Baileigh RDB-325 User manual

OPERATOR’S MANUAL
ROTARY DRAW BENDER
MODEL: RDB-325
© 2015 Baileigh Industrial, Inc.
REPRODUCTION OF THIS MANUAL IN ANY FORM WITHOUT WRITTEN APPROVAL OF BAILEIGH INDUSTRIAL, INC.
IS PROHIBITED. Baileigh Industrial, Inc. does not assume and hereby disclaims any liability for any damage or loss
caused by an omission or error in this Operator’s Manual, resulting from accident, negligence, or other occurrence.
Rev. 03/2015
Baileigh Industrial, Inc.
P.O. Box 531
Manitowoc, WI 54221-0531
Phone: [phone]
Fax: [phone]
[e-mail]

Table of Contents
THANK YOU & WARRANTY .......................................................................................... 1
INTRODUCTION............................................................................................................. 3
GENERAL NOTES.......................................................................................................... 3
SAFETY INSTRUCTIONS .............................................................................................. 4
SAFETY PRECAUTIONS...............................................................................................7
TECHNICAL SPECIFICATIONS.....................................................................................9
TECHNICAL SUPPORT .................................................................................................9
UNPACKING AND CHECKING CONTENTS................................................................10
Cleaning....................................................................................................................10
TRANSPORTING AND LIFTING .................................................................................. 11
INSTALLATION.............................................................................................................11
ASSEMBLY AND SET UP ............................................................................................ 12
GETTING TO KNOW YOUR MACHINE ....................................................................... 13
GENERAL DESIGN DESCRIPTION.............................................................................14
ELECTRICAL................................................................................................................ 15
Plug Connection........................................................................................................16
OPERATION................................................................................................................. 17
Programmer Overview...............................................................................................17
Machine Start up and Homing...................................................................................17
Programmer Display and Key Functions...................................................................18
Main Menu Choices...................................................................................................19
Edit a Program........................................................................................................... 20
Delete Program .........................................................................................................20
Creating a Program................................................................................................... 20
Dry Running...............................................................................................................21
Running a Program ...................................................................................................21
Manual Bend .............................................................................................................22
Homing...................................................................................................................... 24
OEM Screens and Bending More than 180 Degrees................................................. 25
OEM Screen Shots....................................................................................................26
UNDERSTANDING SPRINGBACK .............................................................................. 30
MATERIAL SELECTION............................................................................................... 30
DIE SELECTION AND INSTALLATION........................................................................31
Material Insertion....................................................................................................... 33
Material Removal / Advancement.............................................................................. 35
PIPE AND TUBE BENDING DIAGRAMS .....................................................................36
BENDING GLOSSARY................................................................................................. 37
BENDING SUGGESTIONS .......................................................................................... 38
Aluminum Bending ....................................................................................................38
Heavy Wall DOM tubing ............................................................................................ 38
Bending With Square Dies ........................................................................................39
Square Tooling Setup................................................................................................ 39

Large Size Square.....................................................................................................40
INDEX TABLE ATTACHMENT (OPTIONAL EQUIPMENT).......................................... 41
Introduction................................................................................................................ 41
Connection to Your Machine..................................................................................... 41
Height Adjustment and Leveling................................................................................ 41
Material Layout..........................................................................................................42
IDX OPERATION.......................................................................................................... 42
INDEX TABLE LAYOUT DIAGRAM (OPTIONAL EQUIPMENT)..................................43
LUBRICATION AND MAINTENANCE ..........................................................................44
Gear Box Oil..............................................................................................................44
Main Spindle Bearing ................................................................................................ 44
ELECTRICAL SCHEMATIC.......................................................................................... 45
Electrical Components............................................................................................... 46
TROUBLESHOOTING.................................................................................................. 47
TABLES, CHARTS, & DIAGRAMS...............................................................................48
Diagram 1 ..................................................................................................................... 50
Diagram 2 ..................................................................................................................... 51
PARTS DIAGRAM ........................................................................................................ 52
Base Assembly Parts Diagram.................................................................................. 52
Control Box Parts Diagram........................................................................................ 53
Drive Assembly Parts Diagram.................................................................................. 54
Main Bending Assembly Parts Diagram....................................................................55
Parts List ................................................................................................................... 56

