Axxera MINI AX550D Operating instructions

INSTALLATION / OWNER'S MANUAL
Mobile Power Amplifiers
MINI SERIES
AX550D

2
INSTALLATION
Preparation
Please read entire manual before installation. Due to the technical nature of
amplifiers, it is highly recommended that your Axxera amplifier is installed by a
professional installer or an authorized dealer.
Before You Start
•Disconnectnegativebatteryterminal.(consultaqualifiedtechnicianfor
instructions)
•Avoidinstallingtheamplifierwhereitwouldbesubjecttohightemperatures,such
asfromdirectsunlight,orwhereitwouldbesubjecttodust,dirtorexcessive
vibration.
•Useextremecautionwhendrillingholestoavoiddamagingfuellinesorexisting
vehiclewiring.
•Allamplifierinstallationsrequirepower,signalandspeakerwires(notincluded).
•Anamplifierinstallationkit(soldseparately)ishighlyrecommendedtofacilitatethe
installation. Consult your dealer for recommendations.
Mounting Location
•Chooseamountinglocationfortheamplifier.Suggestedlocationsincludeundera
seatorinthetrunk.
•Theamplifiercanbemountedhorizontal(recommended)orvertical.Foroptimum
performance,makesuretoprovideatleast1"ofspacearoundallsides.Donot
mounttheamplifierundercarpetsorwhereairflowisrestricted.
•Donotinstalltheamplifierwhereitmaybeexposedtomoisture.
•Theoptimummountinglocationvariesbetweenvehicles.Remembertotestall
amplifier functions before completing the final mounting procedure.
TYPICAL MOUNTING METHOD

NOTE:
Be sure to follow specific instructions included with your amplifier installation
kit (not included with this amplifier). The information below should be used as a
general guideline only.
Power Wire (+12V)
•Disconnectnegativebatteryterminalbeforeproceeding.Consultaqualified
technician for instructions if you are unsure.
•Planwireroutingbeforecuttinganywirestolength.Beginbyroutingthepower
+12Vwirefromthebatterytotheamplifierlocation.Useagrommetwhenrunning
wiresthroughthefirewallormetalopenings.Avoidrunningthepowerwirenear
existingvehiclewiringtopreventinducednoisefromenteringtheaudiosystem.
•Useextremecautionwhendrillingholestoavoiddamagingfuellinesorexisting
vehiclewiring.
•The+12VwireMUSTbefusedwithin18"ofthebatteryforprotectionofthe
vehicle’selectricalsystem.
Ground Wire (GND)
•Theamplifiergroundwireshouldbeasshortaspossible(nomorethan36"or
1meter).Chooseacleanunpaintedsectionofmetalorthevehiclechassiswhen
attachingthegroundconnection.Besuretocleantheareaofanydirtorgrease.
Remote Turn-on Wire (REM)
•Theremoteturn-onwireconnectstotheheadunit'samplifierturn-onleadorpower
antenna output.
Speaker Wires
•Chooseadequategaugespeakerwiredependingonyourexactamplifier/speaker
combination.Besuretoobservepolaritywhenconnecting.
•Donotgroundanyspeakerwiresorconnectanyspeakerwirestogether.
Input Signal
•Theamplifier'sinputsignalconnectstotheheadunit'slowlevel(RCA)orhighlevel
(speakerwire)outputs.
•Lowlevelinputsignalsdeliverthebestperformance.Ifunavailable,usethehighlevel
inputs-wheninterfacingwithfactoryheadunitforinstance.
CAUTION
•Donotusebothlowandhighlevelinputsatthesametime.Connectonlyoneorthe
other.
•Keeplowlevelinputsawayfromanypowerwirestoavoidenginenoise.
•Neverrunanywiresunderneathoroutsidethevehicle.
3
INSTALLATION
Connection Descriptions

High Pass Filter
Crossover Mode
Gain
1
2
3
Low Pass Filter
Bass Boost
2 31
4
5
345
INSTALLATION
Audio Inputs and Controls
4
23 1

Speaker Connections
+12VDC Battery Connection
1
2
Ground Connection
Fuse
3
4
4
13
2
INSTALLATION
Power and Speaker Connections
5

6
INSTALLATION
POWER
SPEAKER WIRE
Fuse Rating
When replacing fuses, make sure new fuse
is the correct type and amperage. Using an
incorrect fuse could damage the amplifier.
AX550D 40A x 1
Power/Ground Wire Size
For optimum performance, use only the wire
size listed below or larger. Make sure to use
the same size power and ground wire.
AX550D 4 Ga.
Main Power Connections
Connect +12V, GND and REM wires accordingly. A suitable fuse MUST be installed
on the +12V lead within 18" of the battery for protection of the vehicle’s electrical
system.
Typical Wire Routing

