BainUltra EVANESCENCE 6634 Installation and operating instructions

EVANESCENCE® ADDENDUM
to the OWNER’S MANUAL
IMPORTANT INFORMATION FOR THE INSTALLER
AND THE OWNER
INCLUDED: FREESTANDING EVANESCENCE BATHS INSTALLATION INSTRUCTIONS
IMPORTANT: TO BE KEPT FOR THE OWNER

2 1 800 463.2187 From 8 a.m. to 8 p.m. Monday to Thursday (EST) .From 8 a.m. to 5 p.m. on Friday (EST)
Printed in Canada. Copyright © December 2017 BainUltra Inc. All rights reserved. 45200599
Some products, specifications, and services mentioned in this manual are described in pending patent applications or are protected by patents.
TMU®
EVANESCENCE ADDENDUM to OWNER’S MANUAL |TMU®
PARTS AND TOOLS - SITE PREPARATION
THERMOMASSEUR®
EVANESCENCE 6634 & EVANESCENCE OVAL 5936, 6636, 7440
PARTS AND TOOLS
B. TOOLS REQUIRED
B-1 48-inch level
B-2 Caulking gun
B-3 Silicone
A. PARTS INCLUDED
A-1 Floor anchoring
A-2 Installation template
B-2
B-1
B-3
B-4 B-5
Evanescence Freestanding models require
a 13” x 14” (33 cm X 36 cm) compartment
for the drain, distance air inlet, and space
for control cables and options. Refer to
the installation template.
ACCESS AND AIR INLET
For these model, the turbine is not installed on the bathtub.
Determine a location near the bathtub at a maximum distance
of 15 feet or (4.6 metres) under the floor, in a cabinet or any other
location to conceal the turbine and optional accessory casings.
The location chosen must also be accessible and allow sufficient air
intake for the turbine.
(Refer to the TURBINE–DISTANCE INSTALLATION section of the
Owner’s Manual).
A-1 x2 x1A-2
EVANESCENCE 6634 & EVANESCENCE OVAL 5936, 6636, 7440
SiTE PREPARATION

www.bainultra.com
Printed in Canada. Copyright © December 2017 BainUltra Inc. All rights reserved. 45200599
Some products, specifications, and services mentioned in this manual are described in pending patent applications or are protected by patents.
TMU®
EVANESCENCE ADDENDUM to OWNER’S MANUAL |TMU®
INSTALLATION
1. LOCATION
1-1
1-2
2-1 2-3 2-4 2-52-2
3-1 3-2 3-4 3-53-3
1-1 Place the installation template on the ground
at the chosen location.
1-2 Align the position of the overflow drain with
the floor drain and ensure that the compart-
ment size corresponds to requirements.
1-3 Mark the location of the anchor point screws.
1-4 Remove the installation template and screw
in the anchor points in the marked locations.
3
EVANESCENCE 6634 & EVANESCENCE OVAL 5936, 6636, 7440
INSTALLATION
Installation Template Example
Evanescence Oval 5936, 6636 & 7440
Evanescence 6634
2. INSTALLATION OF BATH
2-1 Assemble the drain on the bathtub.
Use the overflow assembly provided for
the junction to the drain T-joint. Ensure
watertightness. This operation is much
easier to complete when the bathtub rests
on its side. Place a cover or protective
cardboard on the floor before positioning
the bathtub on its side.
2-2 Apply a joint of silicone under the edge
of the base of the bathtub.
1-1 1-2
2-1
2-3 2-4 2-52-2
3-1 3-2 3-4 3-53-3
1-1 1-2
2-1
2-3 2-4 2-52-2
3-1 3-2 3-4 3-53-3
1-1 1-2
2-1 2-3 2-4 2-5
2-2
3-1 3-2 3-4 3-53-3
1-1 1-2
2-1 2-3 2-4 2-5
2-2
3-1 3-2 3-4 3-53-3

4 1 800 463.2187 From 8 a.m. to 8 p.m. Monday to Thursday (EST) .From 8 a.m. to 5 p.m. on Friday (EST)
Printed in Canada. Copyright © December 2017 BainUltra Inc. All rights reserved. 45200599
Some products, specifications, and services mentioned in this manual are described in pending patent applications or are protected by patents.
TMU®
EVANESCENCE ADDENDUM to OWNER’S MANUAL |TMU®
INSTALLATION
2. INSTALLATION OF BATH (Cont’d)
NOTES • To install the Evanescence Freestanding
on a concrete slab with no place for the
passage of the air inlet pipe to the
bathtub: drill a hole 1 5/8 inches in
diameter in the skirt. IMPORTANT: drill
the hole 1 1/2 inches above floor level
and protect the bathtub with a piece
of wood placed behind the location
to be drilled.
2-3 Install the bathtub on the anchor points
fastened to the floor and immediately wipe
away any excess silicone. Connect the drain.
2-4 Install the turbine according to the
instructions in the TURBINE – DISTANCE
INSTALLATION section of the manual.
The air inlet is located to the right of the
bathtub drain and, if applicable, control
and option connection cables to the right.
Connect control and option cables
if applicable. For Geysair-equipped
baths, also run the water hose and
electrical wiring through the floor.
2-5 For Geysair-equipped baths, connect
the Geysair electrical wire supplied with
the male connector with the turbine cable
equipped with the female connector. Test
for grounding continuity between the
bath grounding terminal
and the
bath power supply. Failure to perform
the grounding continuity test could
result in serious personal injury.
Ground Wire
for the Bathtub
Turbine Female
Connector
Geysair Male
Connector
EVANESCENCE 6634 & EVANESCENCE OVAL 5936, 6636, 7440
INSTALLATION
1-1 1-2
2-1 2-3 2-4
2-5
2-2
3-1 3-2 3-4 3-53-3
1-1 1-2
2-1
2-3
2-4 2-52-2
3-1 3-2 3-4 3-53-3
Evanescence Oval 5936, 6636 & 7440
Evanescence 6634