1
1
THANK YOU & WARRANTY
Thank you for your purchase of a machine from Baileigh Industrial. We hope that you find it
productive and useful to you for a long time to come.
Inspection & Acceptance. Buyer shall inspect all Goods within ten (10) days after receipt thereof. Buyer’s
payment shall constitute final acceptance of the Goods and shall act as a waiver of the Buyer’s rights to inspect or
reject the goods unless otherwise agreed. If Buyer rejects any merchandise, Buyer must first obtain a Returned
Goods Authorization (“RGA”) number before returning any goods to Seller. Goods returned without a RGA will be
refused. Seller will not be responsible for any freight costs, damages to goods, or any other costs or liabilities
pertaining to goods returned without a RGA. Seller shall have the right to substitute a conforming tender. Buyer will
be responsible for all freight costs to and from Buyer and repackaging costs, if any, if Buyer refuses to accept
shipment. If Goods are returned in unsalable condition, Buyer shall be responsible for full value of the Goods.
Buyer may not return any special order Goods. Any Goods returned hereunder shall be subject to a restocking fee
equal to 30% of the invoice price.
Specifications. Seller may, at its option, make changes in the designs, specifications or components of the Goods
to improve the safety of such Goods, or if in Seller’s judgment, such changes will be beneficial to their operation or
use. Buyer may not make any changes in the specifications for the Goods unless Seller approves of such changes
in writing, in which event Seller may impose additional charges to implement such changes.
Limited Warranty. Seller warrants to the original end-user that the Goods manufactured or provided by Seller
under this Agreement shall be free of defects in material or workmanship for a period of twelve (12) months from
the date of purchase, provided that the Goods are installed, used, and maintained in accordance with any
instruction manual or technical guidelines provided by the Seller or supplied with the Goods, if applicable. The
original end-user must give written notice to Seller of any suspected defect in the Goods prior to the expiration of
the warranty period. The original end-user must also obtain a RGA from Seller prior to returning any Goods to
Seller for warranty service under this paragraph. Seller will not accept any responsibility for Goods returned without
a RGA. The original end-user shall be responsible for all costs and expenses associated with returning the Goods
to Seller for warranty service. In the event of a defect, Seller, at its sole option, shall repair or replace the defective
Goods or refund to the original end-user the purchase price for such defective Goods. Goods are not eligible for
replacement or return after a period of 30 days from date of receipt. The foregoing warranty is Seller’s sole
obligation, and the original end-user’s exclusive remedy, with regard to any defective Goods. This limited warranty
does not apply to: (a) die sets, tooling, and saw blades; (b) periodic or routine maintenance and setup, (c) repair or
replacement of the Goods due to normal wear and tear, (d) defects or damage to the Goods resulting from misuse,
abuse, neglect, or accidents, (f) defects or damage to the Goods resulting from improper or unauthorized
alterations, modifications, or changes; and (f) any Goods that has not been installed and/or maintained in
accordance with the instruction manual or technical guidelines provided by Seller.
EXCLUSION OF OTHER WARRANTIES. THE FOREGOING LIMITED WARRANTY IS IN LIEU OF ALL OTHER
WARRANTIES, EXPRESS OR IMPLIED. ANY AND ALL OTHER EXPRESS, STATUTORY OR IMPLIED
WARRANTIES, INCLUDING BUT NOT LIMITED TO, ANY WARRANTY OF MERCHANTABILITY OR FITNESS
FOR ANY PARTICULAR PURPOSE ARE EXPRESSLY DISCLAIMED. NO WARRANTY IS MADE WHICH
EXTENDS BEYOND THAT WHICH IS EXPRESSLY CONTAINED HEREIN.
Limitation of Liability. IN NO EVENT SHALL SELLER BE LIABLE TO BUYER OR ANY OTHER PARTY FOR
ANY INCIDENTIAL, CONSEQUENTIAL OR SPECIAL DAMAGES (INCLUDING, WITHOUT LIMITATION, LOST
PROFITS OR DOWN TIME) ARISING FROM OR IN MANNER CONNECTED WITH THE GOODS, ANY BREACH
BY SELLER OR ITS AGENTS OF THIS AGREEMENT, OR ANY OTHER CAUSE WHATSOEVER, WHETHER
BASED ON CONTRACT, TORT OR ANY OTHER THEORY OF LIABILITY. BUYER’S REMEDY WITH RESPECT
TO ANY CLAIM ARISING UNDER THIS AGREEMENT IS STRICTLY LIMITED TO NO MORE THAN THE
AMOUNT PAID BY THE BUYER FOR THE GOODS.

