger assembly.
• Unscrew the drain outlet flange from the tee.
• Unscrew the tailpiece from the tee. Wrap
the threads with plumbers’ thread tape and
replace.
• Install the white, flexible sealing gasket to the
flange. Sit it in the sink outlet.
• From under the sink, install the black mack
gasket, white friction ring , and retainer nut to
the flange. Do not tighten the nut against the
bottom of the sink at this time.
• Thread the tee and tailpiece to the flange. The
pivot must face the faucet. If necessary, turn the
drain assembly.
• Tighten the retainer nut.
• Sit the plunger assembly in the drain.
• Install the horizontal rod so that the end goes
through the loop in the bottom of the height
adjuster.
• Install and hand tighten the pivot ball nut.
• Attach the swivel connector to the end of the
horizontal rod.
• Attach the swivel connector to the end of the
vertical rod. Position as desired, and tighten
with a small, flathead screwdriver.
plunger
height adjuster
drain outlet flange
sealing gasket
mack gasket
retainer nut
tee
pivot ball nut
horizontal rod
swivel connector
friction ring

4
5
Cleaning Recommendation for Hansgrohe Products
Modern faucetry and shower products utilize a combination of materials to comply with the needs of the
market with regard to design and functionality.
To avoid damage, it is necessary to use some caution when cleaning. Damage caused by improper treatment
is not covered under the Hansgrohe warranty.
Cleaning Materials for Faucets and Showers
• To remove lime scale, use only products made specifically for that purpose. Always follow the manufacturer’s
instructions when using.
• Do not use cleaners that contain hydrochloric, formic, acetic, or phosphoric acids, as these will cause
considerable damage to finishes and to plastic components.
• Never mix cleaning materials.
• Never use cleaners containing abrasives. Do not use abrasive cleaning cloths, pads, or sponges.
Cleaning Procedures
• Clean your faucets and shower products as and when required. Regular cleaning will prevent scale
buildup and water spotting.
• Follow the label instructions. Do not allow any cleaner to remain on the product for longer than necessary.
• When using spray cleaners, spray first onto a sponge or cloth – do not spray directly onto the product.
• After cleaning, rinse thoroughly with clear water to remove any cleaner residue.
Important
• Soap and shampoo residue can also cause damage to the product. Rinse well with clean water after use.
• If the surface is already damaged, harsh cleaning materials will cause further damage.

6
7
Limited Lifetime Consumer Warranty
This product has been manufactured and tested to the highest quality standards by Hansgrohe, Inc.
(„Hansgrohe“). This warranty is limited to Hansgrohe products which are purchased by a consumer in the
United States after March 1, 1996, and installed in either the United States or Canada.
WHO IS COVERED BY THE WARRANTY
This warranty extends to the original consumer purchaser only.
WHAT IS COVERED BY THE WARRANTY
This warranty covers only your Hansgrohe manufactured product. Hansgrohe warrants this product
against defects in material or workmanship as follows: Hansgrohe will repair at no charge for parts only
or, at its option, replace any product or part of the product which proves defective because of improper
workmanship and/or material, under normal installation, use, service and maintenance. If Hansgrohe is
unable to provide a replacement and repair is not practical or cannot be timely made, Hansgrohe may
elect to refund the purchase price in exchange for the return of the product.
LENGTH OF WARRANTY
Replacement or repaired parts of products will be covered for the term of this warranty as stated in the
following two sentences. If you are a consumer who purchased the product for use primarily for personal,
family, or household purposes, this warranty extends for as long as you own the product and the home
in which the product is installed. If you purchased the product for use primarily for any other purpose,
including, without limitation, a commercial purpose, this warranty extends only (i) for 1 year, with respect
to Interaktiv and Retroaktiv products, and (ii) for 5 years, with respect to AXOR, ShowerPower and Pharo
products.
THIS WARRANTY DOES NOT COVER, AND HANSGROHE WILL NOT PAY FOR:
A. Conditions, malfunctions or damage not resulting from defects in material or workmanship.
B. Conditions, malfunctions or damage resulting from (1) improper installation, improper maintenance,
misuse, abuse, negligence, accident or alteration, or (2) the use of abrasive or caustic cleaning agents
or „no rinse“ cleaning products, or the use of the product in any manner contrary to the product
instructions.
C. Labor or other expenses for the disconnection or return of the product for warranty service, or for
installation or reinstallation of the product.
D. Accessories or related products not manufactured by Hansgrohe.

6
7
TO OBTAIN WARRANTY SERVICE
Contact your Hansgrohe retailer, or write to Technical Service at:
Hansgrohe Inc.
1492 Bluegrass Lakes Parkway
Alpharetta GA 30004
Or, call Hansgrohe toll-free at [phone].
In requesting warranty service, you will need to provide
1. The sales receipt or other evidence of the date and place of purchase.
2. A description of the problem.
3. Delivery of the product or the defective part, postage prepaid and carefully packed and insured, to
Hansgrohe Inc. 1492 Bluegrass Lakes Parkway, Alpharetta, Georgia 30004, Attention: Technical
Service, if required by Hansgrohe.
When warranty service is completed, any repaired or replacement product or part will be returned to you
postage prepaid.
EXCLUSIONS AND LIMITATIONS
REPAIR OR REPLACEMENT (OR, IN LIMITED CIRCUMSTANCES, REFUND OF THE PURCHASE
PRICE) AS PROVIDED UNDER THIS WARRANTY IS THE EXCLUSIVE REMEDY OF THE PURCHASER.
HANSGROHE NEITHER ASSUMES NOR AUTHORIZES ANY PERSON TO CREATE FOR IT ANY
OBLIGATION OR LIABILITY IN CONNECTION WITH THIS PRODUCT.
HANSGROHE SHALL NOT BE LIABLE TO PURCHASER OR ANY PERSON FOR ANY INCIDENTAL,
SPECIAL, OR CONSEQUENTIAL DAMAGES, ARISING OUT OF BREACH OF THIS WARRANTY
OR ANY IMPLIED WARRANTY (INCLUDING MERCHANTABILITY).
Some States do not allow the exclusion or limitation of incidental or consequential damages, so the above
limitation or exclusion may not apply to you.
This warranty gives you specific legal rights, and you may have other rights which vary from State to
State.
You may be required by law to give us a reasonable opportunity to correct or cure any failure to comply
before you can bring any action in court against us under the Magnuson-Moss Warranty Act.
PRODUCT INSTRUCTIONS AND QUESTIONS
Upon purchase or prior to installation, please carefully inspect your Hansgrohe product for any damage or
visible defect. Prior to installing, always carefully study the enclosed instructions on the proper installation
and the care and maintenance of the product. If you have questions at any time about the use, installation,
or performance of your Hansgrohe product, or this warranty, please call or write to us at the toll-free number
and address printed above.
