Baileigh AFS-2400 User manual

OPERATOR’S MANUAL
AIR FILTRATION SYSTEM
MODEL: AFS-2400
© 2021 Baileigh Industrial Holdings LLC
REPRODUCTION OF THIS MANUAL IN ANY FORM WITHOUT WRITTEN APPROVAL OF BAILEIGH INDUSTRIAL
HOLDINGS LLC IS PROHIBITED. Baileigh Industrial Holdings LLC, Inc. does not assume and hereby disclaims any
liability for any damage or loss caused by an omission or error in this Operator’s Manual, resulting from accident,
negligence, or other occurrence.
Rev. 12/2021
Baileigh Industrial Holdings LLC
P.O. Box 531
Manitowoc, WI 54221-0531
Phone: [phone]
Fax: [phone]
[email protected]
This .pdf document is bookmarked.

Table of Contents
THANK YOU & WARRANTY ..........................................................................................1
INTRODUCTION............................................................................................................. 3
GENERAL NOTES.......................................................................................................... 3
SAFETY INSTRUCTIONS ..............................................................................................4
SAFETY PRECAUTIONS ...............................................................................................6
Dear Valued Customer:................................................................................................... 6
TECHNICAL SPECIFICATIONS.....................................................................................8
TECHNICAL SUPPORT ................................................................................................. 8
UNPACKING AND CHECKING CONTENTS.................................................................. 9
INSTALLATION............................................................................................................. 10
Placement and Positioning........................................................................................ 10
Filtering Performance................................................................................................ 12
ASSEMBLY AND SET UP ............................................................................................ 13
ELECTRICAL................................................................................................................15
Power cord connection:............................................................................................. 16
WIRING DIAGRAM....................................................................................................... 17
OPERATION................................................................................................................. 18
Remote Control Operation......................................................................................... 18
MAINTENANCE............................................................................................................ 19
Changing Filters ........................................................................................................ 19
PARTS DIAGRAM ........................................................................................................ 20
Part List..................................................................................................................... 21

