baaske e-medic SILENCE TP 7 User manual

ii
Version Change History
Date Version Description Remark
2018/8/16 1.0 First release Cosa

iii
Acknowledgments
Intel® Celeron processor is registered trademarks of Intel®
Corporation.
IBM, PC/AT, PS/2 are trademarks of International Business
Machines Corporation.
Microsoft® Windows is a registered trademark of Microsoft®
Corporation.
RTL is a trademark of Realtek Semi-Conductor Co., Ltd.
C&T is a trademark of Chips and Technologies, Inc.
UMC is a trademark of United Microelectronics Corporation.
ITE is a trademark of Integrated Technology Express, Inc.
Intel is a trademark or registered trademark of Intel
Corporation.
Microsoft Windows is a registered trademark of Microsoft
Corporation.
Winbond is a registered trademark of Winbond Electronics
Corporation.
All other product names or trademarks are properties of
their respective owners.

iv
FCC Class B
This equipment has been tested and found to comply with the limits for a
Class B digital device, pursuant to Part 18 of the FCC Rules.
These limits are designed to provide reasonable protection against harmful
interference when the equipment is operated in a residential environment.
This equipment generates, uses and can radiate radio frequency energy. If
not installed and used in accordance with this user manual, it may cause
harmful interference to radio communications.
Note that even when this equipment is installed and used in accordance
with this user manual, there is still no guarantee that interference will not
occur. If this equipment is believed to be causing harmful interference to
radio or television reception, this can be determined by turning the
equipment on and off. If interference is occurring, the user is encouraged
to try to correct the interference by one or more of the following measures:
Reorient or relocate the receiving antenna
Increase the separation between the equipment and the receiver
Connect the equipment to a power outlet on a circuit different from
that to which the receiver is connected
Consult the dealer or an experienced radio/TV technician for help
Warning:
Any changes or modifications made to the equipment which are
not expressly approved by the relevant standards authority could
void your authority to operate the equipment.
To avoid risk of electric shock, this equipment must only be
connected to a supply mains with protective earth.
Do not modify this equipment without authorization of the
manufacturer.

Safety Instructions
Intended use
The e-medic Silence TP7 is intended to serve as a medical monitor
which is designed for general purpose for hospital environment. It
shall not be used for life-supporting system.
Intended User profile
The equipment is intended for infant or adults by profession
Health care professionals.
Greeting & Setup
Thank you for purchasing the e-medic Silence TP7 unit. We wish that
this unit will be durable and reliable in providing your medical
application needs. Please follow the instructions below to ensure
the unit continues to have high performance.
Unpacking
After opening the carton, there will be a medical panel PC unit
with an accessory box. Examine the contents to see if there are
damages to the unit and if all accessories are present.
Setting up
Please read this manual carefully and remember to keep this
manual for future reference.
Safety Instructions & Cleaning
The unit has undergone various tests in order to comply with
safety standards. Inappropriate use of the open frame unit may
be dangerous. Please remember to follow the instructions below
to insure your safety during the installation and operating
process.
Transporting & Placement of unit
1. When moving the unit on a cart; be very cautious. Quick
stops, excessive forces and uneven surfaces may cause
the cart to overturn thus risking the unit to fall to the
ground.
V
Note: Remove all batteries before shipping the device, because
they cannot be turn off separately. We are not liable for dama-
ge caused by accidentally switching on the device during trans-
port.

vi
2. If the medical panel PC unit does fall to the ground,
immediately turn the power off and disconnect cords. Then
contact a service technician for repairs. Continual use of
the unit may result cause a fire or electric shock. Also, do
not repair the unit on your own.
3. Having two or more people transporting the display unit is
recommended. In addition, when installing the unit by
suspending it also requires two or more people.
4. Before suspending the unit, make sure the material used
for suspension is sturdy and stable. If not properly
suspended, the display unit may fall and cause serious
injury to people standing nearby as well as to the unit
itself.
5. If you wish to mount the display unit, remember to use
only the mounting hardware recommended by the
manufacturer.
Electrical and Power Source Related
1. This medical panel PC unit must operate on a power source
as shown on the specification label. If you are not sure
what type of power supply used in the area, consult your
dealer or local power supplier.
2. The power cords must not be damaged. Applied pressure,
added heat, and tugging may damage the power cord.
3. The power cord must be routed properly when setup takes
place. We advise that this aspect measure is to prevent
people from stepping on the cords or while the unit is
suspended to prevent flying objects from getting tangled
with the unit.
4. For plug-in equipment, the power outlet socket must be
located near the equipment and must be easily accessible.
5. Do not overload the AC outlets or extension cords.
Electrical shocks or fires may occur from overloading.
6. Do not touch the power source during a thunderstorm.
7. If your hands are wet, do not touch the plug.

