1.0 SERVICE MANUAL CONTENTS
This manual contains the following service information for the . . .
DIOXOR II (Part No. 0019-7038 & 0019-7043)
MONOXOR II (Part No. 0019-7034 & 0019-7039)
MONOXOR II H (Part No. 0019-8015)
NONOXOR II (Part No. 0019-7036 & 0019-7042).
NOTE: The 0019-7039, 0019-7042, and 0019-7043 versions of these
instruments do not contain a probe, all non-probe related functions
remain the same in this instruction.
•Instrument maintenance, which includes information on how to:
• Open and close the case
• Clean the Fan Assembly and chamber assembly area
• Replace the sensor
• Replace the Printed Circuit Board (P.C.B.)
• Service the gas-sensing chamber assembly (chamber assembly)
•Sensor calibration
•Troubleshooting chart
•Replacement parts list
GENERAL NOTE
If excessive torque is applied to the instrument's
fasteners, poor performance or damage to components
may occur.
The torque specifications are as follows:
Screws Torque
Sensor Mounting 4 - 8 oz. in.
Motor Mounting 6-10 oz. in.
Chamber Sealing 16-20 oz. in.
Rear Cover/Case 18-24 oz. in.
Fan Assembly 32-40 oz. in.

Single Gas Instrument Service Manual
Instruction 0019-9166 Bacharach, Inc. Page 5
2.0 MAINTENANCE
2.1 Opening the Case
Figure 2-1.
Opening and
Closing the Case
Equipment Needed:
•Phillips-head screwdriver, No. 1
Procedure:
1. Lay the instrument face down on a workbench; then detach the metal clip
from the bottom of case and fold the elastic strap over top of the instrument
(Fig 2-1).
2. Slide off battery cover.
3. Remove batteries.
4. Using a No. 1 Phillips-head screwdriver, remove the two screws from the
rear of the case.
5. Lift up the bottom portion of the rear case and slide it forward until the case
clears the inlet port.
6. To gain better access to the components, remove the gas-sensing chamber as-
sembly (Chamber Assembly) and the Printed Circuit Board (P.C.B.) from the
front case by pulling them straight up from the front case (Fig 2-2); then lay
these items on your workbench.

Single Gas Instrument Service Manual
Page 6 Bacharach, Inc. Instruction 0019-9166
2.2 Closing the Case
Figure 2-2.
P.C.B. and
Chamber Assem-
bly
Removal and
Installation
Equipment Needed:
• Phillips-Head Screwdriver, No. 1
Procedure:
CAUTION
When replacing the P.C.B. and chamber assembly, the P.C.B. must
be installed FIRST. The P.C.B. switches could be damaged if the
P.C.B. is installed after the chamber assembly is in place.
1. Ensure that the P.C.B. is properly positioned face down over its locating-tab
on the front case (Fig 2-2).
2. Properly position the chamber assembly between the ribs of the front case.
3. Slide the rear case over the inlet port and properly join the two case halves
together.
4. Secure the case halves to each other using the two screws removed in Sec-
tion 2.1, Step 4 (Tighten to 18–24 oz. in.).
5. Reinstall the batteries (observe proper battery polarity); replace the battery
cover; and attach the elastic strap’s metal clip to the bottom of the instru-
ment.

