B meters HYDRODIGIT-S1 User manual

EN
HYDRODIGIT-S1
Digital single jet smart meter
OPERATING INSTRUCTIONS

2User Manual v1.4.5HYDRODIGIT-S1
INDEX
INDEX 2
CONTENT 3
DESIGN 3
DEVICE DIAL 4
FUNCTIONALITY 5
VERSIONS 5
PACKAGING CONTENT 5
ENVIRONMENTAL CONDITIONS 5
SAFETY INSTRUCTIONS 6
INSTALLATION REQUIREMENTS 8
OPERATION 9
DISPLAY 9
DELIVERY STATUS 9
OPERATING MODE - RADIO ACTIVATION 9
RADIO PARAMETERS 9
DEVICE DISPLAY LOOP 12
ERROR MESSAGE 13
BATTERY AND REPLACEMENT PROCEDURES 14
INFORMATION FOR CORRECT DISPOSAL OF THE PRODUCT 15
TRANSLATION 15
TECHNICAL DATA 16
DECLARATION OF CONFORMITY 17
MANUFACTURER ADDRESS 18

3User Manual v1.4.5HYDRODIGIT-S1
Size mm
in
15
(1/2”)
15
(1/2”)
20
(3/4”)
L mm 80 110 130
B mm 85 85 85
I mm 160 190 228
D Threading in 3/4” 3/4” 1”
H mm 73 73 73
h mm 18 18 18
L
I
B
H
D
h
CONTENT
DESIGN
According ISO4064

4User Manual v1.4.5HYDRODIGIT-S1
SK19-MI001-SMU058
MAP16 U0-D0 ∆P 63
M21
1383
060000001
2031
IP68
2021
R250H
Q
3
2,5
R160VH
DIGIT-S1
T50
Radio activation icon
End life alarm
Conguration
Mode
Historical
data
Measurement
unit
Volume
(8 digits)
Serial Number
Instant owrate
Reverse ow
indication
Test mode
CE marking
Approval
number
Manufacturer
Maximum
admissible
pressure
Temperature
class
Model
End-life
expiration year
IR interface
Manufacturer address
Q3 meter
value
Measuring
class/Permitted
position of
installation RxxH:
horizontal installation
RxxV: vertical installation
RxxVH: vertical and
horizontal installation
Manufacturing
year
DEVICE DIAL

5User Manual v1.4.5HYDRODIGIT-S1
FUNCTIONALITY
The water meter HYDRODIGIT is a single jet water meter with digital display and inductive rotation detection,
anti-magnetic.
It is available for both cold and hot water.
VERSIONS
The device is available in four versions:
• Wireless MBUS compatible
• Wireless MBUS v4 (COMBO, output conguration Wireless MBUS v4 only)
• LoRaWAN (COMBO, output conguration LoRaWAN only)
• LoRaWAN + Wireless MBUS v4 (COMBO, output conguration LoraWAN + Wireless MBUS v4)
PACKAGING CONTENT
• Hydrodigit water meter
• Connection gaskets*
• Connectors*
• Seal*
*if ordered with the meter
ENVIRONMENTAL CONDITIONS
• Storage: from -20°C to +70°C
• Operating: from +1°C to +55°C
• The storage period must not exceed 1 year
• The water meters are precision devices and must be protected from shocks and vibration

