AyrKing M-101Y-CP User manual
Seal with tape. Do not staple.
Thank you for your business!
We trust you will find this new Marinator to be efficient and durable.
Please return this completed page. The owner is required to return this
product registration information immediately.
The model and serial numbers are stamped on the nameplate located next to the
machine’s controls. Please print clearly.
-------------------------------------------------------------------------------Second Fold Line---------------------------------------------------------------------------
Place
stamp
here
AyrKing Corporation
2013 Cobalt Drive
Louisville, KY 40299-2417
USA
---------------------------------------------------------------First Fold Line------Seal with tape------Do not staple-------------------------------------------------------------
Store Name: Store I.D.#:
Address:
City: State/Province/Region:
Country: Postal Code:
Telephone: Fax:
Store Owner:
Model: Serial Number:
This page intentionally left blank.
1
AyrKing
Corporation
2013 COBALT DRIVE
LOUISVILLE, KY 40299 USA
www.ayrking.com
TELEPHONE 1-502-266-6270
USA Toll free 1-866-266-6290
FACSIMILE 1-502-266-6274
Tumble Marinator
Operation, Maintenance, Warranty
M-101Y-CP
Read this manual thoroughly before operating machine.
The model and serial numbers are on the data plate mounted on the machine.
Record the model and serial numbers below.
Refer to these numbers in any correspondence with AyrKing Corporation.
Model _______________________________________________________________
Serial Number _______________________________________________________
Note: All procedures listed on these pages are general use guidelines.
Please refer to your company procedures for exact instructions.
2
IMPORTANT SAFETY INSTRUCTIONS
Read all instructions before operating. When using electrical appliances, basic safety precautions must
be followed. Use this appliance only for its intended use as described in this manual. Verify that appliance
is properly installed and electrically grounded by a qualified technician in accordance with local electrical
codes. Do not attempt to repair or replace electrical components. A qualified technician should complete
all servicing to these components. Before performing any service, disconnect the machine’s power
supply. Never wear loose-fitting or hanging garments while using any appliance. Ties, necklaces, etc. may
catch on moving parts possibly causing injury.
CAUTION - Risk of fire and/or electrical shock. Replace only with manufacturer's cord set:
DO NOT SPRAY MACHINE WITH
WATER
Machine is designed to shed water & dust;
however, IT IS NOT WATER PROOF.
3
INITIAL SETUP
1. Plug in unit.
2. The marinator comes pre-set from the factory for the tumble cycle time. If this time
needs to be adjusted, the access panel in front of the timer can be removed. The timer is
located to the right of the start and stop switches.
3. The timer for the marinating cycle will be set for 10 minutes 0 seconds or some other
time period. For example at 10 minutes, the timer relay display would read “1”，“0”，
“0”，“0”. The 1000 setting causes the drum to tumble for 10 minutes 0 seconds. The two
numbers to the left of the center letter represent minutes. The two numbers to the right
represent seconds. The white buttons on the top and bottom of each digit in the timer
relay will change each individual setting. Set the timer to desired operation time.
4. Attach the stainless steel access panel after timer adjustment.
OPERATION
If anything seems unusual during the tumbling process,
press the red stop-button to terminate operation.
1. Rotate drum cover to open position.
2. Open the lid of the drum. Put the raw protein pieces and marinating solution into the
drum.
3. Make sure the gasket is in place. Close the lid of the drum. Rotate the handle so the
inside latch keeps the lid from coming off. Lock the lid in place by rotating the cam
handle down toward the drum cap. Make sure a portion of the top gasket is visible
around the entire perimeter of lid to ensure a good seal with the lid.
4. Rotate drum cover to closed position.
5. Press the green marinating cycle button to start the rotation of the drum.
6. The drum stops rotating after the preset time has expired. Marinating is now complete.
7. Rotate drum cover to open position.
8. Place an unloading pan onto the lower shelf and take the lid off the drum. Manually
rotate drum so that marinated food pours out slowly into pan.
4
MAINTENANCE
1. At the end of the day, remove the drum for cleaning. Wash thoroughly in a sink with soap
and water. Make sure the gasket is cleaned. After the parts have dried, put the machine
back together.
2. Check the gasket each month, replace if damaged.
3. Once a year the machine should be thoroughly inspected. Any damaged components
should be replaced.
PROBLEM SOLVING GUIDE
Problem #1: Marinator will not operate. No response if start button is pressed.
Solution:
A. Verify safety cover is in the closed position.
B. Make sure unit is plugged into power source. Make sure power source is supplying
power. Check if the stop-button is locked in place. If yes, turn the button clockwise to
unlock.
C. Press reset switch inside motor compartment.
D. Check if the relay is damaged. If yes, contact a repair technician.
Problem #2: The Marinator drum slips while turning.
Solution:
Adjust slip clutch.