7
INSTALLATION
High-Level Input
(speaker cables)
Low-Level Input
(RCA)
Speaker Connections
Connect speaker wires observing polarity. The minimum impedance load for the
AX550D is 2 ohms stereo and 2 ohms mono. Use of loads lower than these is not
recommended and may cause amplifier damage.
Input Signal Connections
Low Level Input (RCA)
Low level (RCA) input signal is preferred for best performance. Typical trunk-mount
amplifier installations require a 17-20 foot RCA cable. Most trucks and under-seat
applications require a 6-9 foot RCA cable. Using twisted pair construction RCA
cables will minimize noise.
High Level Input
(Speaker Wire)
High level inputs should only be
used when RCA outputs are not
available from the head unit.
Connect the head unit speaker
outputs to the high level input
connector as shown below. The
black wire (signal reference
ground) may or may not require a
connection to chassis ground
- depending on your particular
installation.
L
R
Note: Do not use both low and high level inputs
at the same time - connect only one or the other.
Amplifier Connections
CHANNELS 1 & 2 CHANNELS 3 & 4
SUBWOOFER
2-8 ohm 2-8 ohm
2-8 ohm

Theinputlevelcontrol(gain)isusedtoobtainthe
bestpossiblematchbetweentheheadunitaudio
outputandtheamplifierinput.Beginbyturningthe
inputlevelcontrolfullycounterclockwise.Next,turn
uptheheadunitvolumecontrolaround3/4of
thewayup.Adjusttheinputlevelcontrolclockwise
until audible distortion is heard, then slightly
counterclockwisetoprovidethebestmatch.
Repeatforallinputlevelcontrols.
Thecrossoverisusedtofilteroutfrequencies
aboveorbelowacertainpoint.ChooseLPFwhen
usingtheamplifierwithsubwoofers,HPFwhen
usingwithmidrange/tweetercombinationsand
FLATwhenusingwithcoaxial-typespeakers.
Note: Choose FLATwhenusingtheamplifierin
stereo/bridgedsimultaneousmode.Inthismode,
passivecrossoversarerequired.Failuretouse
thecorrectpassivecomponentsmaydamage
theamplifierand/orspeakers.Consultaqualified
professional for recommendations.
Thiscontrolallowspreciseadjustmentofthe
crossoverfrequency.
Thiscontrolprovidesadditionalboost@45Hzwhen
usedwithsubwoofers.Adjustthiscontrolwith
caution-asimproperusecandamagespeakers!
Settingthiscontroltothedesiredfrequencywill
limitharmfulfrequenciesbelowthesettingfrom
goingtothesubwoofer(s),preventingpossible
damagefromfrequenciesthatsubwoofersarenot
designed to handle.
ThegreenLEDindicatorilluminatesduringnormal
operation(POWER)andtheredLEDindicator
isvisiblewhentheamplifierdetectsafault
(PROTECT).
Input level Control
Crossover Mode
Crossover
Frequency Control
Bass Boost
Subsonic Filter
LED Indicators
INSTALLATION
Configuration/Setup
8

Problem Cause Action
Unit will not turn
on
(no power LED
indicator)
+12Vwirenotconnectedorincorrect
voltage.REMwirenotconnectedor
incorrectvoltage
Checkconnectionsforproper
voltage(11~16VDC)
GNDwirenotconnected Checkconnectiontoground
Fuse(s)blown Replacefuse(s)
Unit has power -
LED is green (but
no sound)
Speakerwiresnotconnected Checkconnectionsatspeakers
Volumeturnedallthewaydown Increasevolumelevelatheadunit
Oneormorespeakerwirestouching
each other or touching chassis
ground
Insulateallbarespeakerwiresfrom
each other and chassis ground
Speaker(s)defectiveordamaged Check/replacespeaker(s)
Inputsignalnotconnected Checkhighorlowlevelinputsfor
proper connection
Unit blows fuse(s)
Incorrectfuserating Usefuse(s)withcorrectrating
+12Vwiretouchingchassisground Checkforpinchedwire
Speaker(s)defectiveordamaged Check/replacespeaker(s)
Engine noise
Badgroundconnection Makesureamplifierisgroundedto
clean bare metal
SignalgroundlooporRFI(radio
frequencyinterference)
Re-routeRCAcablesfromexisting
highcurrentwiring
LED illuminates
red
(protect mode)
Oneormorespeakerwirestouching
each other or touching chassis
ground
Insulateallbarespeakerwiresfrom
each other and chassis ground
Speaker(s)defectiveor
damagedinternally(shorted) Check/replacespeaker(s)
Speakerloadlessthan2ohms
(stereo).Speakerloadlessthan4
ohms(bridged)
Adjustspeakerload-amplifierwill
not operate at less than 4 ohms
whenbridged
Distorted audio
output
Incorrectinputsignaltypeor
inputleveltoohigh
Checkconnectionsandreduce/
adjustinputlevel
Low audio output Incorrectinputsignaltypeor
inputleveltoolow
Checkconnectionsandincrease/
adjustinputlevel
Weak bass Speaker(s)arewiredoutofphase
Check(+)and(-)speaker
connections
(Observecorrectpolarity)
INSTALLATION
Troubleshooting
9