6User Manual v1.4.5HYDRODIGIT-S1
SAFETY INSTRUCTIONS
Warning: this symbol highlights the instructions to be strictly followed for the correct functioning
of the smart water meter.
Danger: Items marked with this symbol contain information that must be followed carefully to
avoid dangerous situations.
Notes: the notes indicated by this symbol contain suggestions to keep in mind when using the
smart water meter.
Read all the instructions carefully before proceeding with the installation! Failure to comply with
one or more procedures contained in the manual can be dangerous and cause damage to things
and people.
It is recommended to comply with all applicable safety and accident prevention laws.
Follow nationwide regulations regarding water measurement.
Follow the technical requirements relating to the installation of electrical equipment.
The instrument complies with the requirements of the European Council Directive 2014/30/
EU on electromagnetic compatibility, the Directive 2014/35/EU on electrical safety and the RED
Directive 2014/53/EU.
The warranty and correct functioning are void if the identication plate and seals applied to the
instrument are removed or damaged.
It is forbidden to transport instruments with an active radio interface by air.
To clean the instrument externally, use a soft cloth moistened with water. Do not wash with high
pressure jets or immerse the device in water. Avoid contact with oils and solvent. Do not use
alcohol or detergents.
Remove the instrument from the packaging only at the time of installation to protect it from
damage and dirt.
If multiple instruments are installed in a unit, the installation conditions must be the same for all
instruments in order to ensure the most equitable billing of consumption possible.
Carefully observe the instructions in the data sheet, instruction manual, application notes
and lid. Failure to comply with the operating conditions may lead to situations of danger and
forfeiture of all claims for liability for defects as well as liability based on any warranty.
For more information visit www.bmeters.com.
Dispose of replaced instruments and defective components in accordance with the
environmental regulations in force.

7User Manual v1.4.5HYDRODIGIT-S1
Do not damage the device casing. In case of impact with external objects, the device can be
irreparably damaged and lose the IP65 or IP68 degree of protection. Install in areas protected
against impact. In case of breakage of the protective casing, contact customer support.
The water meter is not suitable for central heating and cooling systems. The water meter is
suitable for drinking water only.
Pay attention to sharp or edgy protrusions in threads, anges and measuring tubes. In this
regard, it is recommended to wear protective gloves.
After installing the water meter, perform a leakage test on the system.
Install or disassemble the meter only after depressurizing the system.
The meter does not have protection against lightning.
Do not expose the instrument to sunlight and other heat sources. Do not throw in the re.
The device must be used in a way that minimizes the potential for human contact during normal
operation. In order to avoid the possibility of exceeding the RF exposure limits, human proximity
to receivers with an integrated antenna should not be less than 20 cm (8 inches) during normal
operation.
Keep out of the reach of children.
The device does not require special protection against electrical interference; however,
electromagnetic interference must be avoided.
If transmission network interfaces are used, especially when cables are routed outside the
building, use increased protection against electrical interference.
If there is a possibility of frosting, empty the system and, if necessary, remove the meter.
Rinse the pipes thoroughly before installing the meter.
The meter must be installed with the direction of the arrow (visible on the lower part of the device)
matching the ow direction.
Avoid collecting air in the meter during the installation process.
The meter must not be subjected to mechanical strain when installed in the pipeline.
Install the meter in order to be protected from all impurities and contamination.
Remove the old gaskets and clean the sealing surfaces.
Grease sealing surfaces (use acid-free, potable water approved grease).
The device may only be installed in frost-free areas.

8User Manual v1.4.5HYDRODIGIT-S1
Fit only the supplied seals (seals must not obstruct the pipeline). The seals supplied must be t for
purpose and comply with local guidelines and directives. No liability is accepted for consequential
damages resulting from the use of third party seals, such as corrosion of sealing surfaces and
threads.
Clamp the meter ttings on both sides at the same time by hand and then tighten in opposite
directions using a suitable tool.
Slowly ll the piping with water after the installation is complete.
The meter must be protected against pressure shocks in the pipeline.
Problem Cause Solution
Display off The batteries may be damaged or
discharged. Report to the after-sales service
Damaged casing Possible external impact or fall to the
ground Report to the after-sales service
Lower case body separated from
electronic unit
Tampering by third parties or strong
external impacts Report to the after-sales service
Open and visible electronic unit Tampering by third parties or strong
external impacts Report to the after-sales service
Consumption is not accounted
Tampering by third parties, strong
external impacts or damage to the
ow detection sensor
Report to the after-sales service
No radio transmission
Failure to pass 5 liters or the
batteries may be damaged or
discharged.
Report to the after-sales service
Error '_ _ _ _L Err'
on the display
Possible leaks in the water network /
system / taps.
Check for leaks in the water supply /
system / tap
Error '_ _ _ _O Err'
on the display
Range higher than Q4 for 10
consecutive minutes.
Check the water supply and the
installation of the meter
Error '_ _ _ _I Err'
on the display
Continuous reverse ow greater than
20 liters
Check the water supply and the
installation of the meter
INSTALLATION REQUIREMENTS
All the versions of the water meter can be installed both horizontally and vertically. For a better performance
it is preferable, however, the horizontal installation, with the turbine axis perpendicular to the ground and the
reading mechanism facing upwards.
The table below displays the troubleshooting procedures:

9User Manual v1.4.5HYDRODIGIT-S1
OPERATION
Note: the following display pictures are given as example.
DISPLAY
DELIVERY STATUS
The factory setting is the energy saving mode. In this mode the radio transmission function is not yet
activated, in order to save battery power during shipping and stock. However, the device can account the
consumption and send, if any, errors (e.g. reverse flow for incorrect installation).
OPERATING MODE – RADIO ACTIVATION
Once the water meter is installed, the radio transmission activates automatically after +/- 5 liters of water
passed through the device (LoRaWAN: starts sending Join requests – wM-BUS: radio is activated).
The display changes and the flow direction/level appear if the flow rate is detected.
RADIO PARAMETERS
Wireless MBUS compatible
As soon as radio operation mode is activated, the meter sends a radio telegram according to Wireless MBUS
T1 mode (unidirectional transmission).
Preconfigured Radio parameters (AMR Mode):
• Transmission frequency: every 200 seconds (current values).
• Transmission intervals: every day, from 0 to 24 h.
• Encryption: disabled (default).
• No historical data.
• Transmitted data: volume, actual date and time, reverse flow, alarms.
Radio transmission status
End-of-life warning
(if it appears,
replace the
whole device)
Measurement
unit
Main display (m3),
internal decimal places (litres)
Flow rate level (appears
when a ow rate is detected)
Backward ow (appears
when a negative ow is
detected)

10 User Manual v1.4.5HYDRODIGIT-S1
It is possible to change the configuration parameters into Walk-By mode with an USB to IR interface (B
METERS mod. UC-Cable) and the B Metering software.
Walk-By mode parameters:
• Transmission frequency: every 60 seconds (current values).
• Transmission interval: every day from 6 to 20.
• Encryption: enabled/disabled.
• Historical Data (12 months).
• Transmitted data: volume, actual date and time, reverse flow, alarms, leakage alarm date, fraud alarm date
(Qmax overflow or Backward flow detection).
Wireless MBUS v4 (COMBO, output conguration Wireless MBUS only)
As soon as radio operation mode is activated, the meter sends a radio telegram according to Wireless MBUS
v4, T1 mode (unidirectional and synchronous transmission).
Preconfigured Radio parameters (AMR and synchronous Mode OMSv4 compliant):
• Transmission frequency: every 200 seconds (current values).
• Transmission interval: every day, from 0 to 24 h.
• Encryption: disabled (default).
• No historical data.
• Transmitted data: volume, actual date and time, reverse flow, alarms.
It is possible to change the configuration parameters into Walk-By mode with an USB to IR interface (B
METERS mod. UC-Cable) and the B Metering software:
• Transmission frequency: configurable (minimum 60 seconds).
• Transmission interval: from Monday to Sunday, maximum 12 hours per day (time span can be selected
freely).
Possibility to select a 24-hours time span with the following mandatory conditions:
 Transmission frequency: > 300 seconds (synchronous)
 Historical data disabled.
• Encryption: enabled/disabled.
• Historical data (12 months).
• Transmitted data (depends on the selected parameters): volume, date and time, reverse flow, alarms,
leakage alarm date, fraud alarm date (Qmax overflow or backward flow detection).
LoRaWAN (COMBO, output conguration LoraWAN only)
As soon as radio operation mode is activated, the meter sends join requests to the Network Server where it
has been provisioned, according to LoRaWAN transmission standard.
During this process, the radio icon on the display will blink every second. If the procedure is successful, the
icon will remain active and stable, otherwise it will turn off.