1
1
THANK YOU & WARRANTY
Thank you for your purchase of a machine from Baileigh Industrial Holdings LLC. We hope that
you find it productive and useful to you for a long time to come.
Inspection & Acceptance. Buyer shall inspect all Goods within ten (10) days after receipt thereof. Buyer’s payment
shall constitute final acceptance of the Goods and shall act as a waiver of the Buyer’s rights to inspect or reject the
goods unless otherwise agreed. If Buyer rejects any merchandise, Buyer must first obtain a Returned Goods
Authorization (“RGA”) number before returning any goods to Seller. Goods returned without an RGA will be refused.
Seller will not be responsible for any freight costs, damages to goods, or any other costs or liabilities pertaining to
goods returned without a RGA. Seller shall have the right to substitute a conforming tender. Buyer will be responsible
for all freight costs to and from Buyer and repackaging costs, if any, if Buyer refuses to accept shipment. If Goods
are returned in unsalable condition, Buyer shall be responsible for full value of the Goods. Buyer may not return any
special-order Goods. Any Goods returned hereunder shall be subject to a restocking fee equal to 30% of the invoice
price.
Specifications. Seller may, at its option, make changes in the designs, specifications or components of the Goods
to improve the safety of such Goods, or if in Seller’s judgment, such changes will be beneficial to their operation or
use. Buyer may not make any changes in the specifications for the Goods unless Seller approves of such changes
in writing, in which event Seller may impose additional charges to implement such changes.
Limited Warranty. Seller warrants to the original end-user that the Goods manufactured or provided by Seller under
this Agreement shall be free of defects in material or workmanship for a period of twelve (12) months from the date
of purchase, provided that the Goods are installed, used, and maintained in accordance with any instruction manual
or technical guidelines provided by the Seller or supplied with the Goods, if applicable. The original end-user must
give written notice to Seller of any suspected defect in the Goods prior to the expiration of the warranty period. The
original end-user must also obtain a RGA from Seller prior to returning any Goods to Seller for warranty service under
this paragraph. Seller will not accept any responsibility for Goods returned without a RGA. The original end-user shall
be responsible for all costs and expenses associated with returning the Goods to Seller for warranty service. In the
event of a defect, Seller, at its sole option, shall repair or replace the defective Goods or refund to the original end-
user the purchase price for such defective Goods. Goods are not eligible for replacement or return after a period of
10 days from date of receipt. The foregoing warranty is Seller’s sole obligation, and the original end-user’s exclusive
remedy, with regard to any defective Goods. This limited warranty does not apply to: (a) die sets, tooling, and saw
blades; (b) periodic or routine maintenance and setup, (c) repair or replacement of the Goods due to normal wear
and tear, (d) defects or damage to the Goods resulting from misuse, abuse, neglect, or accidents, (f) defects or
damage to the Goods resulting from improper or unauthorized alterations, modifications, or changes; and (f) any
Goods that has not been installed and/or maintained in accordance with the instruction manual or technical guidelines
provided by Seller.
EXCLUSION OF OTHER WARRANTIES. THE FOREGOING LIMITED WARRANTY IS IN LIEU OF ALL OTHER
WARRANTIES, EXPRESS OR IMPLIED. ANY AND ALL OTHER EXPRESS, STATUTORY OR IMPLIED
WARRANTIES, INCLUDING BUT NOT LIMITED TO, ANY WARRANTY OF MERCHANTABILITY OR FITNESS FOR
ANY PARTICULAR PURPOSE ARE EXPRESSLY DISCLAIMED. NO WARRANTY IS MADE WHICH EXTENDS
BEYOND THAT WHICH IS EXPRESSLY CONTAINED HEREIN.
Limitation of Liability. IN NO EVENT SHALL SELLER BE LIABLE TO BUYER OR ANY OTHER PARTY FOR ANY
INCIDENTIAL, CONSEQUENTIAL OR SPECIAL DAMAGES (INCLUDING, WITHOUT LIMITATION, LOST
PROFITS OR DOWN TIME) ARISING FROM OR IN MANNER CONNECTED WITH THE GOODS, ANY BREACH
BY SELLER OR ITS AGENTS OF THIS AGREEMENT, OR ANY OTHER CAUSE WHATSOEVER, WHETHER
BASED ON CONTRACT, TORT OR ANY OTHER THEORY OF LIABILITY. BUYER’S REMEDY WITH RESPECT
TO ANY CLAIM ARISING UNDER THIS AGREEMENT IS STRICTLY LIMITED TO NO MORE THAN THE AMOUNT
PAID BY THE BUYER FOR THE GOODS.

