B.E.G. RC-plus next 230 ZW User manual

B.E.G.
Installation instructions and instructions of use
SMARTHOME RC-plus next 230 ZW
GB
1. SMARTHOME
Wireless Motiondetector, Type RC-plus next 230 ZW ,
Part No. 92066 white, Part No. 92074 black
2. How the device works
D D
+
D = max 100 m D = max 30m
230°
20 m
20 m
6 m
2,50 m
4 m
1
3
2
3. Suitable installation locations
–15°C
+50°C
quer zum Melder gehen
frontal zum Melder gehen
Unterkriechschutz
Walk at right angles to the detector
Walk towards the detector
Creep-zone protection
1
2
3
4. Installation
1
3
2
Connector base Cable entry point
min. 0,5 m
TEST
16
12
84
15s 30s
1
1,5 2 3 5 6 7 10
+-
21
10°
3
Programming
button
4
Click
Bild-BA-RC-plus-next-230-ZW_050913_GB.indd 1 05.09.2013 10:01:14

6. Initializing/resetting the device

1:4
1.
0.5
0.25
Futura Book 24Pt
>3 sec. =
2. Group Master
Slave Slave
Home ID x
Home ID x Home ID x
Slave
Home ID x
L
N
E1
5. Connecting the device
L
N
E1










L
N
L΄
΄΄΄LN
C1
E1
L’ for connecting consumers
when using the internal relay.
Creating groups: Please refer to the MyControl operating instructions
7. Taking the device into operation
A) Connection with MyControl
5 sec. 10 sec. 15 sec. 20 sec. 25 sec. 30 sec. 35 sec.
Home ID x
Time
LED-Status
Slave
Slave
Home ID x
(Registration
of additional
control devices
possible)
Max!
1.
2.
<1 sec.
Registration priority
1. Master (MyControl)
2. Actuators
3. Motion/presence detectors

1. Connecting devices
Connecting 00
>
>
Master
Home ID x
Connecting
Training mode active!
Bild-BA-RC-plus-next-230-ZW_050913_GB.indd 2 05.09.2013 10:01:15

2. Group
Master
Slave Slave
Home ID x
Home ID x Home ID x
8. Function test
1. Actuator switching on motion and
presence detectors
2. Testing mode on the device
Active
2 Sec. 2 Sec.
3. Testing mode using the remote control
fAttention: The LUX potentiometer may not be set
to (factory program).
!
30
min
15
min
1000
Lux
500
Lux
min
5Alarm
min
1min
2
1
TEST
+ –S
Lux
300
Lux
50
Lux
10
B.E.G. LUXOMAT®
10
min
S
LED
IR-SMARTHOME
B.E.G. LUXOMAT®
1CH
2 CH
RESET
30
min
15
min
1000
Lux
500
Lux
min
5Alarm
min
1min
2
1
TEST
+ –S
Lux
300
Lux
50
Lux
10
B.E.G. LUXOMAT®
10
min
S
LED
IR-SMARTHOME
B.E.G. LUXOMAT®
1CH
2 CH
RESET
Creating groups: Please refer to the MyControl operating instructions
9. Device Settings
1. Resetting settings
Or with IR-SMARTHOME using
30
min
15
min
1000
Lux
500
Lux
min
5Alarm
min
1min
2
1
TEST
+ –S
Lux
300
Lux
50
Lux
10
B.E.G. LUXOMAT®
10
min
S
LED
IR-SMARTHOME
B.E.G. LUXOMAT®
1CH
2 CH
RESET
30
min
15
min
1000
Lux
500
Lux
min
5Alarm
min
1min
2
1
TEST
+ –S
Lux
300
Lux
50
Lux
10
B.E.G. LUXOMAT®
10
min
S
LED
IR-SMARTHOME
B.E.G. LUXOMAT®
1CH
2 CH
RESET
Settings with
Or may be set manually with &
& works program = 5 min. & 300 Lux
or
30
min
15
min
1000
Lux
500
Lux
min
5Alarm
min
1min
2
1
TEST
+ –S
Lux
300
Lux
50
Lux
10
B.E.G. LUXOMAT®
10
min
S
LED
IR-SMARTHOME
B.E.G. LUXOMAT®
1CH
2 CH
RESET
fProgramming concluded!
i
fNote: Selecting "+" (very high sensitivity) may re-
sult in the wireless detector triggering incorrectly.
The "S" setting (standard) is recommended for
normal applications.
fGreater sensitivity does not extend the detection
range.
i
Outdoors
Indoors
Very high
sensitivity
fAttention: The repeater function is not
active in testing mode!
!
Setting the range over IR Smart Home
B) Connection without MyControl
5 sec. 10 sec. 15 sec. 20 sec. 25 sec. 30 sec. 35 sec.
RC-plus next
230 ZW
Home ID x
LED-Status
Time
LED-Status
Slave
Master
Home ID x
Slave
Home ID x
(Registration
of additional
control devices
possible)
Max!
1. Connecting devices
<1 sec. = Training mode
1.
2.
<1 sec.
Registration priority
1. Master (RC-plus next ZW)
2. Actuators/repeaters
3. Motion/presence detectors

Training mode active!
Bild-BA-RC-plus-next-230-ZW_050913_GB.indd 3 05.09.2013 10:01:16

