B-Qtech BQ-H210 series User manual

1/17
---------------------------------------------------------------------
BQ-H210 series EXT High Speed Dome System
---------------------------------------------------------------------
User Manual
Before installing and using the High Speed Dome，Please read
these instructions thoroughly and retain them for later reference

2/17
Before Installing
zInstallation should be carried out only by qualified personnel and in accordance
with any wiring regulations in force at the time.
zPlease read this instruction and warnings before installing.
zDo not attempt to service or repair the speed domes as opening or removing
covers may expose dangerous voltages or other hazards. Refer all servicing to
qualified service personnel.
zAdequate protection against lightning strikes and power surges must be installed
to prevent damage to the speed dome.
Key Features
z360º Panning, speed is 0.1º-300º/s.
zAuto flip 180º
z128 presets, the error of preset will less than 0.1º
z4 privacy zone
zAuto cruise by preset, the stay time is 1s-250s.
zImage freeze while panning
zManifold of scan, scan speed could be setting from 1º/s to 80º/s
zLeft and right limit scan, could setting any limit position
z7 alarm input and 2 alarm output.
zEasy fixing configuration
z24V power supply built in
zStatic proof and thunder proof design of the RS485 connector and video
connecter.

3/17
Environmental requisition:
Operation Temperature: -40-+60
Humidity: <90%
Air pressure: 86-106Kpa
Power supply: AC24V/2.5A,50/60Hz
The system setting Camera and
switch SW1 address switch
Alarm connector 8P Short connector
RS485 communication 2P
AC24V power supply
AUX4P
1、Power supply and
communication cable:：
AC24V
AC24V RS485
2、Video output：
Alarm signal
Alarm Relay Output “AUX1”
Alarm Relay Output “AUX2
Alarm Input GND
Alarm input signal l -7
AL1、AL2、AL3、AL4…AL7：Alarm input.

4/17
1, Dome setting Instruction
The switch setting SW1 ON=1 OFF=0
Protocol setting Baud rate setting Alarm Alarm mode
DIP Switch 1 2 3 4 5 6 7 8
SW1234=
0000=PELCO-D/PELCO-P Auto
identify
SW5,6=
00=2400
01=4800
10=9600
1=Alarm
enable
0=Alarm
disable
1=Always shor
t
circuit.(Alarm
while open)
0=Always
open
circuit.(Alarm
while short)
Note
： PELCOD PELCOP could be identifying automatically. On and Off is the corresponding
switch positions.
SW2 switch: address switch table.
CAM ID 1 2 3 4 5 6 7 8
1 OFF OFF OFF OFF OFF OFF OFF OFF
2 ON OFF OFF OFF OFF OFF OFF OFF
3 OFF ON OFF OFF OFF OFF OFF OFF
4 ON ON OFF OFF OFF OFF OFF OFF
5 OFF OFF ON OFF OFF OFF OFF OFF
6 ON OFF ON OFF OFF OFF OFF OFF
7 OFF ON ON OFF OFF OFF OFF OFF
8 ON ON ON OFF OFF OFF OFF OFF
9 OFF OFF OFF ON OFF OFF OFF OFF
10 ON OFF OFF ON OFF OFF OFF OFF
11 OFF ON OFF ON OFF OFF OFF OFF
12 ON ON OFF ON OFF OFF OFF OFF
13 OFF OFF ON ON OFF OFF OFF OFF
14 ON OFF ON ON OFF OFF OFF OFF
15 OFF ON ON ON OFF OFF OFF OFF
16 ON ON ON ON OFF OFF OFF OFF