2
2
Force Majeure. Seller shall not be responsible for any delay in the delivery of, or failure to deliver, Goods due to
causes beyond Seller’s reasonable control including, without limitation, acts of God, acts of war or terrorism, enemy
actions, hostilities, strikes, labor difficulties, embargoes, non-delivery or late delivery of materials, parts and
equipment or transportation delays not caused by the fault of Seller, delays caused by civil authorities, governmental
regulations or orders, fire, lightening, natural disasters or any other cause beyond Seller’s reasonable control. In the
event of any such delay, performance will be postponed by such length of time as may be reasonably necessary to
compensate for the delay.
Installation. If Buyer purchases any Goods that require installation, Buyer shall, at its expense, make all
arrangements and connections necessary to install and operate the Goods. Buyer shall install the Goods in
accordance with any Seller instructions and shall indemnify Seller against any and all damages, demands, suits,
causes of action, claims and expenses (including actual attorneys’ fees and costs) arising directly or indirectly out of
Buyer’s failure to properly install the Goods.
Work By Others; Safety Devices. Unless agreed to in writing by Seller, Seller has no responsibility for labor or work
performed by Buyer or others, of any nature, relating to design, manufacture, fabrication, use, installation or provision
of Goods. Buyer is solely responsible for furnishing and requiring its employees and customers to use all safety
devices, guards and safe operating procedures required by law and/or as set forth in manuals and instruction sheets
furnished by Seller. Buyer is responsible for consulting all operator manuals, ANSI or comparable safety standards,
OSHA regulations and other sources of safety standards and regulations applicable to the use and operation of the
Goods.
Remedies. Each of the rights and remedies of Seller under this Agreement is cumulative and in addition to any other
or further remedies provided under this Agreement or at law or equity.
Attorney’s Fees. In the event legal action is necessary to recover monies due from Buyer or to enforce any provision
of this Agreement, Buyer shall be liable to Seller for all costs and expenses associated therewith, including Seller’s
actual attorney fees and costs.
Governing Law/Venue. This Agreement shall be construed and governed under the laws of the State of Wisconsin,
without application of conflict of law principles. Each party agrees that all actions or proceedings arising out of or in
connection with this Agreement shall be commenced, tried, and litigated only in the state courts sitting in Manitowoc
County, Wisconsin or the U.S. Federal Court for the Eastern District of Wisconsin. Each party waives any right it may
have to assert the doctrine of “forum non conveniens” or to object to venue to the extent that any proceeding is
brought in accordance with this section. Each party consents to and waives any objection to the exercise of personal
jurisdiction over it by courts described in this section. Each party waives to the fullest extent permitted by applicable
law the right to a trial by jury.
Summary of Return Policy.
•10 Day acceptance period from date of delivery. Damage claims and order discrepancies will not be accepted after
this time.
•You must obtain a Baileigh issued RGA number PRIOR to returning any materials.
•Returned materials must be received at Baileigh in new condition and in original packaging.
•Altered items are not eligible for return.
•Buyer is responsible for all shipping charges.
•A 30% re-stocking fee applies to all returns.
Baileigh Industrial Holdings LLC makes every effort to ensure that our posted specifications, images, pricing and
product availability are as correct and timely as possible. We apologize for any discrepancies that may occur. Baileigh
Industrial Holdings LLC reserves the right to make any and all changes deemed necessary in the course of business
including but not limited to pricing, product specifications, quantities, and product availability.
For Customer Service & Technical Support:
Please contact one of our knowledgeable Sales and Service team members at:
[phone] or e-mail us at Baileigh-Serv[email protected]m

3
3
INTRODUCTION
The quality and reliability of the components assembled on a Baileigh Industrial Holdings LLC
machine guarantee near perfect functioning, free from problems, even under the most demanding
working conditions. However, if a situation arises, refer to the manual first. If a solution cannot be
found, contact the distributor where you purchased our product. Make sure you have the serial
number and production year of the machine (stamped on the nameplate). For replacement parts
refer to the assembly numbers on the parts list drawings.
Our technical staff will do their best to help you get your machine back in working order.
In this manual you will find: (when applicable)
•Safety procedures
•Correct installation guidelines
•Description of the functional parts of the machine
•Capacity charts
•Setup and start-up instructions
•Machine operation
•Scheduled maintenance
•Parts lists
GENERAL NOTES
After receiving your equipment remove the protective container. Do a complete visual
inspection, and if damage is noted, photograph it for insurance claims and contact your
carrier at once, requesting inspection. Also contact Baileigh Industrial Holdings LLC and inform
them of the unexpected occurrence. Temporarily suspend installation.
Take necessary precautions while loading / unloading or moving the machine to avoid any
injuries.
Your machine is designed and manufactured to work smoothly and efficiently. Following proper
maintenance instructions will help ensure this. Try and use original spare parts, whenever
possible, and most importantly; DO NOT overload the machine or make any modifications.
Note: This symbol refers to useful information throughout the manual.

4
4
SAFETY INSTRUCTIONS
LEARN TO RECOGNIZE SAFETY INFORMATION
This is the safety alert symbol. When you see this symbol
on your machine or in this manual, BE ALERT TO THE
POTENTIAL FOR PERSONAL INJURY!
Follow recommended precautions and safe operating practices.
UNDERSTAND SIGNAL WORDS
A signal word –DANGER,WARNING,or CAUTION –is used with the safety alert symbol.
NOTICE, which is not related to personal injury, is used without a symbol.
DANGER: Indicates a hazardous situation which, if not
avoided, will result in death or serious injury.
WARNING: Indicates a hazardous situation which, if not
avoided, could result in death or serious injury.
CAUTION: Indicates a hazardous situation which, if not
avoided, could result in minor or moderate injury.
NOTICE: Indicates a situation which, if not avoided, could
result in property damage.
IMPORTANT
PLEASE READ THIS OPERATORS MANUAL CAREFULLY
It contains important safety information, instructions, and necessary operating procedures.
The continual observance of these procedures will help increase your production and
extend the life of the equipment.
DANGER
WARNING
CAUTION
NOTICE

