3
HYDROCAL M4 - User Manual
WARNING
The top calculation/electronic unit must not be separated from the bottom brass case.
The first configuration chosen during installation (supply or return pipe) can’t be modified!
This meter contains potentially dangerous batteries, handle them with caution and do not
disperse the components in the environment.
The installation must be carried out by qualified personnel only. The manufacturer doesn’t
assume any responsibility for improper installation or damages caused by third parties.
The HYDROCAL-M4 is a compact thermal energy meter that measures the thermal energy used in heating and
cooling systems.
The meter allows to measure the thermal energy passing into a hydraulic circuit used for heating and\or for cooling,
it also lets the acquisition through external module, of the volume measured by up to 2 device (water, heat, gas,
electricity, HCA) equipped with pulse emitter.
The meter can also be connected to a consumption reading network based on the wired M-BUS, Wireless M-BUS
and LoraWan network protocols.
The product must be stored in a dry place at temperatures between -20 °C and +70 °C (even during transport).
The duration of the storage should not exceed 1 year.
Combined heating or cooling meters are precision devices and must be protected from shock and vibration.
• Before proceeding with the installation and configuration of the product, carefully read the instructions in this
manual. For further technical clarification, please contact Customer Service.
• Installation should be carried out exclusively by qualified personnel.
• The reference standard for the instrument is EN 1434 (1-6) and Directive 2014/32/EC (Annex MI-004).
• Any tampering of the meter or removal of the seals will void the warranty provided.
• For proper energy accounting, always respect the mounting type prescribed (inlet pipe installation/ return pipe
installation).
• The configuration of installation version and unit of measurement can be done with the buttons or an Android
device with NFC connectivity.
• Respect the installation point (input or output) of the instrument.
PACKAGING CONTENT
STORAGE CONDITIONS
GENERAL INFORMATION
1. Introduction
→HYDROCAL-M4 thermal energy meter
→ Installation Manual
→ Antifraud Kit

4
HYDROCAL M4 - User Manual
Attention: this symbol highlights the instructions to be followed scrupulously for the correct functioning of
the combined heat and cooling meter.
Danger: the chapters marked with this symbol contain information that must be followed carefully to avoid
dangerous situations. Thermal energy meters are precision devices and must be protected from shock and
vibration.
Read all instructions carefully before proceeding with the installation! Failure to comply with one or more
of the procedures contained in the manual can be dangerous and cause damage to property and people.
It is recommended to comply with all applicable laws on safety and accident prevention.
Notes: the notes indicated by this symbol contain tips to keep in mind when using the thermal energy meter.
2. Safety information
Observe national regulations relating to the measurement of cooling.
Observe the technical requirements relating to the installation of electrical equipment.
The instrument complies with the requirements of Directive 2014/30/EU of the European Council on
electromagnetic compatibility, Directive 2014/35/EU on electrical safety and Directive RED 2014/53/EU.
If more than one instrument is installed in a unit, the installation conditions must be the same for all
instruments to ensure that consumption is billed as possible.
The warranty and validity of the verification become void if the identification plate or the seals applied to the
instrument are removed or damaged.
Remove the device from the package only at the time of installation to protect it from damage and dirt.
The air transport of active radio devices is prohibited.
Carefully observe the instructions in the data sheet, instruction manual, application notes and lid. Failure to
comply with the operating conditions may result in situations of danger and forfeiture of all claims of liability
for defects as well as liability based on any guarantees expressly granted. For more information visit the
website www.bmeters.com.
Dispose of replaced devices and defective components in accordance with current environmental regulations.
Pay attention to the angular or sharp protrusions in the threads, flanges and measuring tube. Therefore, it is
recommended to wear protective gloves.
The device shall be used in such a way as to minimize the potential for human contact during normal
operation. To avoid the possibility of exceeding radio frequency exposure limits, human proximity to receivers
with integrated antenna should not be less than 20 cm (8 inches) during normal operation.
Do not expose the meter to the sun and heat sources. Do not attempt to burn the device.
Store out of the reach of children.
In case of danger of frost, empty the system and, if necessary, remove the meter.
To clean the device externally use a soft cloth and moistened with water. Do not wash with high-pressure jets
or soak the device in water. Avoid contact with oils and solvent. Do not use alcohol or detergents.
Do not damage the casing of the device. In the event of collisions of blunt objects on the front of the display,
it can be irreparably damaged and lose the IP65 degree of protection. Install in areas protected against
impacts. If the protective casing breaks, contact customer service.
The display turns off. To activate it, press the button on the device. The display remains active for 60 seconds.