5/17
∶
∶
∶
128 ON ON ON ON ON ON ON
129 OFF OFF OFF OFF OFF OFF OFF ON
∶
∶
∶
255 ON ON ON ON ON ON ON OFF
256 ON ON ON ON ON ON ON ON
Alarm
7 alarm input. The dome will alarm when alarm input port connect the GND. The AUX will be
closed when has alarm, and open when on alarm in. The capacitance of the relay is AC24V/1A.
The relay output:
2 relay switch AUX1, AUX2, the biggest capability is AC24V/1A. AUX1 connect with the alarm,
AUX2 is controlled by the master or keyboard.
Camera Module Setting Switch
The dome can be fit different camera, and they have different
switch.
Camera Switch 1 Switch 2 Switch 3 Switch 4
DIP-1 DIP-2 DIP-3 DIP-4
SONY OFF OFF OFF OFF
HITACHI OFF OFF ON OFF
LG OFF ON OFF OFF
CNB-200L OFF ON ON OFF
CNB-M1560 OFF ON ON ON
SAMSUNG
(SDM300/SDM330) ON OFF OFF OFF
Note: The incorrect switch may cause the camera do not work
High Speed Dome Operation,
When Electric
When electric the dome, the version, protocol, baud rate, ID will display on the monitor, and the
dome will check automatic with vertical and level then display the specs of camera.
Example:

6/17
High Speed Dome
Ver：1 00
PELCO D P
2400
ID：001
Tilereference OK
Pan reference OK
SONY FCB-EX480CP
The operation way by keyboard controller
Function Control
Level/Vertical Joystick left, right/ up and down
OSD Confirm OPEN
Cancel and Back CLOSE
OSD Display Call 95 preset
Zero Position Call 34 preset
Level Scan Call 99 preset
Auto Flip Call 33 preset
Left limit: call 92 presetLevel Scan Limit
Point Right limit: call 93 preset
Call preset scan 1 Call 81 preset
Call preset scan 2 Call 82 preset
Call preset scan 3 Call 83 preset
Call preset scan 4 Call 84 preset
Camera mode 1 Call 100 preset
Camera mode 2 Call 101 preset
Camera mode 3 Call 102 preset
4 Privacy mask, only fit to SONY480, SONY980 and HITACHI454 camera.
Level area increase: FAR
Level area reduce: NEAR
Vertical area increase: TELE
Privacy Mask
Vertical area reduce: WIDE
OSD Operation
1, Enter OSD
Please call the number 95 preset to display the OSD on the screen.
At figures the current item, figures the enabled item, and the ►after the item which have
submenu. You can change the item state when it has been enabled. Please press OPEN key to
enter or confirm and CLOSE key to back or cancel, and the key UP and DOWN control the cursor
up and down.

7/17
Exposure ►
White Balance ►
Privacy ►
Other ►
Camera Model ►
Zoom Speed 005
Focus Speed 001
Camera ►
Pan ►
Shortcut Key
Self act Nothing
Leisure Time 030
Exp Mode Auto
Shutter speed 006
Iris 016
Gain 001
Bright 016
Back Light Off
Slow Shutter Off
2 Menu function instructions
Call the number 95 preset to enter the OSD, and you also could setting the shortcut key to display
the OSD.
Main Menu
Camera OSD
Camera ►Press OPEN to enter the camera menu.
Camera Exposure
Exposure ►Press OPEN key to enter the camera exposure submenu.
Exposure operation
1, How to change the exposure
Exp Mode press OPEN key, enable Exp Mode, then
operate up and down by the joystick, the parameters are:
Auto, Manual, Shutter, Iris and bright
2 Confirm Exposure.
Exp Mode press OPEN key, select effect, the
menu change to Exp Mode
3 Cancel Exposure
Exp Mode press CLOSE to cancel the Exposure mode change, the menu change to
Exp Mode
Back the main camera menu
Exp Mode press CLOSE key to cancel the last menu.
Other operation of Exposure Menu
Exp Mode, control the joystick up or down to let the up and down, press OPEN key to
enable the item, then go on control up and down with joystick, and press OPEN key to confirm,
the cursor will change to .