Single Gas Instrument Service Manual
Instruction 0019-9166 Bacharach, Inc. Page 7
2.3 Cleaning
The inside of the chamber assembly is the only part of the instrument that needs
to be cleaned. To clean the chamber assembly, proceed as follows:
Equipment Needed:
•Screwdriver, No. 1 Phillips head •Clean rags
•Screwdriver, 1/8" flat-blade •Cotton Swabs
•Warm soapy water •Pipe cleaners
•Allen Wrench, .05 in.
Procedure:
1. Open the case as described in Section “2.1 Opening the Case.”
2. Using a flat-blade screwdriver, remove the three screws and nuts that secure
the Sensor to the chamber assembly; DO NOT remove the sensor wires.
Then remove the Sensor along with its O-ring and Membrane from the
chamber assembly.
3. Using a No. 1 Phillips-head screwdriver, disassemble the chamber assembly
by removing the two screws and nuts that secure the Chamber to the Motor
Assembly
(Fig 2-3).
NOTE: Do not remove the Fan Assembly unless it's absolutely neces-
sary for cleaning or repair purposes.
4. If it is necessary to remove the Fan Assembly, first loosen the set screw on
the Fan Assembly with the .05 in. Allen wrench, and then pull off the assem-
bly.
NOTE: It is not necessary to disassemble the Motor Assembly. If
motor replacement is required, refer to Section 2.6, Step 5.
5. Clean the Fan Assembly, Chamber & Motor Assembly (see Fig 2-3) using
cotton swabs and clean rags dampened with warm, soapy water. After clean-
ing, dry all parts with clean dry rags and cotton swabs.
NOTE: Replace, DO NOT CLEAN, the Membrane (Fig 2-2) if dirty.
6. Clean the Chamber’s inlet and outlet ports using pipe cleaners dipped in
warm, soapy water. After cleaning, dry them with clean dry pipe cleaners.
7. Reassemble the chamber assembly as follows:
NOTE: DO NOT overtighten any screws; damage to plastic parts
will result.

Single Gas Instrument Service Manual
Page 8 Bacharach, Inc. Instruction 0019-9166
Figure 2-3.
Chamber As-
sembly, Exploded
View
Figure 2-3A.
Fan-blade assem-
bly set screw
a. If disassembled, push the Fan Assembly onto the Motor shaft until it seats
(Fig 2-3). Be sure the set screw (Fig 2-3A) is not screwed in so far that it
prevents the adapter from seating fully. Tighten the set screw to approxi-
mately 32–40 ounce-inches using the .05 in. Allen wrench. Spin the Fan
Assembly to be sure it will run in the chamber.
b. Mate and secure the Chamber and Motor Assembly together with the
two screws and nuts removed in Step 3 (Tighten to 16–20 oz. in.).
8. Reinstall the Membrane (mesh side toward the chamber assembly), O-ring,
and Sensor on the chamber assembly (Fig 2-2); then secure the Sensor using
the three screws and nuts removed in Step 2 (Tighten to 4–8 oz. in.).
9. Close the case as per Section “2.2 Closing the Case.”

Single Gas Instrument Service Manual
Instruction 0019-9166 Bacharach, Inc. Page 9
2.4 Sensor Replacement
When the instrument can no longer be spanned, as described in Section “3.0 Sen-
sor Calibration,” the Sensor has reached the end of its useful life, and should be
replaced. The life of a Sensor is typically two years. The Sensor may also need
to be replaced if the instrument will not zero properly, or if erratic gas readings
occur. Refer to Section “4.0 Troubleshooting Chart.”
Equipment Needed (Refer to Section “5.0 Replacement Parts” for Part
Nos.):
•Phillips-head screwdriver, No. 1 •Replacement Sensor:
•Nutdriver, 4mm (5/32") •Dioxor II - SO2
•Screwdriver, 1/8" flat blade •Monoxor II - CO
•O-Ring and Membrane, if required •Nonoxor II - NOX
•Monoxor II H - CO
Procedure:
WARNING!
Burn hazard! The Sensors contain corrosive chemicals,
DO NOT puncture or take the sensors apart.
1. Open the case as described in Section “2.1 Opening the Case.”
2. Using a nutdriver, loosen the nuts that secure the sensor wires to the Sen-
sor terminals R, S and C; then remove the wires. If the Sensor has pin and
socket connections, simply pull the sockets from the sensor pins.
3. Using a flat-blade screwdriver, remove the three screws and nuts that secure
the Sensor to the chamber assembly; then remove the Sensor along with its
O-ring and Membrane from the chamber assembly.
4. Remove and discard of the old Sensor in accordance with local and federal
regulations. DO NOT discard the sensor’s O-ring and Membrane, unless you
intend to replace these items.
NOTE: Replace the O-ring if it looks deformed, and replace the
Membrane if it is contaminated with oil or dirt. We recommend
that both the O-ring and Membrane be replaced at the same time.
5. Remove the new Sensor from its shipping canister. Do not remove the short-
ing wire (across the R & S terminals) from the Sensor (SO2& CO only, the
NOXdoes not have a shorting wire) until you are ready to make the electrical
connection.
6. Position the Membrane, O-ring, and new Sensor on the chamber assembly
as per Fig 2-2. Ensure that the sensor terminals are positioned as shown.
Secure these items to the chamber assembly using the screws and nuts re-
moved in Step 3 (Torque to 4–8 oz. in.). DO NOT overtighten the screws!
7. Remove the shorting wire from the R & S terminals (SO2& CO only). Con-
nect the blue (S), red (R), and black (C) wires from the P.C.B. to their as-
sociated sensor terminals (See Fig 2-4). If the Sensor uses nuts to secure the
Sensor wires, DO NOT overtighten these connections!
8. Close the case as per Section “2.2 Closing the Case.”
9. Calibrate the new Sensor as per Section “3.0 Sensor Calibration.”

