BaByliss for MEN PRO POWER CARBON 7426BU User manual

Model 7426BU
PRO POWER CARBON FACE AND BODY GROOMER
17_7426BU_IB.indd 1 3/24/17 10:33 AM

PRO POWER CARBON FACE AND BODY GROOMER
The BaByliss for Men Pro Power Carbon is a professional grade, high
powered multi-trimmer for full face and body grooming. The acute angle
carbon steel cutting blade delivers smooth, effortless cutting. A rapid
charging system delivers 40 minutes of cordless, high power from only a 3
hour charge. The 5 interchangeable heads offer total versatility so you can
trim, shave and tidy to dene your style.
FEATURES
• Cord/cordless trimmer with 5 interchangeable attachment heads.
• Precision Trimmer with acute angle carbon steel cutting blades for long
lasting sharpness
• 6-position comb guide (4-18mm)
• 3-position stubble comb guide (1.0mm,1.5mm,2.0mm)
• Body Groomer with acute angle carbon steel cutting blades for long
lasting sharpness
• 6-position comb guide (13-23mm)
• Nose & Ear Hygienic Rotary Head
• Detail Trimmer
• Foil Shaver
• Charging and storage stand
• Cleaning brush
• Oil
• 3 year guarantee
SAFETY CAUTIONS
• This appliance should only be used as described within this
instruction book. Please retain for reference.
IMPORTANT CHILD SAFETY
WARNING! Polythene bags over the product or packaging
may be dangerous. To avoid danger of suffocation, keep away
from babies and children. These bags are not toys.
17_7426BU_IB.indd 2 3/24/17 10:33 AM

IMPORTANT SAFETY
• Do not immerse the appliance in water or other liquids.
• Always inspect the appliance before use for noticeable signs
of damage. Do not use if damaged or if the appliance has
been dropped. In the event of damage contact the Conair
Customer Care Line (refer to UK After Sales Service section
for further information).
• Only use the attachments supplied with this appliance.
• Do not leave the appliance unattended when switched on.
• Do not place the appliance on any surface whilst in operation.
• Special care is required when using the appliance close to
the ears, eyes and face.
• This appliance should not be used by adults whose reduced
physical, sensory or mental capabilities, or whose lack of
experience and knowledge, might cause a hazard, unless
they have been correctly instructed to understand the safe
use and hazards involved and are adequately supervised.
• Careful adult supervision is required when this appliance is
used on or near children. Do not use on very young children.
• This appliance should not be used, cleaned or maintained by
children. Keep out of reach of children.
• Always ensure that this appliance is kept out of the reach
of children at all times, particularly during use and whilst
cooling.
• Allow the appliance to cool before storing away.
• This product complies fully with all appropriate EU and UK
Legislation and the standards relevant to this type and class
of appliance. We are an ISO9001:2015 credited company
that continually evaluates our Quality Management System
performance. If you have any queries regarding product
17_7426BU_IB.indd 3 3/24/17 10:33 AM

safety and compliance, please contact the Conair Customer
Care Line (refer to «UK After Sales Service» section).
• The battery should be removed for safe disposal at the end
of its life.
• When the battery has run down, it should be disposed of at a
recycling centre to safeguard the environment. If the battery
leaks, avoid touching it and dispose of it at a recycling centre.
INSTRUCTIONS FOR USE
IMPORTANT! Only use the adaptor and attachments supplied with this
appliance.
Inserting the Adaptor Cord into the Stand
• Remove the trimmer and accessories from the stand.
• Insert the adaptor plug into the hole on the back of the stand and push
rmly into position.
• Should you wish to charge the appliance without using the charging
stand, simply place the adaptor plug directly into the bottom of the main
trimmer unit.
Charging the Appliance
• Before using for the rst time, the appliance should be fully charged
continuously for 3 hours. This initial super-charge ensures optimum
power performance to ensure smooth fast trimming every time. Maximum
battery capacity will only be reached after 3 charging and discharging
cycles.
• A full 3 hour charge will provide approximately 40 minutes of cordless
use.
• When the appliance is about to run out of power, the charging indicator
will ash and you will have approximately 3 minutes of use remaining.
• Ensure the appliance is switched off.
• Insert the appliance into the charging and storage stand or place the
adaptor plug directly into the main trimmer unit.
17_7426BU_IB.indd 4 3/24/17 10:33 AM