8/17
Exposure ►
White Balance ►
Privacy ►
Other ►
Camera Model ►
Zoom Speed 005
Focus Speed 001
WB Mode Auto
R Gain 210
B Gain 175
WB Mode Auto
R Gain 210
B Gain 175
WB Mode Auto
R Gain 210
B Gain 175
WB Mode Auto
R Gain 210
B Gain 175
Exposure ►
White Balance ►
Privacy ►
Other ►
Camera Model ►
Zoom Speed 005
Focus Speed 001
White Balance
The dome DV860 has the function of Manual White Balance and Auto White Balance.
White Balance ►press OPEN key, enter the White
Balance submenu, then change the parameter,
WB Mode Auto 白平衡模式
R Gain 214(0-255) R 增益
B Gain 175(0-255) B 增益
White Balance Mode operation:
1、WB Mode
2、At WB
Mode, press
OPEN key to
enable the Exp
Mode menu, then it will change to WB
Mode, control the joystick to change the
parameter which order is: Auto, Manual, ATW,
OPW, Outdoor and Indoor. R Gain
3, R Gain
At WB Mode, operate the joystick down let the
cursor come to R Gain, press OPER key to enter the
menu. Then operate the joystick up( increase) and
down( reduce) the R Gain. The homologous parameter is
0-255. Press OPEN key to confirm and back or press
CLOSE to cancel and back.
4, B Gain
At WB Mode operate the joystick to control the
cursor come to B Gain,press OPEN key to enter the B
Gain setting, joystick up and down to increase and reduce
the parameter which from 0-255. Press OPEN key to
confirm and back or press CLOSE to cancel and back.
Privacy Mask
图:2.3.4

9/17
Digital Zoom On
Auto ICR Off
ICR Off
Display Off
Camera Mode Save：
Day Mode
Night Mode 1
Night Mode 2
Camera Mode Exec：
Day Mode
Night Mode 1
Night Mode 2
Privacy1
Privacy2
Privacy3
Privacy4
Exposure ►
White Balance ►
Privacy ►
Other ►
Camera Model ►
Zoom Speed 005
Focus Speed 001
At Exposure ►operate the joystick to let the cursor come to Privacy press OPEN to
enter the submenu, then set the parameter.
There are 4 Privacy masks, they have the same operation.
1, Set privacy mask
At the submenu of the Privacy, press OPEN key to enter
the adjust image, adjust the privacy zone by
OPEN( confirm), CLOSE( cancel), FAR( level increase),
NEAR( level reduce), TELE( vertical increase),
WIDE( vertical reduce). Then press OPEN key to
confirm and back.
2, Clare privacy mask.
a, Restart the speed dome, all of the privacy mask will be cleared.
b, Enter the menu of the Privacy mask, press OPEN key to enter and press CLOSE to clear
the privacy mask you want to clear.
Others of the Camera menu
Press OPEN key to enable the submenu, operate
joystick to change the states of ON and OFF. Press
OPEN to confirm and back and CLOSE to cancel and
back.
Camera Mode
Camera Mode setting menu:
Press OPEN to enter the menu.
There are three mode under the Camera Mode Save
menu, move the cursor to the mode going to be change,
press OPEN the cursor will change to , the setting will
be saved and it will back to after 1 second.