Single Gas Instrument Service Manual
Page 10 Bacharach, Inc. Instruction 0019-9166
2.5 Printed Circuit Board (P.C.B.) Replacement
Figure 2-4.
Sensor & Motor
Wiring Diagram
Equipment Needed (Refer to Section “5.0 Replacement Parts” for Part
Nos.):
•Phillips-head screwdriver, No. 1
•Printed Circuit Board (P.C.B.)
Procedure:
1. Open the case as described in Section “2.1 Opening the Case.”
2. Unplug the motor connector from the P.C.B.
3. Unplug the sensor connector from the P.C.B.
NOTE: (For SO2& CO Sensors only) If the Sensor is not going to
be immediately plugged into the new P.C.B., place a shorting wire
between sensor terminals R and S.
4. Remove the Switch Covers from the old P.C.B. and place them on the new
P.C.B., then replace the old P.C.B. with the new one.
5. Plug the motor connector into the P.C.B.
6. Remove the shorting wire from sensor terminals R & S (if installed); then
plug the sensor connector into the P.C.B.
7. Close the case as per Section 2.2 Closing the Case.”
8. Calibrate the Sensor with the new P.C.B. as per Section “3.0 Sensor Calibra-
tion.”
9. Discard the old P.C.B.

Single Gas Instrument Service Manual
Instruction 0019-9166 Bacharach, Inc. Page 11
2.6 Chamber Assembly Servicing
To disassemble the chamber assembly, proceed as follows:
Equipment Needed (Refer to Section “5.0 Replacement Parts” for Part
Nos.):
•Screwdriver, Phillips head, No. 1
•Screwdriver, 1/8" flat-blade
•Allen Wrench, .05 in.
•Replacement pump parts, as required
Procedure:
1. Open the case as described in Section “2.1 Opening the Case.”
2. Using a flat-blade screwdriver, remove the three screws and nuts that secure
the Sensor to the chamber assembly; DO NOT remove the sensor wires.
Then remove the Sensor along with its O-ring and Membrane from the
chamber assembly.
3. Using a No. 1 Phillips-head screwdriver, disassemble the Chamber from the
Motor Assembly (Fig 2-3).
4. To remove the Fan Assembly, refer to Section 2.3, Step 4.
5. If Motor replacement is required:
a. Unplug the motor connector from the circuit board and discard the Motor
Assembly.
b. Install a new Motor Assembly and connect the motor connector to the
circuit board.
NOTE: A newly installed Motor must be broken in by running it
for at least 30 minutes. A Motor not broken in may cause erratic
display readings.
6. Reassemble the chamber assembly with any replacement parts using Section
2.3, Step 7.
7. Reinstall the Membrane, O-ring, and Sensor using Section 2.3, Step 8.
8. Close the case as per Section “2.2 Closing the Case.”