Channels 1,2,3 and 4
Power [email protected] <1% THD+N
•56 Watts x 4 channels @ 4 Ohms
•79 Watts x 4 channels @ 2 Ohms
•154 Watts x 2 channels @ 4 0hms (bridged)
Peak Music Power Output: 400 Watts
Subwoofer
Power [email protected] <1% THD+N
•400 Watts x 1 channel @ 2 Ohms
Peak Music Power Output: 800 Watts
Total Peak Music Power Output: 1200 Watts
Signal to noise ratio: > 90dB (THD < 0.05% @ 4Ω, 14.4V)
Frequency response: 10Hz -35kHz (-3dB)
Amplifier dimensions: 1.6” (41mm) x 4.7” (119mm) x 10.2” (259mm)
AX550D
INSTALLATION
Specifications

INSTALLATION
One-Year Limited Warranty
Thiswarrantygivesyouspecificlegalrights.
Youmayalsohaveotherrightswhichvary
from state to state.
DualElectronicsCorp.warrantsthisproduct
to the original purchaser to be free from
defectsinmaterialandworkmanshipfor
a period of one year from the date of the
original purchase.
DualElectronicsCorp.agrees,atour
option,duringthewarrantyperiod,torepair
anydefectinmaterialorworkmanship
ortofurnishanequalnew,renewedor
comparableproduct(whicheverisdeemed
necessary)inexchangewithoutcharges,
subjecttoverificationofthedefector
malfunction and proof of the date of
purchase.Subsequentreplacementproducts
arewarrantedforthebalanceoftheoriginal
warrantyperiod.
Who is covered?Thiswarrantyisextended
to the original retail purchaser for products
purchased from an authorized Dual dealer
andusedintheU.S.A.
What is covered?Thiswarrantycovers
alldefectsinmaterialandworkmanshipin
thisproduct.Thefollowingarenotcovered:
software,installation/removalcosts,
damage resulting from accident, misuse,
abuse, neglect, product modification,
improperinstallation,incorrectlinevoltage,
unauthorizedrepairorfailuretofollow
instructionssuppliedwiththeproduct,or
damage occurring during return shipment of
theproduct.Specificlicenseconditionsand
copyrightnoticesforthesoftwarecanbe
foundviawww.dualav.com.
What to do?
1.Beforeyoucallforservice,checkthe
troubleshootingguideinyourowner’s
manual.Aslightadjustmentofany
customcontrolsmaysaveyouaservice
call.
2.Ifyourequireserviceduringthe
warrantyperiod,youmustcarefully
packtheproduct(preferablyinthe
originalpackage)andshipitbyprepaid
transportationwithacopyoftheoriginal
receipt from the retailer to an
authorizedservicecenter.
3.Pleasedescribeyourprobleminwriting
and include your name, a return
UPSshippingaddress(P.O.Boxnot
acceptable), and a daytime phone number
withyourshipment.
4.Formoreinformationandforthelocation
ofthenearestauthorizedservicecenter
pleasecontactusbyoneofthefollowing
methods:
•Callustoll-freeat1-866-382-5476
•E-mailusatcs@dualav.com
ExclusionofCertainDamages:Thiswarranty
isexclusiveandinlieuofanyandallother
warranties,expressedorimplied,including
withoutlimitationtheimpliedwarrantiesof
merchantability and fitness for a particular
purpose and any obligation, liability, right,
claim or remedy in contract or tort,
whetherornotarisingfromthecompany’s
negligence,actualorimputed.Nopersonor
representativeisauthorizedtoassumefor
the company any other liability in connection
withthesaleofthisproduct.Innoeventshall
the company be liable for indirect, incidental
orconsequentialdamages.

DualElectronicsCorp.
TollFree:1-866-382-5476
Monday-Friday,9AM-5PM,EST
www.axxeraaudio.com
©2014DualElectronicsCorp.
NSA1113-V01
Other manuals for MINI AX550D
1
Table of contents
Other Axxera Amplifier manuals

Axxera
Axxera MINI AX460D Installation instructions

Axxera
Axxera MINI AX550D Operating instructions

Axxera
Axxera AX260 Operating instructions

Axxera
Axxera MINI AX460D Operating instructions

Axxera
Axxera MINI AX460D Operating instructions

Axxera
Axxera AXA10D Operating instructions

Axxera
Axxera ULTRA SLIM AX70SM Operating instructions

Axxera
Axxera MINI Series Operating instructions

Axxera
Axxera POWER Series Operating instructions