10/17
Open Menu 095
Auto Flip 033
Reference 034
Left Limit 092
Right Limit 093
Preset scan 1 081
Preset scan 2 082
Preset scan 3 083
Preset scan 4 084
Auto Scan 099
Home place Of
f
AS speed 060
PS1 Speed 120
PS1 time 005
PS2 Speed 120
PS2 time 005
PS3 Speed 120
PS3 time 005
PS4 Speed 120
PS4 time
Auto Flip On
The three items under Camera Mode Exec is opposite the three modes above. Move the cursor to
the mode you want to call and press OPEN to confirm and back. The saved mode could be called
by the shortcut preset: Night Mode1—call 101 preset, Night 2---- call 102 preset.
Zoom Speed
At the submenu of Exposal, move the cursor to Zoom Speed, press OPEN, the cursor will
change to , then the parameter can be changed. Press OPEN to confirm and back or CLOSE
cancel and back.
Focus Speed
Move the cursor to Focus Speed, press OPEN, the cursor will change to , then the parameter
can be changed. Press OPEN to confirm and back or CLOSE cancel and back.
Pan
This operation can control the home place of the dome,
adjust the auto panning speed and 4 cruise line with
presets, also the auto flip function.
Home Place OFF (001-032, OFF)
AS Speed 060(000-080) Auto Pan speed
PS1 Speed 120(100-120) Presets cruise 1 speed
PS1 Time 005(5-120) ) Presets cruise 1 stop time.
PS2 Speed 120 Presets cruise 2 speed
PS2Time 005 Presets cruise 2 stop time.
PS3 Speed 120 Presets cruise 3 speed
PS3 Time 005 Presets cruise 3 stop time.
PS4 Speed 120 Presets cruise 4 speed
PS4 Time 005 Presets cruise 4 stop time.
Auto Flip On(On/Off)
Shortcut Key
The functions can be setting by presets number, and can be called by the preset number which
be set.
Note: The right side number is the default short cut key,
they are the number of presets. The number can be saved by new shortcut but the old one will not
be cancel.
Example: Change the number 095 into 16 which after Open Menu, the Menu can be called by 16
preset, and also can be called by 95 preset.
In the presets, the preset scan line 1 will cruise from
presets 1-8, and preset scan line 2 will cruise from

11/17
Camera ►
Pan ►
Shortcut Key
Self act Nothing
Leisure Time 030
Camera ►
Pan ►
Shortcut Key
Self act Nothing
Leisure Time 030
presets 9-16, the preset scan line 3 will cruise from presets 17-24, and the preset scan line 4 will
cruise from 25-32. Every line will back the first preset when it met the point never be set, and it will
quit cruise if the first preset is not be set. The function Auto Scan is right and left limit scan.
Note: The changing of the shortcut key can not be identical with the shortcut key already have.
Operation: Move the cursor to the item which going to be changed, press OPEN, then change the
parameter, press OPEN to confirm and back or CLOSE cancel and back.
Self Act.
The dome will check itself when electric and it will act
the program automatic.
Nothing
P Scan 1 Preset scan 1
P Scan 2 Preset scan 2
P Scan 3 Preset scan 3
P Scan 4 Preset scan 4
A Scan Auto scan ( left and right limit scan
Home Homeplace
Operation: Press OPEN the cursor will change to , and the parameter can be change. Press
OPEN to confirm and back or CLOSE to cancel and back.
Leisure Time
The dome will back to the home place after a while if it
moved manual, an the time is Leisure Time
The parameter is from 1-240.
Operation: Press OPEN the cursor will change to , and
the parameter can be change. Press OPEN to confirm and
back or CLOSE to cancel and back.
SONY CAMERA MENU
Menu Submenu Third Menu Parameter
Exp Mode Auto（Auto，manual；shutter，iris，bright）
Shutter speed 006(0~19)
Iris 015(0~17)
Gain 001(0~15)
Bright 015(0~18)
Back Light OFF(ON/OFF)
Exposure
Slow Shutter OFF(ON/OFF)
WB Mode Auto( Auto，Manual；ATW，OPW，Outdoor，Indoor)
R Gain 210(0~255)
White Balance
B Gain 175(0~255)
Privacy1
Privacy2
Privacy3
Camera
Privacy
Privacy4
图:2.d

