BAABALI FT01 User manual

Smart Helmet User Manual
FT01 FT03 FT04 KS10

1
Product
FT01
Please take some time to read the following contents for better
understand of how to use your helmet.
Thank you for choosing our great product.
Protective helmets are categorized as personal protective equipment
and help prevent or at least significantly mitigate head injuries.
It is for your safety and maximum comfort.
You will notice we share your passion for cycling.
Like cars, we have now equipped lights and blinkers for bicycle helmets,
on the back and front of the helmet. Using a remote control mounted on
the handlebars, the blinkers can be switched in the desired direction and
depending on the model, you can also enjoy a hands-free speaker device
integrated into the helmet, for example to listen to music or navigation.
The helmet works with a Duplex radio communication that controls both
the blinkers, and is connected to the mobile phone by Bluetooth.
KS10
FT03 FT04

32
Back Turn Signal
Front Turn Signal
goggles
Apply to FT03
FT01
FT03 FT04
Contents:
1. GENERAL INFORMATION
2. CHARGE, WAKE UP AND CONNECT.
3. USER INSTRUCTION/BAABALI SMART HELMET
4. HOW DO I ADJUST THE SIZE AND STRAP CORRECTLY
KS10

54
2.1. Turn signal function
A. Please charge the helmet
(like shown in image*1) for
about 4 hours, turn signal
indicators stop flashing when
fully charged.
B. Please charge the remote
(like shown in image*2) for
about 2 hours. The red LED
indicator stops blinking when
fully charged.
*1 *2 *3 *4
1. GENERAL INFORMATION
This helmet is a high-quality protection for cyclists, skaters and
scooters.
This helmet should not be used by children while climbing or doing
other activities when there is a risk of strangulation /hanging if the
child gets trapped with the helmet.
Warning!
2. CHARGE, WAKE UP AND CONNECT
Please refer to the function that your helmet has.
2012 Europäische Norm von Helmen für
Rad-fahrer und für Benutzer von
Skateboards und Rollschuhen.
EN 1078:
*1 *2 *3 *4
KS10
Press the reset button on the helmet with a needle as shown in
Your Baabali Smart Helmet is still in sleep mode (Battery Safe Mode),
this is because no using in 1 week.

76
3. When successful connected, you will
hear a voice reminder says: your headset is
connected, and the blue LED flashes every
4 seconds as confirmation of the successful
pairing.
4. If the helmet stand by for 10 minutes
without successful connection, it will go off
automatically.
Goggles
Apply to FT03
When changing the goggles of
helmets,please pay attention to
remove and fix the buckle in
perpendicular direction.
Otherwise, the fixing buckle
could be possibly broken.
2.2 Bluetooth function
Get the helmet fully charged first. Then, please follow below
procedures to pair the Baabali Smart Helmet with your mobile phone.
FT01 FT03 FT04
KS10
2. Now turn on the Bluetooth function of your smart phone and try to
connect Bluetooth equipment named as Baabali.
1. Press the M button on chin strap until red and blue LED flashes
alternatively (the red LED lights up first, means the helmet is on, but
Bluetooth is not on).
Now the helmet is standby.
All the LED lights on the helmet flash quickly.
image*3.
At this time, press the reset button the remote control as shown in
image*4