vii
8. Use your thumb and index finger, grip firmly on the power
cord to disconnect from the electrical socket. By pulling the
power cord, may result in damaging it.
9. If the unit is not going to be in use for an extended period
of time, remember to disconnect the unit.
10. The medical panel PC unit uses voltage between
100-240VAC. Connect the unit to a power source with the
same numerical value as shown. Please use only the power
cord provided by the dealer to ensure safety and EMC
compliance.
Various Factors of Environment
1. Do not insert objects into the openings.
2. Do not have liquids seep into the internal areas of the
medical panel PC unit.
3. Having liquids seep in or inserting objects into the unit
may result in electric shocks from taking and/or short
circuiting the internal parts.
4. Do not place the medical panel PC unit in the presence of
high moisture areas.
5. Do not install the medical panel PC unit in a wet
environment.
6. Do not place near unit near heat generating sources.
7. Do not place the unit in a location where it will come in
contact with fumes or steam.
8. Remember to keep the medical panel PC unit away from
the presence of dust.
9. If water has flow in or seep in, immediately disconnect the
open frame unit. Then contact a service technician for
repairs.
Ventilation Spacing
1. Do not cover or block the openings on the top and back
sides of the display unit. Inadequate ventilation may cause
overheating thus reducing the lifespan of the unit.

viii
2. Unless proper ventilation is present, do not place unit in an
enclosed area; such as a built-in shelf. Keep a minimum
distance of 10 cm between the display unit and wall.
Operating principle
A Medical Panel PC has four main components: the
arithmetic logic unit (ALU), the control unit, the memory,
and the input and output devices (collectively termed I/O).
These parts are interconnected by buses, often made of
groups of wires.
The control unit, ALU, and registers are collectively known as
a central processing unit (CPU).
Inside each of these parts are thousands to trillions of small
electrical circuits which can be turned off or on by means of
an electronic switch. Each circuit represents a bit (binary
digit) of information so that when the circuit is on it
represents a "1", and when off it represents a "0" (in positive
logic representation). The circuits are arranged in logic gates
so that one or more of the circuits may control the state of
one or more of the other circuits.
Cleaning the unit
1. Remember to turn off the power source and to unplug the
cord from the outlet before cleaning the unit.
2. Carefully dismount the unit or bring the unit down from
suspension to clean.
3. Please use a dry soft cloth to clean the unit.
4. Take a dry cloth and wipe the unit dry. Remember to avoid
having liquids seep into the internal components and areas
of the medical panel PC unit.
Error message / Troubleshooting
No power
1.
Connect the AC adapter to the compu
ter, and
then plug it into an AC outlet.
2. Turn on the computer.

ix
Servicing, Repairing, Maintenance & Safety Checks
1. If the unit is not functioning properly, observe the
performance level of the display closely to determine what
type of servicing is needed.
2. Do not attempt to repair the medical panel PC unit on your
voltages and other dangerous conditions. Notify and
request a qualified service technician for servicing the unit.
3. To avoid risk of electric shock, this equipment must only be
connected to a supply mains with protective earth.
4. If any of the following situations occur turn the power
source off and unplug the unit. Then contact a qualified
service technician.
(a) A liquid was spilled on the unit or objects have fallen
into the unit.
(b) The unit is soaked with liquids.
(c) The unit is dropped or damaged.
(d) If smoke or strange odor is flowing out of the operating
unit.
(e) If the power cord or plug is damaged.
(f) When the functions of the unit are dysfunctional.
5. When replacement parts are needed for the medical panel
PC unit, make sure service technicians use replacement
parts specified by the manufacturer, or those with the
same characteristics and performance as the original
parts. If unauthorized parts are used it may result in
starting a fire, electrical shock and/or other dangers.

x
ISO 7000-0434: Caution
ISO 7000-1641: Follow operating instructions or
Consult instructions for use.
IEC 60417 -5009: STAND-BY.
IEC 60417-5031: Direct current.
EU-wide legislation, as implemented in each
Member State, requires that waste electrical and
electronic products carrying the mark (left) must
be
disposed of separately from normal household
waste. This includes monitors and electrical
accessories, such as signal cables or power cords.
When you need to dispose of your display products,
please follow the guidance of your local authority, or
ask t
he shop where you purchased the product, or if
applicable, follow any agreements made between
yourself.
The mark on electrical and electronic products only
applies to the current European Union Member
States.