5
HYDROCAL M4 - User Manual
The meter is not suitable for drinking water but is suitable for circulating water in central heating systems.
The quality of the water has to be as specified by the CEN/TR 16911 regulation.
Do not twist, wrap, extend or shorten the cables of the temperature probes and the cable that connects the
electronic unit to the part of the lower-case body.
The thermal energy meter can be installed only in areas protected from frost.
The thermal energy meter must be protected against pressure shocks in the pipeline.
Slowly fill the pipe with water at the end of the installation.
After installing the meter perform a leak test of the system.
Assemble or disassemble the meter only after depressurization of the system.
The meter does not have lightning protection.
Thermal energy meters do not require special protection against electrical interference; however,
electromagnetic interference must be avoided.
If transmission network interfaces are used, especially when cables are routed outside the building, use
increased protection against electrical interference.
Rinse the pipes thoroughly before installing the meter.
The device must be installed pay attention to matching the direction of the arrow on the meter brass body to
the direction of the flow.
Avoid collecting air bubbles in the meter during the installation process.
The thermal energy meter must not be subjected to mechanical stress when installed in the pipeline.
The meter must be installed in such a way as to be protected from all impurities and external contamination.
Manually and simultaneously screw the device fittings on both sides, and then tighten in opposite directions
using a suitable tool.
Remove old seals and clean the sealing surfaces.
Slightly grease the sealing surfaces (use grease approved by MID Standards).
Mount only the newly supplied gaskets (gaskets should not get in the pipeline). Seals provided on site
must be fit for purpose and comply with local guidelines and directives. B METERS disclaim all liability for
consequential damage resulting from the use of third-party gaskets, such as corrosion of sealing surfaces and
threads.
The table below presents troubleshooting steps:
Problem Cause Solution
Display off, pressing buttons does not
respond The battery may be damaged or discharged Inform Customer Service
Damaged brass case or leakage Possible external impact or fall to the ground Inform Customer Service
Lower case brass separated by
electronic unit
Tampering by third party or strong external
impacts Inform Customer Service
Open and visible electronic unit Tampering by third party or strong external
impacts Inform Customer Service
No consumption is accounted Tampering by third party, strong external shocks
or damage to the flow detection sensor Inform Customer Service
Error 12 always present Damaged temperature probes Inform Customer Service
Error 18 or 19 always present Damaged temperature probes or
out of system temperatures limits Inform Customer Service
Does not transmit via radio Failure to pass 5 absolute liters or the batteries
may be damaged or discharged Inform Customer Service

6
HYDROCAL M4 - User Manual
BEFORE INSTALLATION
INSTALLATION
3. Installation
Before the thermal energy meter installation make sure that the two ends of the inlet and outlet pipe are perfectly
aligned, clean them with the utmost care. Moreover, make sure there is a suitable filter placed at the inlet and that
clean and undamaged gaskets are inserted on both sides.
The thermal energy meters must be installed as specified by the CEN-TR 13582 regulation.
Upstream and downstream the meter install an appropriate water flow interception and regulation devices suitable
to allow inspection and maintenance of the meter, control of the water flow and eventual sealing of the system.
Attention should be paid to the direction of flow. Install the thermal energy meter so that the passage of water
takes place in the direction indicated by the arrow in relief on the brass body and respecting the prescribed
position.
It is mandatory to comply with the prescribed type of assembly (return pipe\supply pipe). Always refer to what
is on the meter menu 3 level 06.
The figure below refers to a standard version of the device installation (mounting on return pipe) and positioned
horizontally.
To ensure proper measurement, make sure that there is no air inside the pipe and that the flow is clean and free
of debris (potentially harmful to the meter turbine).
The first configuration chosen during installation (supply or return pipe) can’t be modified!