98
Left turn
Right turn
Go Straight
*5
3.1 Remote control
* 1 Fix the fastening base on the steering
bar with the cable ties, as shown in
image*5.
* 2 Turn on the Smart Helmet: Press the
left, right or straight button.
* 3 Blinker left: Press the left button if you
want to turn left. The blinker on the left of
the helmet turns on and back to straight
indication status automatically after 20
3. USER INSTRUCTIONS
seconds.
* 4 Blinker on the right: Press the right button if you want to turn right. The
blinker on the right of the helmet switches on and back to straight indication
status automatically after 20 seconds.
* 5 Straight: The straight button switches the lighting back to going straight
status, ie no turning status, used when you want to cancel the turn signal
status beforehand.
* 6 key: Turn off the helmet. Please hold the button for 2 seconds.
Note: If the helmet does not follow the key strokes, a tiny red LED near the
button you press flashes quickly. In this case, please check whether the
helmet and the remote control not paired or the helmet is out of power.
Red LED near button flashes during charging, and turns off when fully
charged.
3.2 Operating a Baabali Smart Turn Signal Helmet
* 1 Turn on the smart helmet: Press the left, right or straight button on
the remote control.
* 2 key: Turn off the helmet. Please hold button on the remote control
for 2 seconds.
3.3 Operating a Baabali Smart Bluetooth Helmet
* 1 Answer a call: When there is an incoming call,
you can press the M button on the chin strap or
operate on the phone to answer the call.
* 2 Reject a call: When there is an incoming call, you M button

1110
can hold the M button on the chin strap for 3 seconds or operate on the
phone to reject the call.
* 3 Start a call: When double click the M button on chin strap, you will be
calling the last record on your contact history. You need to operate on the
phone if calling other numbers. (if you have a voice assistant in the phone,
press M button for 2 seconds to reach the assistant and get help from it for
calling.
* 4 End a call: Press the M button on chin strap or operate on the phone to
end a phone conversation.
* 5 Volume control: During the phone call or listening to music, speaker
volume can be adjusted. Hold the + or – button to turn the volume up or
down. Note: the volume of music and that for phone conversation are
independent to each other. When music volume is loudest, the phone call
might not, need to adjust separately.
* 6 Music Play: During music play, press + or –button once to change the
song to be next or previous one.
FT01
FT03 FT04

This Bicycle-Sports Safety Helmet uses a quick-release buckle that is
simple and can be buckled and unbuckled without changing the
adjustment. The straps must be snugly and evenly tensioned. Place
the helmet firmly on your head and fasten the buckle.
Notice which strap is loose. Tighten the loose strap after removing the
helmet.
To tighten the chin strap,hold the buckle with one hand. Then pull the
excess strap in through.(See Diagram A).
Retention System
To tighten the rear strap,pull excess from the
rear of strap 2.Hold the helmet with one
hand.With the other hand,hold the strap
where they pass under your chin. Then pull
from side to side to balance the length of all
four straps.(See Diagram B)
The helmet must sit firmly and level on your
head. (See Diagram C)To lower the front of
4. HOW DO I ADJUST THE SIZE OF MY HELMET AND FITS ME CORRECTLY
The Bicycle-Sports Safety Helmet you have just purchased provides
protection, whether on or off the road. To insure proper use of this
helmet, familiarize yourself with its features, fit and care by carefully
reading through this manual before wearing your new helmet.
Protection and Ventilation
The outer shell allows the helmet to be rated one of the lightest
helmets while providing excellent durability and integrity. The multiple
vents with inner air channels draw the air through the helmet and over
the brow for maximum cooling.
Pad Fitting
The helmet must fit properly to be effective. With a proper fit, the
helmet will not move back and forth or side to side while fastened. If
the helmet does not fit with installed pads, simply remove them and
install a different size pad. To insure the proper fit, mix and match the
pad thickness to best conform to your head shape.
1312

1514
the helmet to cover your forehead,tighten the chin strap and loosen
the rear strap. To raise the front,loosen the chin strap and tighten the
rear strap.
To check fo proper tension,put on the helmet and fasten the
buckle.Open your mouth. You should feel the strap pulling against
your chin.
Then attempt to pull the helmet off the front or rear. If the helmet
comes off,increase strap tension and examine if thick enough pads
are being used. The helmet should not be able to roll forward or
backward excessively.It should not be possible to remove the helmet
without unfastening the buckle.
NOTE: Please check adjustment every time this helmet is worn.
Final Check
The straps should be positioned that they do not cover the ears and
that the buckle is away from the jaw when correctly fitted.
Buyer should always try different sizes and choose the size which feel
secure and comfortable on the head.
It is important for the helmet to fit snugly on your head and must be
fastened to provide maximum protection.
All adjustments should be checked each time the helmet is worn,
making sure it fits snugly at all time.
Caring for Your Helmet
Clean the headgear with mild soap and water only. The use of any
solvents, paints or decals can cause damage to the helmet and make
it ineffective in the result of an accident.
The important thing to remember is that the helmet fits snugly. If you
can fit it forward or backward, you need to tighten the strap
adjustment.