1. Unplug marinator
2. Remove motor compartment lid
3. Hold motor compartment shaft close to motor with pliers, and turn drive
assembly counter clockwise until it unscrews completely.
4. Set drive piece and motor compartment seal aside.
5. Locate locking ring on front face of slip clutch. Using a flat head screw driver
and hammer, bend all tabs on the locking ring so they are no longer folded over
the slip clutch adjustment nut.
6. Hold motor compartment shaft close to motor with pliers, and using a wrench,
turn the slip clutch adjustment nut ¼ to ½ turn clockwise.
7. Bend 2 tabs on the locking ring back over the slip clutch adjustment nut.
8. Put motor compartment seal in place, and screw in the drive piece removed
earlier.
9. Put motor compartment cover back in place.
10. Test unit to verify it is working correctly.
11. If not, repeat steps
5
PARTS VIEW
CONTACT AYRKING FOR ASSISTANCE
1-502-266-6270
6
PARTS LIST
ITEM PARTNO. TITLE
5002364‐008 Marinatordrumlid
4 5000989 Whitesupportbracketfordrum
6 5004573‐010 Motor,115V,60HZ,42RPM
5004604‐010 Motor,230V,50HZ,42RPM
9 3600071 Marinatorcaster
10 3700016 DigitalTimer
11 B137 Startbutton
12 5000375 Greenstartlight
13 3700014 Redemergencystopswitch
14 5001996‐038 S/Stimercover
16 5002364‐030 Timermountingbracket
17 5001996‐081 MotorCompartmentSeal
18 5001996‐023 Drum
19 5001996‐083 Motormountingbracket
20 5001996‐084 siliconsheetformountingmotor
21 5001996‐041 Resetswitchbracket
22 3550436 Resetswitch
23 B145 A/Clinefilterandreceptacle
24 3550412 8pinrelaybase
25 3550411 8pinrelay,115V
3550418 8pinrelay,230V
26 3550413 Timerbase
27 5004589‐003 Motorcompartmentlid
28 5001996‐085 siliconsheetundermotor
30 5001996‐122 slipclutch/driveassembly
34 5004211‐005 drainpanlocatingrails
35 5004526‐075 Proximitysafetyswitch
37 5001996‐135B DrumCover
38 900080 Marinatorpanwithoutholes
38 200912 Marinatorpanwithholes
5001996‐040 Drumopeninggasketforlid
7
TERMS AND CONDITIONS
DAMAGED SHIPMENTS
Notify carrier in event of damaged shipments, whether apparent at time of
delivery or concealed damage discovered after unpacking. File complaint with the
carrier as the customer will be responsible for collection of damage claims. AyrKing
retains no liability for damaged goods once the goods ship from our dock.
RETURNS
No returns will be accepted without written approval from AyrKing. All returned
shipments must be freight prepaid and are subject to handling or re-stocking charges.
WARRANTY
AyrKing Corporation warrants that the AyrKing Marinator shall be free from original defects in
workmanship and material provided the same has been properly stored, installed, serviced,
maintained, and operated. AyrKing Corporation extends this warranty to the original purchaser
only. This warranty specifically covers the mechanical and electrical components that constitute
the drive system of the machine.
This warranty provides non-prorated replacement of defect components and labor coverage.
This warranty begins on the date of initial use or 60 days from the date of shipment from our
factory, whichever occurs first. The parts warranty is in effect for the period of 12 months. The
labor warranty is in effect for the period of 90 days.
The end user is required to register ownership of this product with AyrKing Corporation by
returning the warranty card supplied with the machine. This warranty shall be null and void if the
product is not immediately registered with AyrKing Corporation.
Notify AyrKing Corporation of any performance failure. Specify model and serial number of the
product when contacting AyrKing. AyrKing personnel will assist in evaluating the cause of
failure, ship any necessary replacement components, and authorize a service agency call.
Replacement components will be provided and shipped at no cost (via least expensive route) to
the end user provided that the end user returns the defective component within two weeks (if
required by AyrKing). AyrKing reserves the right to test and evaluate the failed component to
determine whether the failure is covered by this warranty. If AyrKing does not receive defective
components within two weeks of replacement component shipment (if required by AyrKing) or if
the failure is determined not to be covered under this warranty, AyrKing will invoice the end user
for the replacement component, shipping costs, and labor charges if applicable.
AyrKing Corporation is not responsible for any damages due to removal or any expenses
incurred for installation of replacement component including but not limited to travel time, fuel
charges, etc. AyrKing Corporation is not liable for any other expenses or costs due to the non-
performance of the product including shipping costs on the mandatory return of defective
product or component. The buyer assumes all risks and liability for results of use of product.
This warranty does not apply to products that have been misused, subjected to negligence or
accident, or altered/repaired in any way so as to affect the product’s performance or reliability.
This warranty does not apply to any peripheral components such as lugs, plugs, pans, pots,
baskets, or other items that may be bundled in a package with the Marinator.