5
5
SAVE THESE INSTRUCTIONS.
Refer to them often and use them to instruct others.
PROTECT EYES
Wear safety glasses or suitable eye protection
when working on or around machinery.
PROTECT AGAINST NOISE
Prolonged exposure to loud noise can cause impairment or loss of
hearing. Wear suitable hearing protective devices such as earmuffs or
earplugs to protect against objectionable or uncomfortable loud noises.
DUST HAZARD
Wear appropriate dust mask. Dust created while using machinery can
cause cancer, birth defects, and long-term respiratory damage. Be aware
of the dust hazards associated with all types of materials.
DUST PARTICLES AND IGNITION SOURCES
DO NOT operate the table saw in areas where explosion risks are
high. Such areas include locations near pilot lights, open flames, or
other ignition sources.
HIGH VOLTAGE
USE CAUTION IN HIGH VOLTAGE AREAS. DO NOT assume the
power to be off.
FOLLOW PROPER LOCKOUT PROCEDURES.
CALIFORNIA PROPOSITION 65
WARNING: Cancer and Reproductive Harm.
www.P65Warnings.ca.gov

6
6
SAFETY PRECAUTIONS
Wood working can be dangerous if safe and proper operating procedures are not followed. As
with all machinery, there are certain hazards involved with the operation of the product. Using
the machine with respect and caution will considerably lessen the possibility of personal injury.
However, if normal safety precautions are overlooked or ignored, personal injury to the operator
may result.
Safety equipment such as guards, push sticks, hold-downs, feather boards, goggles, dust
masks and hearing protection can reduce your potential for injury. But even the best guard won’t
make up for poor judgment, carelessness or inattention. Always use common sense and
exercise caution in the workshop. If a procedure feels dangerous, don’t try it.
REMEMBER: Your personal safety is your responsibility.
Dear Valued Customer:
•All Baileigh woodworking machines should be used only for their intended use.
•Baileigh does not recommend or endorse making any modifications or alterations to a
Baileigh machine. Modifications or alterations to a machine may pose a substantial risk of
injury to the operator or others and may do substantial damage to the machine.
•Any modifications or alterations to a Baileigh machine will invalidate the machine's warranty.
Please enjoy your Baileigh machine! ....Please enjoy it SAFELY!
1. FOR YOUR OWN SAFETY, READ INSTRUCTION MANUAL BEFORE OPERATING THE
MACHINE. Learn the machine’s application and limitations as well as the specific hazards.
2. Only trained and qualified personnel can operate this machine.
3. Make sure guards are in place and in proper working order before operating
machinery.
4. Keep work area clean. Cluttered areas invite injuries.
5. Overloading machine. By overloading the machine you may cause injury from flying parts.
DO NOT exceed the specified machine capacities.
6. Use the right tool for the job. DO NOT attempt to force a small tool or attachment to do
the work of a large industrial tool. DO NOT use a tool for a purpose for which it was not
intended.
WARNING:FAILURE TO FOLLOW THESE RULES MAY RESULT IN
SERIOUS PERSONAL INJURY