Single Gas Instrument Service Manual
Page 12 Bacharach, Inc. Instruction 0019-9166
3.0 SENSOR CALIBRATION
3.1 Monoxor II CO Calibration
Figure 3-1.
Calibration Kit
Setup
The following calibrates the MONOXOR II to a known concentration of carbon
monoxide.
Equipment Needed (Refer to Section “5.0 Replacement Parts” for Part
Nos.):
•Calibration Kit
•Carbon Monoxide Gas Cylinder, 500 ppm
•Potentiometer adjustment tool
Procedure:
WARNING!
Perform this procedure in a well ventilated area. CO is toxic!
1. Assemble the calibration equipment by connecting the Carbon Monoxide Gas
Cylinder and the components of the Calibration Kit together as shown in Fig
3-1.
NOTE: DO NOT attach the calibration setup to the instrument at this
time.
2. Zero the instrument as follows:
a. Ensure instrument will be sampling CO-free (fresh) air in the following
steps.
NOTE: An indication that the instrument was not zeroed in fresh air
is when a large negative CO display appears when the instrument is
moved into another area.
b. Set front panel POWER switch to ON.

Single Gas Instrument Service Manual
Instruction 0019-9166 Bacharach, Inc. Page 13
3. Connect the CO discharge hose of the calibration equipment to the Monoxor's probe tip; then
open the CO cylinder regulator valve and adjust the regulator for a flowmeter indication of 1
to 2 SCFH.
4. Allow gas to flow for 2 minutes.
5. Read the detected CO level on the instrument’s LCD. Then using a potentiometer adjustment
tool, adjust the CO SPAN potentiometer until the LCD reading matches the gas cylinder’s
concentration value within ±5 ppm.
6. Shut off the regulator and remove the CO discharge hose from the gas inlet port. Then while
observing the displayed CO level, allow the instrument to run until the CO reading drops to
zero.
NOTE: If after 5 minutes the CO reading stabilizes at some value other than zero, readjust the
ADJUST potentiometer for an LCD indica tion of ±3 ppm.
7. Set front panel POWER switch to OFF.
8. Disassemble the calibration-equipment setup and store the components in the calibration kit’s
carrying case.
The presence of SO2and NOXgas in small amounts, and CO gas in larger amounts, can be very toxic.
Calibration at a Bacharach Sales/Service Center is recommended (See Section “5.4 Bacharach Sales/
Service Centers” to find the nearest center). If you have a facility that is properly equipped to handle
toxic gas (i.e.. fume hoods, self contained breathing apparatus etc.), we would be glad to suggest a
calibration method.
Figure 3-2.
ADJUST &
CO Span
Adjustments
3.2 Dioxor SO2, Monoxor II H CO, and Nonoxor NOXCalibration
Important! Do not proceed with this calibration procedure if the instrument’s “LO BAT”
indicator is on. We recommend that the instrument be calibrated with a fresh set of batteries.
c. Wait until the instrument’s CO display settles down (approximately 1 minute); then, using
a potentiometer adjustment tool, turn the front panel ADJUST potentiometer (Fig 3-2) until
the display shows 0 ±3 ppm. The display shows negative numbers for zeroing purposes.

Single Gas Instrument Service Manual
Page 14 Bacharach, Inc. Instruction 0019-9166
4.0 TROUBLESHOOTING CHART
Symptom Cause Remedy
Batteries dead
Batteries installed backwards
P.C.B. defective
Backlight or its switch is defec-
tive
Sensor connections loose or
broken
Sensor Membrane blocked with
water or dirt
Sensor depleted or defective
P.C.B. defective
LCD loose or defective
P.C.B. defective
Replace batteries with four
fresh “C” Alkaline cells.
Insert batteries correctly.
Wait at least one minute be-
fore switching on unit to allow
its PTC resistor to cool.
Replace P.C.B. Refer to
Section “2.5 Printed Circuit
Board Replacement.”
Replace P.C.B. Refer to
Section “2.5 Printed Circuit
Board Replacement.”
Check Sensor connections
(Fig. 2-2).
Remove Sensor and replace
its Membrane. See Fig. 2-2.
Replace Sensor. Refer to
Section “2.4 Sensor Replace-
ment.”
Replace P.C.B. Refer to
Section “2.5 Printed Circuit
Board Replacement.”
Carefully re-seat LCD in its
socket. If segments are still
missing, replace LCD.
Replace P.C.B. Refer to
Section “2.5 Printed Circuit
Board Replacement.”
No display when unit is
switched on
Backlight won't light
Unit doesn't respond to gas
(e.g., from calibration gas)
LCD segments missing