2
2
Force Majuere. Seller shall not be responsible for any delay in the delivery of, or failure to deliver, Goods due to
causes beyond Seller’s reasonable control including, without limitation, acts of God, acts of war or terrorism, enemy
actions, hostilities, strikes, labor difficulties, embargoes, non-delivery or late delivery of materials, parts and
equipment or transportation delays not caused by the fault of Seller, delays caused by civil authorities,
governmental regulations or orders, fire, lightening, natural disasters or any other cause beyond Seller's reasonable
control. In the event of any such delay, performance will be postponed by such length of time as may be reasonably
necessary to compensate for the delay.
Installation. If Buyer purchases any Goods that require installation, Buyer shall, at its expense, make all
arrangements and connections necessary to install and operate the Goods. Buyer shall install the Goods in
accordance with any Seller instructions and shall indemnify Seller against any and all damages, demands, suits,
causes of action, claims and expenses (including actual attorneys’ fees and costs) arising directly or indirectly out
of Buyer’s failure to properly install the Goods.
Work By Others; Safety Devices. Unless agreed to in writing by Seller, Seller has no responsibility for labor or
work performed by Buyer or others, of any nature, relating to design, manufacture, fabrication, use, installation or
provision of Goods. Buyer is solely responsible for furnishing, and requiring its employees and customers to use all
safety devices, guards and safe operating procedures required by law and/or as set forth in manuals and instruction
sheets furnished by Seller. Buyer is responsible for consulting all operator’s manuals, ANSI or comparable safety
standards, OSHA regulations and other sources of safety standards and regulations applicable to the use and
operation of the Goods.
Remedies. Each of the rights and remedies of Seller under this Agreement is cumulative and in addition to any
other or further remedies provided under this Agreement or at law or equity.
Attorney’s Fees. In the event legal action is necessary to recover monies due from Buyer or to enforce any
provision of this Agreement, Buyer shall be liable to Seller for all costs and expenses associated therewith,
including Seller’s actual attorneys' fees and costs.
Governing Law/Venue. This Agreement shall be construed and governed under the laws of the State of
Wisconsin, without application of conflict of law principles. Each party agrees that all actions or proceedings arising
out of or in connection with this Agreement shall be commenced, tried, and litigated only in the state courts sitting in
Manitowoc County, Wisconsin or the U.S. Federal Court for the Eastern District of Wisconsin. Each party waives
any right it may have to assert the doctrine of “forum non conveniens” or to object to venue to the extent that any
proceeding is brought in accordance with this section. Each party consents to and waives any objection to the
exercise of personal jurisdiction over it by courts described in this section. Each party waives to the fullest extent
permitted by applicable law the right to a trial by jury.
Summary of Return Policy.
•10 Day acceptance period from date of delivery. Damage claims and order discrepancies will not be accepted
after this time.
•You must obtain a Baileigh issued RGA number PRIOR to returning any materials.
•Returned materials must be received at Baileigh in new condition and in original packaging.
•Altered items are not eligible for return.
•Buyer is responsible for all shipping charges.
•A 30% re-stocking fee applies to all returns.
Baileigh Industrial makes every effort to ensure that our posted specifications, images, pricing and product
availability are as correct and timely as possible. We apologize for any discrepancies that may occur. Baileigh
Industrial reserves the right to make any and all changes deemed necessary in the course of business including but
not limited to pricing, product specifications, quantities, and product availability.
For Customer Service & Technical Support:
Please contact one of our knowledgeable Sales and Service team members at:
[phone] or e-mail us at [e-mail]