7
7
7. Dress appropriate. DO NOT wear loose fitting clothing or jewelry as they can be caught in
moving machine parts. Protective clothing and steel toe shoes are recommended when
using machinery. Wear a restrictive hair covering to contain long hair.
8. Use eye protection. Always wear ISO approved protective eye wear when operating
machinery. Wear a full-face shield if you are producing metal filings. Eye wear shall be
impact resistant, protective safety glasses with side shields which comply with ANSI Z87.1
specification. Use of eye wear which does not comply with ANSI Z87.1 specification could
result in severe injury from breakage of eye protection.
9. Do not overreach. Maintain proper footing and balance at all times. DO NOT reach over or
across a running machine.
10. Stay alert. Watch what you are doing and use common sense. DO NOT operate any tool or
machine when you are tired.
11. Turn off power before checking, cleaning, or replacing any parts.
12. Check for damaged parts. Before using any tool or machine, carefully check any part that
appears damaged. Check for alignment and binding of moving parts that may affect proper
machine operation.
13. Observe work area conditions. DO NOT use machines or power tools in damp or wet
locations. Do not expose to rain. Keep work area well lighted. DO NOT use electrically
powered tools in the presence of flammable gases or liquids.
14. Keep children away. Children must never be allowed in the work area. DO NOT let them
handle machines, tools, or extension cords.
15. Store idle equipment. When not in use, tools must be stored in a dry location to inhibit rust.
Always lock up tools and keep them out of reach of children.
16. DO NOT operate machine if under the influence of alcohol or drugs. Read warning
labels on prescriptions. If there is any doubt, DO NOT operate the machine.
17. Be sure all equipment is properly installed and grounded according to national, state, and
local codes.
18. Inspect power and control cables periodically. Replace if damaged or bare wires are
exposed. Bare wiring can kill!
19. DO NOT touch live electrical components or parts.
20. Turn off power before checking, cleaning, or replacing any parts.
21. Be sure all equipment is properly installed and grounded according to national, state, and
local codes.
22. DO NOT bypass or defeat any safety interlock systems.
23. Keep visitors a safe distance from the work area.
24.Check for damaged parts before using machinery. Check for binding or misaligned parts,
broken parts, loose bolts, or any other conditions which may impair the machines operation.
Repair or replace any damaged parts before operation.

8
8
25.Do not remove any warning signs.
26.DO NOT insert fingers or foreign objects into the intake or exhaust ports. Keep hair, loose
clothing, fingers, and all body parts away from openings and moving parts of this machine.
27.DO NOT use the filtration system without the filters in place and properly secured.
28.PERIODICALLY INSPECT the filters for any cuts, rips or tears. NEVER operate this
machine with damaged filters.
29.This air filtration system is designed for home use or light commercial duty ONLY!
IMPORTANT:Never operate the air filtration blower without the proper filters
installed.
TECHNICAL SPECIFICATIONS
Motor
3/4 HP (560w) 120V, 60Hz
Power
120V, 60Hz, 14.8A
Motor Speed
1350 RPM
Suction Capacity
2376 CFM
Impeller Size
11” x 7” (280 x 178mm)
Switch
Rocker, On/Off/RF
Noise Level @ 3 Meters (9.8ft)
70dB
Overall Dimensions
60.4” x 24.8” x 21.8” (1535 x 630 x 555mm)
Shipping Dimensions
61.8” x 26.1” x 23.4” (1570 x 665 x 595mm)
N.W.
126lbs (57Kgs)
G.W.
139lbs (63Kgs)
TECHNICAL SUPPORT
Our technical support department can be reached at 920.684.4990 and asking for the support
desk for purchased machines. Tech Support handles questions on machine setup, schematics,
warranty issues, and individual parts needs: (other than die sets and blades).
For specific application needs or future machine purchases contact the Sales Department at:
[email protected], Phone: [phone], or Fax: [phone].
Note: The photos and illustrations used in this manual are representative only and
may not depict the actual color, labeling or accessories and may be intended to illustrate
technique only.
Note: The specifications and dimensions presented here are subject to change
without prior notice due to improvements of our products.

9
9
UNPACKING AND CHECKING CONTENTS
Your Baileigh machine is shipped complete. Separate all parts from the packing material and
check each item carefully. Make certain all items are accounted for before discarding any
packing material.
Cleaning
Your machine may be shipped with a rustproof waxy coating and/or grease on the exposed
unpainted metal surfaces. Fully and completely remove this protective coating using a
degreaser or solvent cleaner. Moving items will need to be moved along their travel path to
allow for cleaning the entire surface. For a more thorough cleaning, some parts will occasionally
have to be removed. DO NOT USE acetone or brake cleaner as they may damage painted
surfaces.
Follow manufacturer’s label instructions when using any type of cleaning product. After cleaning,
wipe unpainted metal surfaces with a light coating of quality oil or grease for protection.
Important: This waxy coating is NOT a lubricant and will cause the machine to
stick and lose performance as the coating continues to dry.
WARNING: SUFFOCATION HAZARD! Immediately discard any plastic
bags and packing materials to eliminate choking and suffocation hazards to children
and animals.
If any parts are missing, DO NOT place the machine into service until the missing parts
are obtained and installed correctly.
WARNING: DO NOT USE gasoline or other petroleum products to clean
the machine. They have low flash points and can explode or cause fire.
CAUTION: When using cleaning solvents work in a well-ventilated area.
Many cleaning solvents are toxic if inhaled.
GAS