Single Gas Instrument Service Manual
Instruction 0019-9166 Bacharach, Inc. Page 15
Symptom Cause Remedy
Erratic display
Unit won't zero and/or span
Low batteries
Faulty Motor
Sensor connections loose or
broken
Sensor depleted or defective
P.C.B. defective
Too much gas present to zero
Probe kinked or blocked pre-
venting gas flow
Sensor connections loose or
broken
Sensor depleted or defective
P.C.B. defective
Replace batteries with four
fresh “C” Alkaline cells.
Break in a new Motor for at
30 minutes.
Replace Motor Assembly.
Refer to Section “2.6 Chamber
Assembly Servicing.”
Check Sensor connections.
See Fig 2-2.
Replace Sensor. Refer to
Section “2.4 Sensor Replace-
ment.”
Replace P.C.B. Refer to
Section “2.5 Printed Circuit
Board Replacement.”
Move unit into an area
known to be gas free.
Unkink or Replace Probe.
Check Sensor connections.
See Fig 2-2.
Replace Sensor. Refer to
Section “2.4 Sensor Replace-
ment.”
Replace P.C.B. Refer to
Section “2.5 Printed Circuit
Board Replacement.”

Single Gas Instrument Service Manual
Page 16 Bacharach, Inc. Instruction 0019-9166
Symptom Cause Remedy
Sensor connections loose
Motor has excessive arcing in
its carbon brush/commutator
interface causing RFI
Chamber assembly screws loose
Fan-blade Assembly loose
Inlet and/or outlet port(s)
blocked
Motor connections loose
Motor defective
P.C.B. defective
Bouncing display > ± 3 counts
Very little (<0.25" H2O) or no
draft indication on manometer
dead headed into instrument
Check Sensor connections.
See Fig 2-2.
Run Motor for at least 3 hours
to wear away arc spots. If
display still bounces, replace
Motor Assembly. Refer to Sec-
tion “2.6 Chamber Assembly
Servicing.”
Tighten screws. Refer to Sec-
tion “2.6 Chamber Assembly
Servicing.”
Open chamber assembly and
ensure that Fan-blade Assem-
bly is mounted on Motor shaft.
Refer to Section “2.6 Chamber
Assembly Servicing.”
Clean ports. Refer to Section
“2.3 Cleaning.”
Reconnect Motor leads. Refer
to Section "2.6 Chamber As-
sembly Servicing."
Check operation of Motor. If
motor is receiving power but
isn’t turning, replace Motor
Assembly. Refer to Section “2.6
Chamber Assembly Servicing.”
Replace P.C.B. Refer to Sec-
tion “2.5 Printed Circuit Board
Replacement.”

Single Gas Instrument Service Manual
Instruction 0019-9166 Bacharach, Inc. Page 17
5.0 REPLACEMENT PARTS
Replacement parts for the instrument are listed below. Please refer to the ap-
propriate figure(s) for part locations.
Item Description Part No.
1 Probe Assembly, Standard 0019-3076
-- Probe Assembly, Flexible (not shown) 0019-3104
2 Probe Tube 0019-3073
3 Probe Handle 0019-3017
4 Screw, Phillips head, M3 x .5 x 8 mm 0501-3806
5 Tubing, 5/16 OD X 3/16 ID 0003-6109
6 Filter Saturator Bushing 0011-0074
7 Filter Packing 0011-0121
8 Filter Tube 0011-0130
9 Front Ferrule 0003-2024
10 Rear Ferrule 0003-2025
11 Knurled Nut 0003-2023
12 Compression Fitting 0003-2021
13 Barbed Fitting 0003-6164
14 Extended Adapter Block 0019-3072
15 Connector Tube 0011-0070
5.1 Probe Assembly (Fig 5-1)
Figure 5-1.
Standard Probe
Assembly

