AZAMERICA S922 User manual

5,000
Channels Blind Scan
MP3 MP4
DV-OUT
User Manual
HIGH DEFINITION DIGITAL RECEIVER
MEDIA PLAYER

Contents
1
Main Features ...........................................................................................................................3
For your Safety ..........................................................................................................................4
Unpacking .................................................................................................................................5
General Operation ....................................................................................................................5
RCU ..........................................................................................................................................6
Front Panel ................................................................................................................................7
Rear Panel ................................................................................................................................7
GENERAL INFORMATION ..........................................................................................3
Connecting to TV using RCA support .......................................................................................8
Connecting to Digital Amplifier ..................................................................................................8
INSTALLATION ............................................................................................................8
Main Menu ................................................................................................................................9
1. Edit Channel ......................................................................................................................11
1.1 TV Channel List .............................................................................................................11
1.2 Radio Channel List ........................................................................................................13
1.3 Delete All .......................................................................................................................14
2. Installation .........................................................................................................................14
2.1 Antenna Connection ......................................................................................................14
2.2 Satellite List ...................................................................................................................14
2.3 Antenna Setup ...............................................................................................................15
2.4 Single Satellite Search ..................................................................................................17
2.5 Multi Satellite Search ....................................................................................................18
2.6 TP List ...........................................................................................................................19
3. System Setup ....................................................................................................................20
3.1 Language ......................................................................................................................20
3.2 TV System ....................................................................................................................21
3.3 Display Setting ..............................................................................................................21
3.4 Local Time Setting ........................................................................................................21
3.5 Timer Setting .................................................................................................................21
3.6 Parental Lock ................................................................................................................22
3.7 OSD Setting ..................................................................................................................23
3.8 Favorite .........................................................................................................................23
MENU INFORMATION .................................................................................................9

Contents
2
3.9 Audio Descrption Setting ..............................................................................................23
3.10 Other ...........................................................................................................................23
4. Tools ..................................................................................................................................24
4.1 Information ....................................................................................................................24
4.2 Factory Setting ..............................................................................................................24
4.3 Upgrade by USB ...........................................................................................................24
4.4 Media Player .................................................................................................................25
4.5 Remove USB device safely ...........................................................................................26
4.6 Network Local Setting ...................................................................................................26
5. Game ................................................................................................................................26
6. REC ..................................................................................................................................26
6.1 PVR Storage Information...............................................................................................26
6.2 PVR Setting ..................................................................................................................27
7. Hot Key .............................................................................................................................27
7.1 Info ................................................................................................................................27
7.2 EPG ..............................................................................................................................27
7.3 Find ...............................................................................................................................28
7.4 Number .........................................................................................................................28
7.5 TV/RADIO .....................................................................................................................28
7.6 Up/Down (Channel Change) .........................................................................................28
7.7 Left/Righ (Volume+/-) ....................................................................................................28
7.8 Mute ..............................................................................................................................28
7.9 Pause ............................................................................................................................28
7.10 OK ..............................................................................................................................29
7.11 Audio ...........................................................................................................................29
7.12 Recall ..........................................................................................................................29
7.13 FAV .............................................................................................................................29
7.14 Teletext .......................................................................................................................30
7.15 Zoom ...........................................................................................................................30
Trouble Shooting ......................................................................................................31

3
General Information
■ MPEG4 HD
■ Twin tuner
■ Smart Card Reader
■ SCPC and MCPC receivable from C/Ku band satellite
■ FULL HD 1080P
■ 5000 channels TV and radio program-mable
■ 8 different favorite groups selection
■ Multi-language OSD
■ Electronic Program Guide (EPG)
■ Picture in Graphics(PIG) support
■ 256 color On Screen Display
■ Automatic network search for newly added transponders
■ DiSEqC 1.2 fully support, 13/18V, 0/22K
■ Various channel editing functions (favorite, moving, locking, renaming, deleting, and sorting)
■ Parental control for channels
■ Easy to use Menu System
■ Timer Reservations, automatically switch to a specific channel
■ Automatic save for last channel
■ Channel list can be sorted by alphabetic A-Z, Scramble, Favorite, Lock, Sat
■ Support FAT 13/FAT32/FAT12/NTFS
■ Software update by USB
■ JPEG viewer
■ Media Player
■ MP3, MP4, wav support
A Digital Satellite Receiver is a convenient product that allows you to view a variety of programs
provided through satellite. This user's guide covers the installation of the DSR and the neces-
sary steps to implement various features. This also explains special features available only in
this DSR in detail, which will allow you to make full use of these feature.
Information confirmed in this document is subject to change. We reserves the right, without
notice, to make change in product design or performances as progress in engineering or
technology.
Main Features
3