10
10
INSTALLATION
IMPORTANT:
Consider the following when looking for a suitable location to place the machine:
•This unit is specifically designed to circulate and filter non-metallic dust, which is generated
throughout the work area.
•Overall weight of the machine.
•Space needed for clear air flow and service access.
•Clearance from walls and other obstacles.
•Maintain an adequate working area around the machine for safety.
•Have the work area well illuminated with proper lighting.
•CEILIING: This tool distributes a large amount of weight over a small area. Make certain that
the ceiling and overhead support is capable of supporting a minimum of 2 times the weight of
the machine.
•If placing the air filtration unit on a stand, verify that the machine is secured to the stand and
that the stand cannot tip over.
•WORKING CLEARANCES: Take into consideration space around this machine to provide
the air flow needed to allow for proper filtration. This unit will work best if it is located away
from corners, and heating/cooling vents.
•POWER SUPPLY PLACEMENT: The power supply should be located close enough to the
machine so that the power cord is not in an area where it would cause a tripping hazard. Be
sure to observe all electrical codes if installing new circuits and/or outlets.
Placement and Positioning
Placement and Positioning planning is a key step to maximize the effectiveness of the air filter.
Because each installation will be different, having different size, shape and obstructions, each
placement and positioning consideration will be different.
Air flow patterners must be thought out with consideration for all obstructions to the air flow path.
Think of air circulation in terms of the circular motion of the air before and after the air filter. The
air exiting the filter is exhausted at a higher velocity than the air entering. Thus, exhaust air
being vented inside a building will have an effect on the pattern of air circulation.
Air circulation patterns will vary depending upon which air flow speed is used and your specific
shop setup.
WARNING:The mounts for this machine must be anchored to the
building structure, which will support a minimum of 2 times the weight of the
machine. Never mount to surfaces such as dry wall or false ceiling grids, etc.

11
11
In general, good air filter placement promotes a circular / recirculating air flow pattern.
An example of poor air circulation, is where the air filter is placed too close to obstructions. This
situation will cause the velocity and flow of the air to be lost and circulation and thus filtration will
be diminished. Common placement and positioning issues are placing the inlet toward the
center of a room with the outlet toward the wall or corner with less than 3 -4 feet (.9 –1.2m) of
clearance. This will create a turbulence on the outlet side of the filter greatly reducing it
efficiency.
Placement and Position considerations:
•Examine the shop layout and try to determine the best location to hang the air filter. Air flow
that is obstructed will cause poor air flow, producing unsatisfactory results. There must be a
clearance of at least 3ft (.9m) from any obstructions in front and back of the unit.
•Try to place the air filter in near high dust producers or near areas where the dust is created.
•Do not place the hanging air filter where overhead items such as doors, cranes, etc. may
impede the air flow, or where the air filter may impede the other device operation of
movement.
•Consider the air flow of other air controlling devices such as HVAC and ceiling fans. Try to
have the air filter work with the air flow of these devices.
•Plan for placement to allow the air filter to be operated, serviced, cleaned, and maintained.
•Plan for and consider the proximity to the power source. Consider the air flow of other air
controlling devices such as HVAC and ceiling fans. Try to have the air filter work with the air
flow of these devices.
•Ability of the remote to operate the air filtration unit.
It is very important that the hanging air filter be supported properly. Please follow these
guidelines when planning where to mount the unit:
•ONLY hang the air filter from the mounting brackets attach to the top of the unit.
•Make sure that an electrical outlet with a properly grounded receptacle is available at the
location you choose. DO NOT allow the power cord to become an interference or
entanglement to this or other machines or people.
•The hanging air filter must be supported by structurally solid components such as joists
which must be capable of supporting a minimum of 2 times the weight of the unit. DO NOT
attach the hanging air filter to items such as but not limited to sheet rock, press board or
paneling. These materials cannot support the filter, and it will fall.
•DO NOT use anchors such as are commonly used for mounting items to sheet rock. These
anchors cannot support the weight of the filter long term and it may fall.
•Hang the air filtration unit so that the bottom is 8 –10ft (2.4 –3m) above the floor. This
typically provides the best operation.