WARNING: If the charging light suddenly starts to ash rapidly, the
appliance is faulty. If this happens, please stop charging and remove the
adapter from the outlet and contact our customer care center for further
advice.
Preserving the batteries
In order to maintain the optimum capacity of the rechargeable batteries,
the trimmer should be fully discharged and then recharged for 3 hours
every 6 months.
• For optimum performance, we recommend you charge the unit for at
least 30 minutes before using the appliance each time. This applies to
whether you are using it with mains or cordless power.
Preparation for Use
• Always inspect the appliance before use for noticeable signs of damage.
Do not use if damaged.
• Ensure the heads are free from hair and debris and that the blades
are properly oiled (refer to Cleaning & Maintenance section for further
information).
• Ensure the appliance is sufciently charged.
• Use on clean, dry hair that has been combed until tangle-free.
Mains Operation
• Ensure the appliance is switched off.
• Connect the adaptor to the base of the appliance and plug the adaptor
into a suitable mains socket.
• The red LED will appear when the adaptor is correctly inserted into the
appliance and connected to the mains.
• The appliance is now ready for use.
• NOTE: The appliance should not be used for longer than 20 minutes
when operated from the mains.
Cordless Operation
• Insert the adaptor into the base of the appliance, plug into a suitable
mains socket and switch on. The red LED will appear when the adaptor
is correctly inserted into the appliance and connected to the mains.
• Once the appliance in fully charged, the red light will stop ashing but
17_7426BU_IB.indd 5 3/24/17 10:33 AM

remain on. Unplug the adaptor from the mains socket and appliance
and prepare for use.
Changing the Heads
• Before changing the heads, ensure the appliance is switched off.
• To remove a head, hold the handle of the appliance with one hand, hold
the head with the other hand and pull the head back and away from the
front of the handle.
• To attach a head, the driving pin needs to be in a central position. If it
is not in the centre, manually move the pin into position. Then, making
sure that the base of the head is seated in the handle, click the head
into position. Make sure taper control is set to position number 1 when
changing head.
Comb Guides
6-Position Comb Guide For Precision Trimmer:
• Ensure the appliance is switched off.
• Attach the Precision Trimmer head.
• Slide the smaller of the 2 comb guides onto the front of the Precision
Trimmer head and push down at the rear to lock into place – you will hear
a clicking noise when it’s in position.
• The comb guide will be set to the shortest of the six cutting lengths.
• To adjust the cutting length, push the guide forward to the required
position. The comb guide has 6 length settings: 4mm, 6mm, 9mm,
12mm, 15mm & 18mm.
• To remove the comb, gently lift the guide off the head by lifting the rear
section.
1
2
3
Installing the nose/ear trimmer
• Insert the pin of the trimmer body into the hexagonal hole
of the trimmer head as shown in Fig.1.
• Press and snap the trimmer head onto the body as shown
in Fig. 2.
• Detaching the nose/ear trimmer:
• Hold the trimmer in the way as shown in Fig.3 with the
thumb pressing the top front part of the trimmer head and
snap it off.
17_7426BU_IB.indd 6 3/24/17 10:33 AM

6-Position Comb Guide For Body Groomer:
• Ensure the appliance is switched off.
• Attach the Body Groomer head.
• Align the larger of the 2 comb guides onto the front of the Body Groomer
head and push down at the rear to lock into place – you will hear a
clicking noise when it’s in position.
• The comb guide will be set to the shortest of the six cutting lengths.
• To adjust the cutting length, push the guide forward to the required
position. The comb guide has 6 length settings, 13, 15, 17, 19, 21 &
23mm.
• To remove the comb, gently lift the guide off the head by lifting the rear
section.
Taper Control
The taper control with 3-position switch enables super ne cut adjustment
for precision trimming.
• The trimmer will be set to it’s shortest cutting length of 0.5mm with the
number 3 visible below the taper control switch.
• To increase the length by 0.5mm to a cutting length of 1mm, slide the
switch down so 2 is visible above the taper control switch.
• To increase the length by a further 0.5mm to a cutting length of 1.5mm,
slide the switch down so both 1 and 2 are visible above the taper control
switch.
NOTE: The taper control function can only be used with the Precision
Trimmer and Body Groomer heads.
TRIMMING
Precision Trimmer
Using the Precision Trimmer with 6-position comb guide:
• Attach the smaller of the 6-position comb guides and select the required
length (4-18mm).
• If you require more than one cutting length, start with the longest length
rst.
• Adjust the taper control for super ne cut adjustment as required.
• Switch the trimmer on.
• Hold the trimmer with the teeth of the trimmer pointing upwards, yet at
17_7426BU_IB.indd 7 3/24/17 10:33 AM

against the skin.
• Move the trimmer upwards and outward through the hair, against the
direction of hair growth.
• The trimmer will work most efciently when cutting through hair at its
own speed.
• Never switch the appliance off whilst in the hair.
• Note: The Precision Trimmer can be used without any comb guides and
will cut roughly to a length of 0.5mm.
Using the Precision Trimmer with the 3-position stubble combs:
• Attach the 3-position stubble comb (I = 1mm, II = 1,5mm and III = 2mm).
• If you require more than one cutting length, start with the longest length
rst (2mm).
• Switch the trimmer on.
• Hold the trimmer with the teeth of the trimmer pointing upwards, yet at
against the skin.
• Move the trimmer upwards and outward through facial hair you wish to
trim.
• To blend-in a shorter length use a shorter length and use in the same way
as above.
• The trimmer will work most efciently when cutting through hair at its
own speed.
• Never switch the appliance off whilst in the hair.
To outline using the Precision Trimmer:
• Do not attach a comb guide.
• Hold the trimmer upside down with the blade facing downwards, yet at
against the skin.
• Move the trimmer gently downwards in small strokes around the edge of
the area you wish to outline.
• Having dened the outline, hold the trimmer with the blades pointing
upwards, yet at against the skin and move the trimmer upwards against
the direction of hair growth. This will trim the unwanted hair adjacent to
the outline.
17_7426BU_IB.indd 8 3/24/17 10:33 AM

