AyrKing SMB Series Installation guide

Seal with tape. Do not staple.
Thank you for your business!
Please return this completed page.
The owner is required to return this product
registration information immediately.
The model and serial numbers are stamped on the nameplate.
Please print clearly.
-------------------------------------------------------------------------------Second Fold Line---------------------------------------------------------------------------
Place
stamp
here
AyrKing Corporation
2013 Cobalt Drive
Louisville, KY 40299-2417
USA
----------------------------------------------------------------First Fold Line------Seal with tape------Do not staple------------------------------------------------------------
-
Store Name: Store I.D.#:
Address:
City: State/Province/Region:
Country: Postal Code:
Telephone: Fax:
Store Owner:
Model: Serial Number(s):

This page intentionally left blank.

AyrKing Corporation
2013 COBALT DRIVE
LOUISVILLE, KY 40299 USA
www.ayrking.com
TELEPHONE [phone]
USA Toll free 1-866-266-6290
FACSIMILE 1-502-266-6274
SMB (Stirrer/Mixer/Blender)
Operation, Maintenance, and Warranty
MODEL NUMBER
NOMENCLATURE:
for Model Numbers
:
SMB7Q360V1H6
SMB7Q360V2H5
SMB8G360V1H6
SMB8G360V2H5
SMB2G140V1H6
SMB2G140V2H5
SMB4Q120V1H6
SMB4Q120V2H5
Read this manual thoroughly before operating machine.
The model and serial numbers are on the data plate mounted on the machine.
Record the model and serial numbers below.
Refer to these numbers in any correspondence with AyrKing Corporation.
Model _______________________________________________________________
Serial Number(s) ______________________________________________________

Note: All procedures listed on these pages are general use guidelines.
Please refer to your company procedures for exact instructions.
IMPORTANT SAFETY INSTRUCTIONS
Read all instructions before operating. When using electrical appliances, basic safety
precautions must be followed. Use this appliance only for its intended use as described in this
manual. Verify that appliance is properly installed and electrically grounded by a qualified
technician in accordance with local electrical codes. Do not attempt to repair or replace
electrical components. A qualified technician should complete all servicing to these
components. Before performing any service, disconnect the machine’s power supply. Never
wear loose-fitting or hanging garments while using any appliance. Ties, necklaces, etc. may
catch on moving parts…possibly causing injury.
CAUTION - Risk of fire and/or electrical shock. Replace only with manufacturer's cord set.
DO NOT SPRAY MACHINE WITH WATER
The MOTOR COMPARTMENT IS NOT WATER PROOF.
OPERATION
(Numbers in parenthesis refer to parts view drawings)
•Place vessel (3) on motor base (2), lining drive shaft (3.1) from vessel up with the motor drive
coupling (5). Pins on the side of the vessel should line up and lock into position on indexing
mounts.
•Attach mixing blade (8) to vessel drive shaft (3.1), spinning on in a clockwise rotation.
•Attach power cord to power supply
•Add liquid to vessel.
•Add dry ingredients to vessel
•Press green start button on timer (10) to begin operation
•Timer can be set to users needs to complete the operation
•Once ingredients are mixed, the volume per vessel should be filled no more than half of each
vessel with the volume of mixed liquid. (The viscosity for the different model will be about the
same as the viscosity of milk (around 3 centipoise)
•At this point the mix can be poured into a separate vessel. To remove vessel, spin the vessel
clockwise and lift straight from the drive coupling.
DAILY CLEANING
•Remove stirrer blade from shaft, wash, rinse and sanitize.
•Remove vessel from motor base. Wash, rinse and sanitize.
•Wipe down motor compartment with cloth and sanitizer. DO NOT SPRAY WITH WATER.

SMB EXPLODED PARTS VIEW

PROBLEM SOLVING GUIDE
Many problems have a simple solution. Please use this guide to help resolve operational
difficulties. Contact AyrKing Corporation if unable to correct any problem.
PROBLEM POSSIBLE SOLUTIONS
Unit does not
turn on.
Make sure unit is plugged into wall. Verify green light on timer is illuminated. If
not, check connection inside motor compartment from power cord to timer board.
Blade not
spinning
Verify motor drive coupling and vessel drive shaft are connected. Verify you
have pressed the green button on the timer. If blade continues to not spin, refer
to above solves.

TERMS AND CONDITIONS
DAMAGED SHIPMENTS
Notify carrier in event of damaged shipments, whether apparent at time of delivery or concealed
damage discovered after unpacking. File complaint with the carrier as the customer will be
responsible for collection of damage claims. AyrKing retains no liability for damaged goods
once the goods ship from our dock.
RETURNS
No returns will be accepted without written approval from AyrKing. All returned shipments must
be freight prepaid and are subject to handling or re-stocking charges.
WARRANTY
AyrKing Corporation warrants that the AyrKing LS Stirrer shall be free from original defects in
workmanship and material provided the same has been properly stored, installed, serviced,
maintained, and operated. AyrKing Corporation extends this warranty to the original purchaser
only. This warranty specifically covers the mechanical and electrical components that constitute
the drive system of the machine.
This warranty provides non-prorated replacement of defect components and labor coverage.
This warranty begins on the date of initial use or 60 days from the date of shipment from our
factory, whichever occurs first. The parts warranty is in effect for the period of 12 months. The
labor warranty is in effect for the period of 90 days.
The end user is required to register ownership of this product with AyrKing Corporation by
returning the warranty card supplied with the machine. This warranty shall be null and void if
the product is not immediately registered with AyrKing Corporation.
Notify AyrKing Corporation of any performance failure. Specify model and serial number of the
product when contacting AyrKing. AyrKing personnel will assist in evaluating the cause of
failure, ship any necessary replacement components, and authorize a service agency call.
Replacement components will be provided and shipped at no cost (via least expensive route) to
the end user provided that the end user returns the defective component within two weeks (if
required by AyrKing). AyrKing reserves the right to test and evaluate the failed component to
determine whether the failure is covered by this warranty. If AyrKing does not receive defective
components within two weeks of replacement component shipment (if required by AyrKing) or if
the failure is determined not to be covered under this warranty, AyrKing will invoice the end user
for the replacement component, shipping costs, and labor charges if applicable.
AyrKing Corporation is not responsible for any damages due to removal or any expenses
incurred for installation of replacement component including but not limited to travel time, fuel
charges, etc. AyrKing Corporation is not liable for any other expenses or costs due to the non-
performance of the product including shipping costs on the mandatory return of defective
product or component. The buyer assumes all risks and liability for results of use of product.
This warranty does not apply to products that have been misused, subjected to negligence or
accident, or altered/repaired in any way so as to affect the product’s performance or reliability.
The faucet screen assembly is excluded from warranty coverage. Nor does this warranty apply
to any peripheral components such as lugs, pans, pots, or other items that may be bundled in a
package with the stirrer.