12/17
Digital Zoom On(On/ Off)
Auto ICR Off(On/ Off)
ICR Off(On/ Off)
Other
Display Off(On/ Off)
Camera Model Save：
Day Mode
Night Mode 1
Night Mode 2
Camera Model Exec
Day Mode
Night Mode 1
Camera Model
Night Mode 2
Zoom Speed 005(001~007)
Focus Speed 001(001~007)
Home place OFF(001-032,OFF)
AS speed 060(000-080)
PS1 Speed 120(100-120)
PS1 time 005(005-120)
PS2 Speed 120(100-120)
PS2 time 005(005-120)
PS3 Speed 120(100-120)
PS3 time 005(005-120)
PS4 Speed 120(100-120)
PS4 time 005(005-120)
Pan
Auto Flip On(On/Off)
Open Menu 095
Auto Flip 033
Reference 034
Left Limit 092
Right Limit 093
Preset scan 1 081
Preset scan 2 082
Preset scan 3 083
Preset scan 4 084
Shortcut
Key
Auto Scan 099
Self act Nothing (Nothing ,P Scan 1,P Scan 2,P Scan 3 , P
Scan 4, Pattern 1, Pattern 2, Pattern 3)
Leisure 030(001~014)
HITACHI Camera
Note: Please check the camera switch which on the PCB, it must be switched as below:
CAMERA 1st switch 2nd switch 3rd switch 4th switch
HITACHI OFF OFF ON OFF
Note: Please make sure the camera parameters are correct or the camera cannot work or
cannot work well. If this, please enter the camera menu and restore factory settings first, then
setting the parameters as request.

13/17
FAR Confirm NEAR Cancel and Back
Joystick Control the cursor up and down or setting the parameters
►Which have submenu, and press FAR key to enter.
Currently menu.
HITACHI CAMERA MENU
Menu Submenu Third Menu Parameter
Exposure Exp Mode Auto(Auto/AE DSS)
Back light Off(On/Off)
BLC Level 016
Iris
091(000～255)
White Balance WB Mode Auto(Auto/Manual)
R Gain
652(640～767)
B Gain
462(384～511)
Lens Digital Zoom On (On/Off)
D
Zoom MAG mag12(mag 0～mag12)
Zoom Speed High(High,Super h,Normal)
Camera
Focus Speed 016(0～31)
Home place OFF(001-032,OFF)
AS speed 060(000-080)
PS1 Speed 120(100-120)
PS1 time 005(005-120)
PS2 Speed 120(100-120)
PS2 time 005(005-120)
PS3 Speed 120(100-120)
PS3 time 005(005-120)
PS4 Speed 120(100-120)
PS4 time 005(005-120)
Pan
Auto Flip On(On/Off)
Open Menu 095
Auto Flip 033
Reference 034
Left Limit 092
Right Limit 093
Preset scan 1 081
Shortcut
Key
Preset scan 2 082

14/17
Preset scan 3 083
Preset scan 4 084
Auto Scan 099
Self act Nothing (Nothing , Home ,A Scan,P Scan1,P Scan2,P
Scan3, P Scan 4, Pattern1,Pattern2,Pattern 3)
Leisure 030(001~014)
CNB CAMERA
Camera switch set up:
Note: Please check the camera switch which on the PCB, it must be switched as below:
CAMERA 1st switch 2nd switch 3rd switch 4th switch
CNB-200L OFF ON ON OFF
CNB-M1560 OFF ON ON ON
Note: Please make sure the camera parameters are correct or the camera cannot work or
cannot work well. If this, please enter the camera menu and restore factory settings first, then
setting the parameters as request.
NEAR Exit FAR Confirm
TELE Control the cursor up and
setting the parameters
WIDE Control the cursor down and
setting the parameters
CLOSE Quite camera menu and back.
Currently menu
CNB CAMERA MENU
Menu Submenu Third Menu Parameter
BACKLIGHT OFF(ON/OFF)
SLOW
SHUTTER FLD24(OFF , FLD2, FLD 4, FLD 8, FLD 12, FLD 16,
FLD 24, FLD 32, FLD 64, FLD128)
DAY/NIGHT AUTO(ON,OFF,AUTO)
WB CONTROL AUTO(AUTO/PUSH)
SHUTTER AUTO
CAMERA ID 000(000～255)
ZOOM START X001(x001～X022)
ZOOM STOP
X220(X220,X209,X198,X187,X176,X165,X154,X143,
X132,X121,X110,X098,X088,X077,X066,X055,
X044,X033,X022,X011,X001)
Camera
BRIGHTNESS
10(0～15)