Body Groomer
Using the Body Groomer with 6-position comb guide:
• Attach the larger of the 6-position comb guides and select the required
length (13-23mm).
• Adjust the taper control for super ne cut adjustment as required.
• Switch the trimmer on.
• Hold the trimmer with the teeth of the trimmer pointing upwards, yet at
against the skin.
• Move the trimmer upwards and outward through the hair, against the
direction of hair growth.
• Make sure to be particularly careful when trimming sensitive areas.
• The trimmer will work most efciently when cutting through hair at its
own speed.
• Never switch the appliance off whilst in the hair.
• Note: The Body Groomer can be used without any comb guides and will
cut roughly to a length of 0.5mm.
Foil Shaver
Using the Foil Shaver:
• Finish edges with a smooth, close shave result with the Foil Shaver head
attachment.
• Always ensure the foil is not damaged before each use.
• Switch the trimmer on.
• Move the shaver gently over the skin, applying minimal pressure and
shaving in the direction of hair growth.
• Make sure to be particularly careful when trimming sensitive areas.
• Never switch the appliance off whilst in the hair.
Nose & Ear Trimmer
Using the Nose & Ear Trimmer:
• For the safe and easy removal of unwanted nose and ear hair use the
rotary trimmer head.
• Switch the trimmer on.
• Insert the trimmer into the nose or ear and gently move the trimmer in a
circular motion.
• Only use the trimmer at the entrance to the ear or nose.
Do not use any deeper, as this could cause injury.
• Never turn the trimmer off whilst in the nose and ear hair.
17_7426BU_IB.indd 9 3/24/17 10:33 AM

Detail Trimmer
Using the Detail Trimmer:
• For accurate tramlines and detailed effects, attach the Detail Trimmer
head.
• Switch the trimmer on.
• Gently move the blade through the area of hair you wish to trim.
• The trimmer will work most efciently when cutting through hair at its
own speed.
• Never turn the trimmer off whilst in the hair.
CLEANING & MAINTENANCE
To maintain optimum performance, the appliance should be cleaned after
each use:
• Remove the comb guide after use. Rinse under running water and dry
thoroughly before storage or use.
• Remove the trimmer head after use. The heads are washable for easy
cleaning. Rinse under running water and dry thoroughly before storage
or use.
• Do not disassemble the blades.
• Periodically, it may be necessary to oil the blades. After cleaning, attach
a trimmer head, switch on and oil the blades using a few drops of the
lubricating oil supplied. Only use the lubricating oil supplied with the
appliance as this is specically formulated for high speed trimmers and
does not evaporate or slow the blades.
• For instructions on how to re-attach the head, please refer to ‘‘Changing
the Heads’’ section.
TO CLEAN THE FOIL SHAVER HEAD
• Press buttons on both sides of the shaver head
and remove the foil attachment for cleaning.
• Do not touch the shaver blade as it is sharp.
• Shaver foil is thin, handle with caution.
17_7426BU_IB.indd 10 3/24/17 10:33 AM

BATTERY DISPOSAL
To minimise hazards to health and the environment at the end of
this product’s life, laws dealing with Waste Electrical and Electronic
Equipment (WEEE) and The Waste Battery Directive require you to
dispose of these products and their batteries at a suitable collection
facility where they will be sent for appropriate recycling. Please
contact your local authorities for more details on recycling and safe
disposal of these in your area.
UK GUARANTEE
This BaByliss for Men appliance is guaranteed for consumer use for 3
years.
This 3 year guarantee will cover defects found due to faulty workmanship
or material. Proof of purchase is required to validate the guarantee. The
guarantee will be void if the damage has been caused by a fall, alteration
or repair by any unauthourised persons. If the appliance does not perform
satisfactorily due to defect in materials or manufacture, it will be repaired
or replaced through Conair UK After Sales Service. The Conair Group Ltd
reserves the right to amend terms and specications without prior notice.
This guarantee in no way affects your statutory rights.
17_7426BU_IB.indd 11 3/24/17 10:33 AM

UK AFTER SALES SERVICE
For further advice on using the appliance or should you need to return
your product, please contact the Conair Customer Care Line on
03705 133191 (09:00 to 17:00 Monday to Friday) or email your enquiry to
[e-mail].
The return address is:
Customer Care Centre
Conair Logistics
Unit 4
Revolution Park
Buckshaw Avenue
Buckshaw Village
Chorley
PR7 7DW
Please enclose your returns number, name and address details, together
with a copy of proof of purchase and details of the fault.
IB-17/084
17_7426BU_IB.indd 12 3/24/17 10:33 AM