7
HYDROCAL M4 - User Manual
ALLOWED INSTALLATION POSITIONS
TEMPERATURE SENSOR INSTALLATION
INSTALLATION IN A SOCKET
All versions of the thermal energy meter can be installed both horizontally and vertically. For a better performance
it is preferable, however, the horizontal installation with the turbine axis perpendicular to the ground and the reading
mechanism facing upwards.
The thermal energy meter is equipped with two digital probes that comply with the MID 2014/32/EC directive and the
EN1434 standard.
1. Screw the socket in the pipe
2. Insert the temperature sensor
3. Tighten the screw
In the standard version (e.g mounting on return pipe), the return probe is already incorporated inside the brass case.
The supply probe must be installed in a ball valve or in a socket mounted on the flow pipe and complies with the
requirements of the sensor itself.
Vice versa, the version for installation on the inlet pipe the probe inserted inside the brass case will be the flow, the
return probe will need to be installed in a valve or a socket on the return pipe.
Ideal position
for a better performance
Additional allowed positions
For a correct installation, always proceed in compliance with the directives prescribed by current regulations.
Before installing the ‘free’ probe (the one not inserted in the meter case), it is necessary to intercept the flow
(close the ball valve or the appropriate shutters).
* This position is not suggested for cooling meters and in cases where moisture can enter the electronic casing due to
condensation (e.g. during an interruption of the plant in the summer)
*

8
HYDROCAL M4 - User Manual
1. Insert the probe into the threaded nut
2. Insert the closing pin
3. Unscrew the valve closing screw, and
place appropriate seals
4. Insert the probe by screwing it on the
threaded guide
BALL VALVE INSTALLATION
For a correct temperature measurement, the tip of the probe must be in the center of the pipe.
In addition, the axis of the probe must be perpendicular to the pipe axis (see figure).
The temperature sensor must be sealed when the installation is complete.

9
HYDROCAL M4 - User Manual
4. Functionality
5. Display and buttons
The HYDROCAL-M4 thermal energy meter is equipped with dedicated sections for the measurement of thermal energy
of a heating/cooling circuit and the volume measurement given by the domestic hot and cold-water meters.
The meter is suitable for domestic applications with two-pipe systems, in a thermal power plant or any other
compatible application.
In residential systems, usually with two pipes systems, the measurement of thermal energy takes place on
a single section both in heating and cooling cycle.
The picture below reports a typical connection diagram:
The device is equipped at the front with an LCD and two buttons (T1 and T2), useful for device initialization and
readings
1) Eight-digit numeric field;
2) Single-digit numeric index (menu level);
3) Heating data index;
4) Cooling data index;
5) Circuit 1-2 pulse emitter (external module);
6) Return temperature index;
7) Indicator of sub level presence
8) Supply temperature index;
9) Battery level indicator;
10) Faults or NFC/IR active communication indicator;
11) Flow presence indicator;
12) M-Bus wired communication data index;
13) LoRaWAN communication data index;
14) Historical index;
15) Pulse value index (k);
16) Measurement unit index;
T1) Levels selection button;
T2) Scroll button within the selected level;
12+13) M-Bus Wireless data index;

10
HYDROCAL M4 - User Manual
6. Commissioning
Premise: before a functional tests, the procedures indicated in this paragraph must be performed for completing
the physical installation phases including the connections.
The device is delivered in sleep mode. Based on the order, if the installation version and the unit of measurement
are already configured, it is necessary to keep T2 button pressed for three seconds to initialize the device.
If a choice has not been made during the order, the meter must be configured. The configuration of the meter can
be performed via buttons or via NFC through android app. If the activation takes place with buttons, the items in the
menu will be two:
By pressing for 3 seconds the right T2 button you can confirm the choice made by passing
directly to the initialization of the device. By pressing the T1 button for 3 seconds the
thermal energy meter will return to installation version mode showing ‘set Mode’ on
display. After confirmation in step 2 the thermal energy meter will perform the initialization
for heating and cooling accounting. The unit of measurement can be changed later via NFC.
1. Installation version: select, through the left/right button (T1/T2), the type of installation (supply or return).
Holding down the right button for 3 seconds can temporarily confirm the choice made by switching to level 2
(unit of measurement). If the T1 button is pressed for 3 seconds the thermal energy meter will return to stock
mode showing ‘SLEEP’ on display.
2. Units of measurement: select through the left/right button (T1/T2), one of the following items, ordered as
described below:
→ 1 (Joule)
→ 2 (MJ)
→ 3 (GJ)
→ 4 (KWh)
→ 5 (MWh)
1
(J)
2
(MJ)
3
(GJ)
4
(KWh)
5
(MWh)
LONG PRESS
T1 BUTTON
LONG PRESS
T1 BUTTON
LONG PRESS
T2 BUTTON
LONG PRESS
T2 BUTTON
LONG PRESS
T2 BUTTON
SELECT WITH
T2 BUTTON
SELECT WITH
T2 BUTTON
The first configuration chosen during installation (supply or return pipe) can’t be modified!
LONG PRESS
T2 BUTTON

