Baby Vida Oxygen Monitor User manual

oxygen monitor
INSTRUCTIONS
& PRODUCT
INFORMATION

2
HOW IT WORKS
3
WHAT YOU NEED
4
FITTING INSTRUCTIONS
7
INSTALLING THE APP
8
APP INSTRUCTIONS
10
APP INDICATORS
12
CARE & PRODUCT MATERIALS
TABLE OF CONTENTS

HOW IT WORKS
MONITORS AND ALARMS TO READINGS
OUTSIDE OF NORMAL RANGE
The Baby Vida Oxygen Monitor monitors your baby’s
oxygen level and heart rate. If either of these readings
fall outside of a normal range, an alarm will sound
through your smart device linked to the Baby Vida App.
0–12 MONTHS0–12 MONTHS
OXYGEN
LEVEL
OXYGEN
LEVEL
93%–100%93%–100%
0%–92%
NORMAL
RANGES
NORMAL
RANGES
MONITOR
ALARMS AT
MONITOR
ALARMS AT
0–3 MONTHS
3–12 MONTHS
0–3 MONTHS
3–12 MONTHS
HEART
RATE
HEART
RATE
90–180bpm90–180bpm
70–150bpm70–150bpm
0–89bpm
or181bpm+
0–69bpm
or151bpm+
*The Baby Vida Oxygen Monitor has a connection radius up to 60 feet.*The Baby Vida Oxygen Monitor has a connection radius up to 60 feet.
If you prefer, you can set your own ranges for Oxygen Levels
and Heart Rate.This allows you to control the levels at which
the App alarm will sound.
If you prefer, you can set your own ranges for Oxygen Levels
and Heart Rate.This allows you to control the levels at which
the App alarm will sound.
MANUAL
SETTINGS
MANUAL
SETTINGS
WHAT YOU NEED
OXYGEN MONITOR (INCLUDED)
The Oxygen Monitor accurately
monitors your baby’s oxygen level
and heart rate.
*ribbon and charger also included
TWO SUPPORT SOCKS (INCLUDED)
Two Support Socks are included.
One for 0–6 months and another
for 6–12 months.
MOBILE APP (INSTRUCTIONS
TO DOWNLOAD ON PAGE 7)
The App is free to download and
accurately displays the information
collected by the Oxygen Monitor.
2 3
wireless portable easy-to-use

FITTING INSTRUCTIONS
1
With the SENSOR SIDE FACING UP, pull
half the ribbon through the TOP LEFT slit.
3
With the sensor side still facing up, grab
the RIGHT side of the ribbon and bring it
around and through the BOTTOM LEFT slit.
2
Pull the other half of the ribbon through
the TOP RIGHT slit.
NOTE: Ribbon should be evenly
distributed on each side.
4
With the sensor side still facing up,
grab the LEFT side of the ribbon
and bring it around and through the
BOTTOM RIGHT slit.
5
With the SENSOR SIDE FACING UP,
gently place your baby’s foot between the
Monitor and the X of the ribbon.
7
Gently press velcro parts together and
make and adjustments to ribbon to
ensure that it is evenly distributed
around your child’s foot.
6
Align the sensor to your baby’s heel
and pull velcro parts to top of foot.
8
Double check that the sensor is
aligned with your baby’s heel and
the power button is facing outward.
4 5

FITTING INSTRUCTIONScont.
9
Lay Support Sock completely at with
the large velcro side facing up.
11
Place the extra ap of the Support Sock
BETWEEN your baby’s leg and the Oxygen
Monitor.
10
Gently slide your baby’s foot through
the foot hole, stopping just short
of the sensor.
NOTE: The Support Sock should NOT
cover the sensor.
12
Wrap large velcro side of the Support
Sock around your baby’s leg and the
Oxygen Monitor.
13
Hold large velcro side against Monitor
and gently pull smaller velcro side
around and press against large velcro.
15
Ensure that the Support Sock is placed
comfortably on your baby’s foot and is
also tight enough to hold the Oxygen
Monitor in place.
14
Make sure that the sensor is still aligned
to your baby’s heel and the Monitor
battery is parallel to your baby’s leg.
For help with this product, please call 402.639.0100
1On your smart device, go to the App Store
2 In the search eld, type “BabyVida” (one word)
3When the App appears, click the FREE box
in the top right to download
INSTALLING THE APP
6 7