3
3
INTRODUCTION
The quality and reliability of the components assembled on a Baileigh Industrial machine
guarantee near perfect functioning, free from problems, even under the most demanding
working conditions. However if a situation arises, refer to the manual first. If a solution cannot be
found, contact the distributor where you purchased our product. Make sure you have the serial
number and production year of the machine (stamped on the nameplate). For replacement parts
refer to the assembly numbers on the parts list drawings.
Our technical staff will do their best to help you get your machine back in working order.
In this manual you will find: (when applicable)
•Safety procedures
•Correct installation guidelines
•Description of the functional parts of the machine
•Capacity charts
•Set-up and start-up instructions
•Machine operation
•Scheduled maintenance
•Parts lists
GENERAL NOTES
After receiving your equipment remove the protective container. Do a complete visual
inspection, and if damage is noted, photograph it for insurance claims and contact your
carrier at once, requesting inspection. Also contact Baileigh Industrial and inform them of the
unexpected occurrence. Temporarily suspend installation.
Take necessary precautions while loading / unloading or moving the machine to avoid any
injuries.
Your machine is designed and manufactured to work smoothly and efficiently. Following proper
maintenance instructions will help ensure this. Try and use original spare parts, whenever
possible, and most importantly; DO NOT overload the machine or make any unauthorized
modifications.
Note: This symbol refers to useful information throughout the manual.

4
4
LEARN TO RECOGNIZE SAFETY INFORMATION
This is the safety alert symbol. When you see this symbol on
your machine or in this manual, BE ALERT TO THE
POTENTIAL FOR PERSONAL INJURY!
Follow recommended precautions and safe operating
practices.
UNDERSTAND SIGNAL WORDS
A signal word – DANGER, WARNING, or CAUTION
is used with the safety alert symbol. DANGER
identifies a hazard or unsafe practice that will result in
severe Injury or Death.
Safety signs with signal word DANGER or WARNING are
typically near specific hazards.
General precautions are listed on CAUTION safety signs.
CAUTION also calls attention to safety messages in this
manual.
IMPORTANT
PLEASE READ THIS OPERATORS MANUAL CAREFULLY
It contains important safety information, instructions, and necessary operating
procedures. The continual observance of these procedures will help increase your
production and extend the life of the equipment.
SAFETY INSTRUCTIONS

5
5
SAVE THESE INSTRUCTIONS.
Refer to them often and use them to instruct others.
PROTECT EYES
Wear safety glasses or suitable eye protection
when working on or around machinery.
PROTECT AGAINST NOISE
Prolonged exposure to loud noise can cause impairment or loss of
hearing. Wear suitable hearing protective devices such as ear muffs or
earplugs to protect against objectionable or uncomfortable loud noises.
BEWARE OF CRUSH HAZARD
NEVER place your hands, fingers, or any
part of your body in the die area of this
machine. Be aware of the area on either side
of the dies for crush points created by
material movement.
BEWARE OF PINCH POINTS
Keep hands and fingers away from the drive
mechanisms, cylinders, ratchets, and other
moving linkage while the machine is in
operation.

6
6
KEEP CLEAR OF MOVING OBJECTS
Always be aware of the position of the material and the swing area in
which the material will travel. The material will swing with significant
force. This swing area will create pinch points and the force of the
material movement may cause serious bodily injuries.
HYDRAULIC HOSE FAILURE
Exercise CAUTION around hydraulic hoses in case of a hose or
fitting failure.
HIGH VOLTAGE
USE CAUTION IN HIGH VOLTAGE AREAS. DO NOT assume the
power to be off.
FOLLOW PROPER LOCKOUT PROCEDURES.