General Information
4
Main Features
1. To avoid electric-shock hazards, do not open the
cabinet, refer servicing to qualified personnel only.
2.Keep the receiver away from flower vases, tubs,
sinks, etc., in order to avoid damaging the equipment.
3. Do not expose the receiver un-der the sunlight. And
keep it away from the heat source.
4. Do not block ventilation holes of the Receiver so that
air can circulate freely.
5.When the abnormal phenomenon occur, you should
cut off the power immediately.
6. Do not touch the receiver during thunder, since that
might create electric-shock hazards.
7. Switch the receiver off whenever it remains out of
service for an extended period.
8. Be sure to turn the Receiver off and disconnect the
AC power cord before cleaning the Receiver surface.
If the surface is dirty, wipe clean with a cloth which has
been dipped in a weak soap-andwater solution and
wrung out thoroughly, and then wipe again with a dry
cloth.

5
General Information
Unpacking
1. Throughout this manual you will notice that the everyday operation of the receiver is based on
a series of user friendly on screen display and menus. These menus will help you get the most
from your receiver, guiding you through installation, channel organizing, viewing and many other
functions.
2. All functions can be carried out using the buttons on the RCU, and some of the functions can
also be carried out using the buttons on the front panel.
3. The receiver is easy to use, always at your command and adaptable for future advances.
4. Please be aware that new software may change the functionality of the receiver.
5. Should you experience any difficulties with the operation of your receiver, please consult the
relevant section of this manual, including the Problem Shooting, or alternatively call your dealer
or a customer service adviser.
General Operation
Remote Control Guide Audio / Video cable

General Information
6
RCU
key Function
Turns power ON/OFF of the DSR
When watching a channel, mute the sound
Enter number of the required menu item or
select a channel number to watch
Switches between TV and Radio mode
Switches back to previous channel
Displays the favorite group list
Timeshift function key
Display the Find window
Show information of the current channel
Press this key one time to run menu on screen
Moves up / down a page in the list
Executes the selected item in the menu screen
or enters the desired value in any input mode
When watching a channel, change channels or
move to the next higher or lower item in the menu
When watching a channel, adjust the volume or
move to the left or right item in the menu
Return to the previous menu on the menu
screen or escape from the menu
Call up the EPG (Electronic Program Guide)
Display the Audio window.
Switch between TV and AV modes
Switch to teletext or subtitle mode
Enter into the zoom in mode
Press once to pause the screen picture,
press once again to go to the normal mode
Enter into the sleep in mode
Enter into the nine-pictures mode displayed on
the screen
Record the program
Play and stop the program
Press to fast Forward or fast backward
Press to slow forward or slow backward
Display the satellite list.
0~9
TV / RADIO
FAV
SHIFT
FIND
INFO
MENU
PAGE+,PAGE-
OK, LIST
PR+,PR-
EXIT
EPG
TV / AV
TXT
ZOOM
PAUSE
SLEEP
RECORD
SAT
PR
L
R
,

7
General Information
Front Panel
Rear Panel
LNB 1 IN : CONNECT TO SATELLITE ANTENNA
LNB 1 OUT : CONNECT TO THE OTHER RECEIVER
CONNECT TO AUDIO R/L TO
TV OR AUDIO TUNER
CONNECT TO APC FOR S/W UPGRADE
POWER ON/OFF
CONNECT TO FOR DIGITAL A/V
CONNECT TO A DIGITAL AMPLIFIER
CONNECT Y / Pb / Pr TO TV USING 3RCA JACK
CONNECT TO THE INTERNET
LNB 1 OUT
LNB 1 IN
LNB 2 OUT
LNB 2 IN
Y
VIDEO
Pb
L
Pr SPDIF DV-OUT LAN USB
POWERRS232
R
175V-250V
50Hz/60Hz
Max.40W
MADE IN CHINA
LNB 2 IN : CONNECT TO SATELLITE ANTENNA
LNB 2 OUT : CONNECT TO THE OTHER RECEIVER
CONNECT TVIDEO TO TV USING RCA JACK
CONNECT TO USB FOR
S/W UPGRADE OR
PVR FUNCTION