LED function display during the self-testing cycle (approx. 60 s)
Function Zone left LED1 (red) Zone right LED2 (red) Zone UKS LED3 (red) Programming-LED (red)
Self-testing cycle reprogrammed
after power from the mains has
been switched on
All 3 LEDs ash simultaneously
Self-testing cycle reprogrammed
after power from the mains has
been switched on
LEDS ash rapidly
Self-testing cycle double-locked
after power from the mains has
been switched on
All 3 LEDs will each ash at one-second intervals for 80 ms
LED function display during operation
Motion detection LED will ash when a motion is
detected
LED will ash when a motion is
detected
LED will ash when a motion is
detected
Party mode active Red and green LEDs will ash alternately for 0.5s
Registration LED will ash during the registra-
tion process
Initialization
The LED will light up continuous-
ly after successful initialization
(key pressed for longer than 3 s)
until it is released
IR command The 3 LEDs will ash once
11. LED function display
2. 1CH/2CH channel settings
Option 1 (1CH)
1CH
Simultaneous Switching
Mains Switching
Wireless - Lux and Motion
Target brightness value
Day mode: Light sensor inactive, switches at every brightness /
Night mode: Very low activation value of around 10 lux
Automatic reading in of the current light value as the new target light value
Continued running time
Permanently deactivate the LEDs on the device
12-hour party mode: Light on for 12 hours
Activating testing mode when closed
Deactivation: Press reset
Resetting when closed
End testing mode
Accept standard settings
Switch light on/off
1CH mode
Alarm function
This key opens the detector to allow the following functions to be programmed.
Attention: The detector will be automatically closed
• each time the power is switched back on
• or after 3 min.
Condition is changed, „closed“.
The white LED will flash every 0.5 seconds in the first 5 seconds.
Sabotage prevention may be activated during this time.
Permanent sabotage prevention
First open the device, then close the device, LED will light up for 5 seconds
Sabotage prevention may be activated during this time. Either carry out a reset
(see Point 4) or proceed as follows to exit this mode:
1. Interrupt the power
2. Apply power for 31 to 59 seconds
3. Interrupt the power again
4. Apply power
5. Open the detector
max
50
Lux
1500
Lux
ON
OFF
t < 5 s
10
Lux


min
1


1CH
Ala rm
10. remote control IR-SMARTHOME
Unlocking the device
or
or
or
to
optional or
Locking the device
Deactivate LEDs
Permanent sabotage
prevention
10
Lux




Reset when open:
Deletion of all values
set with the remote
control, potentiometer
settings will apply.
max
50
Lux
1500
Lux
ON
OFF
t < 5 s
max
50
Lux
1500
Lux
ON
OFF
optional
30
min
15
min
1000
Lux
500
Lux
min
5Alarm
min
1min
2
1
TEST
+ –S
Lux
300
Lux
50
Lux
10
B.E.G. LUXOMAT®
10
min
S
LED
IR-SMARTHOME
B.E.G. LUXOMAT®
1CH
2 CH
RESET
2C H
1
Bild-BA-RC-plus-next-230-ZW_050913_GB.indd 4 05.09.2013 10:01:17

Top limit Bottom limit Delay time
>200 Lux 30 s
<200 Lux >100 Lux 15 s
<100 Lux >50 Lux 7 s
<50 Lux Immediate activation
B.E.G.‘s Smarthome devices may not be opened! Please contact Brück
Electronic GmbH in the event of a fault with your device.
13. Technical data 14. Important information
!
Please stay within the specied power limits with connected consumers so
as to prevent Smarthome actuators from overloading.
Overloading may destroy the devices, result in personal injury and may
even cause re.
!
Brück Electronic GmbH (B.E.G.) herewith declares that the devices described meet the fundamental requirements
and full other relevant regulations set out in the R&TTE Directive 1999/5/EC.
The full declaration of conformity is available at:
http://www.luxomat.com
under "Support" in the "Download" section
Brück Electronic GmbH
Schlosserstraße 30
51789 Lindlar
Please do not plug several Smarthome plug socket actuators behind each
other into a single plug socket.
!
Take the device immediately out of operation should it become defective or
if damage becomes apparent!
!
Article may only be installed by a qualied electrician!
!
Recommended
mounting height: 2 - 3 m
Transmission and
reception frequency: 868,42 MHz
Transmission power: <10 mW
Transmission and
reception range
(open area): max. 100 m
Lux values: 2 - 2500Lux
Time setting: 15 sec. - 16 min./ test
Dimensions: L 121 x W 71 x H 85mm
Declaration: The product meets the Low
Voltage Directive 2006/95/EC and the EMC
Directive 2004/108/EC.
Sensor and power supply in one case
Voltage: 230 V~ ±10 %
Terminals: for single core
conductors
Ambient temperature: -15°C - +50°C
Power consumption: < 0,5 W
Protection class: 2
Protection: IP54
Settings: Rotary control or
remote control
Detection range: 230°, additionally
360° Under-creep
protection function
Range: ca. 20 m
MAN-SM 7727 –050913–1
12. Delay times
The device has various delay times for the change between light and dark
in order to prevent repeated switching on and off at light values that are close to the switching values.