7
7
SAFETY PRECAUTIONS
Metal working can be dangerous if safe and proper operating procedures are not followed. As
with all machinery, there are certain hazards involved with the operation of the product. Using
the machine with respect and caution will considerably lessen the possibility of personal injury.
However, if normal safety precautions are overlooked or ignored, personal injury to the operator
may result.
Safety equipment such as guards, hold-downs, safety glasses, dust masks and hearing
protection can reduce your potential for injury. But even the best guard won’t make up for poor
judgment, carelessness or inattention. Always use common sense and exercise caution in
the workshop. If a procedure feels dangerous, don’t try it.
REMEMBER: Your personal safety is your responsibility.
1. Only trained and qualified personnel can operate this machine.
2. Make sure guards are in place and in proper working order before operating
machinery.
3. Remove any adjusting tools. Before operating the machine, make sure any adjusting tools
have been removed.
4. Keep work area clean. Cluttered areas invite injuries.
5. Overloading machine.By overloading the machine you may cause injury from flying parts.
DO NOT exceed the specified machine capacities.
6. Dressing material edges. Always chamfer and deburr all sharp edges.
7. Do not force tool. Your machine will do a better and safer job if used as intended. DO NOT
use inappropriate attachments in an attempt to exceed the machines rated capacity.
8. Use the right tool for the job. DO NOT attempt to force a small tool or attachment to do the
work of a large industrial tool. DO NOT use a tool for a purpose for which it was not
intended.
9. Dress appropriate. DO NOT wear loose fitting clothing or jewelry as they can be caught in
moving machine parts. Protective clothing and steel toe shoes are recommended when
using machinery. Wear a restrictive hair covering to contain long hair.
10.Use eye and ear protection. Always wear ISO approved impact safety goggles. Wear a full-
face shield if you are producing metal filings.
WARNING:FAILURE TO FOLLOW THESE RULES MAY RESULT IN
SERIOUS PERSONAL INJURY

8
8
11.Do not overreach. Maintain proper footing and balance at all times. DO NOT reach over or
across a running machine.
12.Stay alert. Watch what you are doing and use common sense. DO NOT operate any tool or
machine when you are tired.
13.Check for damaged parts. Before using any tool or machine, carefully check any part that
appears damaged. Check for alignment and binding of moving parts that may affect proper
machine operation.
14.Observe work area conditions. DO NOT use machines or power tools in damp or wet
locations. Do not expose to rain. Keep work area well lighted. DO NOT use electrically
powered tools in the presence of flammable gases or liquids.
15.Keep children away. Children must never be allowed in the work area. DO NOT let them
handle machines, tools, or extension cords.
16.Store idle equipment. When not in use, tools must be stored in a dry location to inhibit rust.
Always lock up tools and keep them out of reach of children.
17.DO NOT operate machine if under the influence of alcohol or drugs. Read warning
labels on prescriptions. If there is any doubt, DO NOT operate the machine.
18.DO NOT touch live electrical components or parts.
19.Turn off power before checking, cleaning, or replacing any parts.
20.Be sure all equipment is properly installed and grounded according to national, state, and
local codes.
21.DO NOT bypass or defeat any safety interlock systems.
22.Keep visitors a safe distance from the work area.

