Baby Elegance Cupla Duo User manual

Baby Elegance
Dublin, Ireland
www.babyelegance.com
Please read the following instructions and warnings
carefully before use and keep for future reference.
By Baby Elegance
2IN1
PUSHCHAIR
user manual

Cúpla Duo Pushchair
Care and maintenance
• Always store in a clean and dry place.
• Clean the frame by wiping with a damp cloth.
• Spot clean fabrics with warm water and mild soap.
• Do not use abrasives, bleach or strong detergents.
• Ensure fabric is dry before storing.
• Occasionally clean and lubricate wheels and axles
with a light lubricating oil.
• Regularly check for loose parts and tighten when required.
• Damaged or broken parts should be replaced.
adjustable
handle button
safety buckle
foot rest
swivel lock
seat fabric
bumper bar
basket
brake lever
front wheel
rear wheel
handle tube
removable
bumper bar button
folding lever
canopy
folding latch
adjustable
foot rest button
cúpla duo pushchair user manual

To open stroller frame
A) When you fold the stroller the folding latch will lock into position automatically.
B) Release the folding latch by pulling out with one hand.
C) Grip the handle and lift up to unfold the stroller with the other hand.
To assemble and disassemble front wheels
2) To assemble, insert front wheel set peg into the plastic case until you hear it
‘click’. To disassemble, press down the button on the plastic base and pull the
wheel set out.
To assemble and disassemble rear wheels
3) Align the cog hole with the axle, push into until you hear it ‘click’.
To disassemble, press the button and pull out the wheel.
To unfold and assemble
To assemble and disassemble seat unit
4) To assemble: fix the rear adapter and front adapter as Fig. 1/3/4, then align
seat pegs with the holes on the frame as Fig. 2/5 and insert unit until you
hear it ‘click’. To disassemble, press in both buttons and pull up seat unit.
To assemble the canopy
5) Align the holes on the canopy fixture with the fixing rivets on the handles. Press
the fixture onto the handles.
To assemble and disassemble bumper bar
6) To assemble: align the bumper bar pegs with holes in the front seat unit and insert
into until you hear it ‘click’. To disassemble, press down both buttons on bumper
bar and pull out.
baby elegance
5 6
4
cúpla duo pushchair user manual
WARNING: DO NOT ADJUST SEAT WHILE YOUR CHILD IS IN THE PUSHCHAIR
A B C
1
23
button
disassemble
assemble
12
3 4 5

To use front swivel lock
7) Press down on swivel lock level to swivel. Pull back the swivel lock lever and fix it
into the base notch so wheels can only move steadily.
To use breaks
8) When stroller is stopped, press down on both rear brake levers with foot.
To unlock, lift up with toe.
To adjust rest
9) Press down both round buttons to adjust foot rest.
To adjust backrest
10) To lower seat, pull the plastic lever and pull down the seat.
To raise seat, pull up the backrest.
To use restraint system
11) To unlock buckle, press in on center button and pull harness from each side. To
lock buckle, push each side of the harness into buckle until they ‘click’ in place.
To adjust handle
12) Press the buttons in to adjust the handle to different heights.
To fold stroller
13) Take hold of the handlebars and pull the folding levers on both edges upwards.
At the same time, press down handles to fold stroller.
812
10
711
9
Instructions for use
13
baby elegance cúpla duo pushchair user manual

For one child
For two children
14
15
16
To Convert Seat Unit To Carry Cot
16) Release two buckles at the back of seat, the seat can transfer into carry cot function.
twin mode single mode
1 2 3
Using the pushchair in single and twin modes
14) For single use: The rear seat adapter receiving end should be facing down towards
the front of the buggy (Fig. 3).
For twin use: Push the button to remove the adaptor and rotate 180°, with the
receiving end facing towards the handle (Fig 1-2).
15) Once the rear seat adapter is in twin version, assemble your front seat adapter
and one more seat. The stroller can be used for two children.
For demo videos and more, visit babyelegance.com
baby elegance cúpla duo pushchair user manual

PLEASE READ THESE INSTRUCTIONS CAREFULLY AND
ENSURE THAT THEY ARE FOLLOWED AT ALL TIMES.
WARNINGS
• Follow the manufacturer’s instructions at all times.
• Put on all the brakes whenever you park the pushchair.
• Do not leave children unattended.
• Do not carry extra children or bags on this pushchair, unless it is an
approved accessory.
• Never add heavy objects or shopping to the pushchair as this will cause
the balance of the pushchair to be distorted.
• When adjusting the pushchair, please ensure children are clear of any
moving parts to avoid injury.
• Please ensure that the safety harness is adjusted and used at all times.
• Check that the pushchair is fully erected and that all safety locks
are engaged before placing a child in the pushchair.
• The weight of the child using this pushchair should not be more
than 15 kg.
• Suitable age: 0-36months.
• If using this pushchair for a new born, it is recommended to use
the most reclined position.
• The maximum weight of the basket is 5kgs.
• The bumper bar of the front seat unit should not be used as
a carrying handle.
• Do not allow children to stand on the seat or footrest.
• Do not use on stairs or escalators.
• Do not use the pushchair near an open fire, barbeque, or exposed flame.
• Do not run or jog with this pushchair.
• Do not attempt to lift the pushchair by the bumper bar / tray
as it may disengage.
• Only use replacement parts supplied by the manufacturer.
• Always take care when placing and removing children from the pushchair
to ensure the unit does not become unbalanced.
For two children
IMPORTANT: THESE INSTRUCTIONS DETAIL THE SAFE USE,
OPERATION AND MAINTENANCE OF THE PUSHCHAIR.
PLEASE KEEP THIS USER MANUAL FOR FUTURE REFERENCE.
EN1888-2012 APPROVED
baby elegance