11 User Manual v1.4.5HYDRODIGIT-S1
Preconfigured radio parameters:
• Transmission frequency: every 12 hours (current values).
• Transmission interval: 7/7d, 0/24h.
• Transmitted data: volume, reverse flow, diameter, medium, alarms
It is possible to change the configuration parameters into Walk-By mode with an USB to IR interface (B
METERS mod. UC-Cable) and the B Metering software:
• Transmission frequency: every 6 hours (current values)
• Temperature data sending
• Transmitted data: volume, reverse flow, diameter, medium, alarms, temperature (if enabled)
• ABP mode and relative keys
LoRaWAN + Wireless MBUS v4 (COMBO, output conguration LoraWAN + Wireless MBUS OMSv4)
As soon as radio operation mode is activated, the meter sends join requests to the Network Server where it
has been provisioned, according to LoRaWAN transmission standard. Moreover, it enables the transmission
based on the Wireless M-BUS v4 mode T1 (unidirectional but asynchronous transmission) standard.
During this process, the radio icon on the display will blink every second. If the procedure is successful, the
icon will remain active and stable, otherwise it will turn off.
Preconfigured radio parameters (LoRaWAN):
• Transmission frequency: every 12 hours (current values).
• Transmission interval: 7/7d, 0/24h.
• Transmitted data: volume, reverse flow, diameter, medium, alarms
Preconfigured radio parameters (wM-Bus):
• Transmission frequency: every 60 seconds (asynchronous).
• Transmission interval: from Monday to Friday, from 8 to 18 h.
• Encryption: disabled
• Historical data (12 months)
• Transmitted data volume, date and time, reverse flow, alarms, leakage alarm date, fraud alarm date (Qmax
overflow or backward flow detection).
It is possible to change the configuration parameters into Walk-By mode with an USB to IR interface
(B METERS mod. UC-Cable) and the B Metering software:
LoRaWAN:
• Transmission frequency: every 6 hours (current data)
• Temperature data sending
• Transmitted data: volume, backward flow, diameter, medium, alarms, temperature (if enabled)
• ABP mode and relative keys

12 User Manual v1.4.5HYDRODIGIT-S1
wM-Bus:
• Transmission frequency: configurable (minimum 60 seconds).
• Transmission interval: from Monday to Sunday, maximum 12 hours per day (time span can be selected
freely).
Possibility to select a 24-hours time span with the following mandatory conditions:
 Transmission frequency: > 300 seconds (synchronous)
 Historical data disabled.
• Encryption: enabled/disabled.
• Historical data (12 months).
• Transmitted data (depends on the selected parameters): volume, date and time, reverse flow, alarms,
leakage alarm date, fraud alarm date (Qmax overflow or backward flow detection).
DEVICE DISPLAY LOOP
Device display Display time Example description
10 seconds
Consumption: 12,561 m³
Flow: present
Radio: activated
2 seconds
Firmware version Fu_01_01
(In the “COMBO” version, “Combo
002” will be displayed)
2 seconds Display test “ALL ON”
2 seconds Display test “ALL OFF”
2 seconds Error message