9
9
TECHNICAL SPECIFICATIONS
Maximum Center Line Radius (CLR)*
16.5" (419mm)
Minimum Center Line Radius (CLR)*
.5" (12.7mm)
Minimum OD
.25" (6.35mm)
Mild Steel Pipe (Schedule 80)
2" (50.8mm)
Aluminum Pipe (Schedule 40)
2" (50.8mm)
Stainless Steel Pipe (Schedule 40)
2" (50.8mm)
Mild Steel Round Tube (Wall) 3" (.095) (76.2mm [2.41mm])
Aluminum Round Tube (Wall)
3" (.203) (76.2mm [5.15mm])
Stainless Steel Round Tube (Wall)
3" (.095) (76.2mm [2.41mm])
Chromolly Round Tube (Wall)
3" (.083) (76.2mm [2.1mm])
Mild Steel Solid Rod
1.25" (31.75mm)
Mild Steel Square Tube (Wall)
2" (.187) (50.8mm [4.75mm])
Maximum Speed to 180
9 Seconds
Power Supply
208-240 VAC, 20A, 1ph, 60Hz
(250-460 VAC, 10A, 3ph, 50/60Hz) available
Sound level
<70db
Shipping Weight (Lbs.)
1200lbs. (545kg)
Shipping Dimensions (L x W x H)
68 x 60” x 44” (1727 x 1524 x 1118mm)
TECHNICAL SUPPORT
Our technical support department can be reached at 920.684.4990, and asking for the support
desk for purchased machines. Tech Support handles questions on machine setup, schematics,
warranty issues, and individual parts needs: (other than die sets and blades).
For specific application needs or future machine purchases contact the Sales Department at:
[e-mail], Phone: [phone], or Fax: [phone].
Note: The photos illustrations used in this manual are representative only and may
not depict the actual color, labeling or accessories and may be intended to illustrate technique
only.
Note: The specifications and dimensions presented here are subject to change
without prior notice due to improvements of our products.

10
10
UNPACKING AND CHECKING CONTENTS
Your Baileigh machine is shipped complete in one crate. Separate all parts from the packing
material and check each item carefully. Make certain all items are accounted for before
discarding any packing material.
Cleaning
Your machine may be shipped with a rustproof waxy oil coating and grease on the exposed
unpainted metal surfaces. To remove this protective coating, use a degreaser or solvent
cleaner. For a more thorough cleaning, some parts will occasionally have to be removed. DO
NOT USE acetone or brake cleaner as they may damage painted surfaces.
Follow manufacturer’s label instructions when using any type of cleaning product. After cleaning,
wipe unpainted metal surfaces with a light coating of quality oil or grease for protection.
WARNING:
SUFFOCATION HAZARD! Immediately discard any plastic
bags and packing materials to eliminate choking and suffocation hazards to children
and animals.
If any parts are missing, do not plug in the power cable, or turn the power switch on
until the missing parts are obtained and installed correctly.
WARNING: DO NOT USE gasoline or other petroleum products to clean
the machine. They have low flash points and can explode or cause fire.
CAUTION: When using cleaning solvents work in a well-ventilated area.
Many cleaning solvents are toxic if inhaled.
GAS

11
11
TRANSPORTING AND LIFTING
Follow these guidelines when lifting:
•The lift truck must be able to lift at least 1.5 – 2 times the machines gross weight.
•Make sure the machine is balanced. While transporting, avoid rough or jerky motion, and
maintain a safe clearance zone around the transport area.
•Use a fork lift with sufficient lifting capacity and forks that are long enough to reach the
complete width of the machine.
•Remove the securing bolts that attach the machine to the pallet.
•Approaching the machine from the side, lift the machine on the frame taking care that there
are no cables or pipes in the area of the forks.
•Move the machine to the required position and lower gently to the floor.
•Level the machine so that all the supporting feet are taking the weight of the machine and no
rocking is taking place.
INSTALLATION
IMPORTANT:
Consider the following when looking for a suitable location to place the machine:
•Overall weight of the machine.
•Weight of material being processed.
•Sizes of material to be processed through the machine.
•Space needed for auxiliary stands, work tables, or other machinery.
•Clearance from walls and other obstacles.
•Maintain an adequate working area around the machine for safety.
•Have the work area well illuminated with proper lighting.
CAUTION:
Lifting and carrying operations should be carried out by
skilled workers, such as a truck operator. Make sure the machine is well balanced.
Choose a location that will keep the machine free from vibration and dust from other
machinery. Keep in mind that having a large clearance area around the machine is
important for safe and efficient working conditions.