15/17
SHARTNESS
25(0～48)
FOCUS PUSH(PUSH/AUTO)
INIT SET OFF(ON/OFF)
Home place OFF(001-032,OFF)
AS speed 060(000-080)
PS1 Speed 120(100-120)
PS1 time 005(005-120)
PS2 Speed 120(100-120)
PS2 time 005(005-120)
PS3 Speed 120(100-120)
PS3 time 005(005-120)
PS4 Speed 120(100-120)
PS4 time 005(005-120)
Pan
Auto Flip On(On/Off)
Open Menu 095
Auto Flip 033
Reference 034
Left Limit 092
Right Limit 093
Preset scan 1 081
Preset scan 2 082
Preset scan 3 083
Preset scan 4 084
Shortcut
Key
Auto Scan 099
Self act Nothing (Nothing , Home ,A Scan,P Scan1,P Scan2,P
Scan3, P Scan 4, Pattern1,Pattern2,Pattern 3)
Leisure 030(001~014)
LG CMERA
Camera switch set up:
Note: Please check the camera switch which on the PCB, it must be switched as below:
CAMERA 1st switch 2nd switch 3rd switch 4th switch
LG OFF ON OFF OFF
Note: Please make sure the camera parameters are correct or the camera cannot work or
cannot work well. If this, please enter the camera menu and restore factory settings first, then
setting the parameters as request.
NEAR Confirm or decrease the
parameter；
FAR Confirm or increase the
parameter
TELE Up；WIDE Down

16/17
NOT USE Can’t be use Have submenu and back
OSD Format
OSD show position
FUNCTION OSD Format Description Remarks
Non display Auto Mode
1 Focus Mode
Manual/ Push Auto mode
Non display Back Light OFF
2 Back Light “BL’’display BLC ON/ Auto BLC Mode
Non display Normal Shutter：NTSC：1/60
PAL：1/50
“F1”display Flickerless Mode
3 Shutter
Speed 1/125
：
：
1/10，000
28 variable steps
4 Motion
Detect
MOTION DETECTED Display when motion is
detected
5 STAND-BY
Mode
Indicate the camera stand-by during the camera’s power turning on
DX270 Digital Zoom Model
6 Zoom
Display X27 Optical Zoom Model
7 CAMERA ID According to write the identification number to each camera,
multi-point control is available are available (PC Control 000-255)
AWB White Balance Auto
SWB
Special Auto White Balance; Adjustment Mode
according to change of external illuminant. RED
ADJUST and BLUE ADJUST (0-255) are
available. After changing R/W value, the
maintenance mode is AUTO.
WB Preset for Indoor
WB Preset for Outdoor
Manual WB Adjustment; In manual mode the
HUE control is available 0-99
8 WBC Mode
PWB
Push Auto White Balance; Turn this mode ON,
the white trace automatically. Turn this mode
OFF, preserve the white of final auto tracing
action (Manual)
The Menu shortcut List of High speed dome with LG camera
Main Submenu Last Menu Parameters(optical)
Exp Mode Auto（Auto，manual；shutter up，iris，bright）
Shutter speed 006(0~19)
Camera Exposure
Iris 015(0~17)

17/17
Gain 001(0~15)
Bright 015(0~18)
Back Light OFF(ON/OFF)
Slow Shutter OFF(ON/OFF)
WB Mode Auto( Auto，Manual；ATW，OPW，Outdoor，Indoor)
R Gain 210(0~255)
White Balance
B Gain 175(0~255)
Privacy1
Privacy2
Privacy3
Privacy
Privacy4
Digital Zoom On(On/ Off)
Auto ICR Off(On/ Off)
ICR Off(On/ Off)
Other
Display Off(On/ Off)
Camera Model Save：
Day Mode
Night Mode 1
Night Mode 2
Camera Model Exec
Day Mode
Night Mode 1
Camera Model
Night Mode 2
Zoom Speed 005(001~007)
Focus Speed 001(001~007)