Single Gas Instrument Service Manual
Page 18 Bacharach, Inc. Instruction 0019-9166
5.2 Instrument Assembly (Figs 5-2 & 5-3)
Figure 5-2.
Replacement
Parts,
Chamber Assem-
bly
Exploded View
Item Description Part No.
1 Adapter, Motor Shaft 0024-0412
2 Battery Clip, push on0004-3113
3 Battery Cover with Foam Pad 0019-3029
4 Chamber 0019-3090
5 Front Cover w/Display Window (Dioxor II) 0019-3079
Front Cover w/Display Window (Monoxor II) 0019-3055
Front Cover w/Display Window (Nonoxor II) 0019-3078
Front Cover (Monoxor II H) (order with 0019-0437) 0019-3014
Display Window (Monoxor II H) (order with 0019-3014)0019-0437
6 (Not Used)
7 Fan-Blade Assembly 0019-3013
8 LCD 0004-3700
9 Motor Assembly 0019-3063
10 Nut, Hex M2 x .4 0502-0007
11 O-Ring and Membrane 0024-0520
12 Printed Circuit Board Assy. (Dioxor II) 0019-3022
Printed Circuit Board Assy. (Monoxor II) 0019-3012
Printed Circuit Board Assy. (Nonoxor II) 0019-3020
Printed Circuit Board Assy. (Monoxor II H) 0019-3094
13 PTC Resistor 0204-9427
14 Rear Case w/ Label (Dioxor II) 0019-3082
Rear Case w/ Label (Monoxor II) 0019-3053
Rear Case w/ Label (Nonoxor II) 0019-3081
Rear Case (Monoxor II H) (order with 51-2347) 0019-3008
Label (Monoxor II H) (order with 0019-3008) 0051-2347
15 Retaining Ring 0002-2675
16 Screw, Cheese head, M2 x .4 x 30 mm 0501-3807
17 Screw, Phillips head, M2 x .4 x 6 mm 0501-3803
18 Screw, Phillips head, M3 x .5 x 8 mm 0501-3806
19 Sensor, SO2(Dioxor II) 0019-8002
Sensor, CO (Monoxor II) 0024-0498
Sensor, ,NOX(Nonoxor II) 0019-8001
Sensor, CO (Monoxor II H) 0019-8016
20 Set Screw, #4-40 x 1/8 LG 0002-0001
21 Strap 0019-3028
22 Strap Clip 0019-3030
23 Strap Retainer 0019-3027
24 Switch Cover 0019-3021

Single Gas Instrument Service Manual
Instruction 0019-9166 Bacharach, Inc. Page 19
Figure 5-3.
Replacement Parts,
Back and Front
Exploded Views

Description Part No.
Calibration Kit 0024-7059
Carbon Monoxide Gas Cylinder, 500 ppm 0024-0492
Potentiometer adjustment tool 0006-9456
Custom Carrying Case (1 Instrument) 0019-0377
Custom Carrying Case (2 Instrument) 0019-3040
Instruction Manual, (Dioxor II) 0019-9121
Instruction Manual, (Monoxor II) 0019-9113
Instruction Manual, (Nonoxor II) 0019-9120
Instruction Manual, (Monoxor II H) 0019-9180
Calibration Card 0019-9150
Service Manual, (This Manual) 0019-9166
Label, Carrying Case 0019-3077
Probe Stop (for Securing ¼ Probe in a Flue or Stack) 0024-0434
Warranty Card 0006-8825
5.3 Miscellaneous Parts and Accessories
5.4 BACHARACH Sales/Service Centers
United States
Bacharach, Inc.
621 Hunt Valley Circle
New Kensington, PA 15068
Phone: [phone]
Fax: [phone]
E-mail: [email protected]
Canada
Bacharach of Canada, Inc.
20 Amber St. Unit #7
Markham, Ontario L3R SP4
Canada
Phone: [phone]
Fax: [phone]
Email: [email protected]