11
HYDROCAL M4 - User Manual
7. Consultation menu
The consultation menu is divided into 9 levels by a numerical index always visible at the top left of the display.
By pressing the T1 button you can choose the desired level, while pressing the T2 button you can view the sublevels
of the preset level.
After 60 seconds without iteration the display turns off. If no button is pressed within 20 seconds (with the display off)
the display cycle will start again from level 1. If a button is pressed within 20 seconds (with the display off) the last
level consulted will be displayed.
In any level or sublevel, holding down the T1 button for 3 seconds will direct the index to level 1.
To access to a sublevels, where present (indicate by the symbol ‘–‘), it is necessary to hold down the T2 button for
3 seconds. To return to a main level from a sublevel it’s necessary to hold down the T2 button again for 3 seconds.
Each level consists of a brief indication in letters of the data that will be shown after a few seconds in a second screen.
Specifically, the cycle will be defined as follows:
→ (First consultation): 2,5 seconds the indication in letters and 5,5 seconds the data
→ (2-n consultations): 1 second according to the indication in letters and 6 seconds the data
User configuration data can be configured via NFC device and NFC app.
Below the list of data available:
NOTE: In absence of historical data, levels 6-7-9 will show - - (text).
Below, the navigation map of the consultation menu is shown.
→ All averages values (temperatures, flow rates, etc) are saved every hour.
→ The biweekly and monthly historical data, present in level 6, are saved at each occurrence (default: day 1, end of
month). if the configured days are the same (example: day 15 or leaving the default values) the data are saved as
‘monthly’ and therefore will be stored in memory up to 24 previous historical months.
If two different dates are selected (example: day 15 for bimonthly historical data and day 1 for monthly historical
data) a maximum of 48 values are stored in the device (including 24 previous historical monthly values and 24
previous historical bimonthly values). The range of days selectable are between 1 and 28.
→ The bi-annual historical data (memory day 1 and 2), present in level 4, are saved and displayed with the format
DD/MM/D1 and DD/MM/D2 (where Dx indicates the year of saving).
Default: 01/09 for memory day 1 and 30/06 for memory day 2. The range of days/month selectable are between
1..28 (days) and 1..12 (months).
PROCEDURE FOR COMMISSIONING
1) Check that the mounting position of the thermal energy meter and all electrical wiring are carried out correctly
2) Check if the device is configured, otherwise set the installation version and the unit of measurement
3) Check at level 3 that all configured parameters are correct (heating and cooling data)
4) Check that the thermal energy meter, pulse devices, probes etc. are installed correctly (refer to the specific
installation manuals for each product)
5) Start the heating/cooling system:
→ Check the consistency of the reported values (energy and volume)
→ Check in level 2 the instant data
6) Check for errors
7) Apply installation seals. Apply installation seals. It’s recommended to lock the device with a password set through
the BMETERING NFC Config android app (downloadable from the Google Play Store).
Displayed data are only for examples

12
HYDROCAL M4 - User Manual
LEVEL S1: INITIALIZATION
LEVEL S2: CONFIGURATION AND INITIALIZATION
In this level, based on the order, the configuration of the thermal energy meter (installation version and unit of
measurement) is already managed. NFC communication it is disabled in this sleep phase.
Note: it’s necessary to holding down the T2 button for 3 seconds for the thermal energy meter initialization.
In this level, the configuration of the thermal energy meter is managed through buttons before its installation.
The “not Set” condition remains active only until no other condition has been selected. When the condition is changed
(by pressing T1 or T2) it will no longer appear. Through NFC it is possible to set unit and installation version.
If the parameters are not set via NFC, the device remains in ‘not set’ mode.
The device is in sleep mode, waiting for T2 long press
The device is in sleep mode, waiting for configuration via buttons or NFC
Installation version (return, supply)
Units of measurement
(1=Joule, 2=MJ, 3=GJ, 4= kWh, 5=Mwh)
Meter initialization, level 1 (Cumulative energy heating)
Meter initialization, level 1 (Cumulative energy heating)
To configure the device please refer to ‘COMMISSIONING’ paragraph
LEVEL 1: CUMULATIVE VALUES
1.1 Cumulative energy (heating) – Cumulative value
1.2 Cumulative energy (cooling) – Cumulative value
1.3 Volume useful for accounting (heating) – Cumulative
value