APP INSTRUCTIONS
1Open BabyVida App
2In the top right of your screen, click “Settings”
3Your screen will say “Not Connected”
4Click “Set a Device”
5Under “Choose a Device” you will see “SP02-”
followed by your monitor’s seriel number
*If you do not see your device listed, please
make sure the Oxygen Monitor is powered ON by
pushing the power button on the Monitor itself.
You will know it is ON when the sensor glows red.
6Touch that seriel number (it will change to green)
7The top right of your screen should now read
“Connected”
8Click “<Settings” and then “Advanced Settings”
9In “Advanced Settings” select your baby’s age
(preset ranges) or manually set your own ranges
10 Click “<Back” to return to the home screen and
choose to have alarming on or off
11 You Baby Vida monitor is now working. To view
your child’s vital charts, click “See Statistics” or
choose to view current vitals from the home screen
Your screen will ash red, an alarming message
will appear, and an alarm will sound if your child’s
vitals fall outside of normal ranges.
HOME PAGE
DEVICE SETUP
ADVANCED SETTINGS
STATISTICS
SETTINGS
For help with this product, please call 402.639.0100
Alarming ON
0–3 mnths preset
NOT Connected
0–12mnths preset
Vitals ChartsAlarming OFF
Connected
Manual Settings
8 9

APP INDICATORS
Indicates that your device is connected and
receiving valid data.
App alarming function is turned ON.
Alarm will sound when necessary.
App alarming function is turned OFF.
Alarm will NOT sound.
Indicates that your device is disconnected.
Either the Monitor is powered OFF or you are
outside of the 60ft connection radius.
Indicates rapid foot movement and device is
waiting for deceleration of monitor to obtain
accurate data.
Indicates that your device is no longer on
your child’s foot. Please follow instructions
on page 4 to resume data readings.
Monitor battery is full
Monitor battery is depleted.App alarm
will sound to alert you of depleted battery
if alarming function is turned ON.
Monitor battery level is being computed
For help with this product, please call 402.639.0100
NOTE: Estimated battery life is 17 hours
10 11

PRODUCT MATERIALS
CARE
OUR STORY
OXYGEN MONITOR
The Oxygen Monitor has a water resistant casing
and the sensor head is protected with a plastic lens.
Wipe with damp cloth when necessary. Ensure that
sensor head is free of any residue that could block
sensor from taking accurate readings.
Do not submerge in water.
Handle with care. Sensor head is fragile.
SUPPORT SOCK
The Baby Vida Support Sock can be laundered.
Delicate or hand wash cold only. Air dry.
SUPPORT SOCK
80% polyester
20% spandex
w/ Velcro
OXYGEN MONITOR
Plastic:
EVAMV1055
RIBBON
Elastic
w/ Velcro
For help with this product, please call 402.639.0100
MEET MOLLIE—
THE MOM BEHIND THE MONITOR
When Mollie and her husband were expecting
their rst child, they prepared in every way they
knew how. They had a healthy baby boy and were
overjoyed to take him home. Mollie had an
audio/video monitor to help her hear if her new
baby was crying, but she started to wonder:
“What would it sound like if my
baby stopped breathing?”
Through research, she found that she wasn’t
alone in her concern, but the right solution
wasn’t out there yet. So Mollie enlisted the help
of renown engineers to develop this life changing
device and nally bring parents vital peace of mind.
12 13

www.babyvida.us
This device complies with part 15 of the FCC Rules. Operation is subject
to the following two conditions: (1) This device may not cause harmful
interference, and (2) this device must accept any interference received,
including interference that may cause undesired operation.
Changes or modications not expressly approved by the party responsible
for compliance could void the user’s authority to operate the equipment.
Note: This equipment has been tested and found to comply with the
limits for a Class B digital device, pursuant to part 15 of the FCC Rules and
Industry Canada license-exempt RSS standards. These limits are designed to
provide reasonable protection against harmful interference in a residential
installation.This equipment generates, uses and can radiate radio frequency
energy and, if not installed and used in accordance with the instructions,
may cause harmful interference to radio communications. However, there is
no guarantee that interference will not occur in a particular installation. If this
equipment does cause harmful interference to radio or television reception,
which can be determined by turning the equipment off and on, the user is
encouraged to try to correct the interference by one or more of the following
measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
• Connect the equipment into an outlet on a circuit different from
that to which the receiver is connected.
• Consult the dealer or an experienced radio/TV technician for help.
Son fonctionnement est soumis aux deux conditions suivantes: (1) cet
appareil ne peut pas provoquer d’interférences, et (2) cet appareil doit
accepter toute interférence, y compris celles susceptibles de provoquer
le fonctionnement du dispositif.