Error Type Descrizione Activation Troubleshooting Reset Radio telegram
I_ _ _ _ Err Backow Reverse ow detected, a ow in
opposite direction is detected.
The error activates after continuous
reverse ow higher than 20 liters.
Check water network and the
meter installation.
Reset the alarm via LoRa
downlink (if in LoRa version) or
directly on eld with IR interface
and B Metering software.
The payload contains the status of the alarm
and the date of the alarm activation. After
resetting it the status is updated and the date
will be removed from the radio payload.
_O_ _ _ Err Overow Water meters was used in an
improper condition, ow rate
exceeded the operating conditions.
Manufacturer warranty expires.
The error activates after the meter
operates at a ow rate higher than Q4
for 10 minutes continuously.
Check water network
parameters.
Reset the alarm via LoRa
downlink (if in LoRa version) or
directly on eld with IR interface
and B Metering software.
The payload contains the status of the alarm
and the date of the alarm activation. After
resetting it the status is updated and the date
will be removed from the radio payload.
_ _B_ _ Err Burst High consumption in a short term is
detected. This is probably linked to a
pipeline failure/break.
If the ow rate of the meter stays
continuously over Q3 for 30 minutes
the alarm is set.
Check water network. The alarm automatically resets
when the ow rate decreases
below 0,5*Q3
The payload contains the status of the alarm
and the date of the alarm activation. After the
alarm resets, the date changes to the date of
deactivation.
_ _ _R_ Err Reverse
installation
The meter starts owing in the
opposite direction. This is probably
due to a wrong installation.
During rst installation only, if the
absolute counter (forward counter -
reverse counter) is equal to 0 and a
reverse ow (>8 Liters) is detected,
the alarm turns on.
Check water meter installation. Automatically resets when ow
is on the correct direction.
The payload contains the status of the alarm
and when ow direction turns to the correct
one the status updates.
_ _ _ _L Err Leakage A continuous ow for a long time is
detected. This is probably linked to a
leakage in the water network.
The meter detects a continuous ow
of >0.5*Q1 for 12 hours.
Check water network\system\
taps against leakages.
Resets automatically when a
ow interruption happens.
The payload contains the status of the alarm
and the date of the alarm activation. After the
alarm reset the date changes to the date of
deactivation.
13 User Manual v1.4.5HYDRODIGIT
ERROR MESSAGE
If an error occurs, an error message is displayed. The error message will be integrated into the device display loop for 2 seconds.

14 User Manual v1.4.5HYDRODIGIT-S1
Do not recharge or replace the battery;
Do not open, puncture or damage the batteries;
Do not short-circuit the battery;
Do not expose the battery to temperatures above 85° C;
Do not insert into ovens, crush or cut: these actions could cause an explosion or leakage of
ammable gases or liquids;
Do not use naked ames near the device;
Do not put in contact with water;
Do not expose the battery to an extremely low pressure environment which could cause an
explosion or a leak of gases or ammable liquids;
Always dispose of batteries in compliance with current regulations;
Always use original spare parts authorized by the manufacturer.
BATTERY AND REPLACEMENT PROCEDURES
The water meter constantly monitors the battery status (maximum duration: 10 years) and reports the
upcoming discharge via LoRaWAN or WM-BUS radio, by displaying the icon ..
The notification occurs one year before the total discharge.
For the replacement, contact the manufacturer.
The instrument is equipped with a non-rechargeable battery, which can be dangerous if used
improperly. To reduce the risks, the following precautions must be observed:

15 User Manual v1.4.5HYDRODIGIT-S1
INFORMATION FOR CORRECT DISPOSAL OF THE PRODUCT
This product falls into the scope of the Directive 2012/19/EU concerning the management
of Waste Electrical and Electronic Equipment (WEEE). This product shall not be disposing
into the domestic waste as it is made of different materials that must be recycled at the
appropriate facilities. Inquire through the municipal authority regarding the location of the
ecological platforms to receive the product for disposal and its subsequent correct recycling.
The product is not potentially dangerous for human health and the environment, but if abandoned in the
environment can have negative impact on the environment.
The crossed-out wheeled dustbin symbol, on the label on the product, indicates the compliance of this
product with the regulations regarding Waste Electrical and Electronic Equipment.
Abandonment in the environment or illegal disposal of the product is punishable by law.
TRANSLATION
For deliveries to countries in the European Economic Area, the operating instructions are to be translated
into the appropriate language of user country.
Should there be any inconsistencies in the translated text, the original operating instructions (Italian) are to
be consulted or the manufacturer should be contacted.