13
HYDROCAL M4 - User Manual
LEVEL 2: INSTANTANEOUS OPERATING VALUES
1.4 Volume useful for accounting (cooling) – Cumulative
value
2.1 Actual power (kW)
1.7 Reverse volume accounted (heating and cooling) –
Cumulative value
2.4 Actual flow rate
1.5 Total accounted volume (heating and cooling) –
Absolute value
2.2 Instantaneous power (W) – given per second
1.8 Total value (first additional impulse input) –
Cumulative value [value visible only if enabled]
2.5 Supply temperature
1.6 Forward accounted volume (heating and cooling) –
Cumulative value
2.3 High resolution energy (heating) – extension value of
1.01 level
1.9 Total value (second additional impulse input) –
Cumulative value [visible only if enabled]
2.6 Return temperature
1.10 Lost volume (heating and cooling) – Cumulative
value

14
HYDROCAL M4 - User Manual
LEVEL 3: SETTINGS (DISPLAYING ONLY)
2.7 Temperature difference
3.1 Serial number
3.7 Current date
3.4 Radio Communication Firmware Version (Non-Legal
Part)
3.10 Pulse Input 1 (on, off)
2.8 CPU temperature (approximately ±3°C accuracy)
3.2 CRC Calculation firmware (legal part)
3.8 Current time
3.5 Radio Stack Firmware Version (Non-Legal Part)
3.10.1 Liters/pulse ratio - additional pulse input 1
3.3 Calculation Firmware Version (legal part)
3.9 Unit of measurement (1= Joule, 2=MJ, 3=GJ, 4= kWh,
5 Mwh)
3.6 Installation version (return or supply)

15
HYDROCAL M4 - User Manual
3.10.2 Initial input value - additional pulse input 1
3.11 Pulse Input 2 (on, off)
3.12.2 MBUS secondary address (heating and cooling)
3.11.3 Medium - additional pulse input 2
3.14 Biweekly historical save day (default 01, biweekly
disabled)
3.16 Day and month saving (Memory day 2)
3.10.3 Medium - additional pulse input 1
3.11.1 Liters/pulse ratio - additional pulse input 2
3.12.3 Baud rate MBUS (300, default: 2400, 9600)
3.12 MBUS interface (on, off)
3.15 Day and month saving (Memory day 1)
3.11.2 Initial input value - additional pulse input 2
3.13 Monthly historical save day (default 01)
3.12.1 MBUS primary address (heating and cooling)

16
HYDROCAL M4 - User Manual
3.17 Day and month saving (Annual historical data)
3.19 LoRa interface (on, off)
4.1.2 Cooling – cumulative value Memory 1
4.2 Memory 2 date of storage
4.2.2 Cooling – cumulative value Memory 2
3.18 WMBUS mode (AMR, Walk-by, AMR Custom, Off)
3.20 Display test – All segments on and all segments off
(repeat every 2 seconds)
4.1.3 Additional first impulse input consumption –
cumulative value Memory 1
4.1 Memory 1 date of storage
4.2.1 Heating – cumulative value Memory 2
4.1.4 Consumption according to additional impulse input
– cumulative value Memory 1
4.1.1 Heating – cumulative value Memory 1
LEVEL 4: STORAGE DAY DATA 1-2

17
HYDROCAL M4 - User Manual
LEVEL 5: COUNTER DATA
LEVEL 6: MONTHLY/BIWEEKLY HISTORICAL DATA
4.2.3 Additional first impulse input consumption –
cumulative value Memory 2
5.6 Total counting hours without errors (DDDD.HH.MM)
5.3 Total counting hours - heating (DDDD.HH.MM)
6.1.1 Accounted energy (heating) – cumulative value at
monthly historical data
6.1.3 Accounted impulse input 1 – cumulative value at
monthly historical data
4.2.4 Consumption according to additional impulse input
– cumulative value Memory 2
5.1 Total hours of device life (DDDD.HH.MM)
5.4 Total counting hours - cooling (DDDD.HH.MM)
6.1.2 Accounted energy (cooling) – cumulative value at
monthly historical data
5.2 Total counting hours (DDDD.HH.MM)
6.1 Date of storage of the monthly history (up to 24
possible values). Default: save at the end of the month,
biweekly historical data disabled.
5.5 Total counting hours with flow and without a
difference of temperature (DDDD.HH.MM)