12
12
•Avoid hanging the filter so low and / or in a location that will cause / allow personnel to hit
their head on the hanging air filter. Make sure there is enough clearance between the unit
and the ground, especially important in low ceiling height locations. If possible, position the
air filter in an area that has little foot traffic but still offers easy access to the switch and
filters.
Filtering Performance
When used together with an efficient dust collection system, this air filter removes most fine
particles up to 1 micron from the air.
At full speed, this air filter is capable of recirculating the air in a 40' x 40' x 10' room
approximately 9 times an hour. If the recirculation calculation falls below 5 times per hour it is
recommended to have either a larger air filtration unit or a second air filtration unit. Often, a
second air filtration unit is the better answer as it will generally provide the opportunity for
placement and positioning that will be complimentary to the first air filtration unit. In short, rooms
with a larger volume may require two or more air filters to achieve proper filtering.
To calculate the recirculating rate for your shop space:
1. Calculate the volume of air in your shop by multiplying the length x width x height of the
room. Then, divide the volume by the speed (CFM) you have chosen to operate the air filter.
This will give you how many minutes it takes to recirculate the air in the room.
Example: For a room that measures 40' x 40' x 10' with this air filter running at 2400CFM, hi
speed, the following calculation indicates the number of minutes to recirculate the air in the
room.
40' x 40' x 10'
=
16000 ft3
=
6.6 Minutes
2400CFM
2400CFM
2. Once the first calculation is complete to determine the minutes to recirculate the air, the next
calculation may be completed by dividing 60 minutes by the circulating time. This will give
you how many times an hour the air in the room is recirculated
60 Min.
=
9.09 Times per Hour
6.6 Min.
Important: These calculations provide results based upon best case conditions.
Specific results and actual performance will vary based upon each individual installation,
obstructions, motor speed, cleanliness of the filters etc.

13
13
ASSEMBLY AND SET UP
3. Open each end of the cabinet and remove any packing materials.
4. Check for and tighten any loose fasteners.
5. To assemble, first place the hanger (NO.3) to
cabinet (NO.4) and tighten up. See FIG.1
Fig.1
6. Installed the Inn-Bag Filter (NO.2) into the cabinet
(NO.4). See FIG.2
Fig.2
WARNING:For your own safety, DO NOT connect the machine to the
power source until the machine is completely assembled and you read and
understand the entire instruction manual.

14
14
7. Installed the Outer Pre-Filter (NO.1) into the
cabinet (NO.4). See FIG.3
Fig.3
IMPORTANT:Never operate the air filtration blower without the proper filters
installed.
Two Person Lift. Use an assistant or lifting devise to support the weight of the air
filtration unit.
8. Following the Installation guidelines and the
placement and positioning guidelines, install
mounting hardware (customer supplied)
into/onto the support structure of the
building.
9. Verify that the mounting is into/onto solid
components such as joists which are
capable of supporting a minimum of 2 times
the weight of the unit. DO NOT attach the
hanging air filter to items such as but not
limited to sheet rock, press board or
paneling. These materials cannot support
the filter, and it will fall.