16 User Manual v1.4.5HYDRODIGIT-S1
Model HYDRODIGIT
Measuring class/Permitted installation R400H, R160V
R250H, R160V
R160H, R160V
Depending on the order
Flow detection technology Turbine reading by inductive system
Temperature class T50 cold water, T30-90 hot water
Display LCD, 8 digits + icons
Protection class IP68*
Local Interface Optical interface IR IEC 62056-21
Radio standard Depending on the version:
- Wireless MBUS EN 13757-4 compatible;
- COMBO - output conguration:
Wireless MBUS EN 13757-4;
- COMBO - output conguration: LoRaWAN;
- COMBO - output conguration:
LoRaWAN + Wireless MBUS EN 13757-4 ;
Radio Frequency 868 MHz
Radio range / radio power Wireless MBUS: 300 meters**
LoRaWAN: 5 Km**
Battery life max 10 years***
*IP68: maximum 24 hours of continuous submersion at 1 m depth.
Note: in case of damage caused by involuntary impact, the meter must be replaced with a new one, to
restore the protection class.
**Under optimal propagation conditions, the radio range depends on physical conditions (building
constructions, climatic conditions, …) where propagation of the radio signal can therefore vary.
*** The battery life strongly depends on the working time window, set during the configuration process, and
on the environmental conditions. Estimation of the battery life is given by the configuration software.
TECHNICAL DATA

17 User Manual v1.4.5HYDRODIGIT-S1
DECLARATION OF CONFORMITY
EU DECLARATION OF CONFORMIT
1. Product type/model: Water Meter – HYDRODIGIT
2. Name and address of the manufacturer:
B METERS SRL Via del Friuli, 3 – 33050 GONARS (UDINE) ITALY
3. This declaration of conformity is issued under the sole responsibility of the manufacturer.
4. Object of declaration: HYDRODIGIT
Vane-wheel single jet with electronic indicating device and radio transmitter
5. Above mentioned object is in conformity with relevant EU harmonization legislation:
Directive No. 2014/32/EU
6. Relevant harmonized standards or normative documents and references or other technical
specifications or instructions used for the declaration:
OIML R 49-1:2006 EN 14154-1:2005+A2:2011 EN ISO 4064-1:2017
OIML R 49-2:2004 EN 14154-2:2005+A2:2011 EN ISO 4064-2:2017
OIML R 49-1:2013 EN 14154-3:2005+A2:2011
OIML R 49-2:2013
7. Notified body
8. Another lnformation
Signed by the General Manager:
Mr. Mauro Budai
On behalf of:
B Meters Srl
Place and date of declaration issue:
Gonars, ltaly, 1st February 2022
Name and number of NB Performed Issue the Certicate No.
Slovensky mtrologicky ustav, NB 178
Karloveska 63
84255 Bratislava 4
Slovenska Republika
EU type certication in
accordance with Module B of
Directive No. 2014/32/EU
SK 19-MI001-SMU058
(rev. 3)
Czech Metrology Institute, NB 1383
Okruzni 31
638 00 Brno
Czech Republic
Certication of production, nal
product inspection and testing
in accordance with Module D of
Directive No. 2014/32/EU
0119-SJ-A011-08

18 User Manual v1.4.5HYDRODIGIT-S1
MANUFACTURER ADDRESS
B METERS srl
Via Friuli, 3 • Gonars 33050 (UD) • ITALY
Tel: [phone]
Tel: [phone]
Fax: [phone]
E-mail (sales/info): [email protected]
E-mail (support): [email protected]
Web: www.bmeters.com