18
HYDROCAL M4 - User Manual
6.1.4 Accounted impulse input 2 – cumulative value at
monthly historical data
6.1.6 Average return temperature – average value at
monthly historical data
7.1.1 Accounted energy (heating) – cumulative value at
annual historical data
6.1.9 Average flow rate (m3/h) – average value at
monthly historical data
7.1.4 Accounted impulse input 2 – cumulative value at
annual historical data
7.1.6 Average return temperature – average value at
annual historical data
6.1.5 Average supply temperature – average value at
monthly historical data
6.1.7 Average ambient temperature – average value at
monthly historical data
7.1.2 Accounted energy (cooling) – cumulative value at
annual historical data
7.1.5 Average supply temperature – average value at
annual historical data
6.1.8 Average power (Kw) – average value at monthly
historical data
7.1.3 Accounted impulse input 1 – cumulative value at
annual historical data
7.1 Date of storage of the annual history (up to 12
possible values). Default: save at the end of the year
LEVEL 7: ANNUAL HISTORICAL DATA

19
HYDROCAL M4 - User Manual
7.1.7 Average ambient temperature – average value at
annual historical data
7.1.9 Average flow rate (m3/h) – average value at annual
historical data
9.1 Active error logs (up to 32 possible values)
8.2 Displaying Active Errors
9.1.3 Total count error occurrences
7.1.8 Average power (Kw) – average value at annual
historical data
9.1.1 Date of error storage
8.1 Number of active errors
9.1.2 Time of error storage
LEVEL 8: ERRORS AND ANOMALIES
LEVEL 9: ERROR LOG

20
HYDROCAL M4 - User Manual
8. Operating mode – Radio activation
This section describes the radio communication management implemented.
For the WM-Bus interface there is a test mode that can be activated via NFC (only before the passage of +- 5 liters),
that allows to verify the correct functioning of the device. With an NFC command the WM-Bus interface will be enabled
for 1 minutes sending standard transmission data every 5 seconds. After this cycle the thermal energy meter will
return to the initial mode waiting for the passage of +- 5 liters.
Wireless MBUS - OMSv4 compliant (output configuration Wireless MBUS only)
As soon as radio operation mode is activated, the thermal energy meter sends a radio telegram according to Wireless
MBUS, T1 mode (unidirectional and synchronous transmission).
Preconfigured Radio parameters (AMR and synchronous mode, OMSv4 compliant):
LoRaWAN (output configuration LoRaWAN only) – Available soon
It is possible to change the configuration into Walk-By or Advanced mode with BMetering NFC Config app:
The transmission of the packets will take place according to the default schedule or chosen by the customer via NFC.
An ordered schedule is provided based on the selected WM-Bus packets (default: standard packet every 200 second
of transmission). If the transmission is < 200 seconds, the transmission will be asynchronous otherwise synchronous.
→ Transmission frequency: every 200 seconds (current values)
→ Transmission interval: every day, from 0 to 24 h
→ Encryption: disabled (default)
→ No historical data
→ Transmitted data: standard data (heating energy, heating volume), errors, battery value as a percentage
→ Transmission frequency: configurable (minimum 60 seconds)
→ Transmission interval: from Monday to Friday (optional Weekend), maximum 12 hours per day
→ Possibility to select a 24-hours’ time span with the following mandatory conditions:
- Transmission frequency: > 300 seconds (synchronous)
- Historical data disabled
→ Encryption: enabled/disabled
→ Historical data (12 months)
→ Transmitted data:
- Standard data (max. 13 bytes): heating energy, heating volume
- Combined (max 28 bytes): standard data with the addition of optional cooling energy and cooling volume
- Instantaneous (max. 31 bytes): standard data with the addition of optional instantaneous data
- Pulses (max. 31 bytes): standard data with the addition of optional data regarding pulse input 1 and 2 (if
used)
- Battery value as a percentage
- Errors
- Historical data:
• 6 months of heating energy
• 12 months of heating energy
• 6 months of heating energy and 6 month of cooling energy
• 12 months of heating energy and 12 month of cooling energy
• 12 months of heating energy and 12 months of heating volume
• 12 months of cooling energy and 12 months of cooling volume
• 6 months of heating energy and 6 months of pulse 1 - 2
• 6 months of heating energy and 6 months of cooling energy + 6 months of pulse 1 - 2
RADIO PARAMETERS