xi
When networking with electrical devices, the operator is
responsible for ensuring that the resulting system meets the
requirements set forth by the following standards:
EN 60601-1 (IEC 60601-1)
Medical electrical equipment
Part 1: General requirements for safety
EN 60601-1-1 (IEC 60601-1-1)
Medical electrical equipment
Part 1-1: General requirements for safety
Collateral standard: Safety requirements for
Medical electrical systems
EN 60601-1-2 (IEC 60601-1-2)
Medical electrical equipment
Part 1-2: General requirements for safety
Collateral standard: Electromagnetic compatibility;
Requirements and tests

xii
Accessory equipment connected to the analog and digital
interfaces must be in compliance with the respective nationally
harmonized IEC standards (i.e. IEC 60950 for data processing
equipment, IEC 60065 for video equipment, IEC 61010-1 for
laboratory equipment, and IEC 60601-1 for medical equipment.)
Furthermore all configurations shall comply with the system
standard IEC 60601-1-1. Everybody who connects additional
equipment to the signal input part or signal output part
configures a medical system, and is therefore, responsible that
the system complies with the requirements of the system
standard IEC 60601-1-1. The unit is for exclusive interconnection
with IEC 60601-1 certified equipment in the patient environment
and IEC 60XXX certified equipment outside of the patient
environment. If in doubt, consult the technical services
department or your local representative.

xiii
Caution:
DO NOT LEAVE THIS EQUIPMENT IN AN UNCONTROLLED
ENVIRONMENT WHERE THE STORAGE TEMPERATURE IS BELOW
-20° C (-4° F) OR ABOVE 60° C (140° F). THIS MAY DAMAGE THE
EQUIPMENT.
This equipment shall not be used in life support systems.
The user is not to touch SIP/SOPs and the patient at the same
time.
Caution Use suitable mounting apparatus to avoid risk of injury.
Caution - Risk of explosion if battery is replaced by an incorrect
type. Dispose of used batteries according to the instructions.
(If battery pack is not used for 1 month, it is recommended to
remove the battery pack from equipment.)
IEC 704-1:1982 is no more than 70dB (A).
A) Grounding reliability can only be achieved when the equipment
B) Use a power cord that matches the voltage of the power
outlet, which has been approved and complies with the safety
standard of your particular country.
C) Caution: This adapter Sinpro HPU101-107 is a forming part
of the medical device
Contact information:
Baaske Medical GmbH & Co. KG
Bacmeisterstraße 3
32312 Lübbecke | GERMANY
Tel. [phone]
E-Mail: [email protected]

xiv
Table of Contents
Acknowledgments ...................................... iii
FCC Class B............................................... iv
Safety Instructions......................................v
Introduction ............................................1
Product Description .....................................1
Package list ................................................2
Features ....................................................3
Specifications .............................................4
electromagnetic emissions.......................7
electromagnetic immunity .......................9
Immunity.................................................10
Cleaning/Disinfecting .................................12
Getting Started ......................................13
System Set Up..........................................13
Dimension................................................14
System View ............................................15
Disconnect Device .....................................20
BIOS Setup ............................................21
Appendix................................................34
A. Jumper settings and Connectors .............34
B. Battery Pack Specifications (optional kit)..54
C. Scrap Computer Recycling......................57

Introduction
Product Description
The e-medic Silence TP7 Medical Panel PC is based on Intel 7th
generation Core i mobile CPU (U series) processor, it accommodates
one M.2 SATA SSD as drive disk and up to 32GB DDR4 SODIMM.
The high brightness LCD, Fanless solution, integrated multimedia
functions and extensive expansion options make them the perfect
platform upon which to build comprehensive lifestyle computing
applications.
The e-medic Silence TP7 includes all the features of a powerful
computer into a slim and attractive chassis. Resolutions. Integrating
with high brightness LCD is easier to analyze DICOM image.
The e-medic Silence TP7 is compact, Giga LAN and selectable WLAN
network compatible PC with full safety and medical approval and
features to control a dedicated system with a wide variety of
applications. Combining the e-medic Silence TP7 into your system can
achieve both cost-saving and efficient improvements.
Common applications include LIS (Lab Information Systems) and
Electronic Medical Record. The e-medic Silence TP7 are definitely your
perfect choices.
1

Package list
Before you begin installing your Medical Station, please make
sure that the following items have been shipped:
• The e-medicTM Silence TP7 Medical Panel PC unit
• User‘s manual, chipset drivers
• Power Adapter x 1 (Mf:Sinpro, type/model: HPU101-107)
• Power cord Hospital grade used (US type), or other type
in UK, EU etc.
• Screw x 8 (VESA 100 use)
2