15
15
ELECTRICAL
Power Specifications
Your machine is wired for 120 volts, 60hz alternating current. Before connecting the machine to
the power source, make sure the power source is OFF.
Before switching on the power, you must check the voltage and frequency of the power to see if
they meet with the requirement, the allowed range for the voltage is ±5%, and for the frequency
is ±1%.
Considerations
•Observe local electrical codes when connecting the machine.
•The circuit should be protected with a time delay fuse or circuit breaker with an amperage
rating slightly higher than the full load current of machine.
•A separate electrical circuit should be used for your machines. Before connecting the motor
to the power line, make sure the switch is in the “OFF” position and be sure that the electric
current is of the same characteristics as indicated on the machine.
•All line connections should make good contact. Running on low voltage will damage the
motor.
•In the event of a malfunction or breakdown, grounding provides a path of least resistance for
electric current to reduce the risk of electric shock. This machine is equipped with an electric
cord having an equipment-grounding conductor and a grounding plug. The plug must be
plugged into a matching outlet that is properly installed and grounded in accordance with all
local codes and ordinances.
CAUTION: HAVE ELECTRICAL UTILITIES CONNECTED TO MACHINE BY
A CERTIFIED ELECTRICIAN!
Check if the available power supply is the same as listed on the machine nameplate.
WARNING: Make sure the grounding wire (green) is properly connected
to avoid electric shock. DO NOT switch the position of the green grounding wire if any
electrical plug wires are switched during hookup.
WARNING:In all cases, make certain the receptacle in question is
properly grounded. If you are not sure, have a qualified electrician check the
receptacle.

16
16
•Improper connection of the equipment-grounding conductor can result in risk of electric
shock. The conductor with insulation having an outer surface that is green with or without
yellow stripes is the equipment-grounding conductor. If repair or replacement of the electric
cord or plug is necessary, do not connect the equipment-grounding conductor to a live
terminal.
•Check with qualified electrician or service personnel if the grounding instructions are not
completely understood, or if in doubt as to whether the machine is properly grounded.
•Repair or replace damaged or worn cord immediately.
Extension Cord Safety
Extension cord should be in good condition and meet the minimum wire gauge requirements listed
below:
LENGTH
AMP RATING
25ft
50ft
100ft
1-12
16
16
14
13-16
14
12
12
17-20
12
12
10
21-30
10
10
No
WIRE GAUGE
An undersized cord decreases line voltage, causing loss of power and overheating. All cords
should use a ground wire and plug pin. Replace any damaged cords immediately.
Power cord connection:
1. Turn the main disconnect switch on the control panel to the OFF position.
2. Unwrap the power cord and route the cord away from the machine toward the power supply.
a. Route the power cord so that it will NOT become entangled in the machine in any
way.
b. Route the cord to the power supply is a way that does NOT create an entanglement
hazard.
3. Connect the power cord to the power supply and check that the power cord has not been
damaged during installation.
4. When the machine is clear of any obstruction. The main power switch may be turn ON to test
the operation.
5. Turn the switch OFF when the machine is not in operation.

17
17
WIRING DIAGRAM

18
18
OPERATION
The control panel on the filtration unit has a three-position rocker switch.
•The Off position will turn the unit Off and disable the remote control.
•The On position will override the remote control and power the filtration unit On at full speed.
The unit will run until the rocker switch is turned Off.
•The RF position will activate the remote control. Blower speed and run time will be controlled
by the remote.
When the air filtration unit is safely positioned on a stand or mounted to the ceiling, place the
rocker On/Off/RF switch on the control panel to the desire position. RF is typical.
Remote Control Operation
Note: The switch on the filtration unit may remain in the RF position for normal
daily operation. It is advised to turn the rocker switch Off during extended period of nonuse such
as vacations.
The remote control has four control buttons: ON (Hour/Speed), OFF,
SPEED/HOUR –(minus), SPEED/HOUR + (plus).
There are also 3 Speed LED’s and 5 Hour LED’s.
1. Press the On button to activate the unit. The filter will power On at
Low speed with infinite running time. The remote will be in Speed
mode as well.
2. Press the Speed/Hour + (Plus) button to increase (or minus button to
decrease) the blower speed.
3. Press the On button a second time to enter the Hour mode.
4. Press the Speed/Hour + (Plus) button to increase (or minus button to
decrease) the time setting to the hours desired. The choices are
Infinite (On until the operator turns the unit off), 2, 4, 6, or 8 hours.
5. At any time when desired, press the Off button to stop the filter.
Note: Theremote requires two (2) AAA batteries. The
Battery housing is located underneath the back cover.