12
12
•Keep the floor free of oil and make sure it is not slippery.
•Remove scrap and waste materials regularly, and make sure the work area is free from
obstructing objects.
•If long lengths of material are to be fed into the machine, make sure that they will not extend
into any aisles.
•LEVELING: The machine should be sited on a level, concrete floor. For stationary machines,
provisions for securing it should be in position prior to placing the machine. The accuracy of
any machine depends on the precise placement of it to the mounting surface.
•FLOOR: This tool distributes a large amount of weight over a small area. Make certain that
the floor is capable of supporting the weight of the machine, work stock, and the operator.
The floor should also be a level surface. If the unit wobbles or rocks once in place, be sure to
eliminate by using shims.
•WORKING CLEARANCES: Take into consideration the size of the material to be
processed. Make sure that you allow enough space for you to operate the machine freely.
•POWER SUPPLY PLACEMENT: The power supply should be located close enough to the
machine so that the power cord is not in an area where it would cause a tripping hazard. Be
sure to observe all electrical codes if installing new circuits and/or outlets.
ASSEMBLY AND SET UP
1. Remove the machine from the skid it was shipped on and install the casters.
2. Check the oil level and top off if necessary.
3. Read through the remainder of the manual and become familiar with the die installation and
settings as well as normal operation.
4. Position the machine as desired following the installation guidelines.
5. Follow the electrical guidelines to connect the machine to a power supply.
WARNING:For your own safety, DO NOT connect the machine to the
power source until the machine is completely assembled and you read and
understand the entire instruction manual.

13
13
GETTING TO KNOW YOUR MACHINE
A
B
C
D
E
F
G
H
J
I
K
L
M
N

14
14
Item
Description
Function
A
Grease Zerk
For Greasing Main Spindle Bearing
B
Main Spindle And Drive Pins
For Supporting The Bend Dies And Driving The Dies
C
Center Pin
For Aligning Die Onto Spindle
D
Hitch Pin
For Mounting The Counter Die
E Quick Release
For Pivoting Counter Die Away From Bend Die To
Remove Material Quickly
F
Numerical Counter
For Indicating Counter Die Position
G Touch Screen Controller For Programming Bend Data
H
3 Legged Handwheel
For Adjusting Counter Die Position
I
Push Handle
For Maneuvering Machine On Its Wheels
J
Main Disconnect Switch
For Turning Power On/Off
K
Power Cord
For Connecting To Main Power Source
L
Foot Pedal Guard
Protect Against Accidental Operation
M
Forward Foot Pedal
Will Operate The Machine In The cw Direction
N
Reverse Foot Pedal
Will Operate The Machine In The ccw Direction
GENERAL DESIGN DESCRIPTION
You have made a practical choice in purchasing the RDB-325 Fully Programmable Bending
Machine. It has been carefully built of high quality materials and designed to give many years of
efficient service. The simplicity of design and minimum effort required to operate the machine
contributes towards meeting schedules and producing greater profits.
The RDB-325 is an electric powered “Rotary Draw” bending machine. To bend material, a
bending die and counter die are required. The material is hooked by the bending dies’ hook arm
and is powerfully rotated in the clockwise direction. As the bending die rotates, the counter die
remains stationary, forcing the material to conform to the radius and shape of the bending die.
The RDB-325 Bending Machine you have purchased is built of solid steel ensuring maximum
rigidity. Tongue and groove design with grade 8 bolts throughout provides very high rigidity and
stability.
Throughout this manual are listed various safety-related descriptions for attention. These
matters for attention contain the essential information to the operators while operating, and
maintaining. Failure to follow these instructions may result in great damage to the machine or
injury to the operator.