3
Features
Anti-bacteria (MRSA) plastic housing
22"/ 24" full HD (1920X1080) MVA Diagnostic Panel
High performance intel 7th generation Core i CPU (Kabylake U
series), 15W max.
Integrated hot-swappable batteries
Support Intel Vpro technology by CPU
Supports Dual Channel DDR4 SODIMM up to 32GB
P.cap Multi-Touch Screen (support 10 fingers)
M.2 SATA SSD as drive disk (by model), and optional 2.5
HDD driver bay with doggy door
Internal expansion support M.2 E key x 1, mini PCIe x 1
Easy wipe surfaces with no internal corners
IP65 at front side
Fanless solution
USB3.1 gen2 x 2 (optional order configuration)
USB/LAN/COM isolated module by different configuration
(optional order configuration)
Supports PCI-E x4 slot
Full HD capture card as option
Optional WLAN/Bluetooth module with inner antenna, battery
pack, 5M pixel camera, desktop stand and project with RFID
solution
USB/LAN/COM isolated module by different configuration
(optional order configuration)

4
Specifications
[
Hardware Specifications
Display 22"/24" 250 nits 1920x1080 TFT LCD
CPU Support FCBGA1356 7th generation Intel® Core i7/i5/i3
and Celeron processor (15W max.)
Disk Drive Space
M.2 Type SATA SSD 2260 slot interface x 1
(SSD, 3.3Vdc, 1.5A max.)
Optional
door (5Vdc, 1.0A max.)
Expansion
One Mini PCIe slot (total loaded 2.277W)
One M.2 Type E slot (total loaded 2.277W)
One PCI-E x 4 expansion slot
(total loaded 13.25W
max.)
Button
Power // Audio adjustment (+)(-) // brightness (+)(-
)
// Reading Light // LCD on/
off // Clean me(auto
release after 1 minute) // Fn

5
I/O
Standard version
PCI-E x 4 slot *1
PCI-E x 4 slot *1 (Gold finger)
RS-232 port *1 + RS-232/422/485 port *1
USB 3.0 port *4
Side USB 3.0 port *2 (Option )
DC-in w/ lock function *1
Gigabit LAN RJ-45 Connectors *2
DP output *2
Sound:
Line-in *1
Line-out *1
2W Speaker *2
Isolated version
Isolated 4KV USB2.0 *1
Isolated 4KV GigaLAN *1
Isolated 4KV RS-232 *1, RS-232/422/485 *1
(The isolated ports verified through Dielectric test
4000Vac only)
PCI-E x 4 slot *1
USB 3.0 port *4
Side USB 2.0 port *2
DC-in w/ lock function *1
Gigabit LAN RJ-45 Connectors *1
DP output *2
Sound:
Line-in *1
Line-out *1
2W Speaker *2
USB3.1 gen2
PCI-E x 4 slot *1
PCI-E x 4 slot *1 (Gold finger)
RS-232 port *1 + RS-232/422/485 port *1
USB 3.0 port *4
USB 3.1 gen2 *2
Side USB 3.0 port *2 (Option )
DC-in w/ lock function *1
Gigabit LAN RJ-45 Connectors *2
DP output *2
Sound:
Line-in *1
Line-out *1
2W Speaker *2

LCD Specifications
Model Name e-medic Silence TP7
Display Type LED
Max. Resolution 1920 x 1080 (Full HD)
Contrast Ratio 3000 : 1 (Typ)
Pixel Pitch (um) 248.25 x 248.25
Luminance (cd/m2) 250 (TYP)
Viewing Angle 178°(H)
178°(V)
Cautions:
Continuous displaying fixed pattern may induce image sticking.
It`s recommended to use screen saver or moving content
periodically if fixed pattern is displayed on the screen.
Power Adapter Specifications
Power Close-frame
MFR Sinpro
Type HPU101-107
Input Rating AC 100 ~ 240 V, 1.2 0.5A @
47 ~ 63 Hz
Output Rating DC 18V, 5.55A
MTBF 100,000 hrs operation at 25°C
Classification Power by Class I certified po-
wer adapter. No applied part.
Mode of operation Continuous operation
System input rating DC 18V, 5.55A
Mechanical Specifications
Architecture Close-frame
Front Bezel PCT touch screen / PET bezel
with resistive touch screen
Color Medical-white
Mounting / Holder VESA 100mm
Construction 3mm ABS + PC TYPE Plastic
housing
Dimension (WxHxD) 22" 541 x 352.8 x 56 mm
24" 594 x 397.0 x 56 mm
Net Weight 22" 7.0 kg (w/o power adapter)
24" 9.0 kg (w/o power adapter)
Packing Filler PE
6