1716
The helmet should not be adapted for the purpose of fitting
accessories in a way not recommended by the manufacturer.
The helmet shall be replaced after 3 years, since the manufacture
date.
For the used helmet disposal, please follow up the local disposal low
for the waste product.
It's danger to modify or remove any of original component parts of the
helmet other than as recommended by the manufacturer;
The Bicycle-Sports Safety Helmet is designed and intended
exclusively for use while cycling, and other non-motorized sports. It is
not intended for and will not provide adequate safe protection if used
during motorsport or moped use. No helmet can protect the wearer
against all unforeseeable impacts. However, for maximum protection,
the helmet must fit well and all retention straps must be securely
fastened.
Keep Helmet Out of Extreme Heat
Helmet will be damaged if exposed to temperatures exceeding 150℉.
Dark vehicles and storage bags can exceed this on very hot days,
Heat damaged helmets will have random disfigured areas where the
texture appears bubbly and uneven. If damaged, helmets should be
destroyed and replaced immediately.
Warning
Bicycle - Sports Helmets
Unfortunately some accidents result in head injury that cannot be
prevented by any helmet. Depending on the type of impact, even very
low speeds can result in a serious head injury or fatality. Always ride
with extreme caution and be sure to read this manual thoroughly.
This headgear is designed to absorb the energy of a blow by partial
destruction or damage itself. Even though such damage may not be
visible, the helmet should be destroyed or replaced, if it is involved in
an injury-related fall.
Important Information

We strive to deliver impeccable products, but if something is not to your
satisfaction or if there are defects, please contact us.
Customer Service
1918
THIS HELMET
MEETS CE EN 1078:2012+A1:2012 HELMET STANDARDS
IMPORTANT!
This helmet has passed EN1078:2012+A1:2012 to show conformity to
the respectively Regulation EU 2016/425.
EU declaration of conformity will pack with product for sell.
Tillystraße 2
90431 Nürnberg
NOTIFIED BODY REFERENCE No. 0197
EC TYPE EXAMINATION CERTIFICATE ISSUED BY:
TÜV Rheinland LGA Products GmbH
BAABALI HELMET
OWNERS MANUAL

20
8Ω300mW
Permanent-magnet dynamic loudspeaker
15.3*6.9 mm in diameter
Nominal input 300mW, maximum input 800mW
1.8 V
3.7 V
8Ω±15% test @200Hz 3 v
100~18,000Hz
88~1kHz
200mA
5% less
-20~60℃
-30~+70℃
Must be normal after load test in pink noise,0.3W, for
consecutively 48 hours
Must be normal after heat resistance test at 60±2℃and relative
humidity 20-25%16hours and then room temperature 1hour
Must be normal after cold resistance test at -20±3℃ and relative
humidity - %16hours and then room temperature 1 hour
applicable scope
Type
Dimensions
Power
Mean working voltage
Working voltage (maximum value)
Nominal Impedance
Resonant frequency
Sound pressure level (dB)
Distortion
Working temperature
Storage temperature
Reliability
Continuous load test
Heat resistance test
Cold resistance test
Current consumption (maximum value)
Bluetooth version
Maximum Bluetooth transmission power
Bluetooth frequency band
Maximum General 2.4GHz transmission power
General 2.4GHz frequency
4.1
5dBm
2402MHz-2480MHz
0dBm
2438MHz
Warm prompt: The parameters are subject to that of physical product.There might be
changeswithout prior notice.
Version: January 2019