15
15
ELECTRICAL
Motor Specifications
Your tool is wired for 220 volt, 60Hz alternating current. Before connecting the tool to the power
source, make sure the machine is cut off from power source.
Considerations
•Observe local electrical codes when connecting the machine.
•The circuit should be protected with a time delay fuse or circuit breaker with a amperage
rating slightly higher than the full load current of machine.
•A separate electrical circuit should be used for your tools. Before connecting the motor to the
power line, make sure the switch is in the “OFF” position and be sure that the electric current
is of the same characteristics as indicated on the tool.
•All line connections should make good contact. Running on low voltage will damage the
motor.
•In the event of a malfunction or breakdown, grounding provides a path of least resistance for
electric current to reduce the risk of electric shock. This tool is equipped with an electric cord
having an equipment-grounding conductor and a grounding plug. The plug must be plugged
into a matching outlet that is properly installed and grounded in accordance with all local
codes and ordinances.
CAUTION: HAVE ELECTRICAL UTILITIES CONNECTED TO MACHINE BY
A CERTIFIED ELECTRICIAN!
Check if the available power supply is the same as listed on the machine nameplate.
WARNING: Make sure the grounding wire (green) is properly connected
to avoid electric shock. DO NOT switch the position of the green grounding wire if
any electrical plug wires are switched during hookup.
WARNING:In all cases, make certain the receptacle in question is
properly grounded. If you are not sure, have a qualified electrician check the
receptacle.

16
16
•Improper connection of the equipment-grounding conductor can result in risk of electric
shock. The conductor with insulation having an outer surface that is green with or without
yellow stripes is the equipment-grounding conductor. If repair or replacement of the electric
cord or plug is necessary, do not connect the equipment-grounding conductor to a live
terminal.
•Check with a qualified electrician or service personnel if the grounding instructions are not
completely understood, or if in doubt as to whether the tool is properly grounded.
•Repair or replace damaged or worn cord immediately.
Extension Cord Safety
Extension cord should be in good condition and meet the minimum wire gauge requirements
listed below:
LENGTH
AMP RATING
25ft
50ft
100ft
0-6
16
16
16
7-10
16
16
14
11-12
16
16
14
13-16
14
12
12
17-20
12
12
10
21-30
10
10
No
WIRE GAUGE
An undersized cord decreases line voltage, causing loss of power and overheating. All cords
should use a ground wire and plug pin. Replace any damaged cords immediately.
Plug Connection
1. Have an electrician install the correct plug for the application.
2. Once hooked up, turn on the power supply and start the machine.
3. For three phase applications, check that the motor is running in
the correct direction.
4. If not, cut the power to the machine. Swap the position of any two
of the three power wires; but DO NOT change the position of the
green grounding wire!

17
17
OPERATION
Programmer Overview
•This draw bender utilizes a fully programmable touch screen operator interface. The unique
operator interface allows you to write and save 170 programs with 10 bends per program.
Operation is extremely simple to learn. Simple foot pedal controls allow you to easily
produce fast and accurate bends. The following instructions will walk you through the basic
functions.
•Be sure to follow the dry running instructions to familiarize yourself with all the functions of
the control before any actual bending of material is performed.
Note: See the Screen Shots section of the manual to match the figure call outs.
Machine Start up and Homing
1. Tum the main power switch to the "ON" position.
2. It takes about 1 minute for the programmer to boot
up. The machine has been homed from the factory
and does not need to be re-homed unless the
encoder or drive motor needs servicing. In the
Home or “0” position, the flat of the spindle is
parallel to the machine frame.
3. The programmer will display the "RMD MAIN
SCREEN" see Fig.1.
4. On the RMD MAIN SCREEN, you can chose
"MANUAL MODE" or "RUN, VIEW OR EDIT A
PROGRAM".
CAUTION: Keep hands and fingers clear of the dies and swing arms.
Stand to the front of the machine to avoid getting hit with the material during the
bending process. When handling large heavy materials make sure they are properly
supported.
CAUTION:
Always wear proper eye protection with side shields, safety
footwear, and leather gloves to protect from burrs and sharp edges.
OP Screen Figure 1
